Model Image
Manufacturer

GE

Model Number

PGB965BP2TS

Description

Gas Range Or Dual Fuel

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB02K0003 WB02K0003 ANGLE SUPPORT
WB29K10023 WB29K10023 ASM BURNER CAP (9500)
WB16X28654 WB16X28654 ASM. CAP, BURNER SMALL V2
WB02X29637 WB02X29637 BADGE ASM
WB56X20457 WB56X20457 BARRIER BOTTOM FLOOR
WB16X28656 WB16X28656 BASE BURNER
WB34X31704 WB34X31704 BLACK COVER BACK UPPER
WB63X31653 WB63X31653 BLACK RANGE BACK
WB36X44709 WB36X44709 BLACK STAINLESS BACKGUARD RANGE
WB15X35051 WB15X35051 BLACK STAINLESS HANDLE
WB15X35052 WB15X35052 BLACK STAINLESS HANDLE W / LOGO
WB56X28174 WB56X28174 BLACK STAINLESS LOWER OUTER DOOR
WB36X44706 WB36X44706 BLACK STAINLESS MANIFOLD PANEL
WB56X40188 WB56X40188 BLACK STAINLESS UPPER OUTER DOOR
WB27X41006 WB27X41006 BOARD DAUGHTER RELAY
WB63X21725 WB63X21725 BOTTOM DUCT
WB34X24912 WB34X24912 BOTTOM OVEN
WB63X20441 WB63X20441 BOTTOM RANGE
WB02X20414 WB02X20414 BRACE
WB02K10254 WB02K10254 BRACKET ANTI-TIP ASM
WB02X20519 WB02X20519 BRACKET CAVITY
WB34X41012 WB34X41012 BRACKET CONTROL
WB02X24913 WB02X24913 BRACKET HANDLE
WB02X24914 WB02X24914 BRACKET HANDLE
WB02X20520 WB02X20520 BRACKET HANDLE
WB02K0041 WB02K0041 BRACKET OVEN CORNER
WB44X47938 WB44X47938 BROIL ELEMENT
WB02X24790 WB02X24790 BUMPER
WB16X28249 WB16X28249 BURNER BAKE
WB16X28670 WB16X28670 BURNER BAKE
WB16X28251 WB16X28251 BURNER BROIL
WB16X24724 WB16X24724 BURNER, MEDIUM V2
WB16X24721 WB16X24721 BURNER, SMALL V2
WB16X24722 WB16X24722 BURNER, XL V2
WB28K10222 WB28K10222 CAP BURNER XL
WB02K10360 WB02K10360 CKT BRACKET SMALL
WB01X24735 WB01X24735 CKT SCREW
WB02K0031 WB02K0031 CLIP CABLE
WB02X26569 WB02X26569 CLIP RANGETOP
WB02K10307 WB02K10307 CLIP WIRE
WB02K10267 WB02K10267 CLIP WIRE
WB02X24976 WB02X24976 CLIP, IGNITER V2
WB27X41009 WB27X41009 CONTROL OVEN ASM
WB44X10051 WB44X10051 CONVECTION ELEMENT
WB35X21685 WB35X21685 CORD FIBER GLASS
WB02K10337 WB02K10337 COVER CAP
WB34X24753 WB34X24753 COVER IGNITOR
WB34X25587 WB34X25587 COVER MOTOR
WB34X20526 WB34X20526 COVER SHUTTER
WB02K0024 WB02K0024 COVER VALVE
WB07X29140 WB07X29140 COVER VENT TRIM DD
WB57K10156 WB57K10156 CRYSTAL WINDOW
WB57K10155 WB57K10155 CRYSTAL WINDOW
WB07X29144 WB07X29144 DARK DORIAN END SUPPORT LH
WB07X29143 WB07X29143 DARK DORIAN END SUPPORT RH
WB34X31700 WB34X31700 DARK DORIAN GRAY BACKGUARD EYEBROW
WB56X46211 WB56X46211 DARK DORIAN GRAY PANEL SIDE
WB62X38001 WB62X38001 DARK DORIAN GRAY RANGETOP & BRACKET
WB10X24930 WB10X24930 DOOR LATCH AUTOMATIC
WB10X28795 WB10X28795 DOOR LATCH AUTOMATIC
WB01K10037 WB01K10037 ECONOMIC NUT
