Model Number

PH50S10BNY01

Description

Ge Profile Geospring Smart Hybrid Heat Pump Water

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WS01X24894 WS01X24894 ANCHOR SCREW CTA
WS21X24886 WS21X24886 B - INVERTER ASM 240V
WS21X24896 WS21X24896 B - MAIN BOARD ASM HP
WR04X10181 WR04X10181 BADGE GE ASM
WS04X21920 WS04X21920 BARRIER DIELECTRIC LE
WS21X24895 WS21X24895 BEZEL CONTROL WH
WS04X24879 WS04X24879 BODY SOUND BLANKET ASM
WS04X24880 WS04X24880 CAP SOUND BLANKET ASM
WS21X24906 WS21X24906 CAT5/6 CONNECTION CABLE (RJ45) CTA2045
WS03X21911 WS03X21911 CLIP SPRING THERMOSTAT
WS98X24875 WS98X24875 COMPRESSOR VS
WS06X24881 WS06X24881 CONDENSATE DRAIN PAN
WS35X24891 WS35X24891 CONNECTOR WAGO
WS35X24981 WS35X24981 DC WIRE HARNESS
WS08X24865 WS08X24865 DIP TUBE PEX PLUGGED (50G HP & 40S/50S E
WS06X21924 WS06X21924 DRAIN VALVE
WS51X21905 WS51X21905 ELEMENT COVER METALLARGEUE/LE
WS51X24862 WS51X24862 ELEMENT HEATING W/ GASKET (HWD 3600/900W
WS31X24961 WS31X24961 ENCLOSURE ARC TCO (BMC)
WS31X24887 WS31X24887 ENCLOSURE INVERTER OUTBOARD (BMC)
WS87X24883 WS87X24883 EVAPORATOR (2 BANK)
WS94X24964 WS94X24964 FAN MOTOR AND BLADE
WS12X24884 WS12X24884 FAN SHROUD PLASTIC
WS85X24902 WS85X24902 FILTER AIR SIDE
WS85X24901 WS85X24901 FILTER AIR TOP
WS53X24965 WS53X24965 FILTER DRYER ASM
WS51X21907 WS51X21907 FIXED J-BOX COVER
WS31X24892 WS31X24892 FRONT SHROUD HP
WS01X22235 WS01X22235 GROMMET INLET, BLUE
WS01X22234 WS01X22234 GROMMET INLET, RED
WS35X24874 WS35X24874 HARNESS BNDL INVRTR AC AND DC HP
WS35X24873 WS35X24873 HARNESS BNDL INVRTR COMM N CMP TCO HP
WS51X23622 WS51X23622 HEATING ELEMENT W/ GASKET
WS04X21914 WS04X21914 INSULATION UE/LE (POLYESTER)
WS51X21906 WS51X21906 J-BOX ACCESS COVER
WS02X24900 WS02X24900 J-BOX COVER
WS21X24904 WS21X24904 LEAK DETECT MODULE
WS03X10075 WS03X10075 MASTIC THERMAL SENSOR
WS21X24905 WS21X24905 MODULE CTA2045
WS02X24877 WS02X24877 NUT M8X1.25 HEX FLANGE NY INS
WS31X24898 WS31X24898 OVERLAY WH
WS04X24868 WS04X24868 PIPE INSULATION (FULL, 16-INCH ) OVER 19-INCH EXT
WS07X24867 WS07X24867 PIPE NIPPLE (FULL, 19-INCH ALLPASS)RIFENG
49-6000333 49-6000333 PRINTED AND ONLINEINSERT INSTRUCTIONS
31-6000341 31-6000341 PRINTED AND ONLINEINSTALL INSTRUCTIONS
49-6000330 49-6000330 PRINTED AND ONLINEOWNERS AND INSTALL
WS31X24962 WS31X24962 REAR ENCLOSURE (TCO OPENING)
WS31X24889 WS31X24889 REAR SHROUD HP
WS02X24882 WS02X24882 SCR 10-16 HXW 1.75
WS02X22081 WS02X22081 SCR 10-32 GX HXWP 1/2 S ZN GRN
WS02X22082 WS02X22082 SCR 10-32 GX PNP 1/2 S ZN
WS02X10076 WS02X10076 SCR 10-32 PNUP 3/8 S
WS02X22226 WS02X22226 SCR 8-32 GX PNP 1.25S ZN
WS02X21904 WS02X21904 SCR 8-32 GX PNP 3/8 S ZN
WS02X22227 WS02X22227 SCR10-16 PL PNP 7/8 S BLK
WS02X24861 WS02X24861 SCR10-16 PL PNSP 1-1/4 S ZN
WS02X22224 WS02X22224 SCR6-19 PL PNP 3/8
WR01X28349 WR01X28349 SCREW M4 X 8
WS02X22961 WS02X22961 SENSING ANODE ROD 40-INCH M
WS07X24903 WS07X24903 SHUTOFF VALVE KIT
WS53X24966 WS53X24966 SUCTION TUBE ASM
WS04X21913 WS04X21913 T-P INSULATION
WS06X21923 WS06X21923 T-P VALVE
WS17X22381 WS17X22381 T1 SENSOR TANK LOWER
WS17X22382 WS17X22382 T2 SENSOR TANK UPPER
WS03X22261 WS03X22261 TANK SENSOR SPRING CLIP
WS17X22386 WS17X22386 TCO 180F
WS21X24963 WS21X24963 TCO ARC LIMIT
WS03X22401 WS03X22401 TCO BRACKET
WS07X24876 WS07X24876 TUBE DISCHARGE ASM
WS01X24893 WS01X24893 WASHER CTA
WS02X22233 WS02X22233 WASHER SHOULDER
WH22X36577 WH22X36577 WIFI BOARD
WS21X22981 WS21X22981 WIFI BOARD WIRE HARNESS
WS35X24888 WS35X24888 WIRE GROUND HARNESS (WRAPPER)
WS35X24878 WS35X24878 WIRE GROUND HARNESS FERRITE ASM (COMPRES
