Model Image
Manufacturer

GE

Model Number

PSB9120EF4ES

Description

Microwave Or Advantium

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB18X33767 WB18X33767 "HARNESS, SINGLE"
WB26X10211 WB26X10211 AC FAN MOTOR
WB49X10187 WB49X10187 ADVANTIUM METAL COOKING TRAY
WB34X32602 WB34X32602 AIR TUNNEL
WB07X32844 WB07X32844 BARRIER SS
WB02X32634 WB02X32634 BOARD SUPPORTER
WB56X32579 WB56X32579 BOTTOM PANEL
WB07X37266 WB07X37266 BOTTOM SLATE TRIM
WB02X32591 WB02X32591 BRACKET
WB02X32582 WB02X32582 BRACKET
WB02X32587 WB02X32587 BRACKET
WB02X32593 WB02X32593 BRACKET CAPACITOR
WB02X11223 WB02X11223 BRACKET HEATER
WB02X32682 WB02X32682 BRACKET HEATER
WB06X10638 WB06X10638 CANOPY MICA
WB06X10642 WB06X10642 CHAMBER
WB56X32580 WB56X32580 COVER BACK
WB06X32848 WB06X32848 COVER HEATER
WB19X42246 WB19X42246 DAMPER ASM
WB27X10856 WB27X10856 DIGITRON
WB27X41746 WB27X41746 DISPLAY BOARD
WB01X34910 WB01X34910 DOOR REMOVAL TOOL
WB56X32578 WB56X32578 FLAT OUTER CASE
WB02X35488 WB02X35488 HALOGEN BULB 130V/50W
WB18X33768 WB18X33768 HARNESS
WB18X32853 WB18X32853 HARNESS SINGLE
WB18X32597 WB18X32597 HARNESS WIRE
WB34X32589 WB34X32589 HEATER COVER
WB21X28572 WB21X28572 HEATER HALOGEN
WB44X41527 WB44X41527 HEATER MIRACLON
WB44X10050 WB44X10050 HEATER SHEATH
WB17X10030 WB17X10030 HIGH VOLTAGE TRANSFORMER
WB02X11233 WB02X11233 HOLDER WIRE
WB27X30032 WB27X30032 INDICATOR
WB01X32574 WB01X32574 INSTALLATION HARDWARE
WB34X32583 WB34X32583 LIGHT COVER
WB26X32629 WB26X32629 MAGNETRON
WB27X32847 WB27X32847 MAIN BOARD
WB49X47646 WB49X47646 METAL BB TRAY
WB06X10641 WB06X10641 MICROWAVE BOTTOM PANEL
WB06X10570 WB06X10570 MICROWAVE BRACKET
WB02X11225 WB02X11225 MICROWAVE BRACKET
WB27X11033 WB27X11033 MICROWAVE CAPACITOR
WB02X11320 WB02X11320 MICROWAVE CONTROL PANEL BRACKET
WB27X10037 WB27X10037 MICROWAVE DIODE CABLE
WB34X32594 WB34X32594 MICROWAVE DUCT ASSEMBLY
WB26X32609 WB26X32609 MICROWAVE FAN MOTOR
WB02X32572 WB02X32572 MICROWAVE HEAT SHIELD
WB10X32573 WB10X32573 MICROWAVE LATCH BODY - LEFT
WB10X32577 WB10X32577 MICROWAVE LATCH BODY - RT
WB02X32588 WB02X32588 MICROWAVE LEVER
WB27X10928 WB27X10928 MICROWAVE LINE FUSE
WB02X35865 WB02X35865 MICROWAVE NOISE FILTER
WB34X32592 WB34X32592 MICROWAVE PROTECTOR
WB24X10047 WB24X10047 MICROWAVE SWITCH
WB21X10148 WB21X10148 MICROWAVE THERMOSTAT
WB07X32622 WB07X32622 MICROWAVE TRIM - RIGHT
WB34X32628 WB34X32628 MOTOR BRACKET
WB26X10193 WB26X10193 MOTOR TURNTABLE
WB26X10182 WB26X10182 MOTOR(CIRC) CIRCULATION
WB34X32596 WB34X32596 MOUNT
WB02X32599 WB02X32599 MOUNT
WB6X475 WB6X475 MTR CL BLADE
WB56X32575 WB56X32575 PANEL
31-2000001 31-2000001 PM INSTALL INSTRUCTIONS
31-30804 31-30804 PM MINI MANUAL
49-40685 49-40685 PM OWNERS MANUAL
WB27X32842 WB27X32842 POWER BOARD
WB27X43190 WB27X43190 POWER CORD ASSEMBLY
WB49X10213 WB49X10213 RACK
WB07X32843 WB07X32843 RANGE BOTTOM PLATE
WB34X32584 WB34X32584 RANGE DOOR SWITCH ACCESS COVER
WB02X10542 WB02X10542 RANGE MOTOR BRACKET
WB02X11318 WB02X11318 REFLECTOR
WB02X32581 WB02X32581 REFLECTOR
WB27X32849 WB27X32849 RELAY BOARD
WB02X32600 WB02X32600 ROTATING RING ASSEMBLY
WB01X1504 WB01X1504 SCREW - HEATER SHEATH
WB1X1504 WB1X1504 SCREW TRUSS
WB02X32576 WB02X32576 SEAL TAPE
WB27X10857 WB27X10857 SENSOR ASSEMBLY
WB06X10693 WB06X10693 SHAFT ASSEMBLY
WB1X1518 WB1X1518 SHAFT RING
WB56X37190 WB56X37190 SLATE CONTROLER ASSEMBLY
WB56X37198 WB56X37198 SLATE DOOR ASSEMBLY
WB03X35392 WB03X35392 STAINLESS STEEL KNOB
WB27X32846 WB27X32846 SUB PCB ASSEMBLY
WB02X32606 WB02X32606 SUPPORT
WB24X25397 WB24X25397 SWITCH MICRO
WB18X10287 WB18X10287 THERMISTOR NTC
WB21X10149 WB21X10149 THERMOSTAT
WB34X21258 WB34X21258 TOP COVER
WB17X10021 WB17X10021 TRANSFORMER POWER
WB27X43590 WB27X43590 TRAY GLASS
WB07X32627 WB07X32627 TRIM LH
WB01X1522 WB01X1522 WASHER COMMON
WB1X1521 WB1X1521 WASHER PLAIN
WB1X1522 WB1X1522 WASHER SPLK
WB01X1521 WB01X1521 WASHER- PLAIN
