Model Image
Manufacturer

GE

Model Number

PGB911SEJ1SS

Description

Gas Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB29K10023 WB29K10023 GE 500 BTUS GAS RANGE MEDIUM BURNER CAP; 9
WB28K10023 WB28K10023 GE 89MM RANGE ORIFICE SPUD - NG TO LP
WB34X25717 WB34X25717 GE BACKGUARD EYEBROW
WB36X24974 WB36X24974 GE BACKGUARD RANGE
WB2X8351 WB2X8351 GE BLADE FAN
WB35X37975 WB35X37975 GE BOTTOM OVEN AND DEFLECTOR ASM
WB02K0032 WB02K0032 GE BOTTOM OVEN BRACKT SUPPO
WB63K0015 WB63K0015 GE BRACE BOTTOM
WB34X20456 WB34X20456 GE BRACE VENT
WB02K10254 WB02K10254 GE BRACKET ANTI-TIP ASSEMBLY
WB02K0041 WB02K0041 GE BRACKET OVEN CORNER
WB02X24790 WB02X24790 GE BUMPER
WB02K10171 WB02K10171 GE BUMPER
WB16X20463 WB16X20463 GE BURNER BAKE
WB16X20418 WB16X20418 GE BURNER BROIL
WB16X28654 WB16X28654 GE BURNER SMALL V ASSEMBLY. CAP
WB02K10360 WB02K10360 GE CKT BRACKET SMALL
WB01X24735 WB01X24735 GE CKT SCREW
WB02K0036 WB02K0036 GE CLAMP CABLE
WB2K36 WB2K36 GE CLAMP CABLE
WB02T10111 WB02T10111 GE CLEANER-SS
WB02K0031 WB02K0031 GE CLIP CABLE
WB02X21679 WB02X21679 GE CLIP CABLE
WB02K10380 WB02K10380 GE CLIP INSULATION
WB02K0052 WB02K0052 GE CLIP RANGETOP
WB2K52 WB2K52 GE CLIP RNGETOP
WB02X7066 WB02X7066 GE CLIP WIRE
WB02K10267 WB02K10267 GE CLIP WIRE
WB35X21685 WB35X21685 GE CORD FIBER GLASS
WB34K0016 WB34K0016 GE COVER BACK
WB34X21575 WB34X21575 GE COVER BACK
WB34K16 WB34K16 GE COVER BACK
WB34X24746 WB34X24746 GE COVER BACK LOWER
WB34X24745 WB34X24745 GE COVER BACK UPPER
WB34X25587 WB34X25587 GE COVER MOTOR
WB63K10040 WB63K10040 GE COVER TERMINAL
WB02K0024 WB02K0024 GE COVER VALVE
WB07X29141 WB07X29141 GE COVER VENT TRIM
WB57K10174 WB57K10174 GE CRYSTAL WINDOW
WB56X25504 WB56X25504 GE DEFLECTOR BOTTOM DOOR
WB49K10037 WB49K10037 GE DEFLECTOR OVEN
WB38K10022 WB38K10022 GE DIFFUSER VENT
WB34X24749 WB34X24749 GE DOOR GUARD
WB10X24776 WB10X24776 GE DOOR HINGE
WB34X21570 WB34X21570 GE DOOR STIFFENER
WB49X26422 WB49X26422 GE DRAWER BODY ASSEMBLY
WB01K10037 WB01K10037 GE ECONOMIC NUT
WB28X20389 WB28X20389 GE ELBOW 90 ASSEMBLY
WB18X26985 WB18X26985 GE ELECTRODES AND HARNESS H.V
WB07X29144 WB07X29144 GE END SUPPORT DD
WB07X29143 WB07X29143 GE END SUPPORT DD
WB02X8351 WB02X8351 GE FAN BLADE
WB26K10003 WB26K10003 GE FAN MOTOR CONVECT-2SPEED
WB49K0044 WB49K0044 GE FLAME SPREADER
WB01X1378 WB01X1378 GE FLAT WASHER-M4
WB02X28737 WB02X28737 GE FRAME FRONT BUMPER
WB63X24740 WB63X24740 GE FRAME WELD ASSEMBLY
WB28K10222 WB28K10222 GE GAS RANGE BURNER CAP - XL V2
WB31X24998 WB31X24998 GE GAS RANGE REVERSIBLE GRILL/GRIDDLE
WB32K2 WB32K2 GE GASKET OVEN SEAL LG
WB02T10589X WB02T10589X GE GE BADGE GRAY
WB56X24827 WB56X24827 GE GLASS DOOR ASSEMBLY
WB31X24736 WB31X24736 GE GRATE ASM
WB2K8 WB2K8 GE GROMMET
WB63K0016 WB63K0016 GE GUARD BOTTOM
WB15X27280 WB15X27280 GE HANDLE AND END CAP ASSEMBLY
