Model Image
Manufacturer

GE

Model Number

PSB42LSRBV

Description

Built In S X S

Interactive Exploded View

Parts List

Part Number Description
WR57X10059 WR57X10059 3 WAY VALVE COIL
WR57X10054 WR57X10054 3-WAY VALVE
40A15 40A15 40WATT 15AMP
WR82X10098 WR82X10098 ACCESS COVER
WR02X11897 WR02X11897 ASM BRACKET HINGE LOW
WR24X10162 WR24X10162 ASM GASKET DOOR FZ
WR21X10100 WR21X10100 ASM-BASKET WIRE LOW
WR21X10099 WR21X10099 ASM-BASKET WIRE UPPER
WR78X11086 WR78X11086 ASSEMBLY DOOR-STS FZ
WR02X12296 WR02X12296 ASSEMBLY GROMMET LINK
WR71X10600 WR71X10600 ASSEMBLY GUARD REF
WR71X10601 WR71X10601 ASSEMBLY GUARD-GALLON
WR12X10705 WR12X10705 ASSEMBLY HANDLE-DOOR
WR55X22607 WR55X22607 ASSEMBLY PCB
WR78X11087 WR78X11087 ASSEMBLY-DOOR STS FF
WR60X10179 WR60X10179 ASSEMBLY-FAN MOTOR REF
WR24X10163 WR24X10163 ASSEMBLY-GASKET DOOR FF
WR74X10192 WR74X10192 ASSEMBLY-GRILLE
WR02X11896 WR02X11896 ASSEMBLY-STOPPER DOOR A
WR02X11926 WR02X11926 BAG ENVELOPE-PE
WR22X10051 WR22X10051 BIN/DOOR DAIRY ASM
WR60X10181 WR60X10181 BLADE CONDENSER FAN
WR01X10462 WR01X10462 BOLT 10MM
WR02X11921 WR02X11921 BRACKET ACCESS COVER
WR02X11901 WR02X11901 BRACKET HINGE BOTTOM FF
WR02X11899 WR02X11899 BRACKET HINGE-UPPER FF
WR02X11872 WR02X11872 BRACKET THERMOSTAT FZ
WR02X11894 WR02X11894 BRKT-SOCKET LAMP DISP
WR02X11892 WR02X11892 CAP-CHUTE ICE
WR02X11878 WR02X11878 CAP-SCREW
WR02X12016 WR02X12016 CAP-TUBE WATER LINE
WR17X11730 WR17X11730 CASE EVAP FZ FRONT
WR02X11909 WR02X11909 CASTER ASM
WR02X11927 WR02X11927 CLAMP
WR02X11873 WR02X11873 CLAMP HOSE FZ
WR17X36266 WR17X36266 COIL FILTER-REACTOR
WR85X10065 WR85X10065 COMPLETE EVAP ASM FF
WR85X23077 WR85X23077 COMPLETE EVAP ASM FZ
WR13X10346 WR13X10346 COMPLETE HINGE ASM LH
WR13X10348 WR13X10348 COMPLETE HINGE ASM RH
WR78X23067 WR78X23067 COMPRESSOR
WR01X24369 WR01X24369 COMPRESSOR BOLT
WR84X10068 WR84X10068 CONDENSER ASM
WR17X11762 WR17X11762 CONDENSER DRAIN PAN
WR60X10177 WR60X10177 CONDENSER FAN ASM
WR17X11753 WR17X11753 CONDENSER SUPPORT ASM
WR17X11768 WR17X11768 CONTROL DISPENSER BK
WR17X11733 WR17X11733 COVER AIR DUCT ASM FZ
WR22X10050 WR22X10050 COVER DOOR-DAIRY
WR17X11741 WR17X11741 COVER DUCT ASM FF
WR02X11876 WR02X11876 COVER DUCT FZ
WR17X11744 WR17X11744 COVER DUCT UPPER FF ASM
WR02X11884 WR02X11884 COVER EVAP FRONT FF
WR17X11732 WR17X11732 COVER EVAP FZ
WR02X11914 WR02X11914 COVER FILL TUBE ASM
WR02X11929 WR02X11929 COVER LAMP-DISPENSER
WR02X11867 WR02X11867 COVER LEVER ARM
WR02X11949 WR02X11949 COVER RELAY
WR32X10497 WR32X10497 COVER VEG PAN LOWER
WR02X11928 WR02X11928 COVER-CONNECTOR
WR17X11772 WR17X11772 COVER-DISPENSER
WR02X11886 WR02X11886 COVER-GRILLE FF