WB28X20451 WB28X20451 ELBOW 90 ASM
WB28X28696 WB28X28696 ELBOW 90 ASM
WB28X28695 WB28X28695 ELBOW 90 ASM
WB18X38052 WB18X38052 ELECTRODES & HARNESS H.V.
WB02X8351 WB02X8351 FAN BLADE
WB34X28701 WB34X28701 FAN COVER
WB35K10013 WB35K10013 FAN INSULATION
WB26X28953 WB26X28953 FAN MOTOR CONVECT
WB02K10034 WB02K10034 FAN SUPPORT
WB02X28737 WB02X28737 FRAME FRONT BUMPER
WB02X28738 WB02X28738 FRAME FRONT BUMPER
WB34X28740 WB34X28740 FRAME WINDOW ASSEMBLY
WB34X28741 WB34X28741 FRAME WINDOW ASSEMBLY
WB35X25645 WB35X25645 GASKET DRAWER ASM
WB32K10044 WB32K10044 GASKET OVEN LIGHT
WB32X29538 WB32X29538 GASKET OVEN LOWER CAVITY
WB32K10047 WB32K10047 GASKET OVEN UPPER CAVITY
WB31X24736 WB31X24736 GRATE ASM
WB2K8 WB2K8 GROMMET
WB35X21704 WB35X21704 GUARD INSULATION
WB56K10079 WB56K10079 GUARD INSULATION
WB18X41007 WB18X41007 HARNESS DRM2
WB18X24748 WB18X24748 HARNESS GROUND
WB18X25597 WB18X25597 HARNESS GROUND
WB18X27594 WB18X27594 HARNESS GROUND
WB18X41008 WB18X41008 HARNESS MASTER
WB18X38063 WB18X38063 HARNESS SWITCHES
WB18X24923 WB18X24923 HARNESS WIFI MODULE
WB16X28764 WB16X28764 HEAD BURNER
WB10X28783 WB10X28783 HINGE ASM LH
WB10X25637 WB10X25637 HINGE DOOR LH
WB10X26766 WB10X26766 HINGE DOOR RH
WB14K10003 WB14K10003 HINGE RANGE TOP
WB02X24941 WB02X24941 HOLDER RANGETOP
WB02X24942 WB02X24942 HOLDER RANGETOP
WB28X28781 WB28X28781 IGNITER GLOWBAR
WB13X25633 WB13X25633 IGNITER GLOWBAR
WB28X28780 WB28X28780 IGNITER GLOWBAR
WB13X24741 WB13X24741 IGNITION MODULE
WB16X28867 WB16X28867 INJECT BURNER MRHOB ASM
WB02X24727 WB02X24727 INJET, MEDIUM V2
WB02X24728 WB02X24728 INJET, SMALL V2
WB02X24725 WB02X24725 INJET, XL V2
WB16X28252 WB16X28252 INNER CAP BLACK
WB35X24985 WB35X24985 INSULATION BURNER BOX
WB34X21730 WB34X21730 INSULATION DOOR
WB34X21729 WB34X21729 INSULATION DOOR
WB34X21727 WB34X21727 INSULATION DOOR
WB34X21726 WB34X21726 INSULATION DOOR
WB34X21728 WB34X21728 INSULATION DOOR
WB35X21691 WB35X21691 INSULATION DOOR
WB35X30900 WB35X30900 INSULATION FRONT DOOR
WB35X28788 WB35X28788 INSULATION OVEN BACK
WB35X28790 WB35X28790 INSULATION OVEN BACK
WB35X28789 WB35X28789 INSULATION OVEN BACK
WB28X29255 WB28X29255 KIT LP HIGH ALTITUDE ASM
WB28X29254 WB28X29254 KIT NG HIGH ALTITUDE ASM
WB27X39766 WB27X39766 KIT WIFI MODULE SERVICE
WB03X29785 WB03X29785 KNOB ASM
WB03X38003 WB03X38003 KNOB ASM
WB02K10182 WB02K10182 LEG LEVELER
WB18X28855 WB18X28855 LINE CORD
WB34X28839 WB34X28839 LINER DOOR ASSEMBLY
WB56X24931 WB56X24931 LINER DOOR WELD ASSEMBLY
WB28X41066 WB28X41066 LP CONVERSION KIT ASM
WB28X25074 WB28X25074 MANIFOLD PIPE
WB34X20680 WB34X20680 MANIFOLD SUPPORT