WB18X25597 WB18X25597 GE HARNESS GROUND
WB18X24748 WB18X24748 GE HARNESS GROUND
WB18X27596 WB18X27596 GE HARNESS SWITCH
WB10X25550 WB10X25550 GE HINGE DOOR RT
WB14K10003 WB14K10003 GE HINGE RANGE TOP
WB13X40207 WB13X40207 GE IGNITER GLOWBAR
WB13X24741 WB13X24741 GE IGNITION MODULE
WB34X24756 WB34X24756 GE INNER DOOR DEFLECTOR
WB35X21198 WB35X21198 GE INSULATION ASSEMBLY
WB35X24985 WB35X24985 GE INSULATION BURNER BOX
WB35X21688 WB35X21688 GE INSULATION DOOR
WB35X24786 WB35X24786 GE INSULATION OVEN WRAP
WB28X39147 WB28X39147 GE KIT LP CONVERSION ASSEMBLY
WB10X24780 WB10X24780 GE LATCH AUTOMATIC
WB18K10055 WB18K10055 GE LINE CORD
31-11011 31-11011 GE LP CONVERSION INST
WB36X32655 WB36X32655 GE MANIFOLD PANEL
WB28X24765 WB28X24765 GE MANIFOLD PIPE
WB34X20680 WB34X20680 GE MANIFOLD SUPPORT
WB16X24724 WB16X24724 GE MEDIUM V2 BURNER
WB02T10017 WB02T10017 GE NUT
WB28X24850 WB28X24850 GE ORIFICE HOLDER
WB28X24858 WB28X24858 GE ORIFICE HOLDER
WB28X24762 WB28X24762 GE ORIFICE HOLDER CENTRAL
WB28X24761 WB28X24761 GE ORIFICE HOLDER RF
WB28K10834 WB28K10834 GE ORIFICE SPUD
WB28X24768 WB28X24768 GE ORIFICE SPUD
WB16K10076 WB16K10076 GE OVAL BURNER ASSEMBLY
WB63X20423 WB63X20423 GE OVEN BACK
WB53K10053 WB53K10053 GE OVEN SIDE
WB53K10052 WB53K10052 GE OVEN SIDE
WB63X20437 WB63X20437 GE OVEN TOP
WB27X32206 WB27X32206 GE OVERLAY AND CONTROL ASSEMBLY
WB56X24829 WB56X24829 GE PANEL DRAWER
WB63K10203 WB63K10203 GE PANEL REAR BROIL
WB56X22013 WB56X22013 GE PANEL SIDE
WB63X25598 WB63X25598 GE PANEL SIDE BROIL LEFT
WB63X25599 WB63X25599 GE PANEL SIDE BROIL RT
WB24X24769 WB24X24769 GE PLUNGER SWITCH DUAL
49-85225 49-85225 GE PM GAS QUICK GUIDE
31-10999 31-10999 GE PM INSTALL INSTRUCTIONS
31-17178 31-17178 GE PM MINI MANUAL
WB63X23200 WB63X23200 GE RANGE BACK
WB34K10038 WB34K10038 GE RANGE BACK FAN COVER
WB07X20288 WB07X20288 GE RANGE BARRIER DOOR
WB63K10187 WB63K10187 GE RANGE BOTTOM INNER GUARD
WB2K32 WB2K32 GE RANGE BRACKET SUPPORT
WB28K10215 WB28K10215 GE RANGE BURNER ORIFICE
WB28X24773 WB28X24773 GE RANGE BURNER TUBE SUPPLY
WB49K10025 WB49K10025 GE RANGE DEFLECTOR
WB35X21691 WB35X21691 GE RANGE DOOR INSULATION
WB56X24760 WB56X24760 GE RANGE DOOR LINER
WB02X24742 WB02X24742 GE RANGE DRAWER BRACKET
WB34K10142 WB34K10142 GE RANGE FAN COVER
WB02K10034 WB02K10034 GE RANGE FAN SUPPORT
WB02X24743 WB02X24743 GE RANGE HANDLE BRACKET
WB02X24744 WB02X24744 GE RANGE HANDLE BRACKET
WB28X29255 WB28X29255 GE RANGE HIGH ALTITUDE KIT - LP
WB28X29254 WB28X29254 GE RANGE HIGH ALTITUDE KIT - NP
WB02X24976 WB02X24976 GE RANGE IGNITER CLIP V2
WB13X40206 WB13X40206 GE RANGE IGNITER GLOWBAR
WB1X1293 WB1X1293 GE RANGE IGNITER MOUNTING SCREW
WB34X24753 WB34X24753 GE RANGE IGNITOR COVER
WB02X24727 WB02X24727 GE RANGE INJET MEDIUM
WB02X24728 WB02X24728 GE RANGE INJET SMALL