WR02X11919 WR02X11919 COVER-HOUSING
WR02X11868 WR02X11868 COVER-MOTOR AUGER
WR02X11920 WR02X11920 COVER-NOISE FILTER
WR17X11758 WR17X11758 COVER-PCB PANEL
WR02X11911 WR02X11911 COVER-WATER LINE
WR50X10063 WR50X10063 DEFROST HEATER FZ
WR49X10106 WR49X10106 DISP UPGRADE KIT BK
WR01X37886 WR01X37886 DISPENSER LIGHT
WR71X10599 WR71X10599 DOOR MODULE FZ
WR02X11874 WR02X11874 DRAIN CONNECTOR FZ
WR17X11754 WR17X11754 DRAIN PAN
WR02X11885 WR02X11885 DRAIN TROUGH ASM FF
WR51X10082 WR51X10082 DRAIN/HEATER ASM FZ
WR02X11869 WR02X11869 DRIVE FORK AUGER
WR17X11876 WR17X11876 DUCT DOOR ASM
WR02X23852 WR02X23852 DUCT FOAM UPPER FZ
WR62X10067 WR62X10067 EMI NOISE FILTER
WR17X23073 WR17X23073 EVAP CASE ASM FF
WR17X11731 WR17X11731 EVAP CASE W/REAR HTR
WR85X10063 WR85X10063 EVAP/DEFROST HTR ASM FF
WR85X10062 WR85X10062 EVAP/DEFROST HTR FZ ASM
WR29X10065 WR29X10065 FILL CUP IM
WR02X11913 WR02X11913 FILL TUBE ASM
WR17X11756 WR17X11756 FILTER HEAD
WR02X11947 WR02X11947 FIXER-GROMMET DOOR
WR02X11916 WR02X11916 FOAM INSULATION BLOCK
WR02X11922 WR02X11922 FOAM SEAL
WR17X11763 WR17X11763 FUNNEL BK
WR02X11923 WR02X11923 GAS SHOCK
WR17X11770 WR17X11770 GRILLE RECESS BK
WR02X11915 WR02X11915 GROMMET-COMP
WR02X11917 WR02X11917 GROMMET-COND
WR02X11948 WR02X11948 GROMMET-PIPE WATER FILL
WR23X10399 WR23X10399 HARNESS AC ASM
WR23X10400 WR23X10400 HARNESS AC ASM
WR23X10397 WR23X10397 HARNESS AC ASM
WR23X10398 WR23X10398 HARNESS DC ASM
WR23X10393 WR23X10393 HARNESS LAMP FZ
WR23X10395 WR23X10395 HARNESS LOWER LIGHTS FF
WR23X10394 WR23X10394 HARNESS UPPER LIGHTS FF
WR17X11757 WR17X11757 HEAT EXCHANGER ASM
WR13X10347 WR13X10347 HINGE ARM LINK LH
WR13X10349 WR13X10349 HINGE ARM LINK RH
WR13X10343 WR13X10343 HINGE UPPER FZ
WR13X10345 WR13X10345 HINGE-UPP R
WR17X11808 WR17X11808 HSNG UPPER LIGHT ASM FF
WR30X10057 WR30X10057 ICE BUCKET ASM
WR30X10056 WR30X10056 ICE BUCKET ASM W/FRONT
WR17X22614 WR17X22614 ICE BUCKET DOOR
WR17X11722 WR17X11722 ICE BUCKET FRONT
WR82X10099 WR82X10099 INSULATION EVAP MTR FF
WR02X11957 WR02X11957 J-NUT
WR02X30348 WR02X30348 LAMP SOCKET
WR17X11752 WR17X11752 LEVELING JACK REAR
WR30X10093 WR30X10093 MECH ICEMAKER ASM
WR17X11764 WR17X11764 MICROS/HRNS/SUPT ASM
WR60X10180 WR60X10180 MOTOR & CAM - DUCT DOOR
WR60X10178 WR60X10178 MOTOR & SWITCH ASM CUBE
WR60X10175 WR60X10175 MOTOR AUGER
WR60X10176 WR60X10176 MOTOR FAN ASM FZ
WR02X11945 WR02X11945 PAD CRADLE
WR32X10498 WR32X10498 PAN VEG LOWER
WR71X23467 WR71X23467 PAN VEG MID 42
WR71X23466 WR71X23466 PAN VEG UPPER 42
WR17X23074 WR17X23074 PANEL TOE KICK
WR02X11879 WR02X11879 PLUG COVER FZ
WR23X10300 WR23X10300 POWER CORD
WR02X11902 WR02X11902 QUICK CONNECTOR TUBING