WB02T10017 WB02T10017 NUT
WB01T10086 WB01T10086 NUT KEPS 6-32 SPECIAL
WB28X24858 WB28X24858 ORIFICE HOLDER
WB28X24763 WB28X24763 ORIFICE HOLDER
WB28X24850 WB28X24850 ORIFICE HOLDER
WB28X24762 WB28X24762 ORIFICE HOLDER CENTRAL
WB29X28253 WB29X28253 OUTER CAP
WB16K10076 WB16K10076 OVAL BURNER ASM
WB63X24934 WB63X24934 OVEN BOTTOM UC
WB34X20444 WB34X20444 OVEN DEFLECTOR
WB34X20443 WB34X20443 OVEN DEFLECTOR
WB08T10002 WB08T10002 OVEN LAMP HOLDER ASM
WB48X20249 WB48X20249 OVEN RACK
WB56X29670 WB56X29670 PANEL SIDE DD
WB35X26892 WB35X26892 PANEL SIDE FOIL
WB24X27550 WB24X27550 PLUNGER SWITCH
31-2000752 31-2000752 PM INSTALL INSTRUCTIONS
31-2000743 31-2000743 PM INSTALL INSTRUCTIONS
31-2000885 31-2000885 PM MINI MANUAL AND WIRING
49-2000884 49-2000884 PM OWNERS MANUAL
49-2000735 49-2000735 PM QUICK OWNERS MANUAL
31-11013 31-11013 PM WI FI INSTRUCTIONS
WB19K10077 WB19K10077 PRESSURE REGULATOR
WB07X41566 WB07X41566 RC15 OVERLAY
WB10X28563 WB10X28563 RECEIVER HINGE
WB10X29636 WB10X29636 RECEIVER HINGE LH
WB10X29635 WB10X29635 RECEIVER HINGE RH
WB31X24998 WB31X24998 REVERSIBLE GRIDDLE
WB21X28835 WB21X28835 SAFETY VALVE DUAL
WB21X28836 WB21X28836 SAFETY VALVE SINGLE
WB01K10116 WB01K10116 SCR 10-16 AB TRW20 1/2
WB01K10067 WB01K10067 SCR 8 HD 1/4 - 20
WB01X26995 WB01X26995 SCR 8-18 AB X 5/16S
WB02X32443 WB02X32443 SCR 8-18 B HXW 1/4S UH
WB01K0021 WB01K0021 SCREW
WB01K10091 WB01K10091 SCREW
WB01K0042 WB01K0042 SCREW (BLK)
WB01X32512 WB01X32512 SCREW 10-24
WB01T10008 WB01T10008 SCREW 10-32 TR T
WB01T10016 WB01T10016 SCREW 8-18 AB HXW 5/8 S
WB01X5754 WB01X5754 SCREW 8-18 ABT 1/2 S
WB01X1261 WB01X1261 SCREW GROUND
WB01K0050 WB01K0050 SCREW MTG IGNITER
WB24X25056 WB24X25056 SENSOR ASM
WB24X25557 WB24X25557 SENSOR ASM
WB16X20448 WB16X20448 SPACER BASE FRONT
WB16X20449 WB16X20449 SPACER BASE REAR
WB02X20849 WB02X20849 SPACER SIDE
WB01K0002 WB01K0002 SPEEDNUT
WB63X25481 WB63X25481 SUPPORT BASE LT
WB63X25480 WB63X25480 SUPPORT BASE RT
WB02X21705 WB02X21705 SUPPORT REGULATOR
WB02K10325 WB02K10325 SUPPORT VALVE SINGLE
WB56X29146 WB56X29146 TOP COVER ASM. DD
WB28X31693 WB28X31693 TUBE BURNER BOX SUPPLY
WB28X30712 WB28X30712 TUBE DUAL VALVE
WB28X30713 WB28X30713 TUBE DUAL VALVE
WB28X28152 WB28X28152 TUBE LOWER BAKE SUPPLY
WB28X28159 WB28X28159 TUBE OVEN SUPPLY
WB28X28163 WB28X28163 TUBE UPPER BAKE SUPPLY
WB28X28164 WB28X28164 TUBE VALVE SAFETY
WB21X25979 WB21X25979 VALVE BURNER 270
WB21X20612 WB21X20612 VALVE BURNER 270
WB21X20471 WB21X20471 VALVE BURNER 270
WB21X20470 WB21X20470 VALVE BURNER 270
WB21X28821 WB21X28821 VALVE BURNER 3R 310
WB02X32440 WB02X32440 WASHER CONTOURED