WB02X24725 WB02X24725 GE RANGE INJET XL V2
WB35K10222 WB35K10222 GE RANGE INSULATION
WB35K10221 WB35K10221 GE RANGE INSULATION
WB35K10038 WB35K10038 GE RANGE INSULATOR FAN
WB03X24988 WB03X24988 GE RANGE KNOB - STAINLESS STEEL
WB02K10182 WB02K10182 GE RANGE LEVELING LEG
WB34K10086 WB34K10086 GE RANGE LOWER HEAT SHIELD
WB28X24763 WB28X24763 GE RANGE ORIFICE HOLDER LR
WB2K41 WB2K41 GE RANGE OVEN BRACKET
WB32K10052 WB32K10052 GE RANGE OVEN GASKET
WB34K10141 WB34K10141 GE RANGE OVEN GLASS METAL FRAME
WB08T10002 WB08T10002 GE RANGE OVEN LAMP ASSEMBLY
WB32K10044 WB32K10044 GE RANGE OVEN LIGHT GASKET
WB48X20249 WB48X20249 GE RANGE OVEN RACK
WB63K16 WB63K16 GE RANGE PANEL
WB10X25602 WB10X25602 GE RANGE RECEIVER HINGE
WB02X24940 WB02X24940 GE RANGE SIDE MANIFOLD BRACKET
WB02X24939 WB02X24939 GE RANGE SIDE MANIFOLD BRACKET
WB02X20849 WB02X20849 GE RANGE SIDE SPACER
WB63X27680 WB63X27680 GE RANGE SLIDE BEARING
WB01K10080 WB01K10080 GE RANGE THERMOSTAT SCREW
WB02X20735 WB02X20735 GE RANGE TOP REAR SUPPORT
WB02K10297 WB02K10297 GE RANGE VALVE BRACKET
WB63K15 WB63K15 GE RANGE VENT BRACE
WB62X24887 WB62X24887 GE RANGETOP AND BRACKET ASSEMBLY
WB02X24942 WB02X24942 GE RANGETOP HOLDER
WB02X24941 WB02X24941 GE RANGETOP HOLDER
WB1K44 WB1K44 GE SCEW LATCH
WB01K0021 WB01K0021 GE SCREW
WB01K10091 WB01K10091 GE SCREW
WB1K5062 WB1K5062 GE SCREW
WB1X1261 WB1X1261 GE SCREW
WB1X5754 WB1X5754 GE SCREW
WB1X536 WB1X536 GE SCREW
WB01K0042 WB01K0042 GE SCREW (BLK)
WB01X5364 WB01X5364 GE SCREW (CR)
WB01X0593 WB01X0593 GE SCREW - DOOR ASM (4 PER)
WR01X10065 WR01X10065 GE SCREW 10-32 GXTT FLP 595 S
WB01T10008 WB01T10008 GE SCREW 10-32 TR T
WB1K78 WB1K78 GE SCREW 12-14
WB01K0078 WB01K0078 GE SCREW 12-14, 5/8S
WB01X5754 WB01X5754 GE SCREW 8-18 ABT 1/2 S
WZ4X345D WZ4X345D GE SCREW 8-18X5/8 HXW
WB01K0044 WB01K0044 GE SCREW DOOR LATCH
WB01X1261 WB01X1261 GE SCREW GROUND
WB1X5364 WB1X5364 GE SCREW MTG
WB01K0050 WB01K0050 GE SCREW MTG IGNITER
WB24X25557 WB24X25557 GE SENSOR ASSEMBLY
WB34X20303 WB34X20303 GE SHIELD BROIL
WB34K12 WB34K12 GE SHIELD RADIA
WB34K0012 WB34K0012 GE SHIELD RADIATION
WB16X24721 WB16X24721 GE SMALL V2 BURNER
WB16X20449 WB16X20449 GE SPACER BASE
WB16X20448 WB16X20448 GE SPACER BASE
WB01K0002 WB01K0002 GE SPEEDNUT
WB1K2 WB1K2 GE SPEEDNUT
WB63X20216 WB63X20216 GE SUPPORT BASE
WB63X20215 WB63X20215 GE SUPPORT BASE
WB34X29145 WB34X29145 GE TOP COMPLEMENT BACKGUARD
WB34X24779 WB34X24779 GE TRIM FRONT FRAME
WB28X24772 WB28X24772 GE TUBE MANIFOLD SUPPLY
WB21X20260 WB21X20260 GE VALVE BURNER 270
WB21X20261 WB21X20261 GE VALVE BURNER 270
WB21X20262 WB21X20262 GE VALVE BURNER 270
WB21X20394 WB21X20394 GE VALVE BURNER 270
WB21X21506 WB21X21506 GE VALVE CONTROL ASSEMBLY NOR. D
WB2K24 WB2K24 GE VALVE COVER
WB34X20294 WB34X20294 GE VENT ASSEMBLY
WB16X24722 WB16X24722 GE XL V2 BURNER