WR86X25269 WR86X25269 R134 DRIER
WR17X11734 WR17X11734 RACK SHELVING FZ
WR17X11724 WR17X11724 RAIL LH AUGER
WR17X11728 WR17X11728 RAIL LH BASKET FZ
WR17X11735 WR17X11735 RAIL LOWER GLASS SHELF F
WR17X11725 WR17X11725 RAIL RH AUGER
WR17X11727 WR17X11727 RAIL RH BASKET FZ
WR17X11736 WR17X11736 RAIL VEG PANS LH
WR17X11737 WR17X11737 RAIL VEG PANS RH
WR23X31507 WR23X31507 REFRIGERATOR DOOR LIGHT SWITCH
WR07X10088 WR07X10088 RELAY PROTECTOR O/L
WR01X10436 WR01X10436 RETAINING SPRING FAN
WR02X11882 WR02X11882 ROLLER VEG PAN
WR01X10769 WR01X10769 SCREW TAPPING
WR01X10460 WR01X10460 SCREW-MACHINE
WR02X11898 WR02X11898 SCREW-SPECIAL
WR02X11870 WR02X11870 SCREW-SPECIAL
WR01X10464 WR01X10464 SCREW-TAPPING
WR01X10468 WR01X10468 SCREW-TAPPING
WR01X10461 WR01X10461 SCREW-TAPPING
WR01X10463 WR01X10463 SCREW-TAPPING
WR02X11930 WR02X11930 SCREW-TAPPING
WR02X11871 WR02X11871 SCREW-TAPPING
WR02X11865 WR02X11865 SCREW-TAPPING
WR71X22620 WR71X22620 SHELF GLASS FF
WR71X10598 WR71X10598 SHELF GLASS FF LOWER
WR71X10596 WR71X10596 SHELF WIRE ASM
WR17X11738 WR17X11738 SHELF-WINE
WR02X11877 WR02X11877 SHIELD LAMP FZ
WR02X11888 WR02X11888 SHIELD LAMP LOWER FF
WR02X11887 WR02X11887 SHIELD LAMP UPPER FF
WR13X10351 WR13X10351 SHIM HINGE-UPP L
WR13X10350 WR13X10350 SHIM HINGE-UPP R
WR02X11907 WR02X11907 SHOCK ABSORBER RH
WR02X11889 WR02X11889 SHOCK POST
WR02X11904 WR02X11904 SNUGGER
WR02X11905 WR02X11905 SNUGGER LG
WR02X11893 WR02X11893 SOCKET LAMP DISP
WR02X11900 WR02X11900 STOPPER DOOR FF
WR02X11895 WR02X11895 STRIKE SWITCH
WR02X11925 WR02X11925 SUPPORT DRAIN PAN REAR
WR02X11880 WR02X11880 SUPPORT LOWER VEG PAN
WR02X11881 WR02X11881 SUPPORT RAIL LH
WR02X11883 WR02X11883 SUPPORT RAIL RH
WR23X10401 WR23X10401 SWITCH ASM MAIN
WR23X10396 WR23X10396 SWITCH-MICRO
WR50X10062 WR50X10062 THERMISTOR - EXT TEMP
WR50X10058 WR50X10058 THERMISTOR - FZ
WR50X10056 WR50X10056 THERMISTOR - FZ EVAP
WR50X10061 WR50X10061 THERMISTOR FF
WR50X10059 WR50X10059 THERMISTOR FF EVAP
WR50X10060 WR50X10060 THERMOSTAT DEFROST FF EV
WR50X10057 WR50X10057 THERMOSTAT DEFROST FZ
WR02X11910 WR02X11910 THIMBLE HINGE LOWER
WR02X11903 WR02X11903 THIMBLE HINGE UPPER
WR17X11742 WR17X11742 TRACK SHELVING FF
WR17X11771 WR17X11771 TRAY-DISP BK
WR38X10345 WR38X10345 TRIM FRAME BOTTOM
WR38X10344 WR38X10344 TRIM FRAME LH
WR38X10343 WR38X10343 TRIM FRAME RH
WR17X11759 WR17X11759 TRIM FRAME UPPER
WR38X10346 WR38X10346 TRIM LIGHT SWITCHES
WR02X11943 WR02X11943 TRIM PAD CRADLE
WR02X11918 WR02X11918 TUBING SUCTION LINE
MWFP MWFP WATER FILTER
WR17X11743 WR17X11743 WATER TANK ASM
WR02X11890 WR02X11890 WATER TUBE LINE A
WR57X33326 WR57X33326 WATER VALVE WITH GUARD
