Model Image
Manufacturer

GE

Model Number

PSI23NCNABB

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
40A15-2PK 40A15-2PK GE 60A - 2BULBS
40A15 40A15 GE 60A - 2BULBS
WR01X10241 WR01X10241 GE 8-18 X 13/16 TX PH WHITE
WR01X10613 WR01X10613 GE 8-18 X 7/16 TX PH WHITE
WR87X20798 WR87X20798 GE A ASSEMBLY HI SIDE
WR82X10103 WR82X10103 GE ACCESS COVER
WR17X13159 WR17X13159 GE BAFFLE COND AIR
WR17X10693 WR17X10693 GE BASEPLATE HIGH SIDE
WR21X10156 WR21X10156 GE BASKET
WR21X10041 WR21X10041 GE BASKET WIRE FZ
WR21X10110 WR21X10110 GE BASKET WIRE TILTOUT FZ
WR21X10111 WR21X10111 GE BASKET WIRE TILTOUT FZ
WR71X10290 WR71X10290 GE BEZEL LIGHT FF
WR60X24484 WR60X24484 GE BLADE CONF FAN ASSEMBLY
WR02X10669 WR02X10669 GE BLOCK EVAP SEAL
WR55X10942 WR55X10942 GE BOARD ASM MAIN CONTROL
WR02X10815 WR02X10815 GE BOSS SPACER
WR02X10656 WR02X10656 GE BRACKET ANGLE
WR02X11863 WR02X11863 GE BRACKET COND FAN (MTG)
WR02X10593 WR02X10593 GE BRACKET COND FAN (REAR)
WR17X10763 WR17X10763 GE BRACKET CONDENSER BAR
WR02X10667 WR02X10667 GE BRACKET EVAP COVER
WR02X10764 WR02X10764 GE BRACKET EVAP FAN BTM
WR02X11336 WR02X11336 GE BRACKET IM MOUNTING
WR02X10653 WR02X10653 GE BRACKET ORIFICE FAN
WR30X10023 WR30X10023 GE BUCKET NON DISPLAY
WR02X10540 WR02X10540 GE BUMPER LID
WR1X5278 WR1X5278 GE CABLE CLAMP
WR02X10779 WR02X10779 GE CAM CLOSURE FF BK
WR02X10637 WR02X10637 GE CAM CLOSURE FF WH
WR02X10780 WR02X10780 GE CAM CLOSURE FZ BK
WR02X10638 WR02X10638 GE CAM CLOSURE FZ WHITE
WR02X10785 WR02X10785 GE CAP CORNER OC BISQUE
WR02X10781 WR02X10781 GE CAP CORNER OC BLACK
WR02X10640 WR02X10640 GE CAP CORNER OC WHITE
WR02X10322 WR02X10322 GE CAP DUST
WR17X11280 WR17X11280 GE CAP TRIM BTM FF BK
WR17X11284 WR17X11284 GE CAP TRIM BTM FF BQ
WR17X11271 WR17X11271 GE CAP TRIM BTM FF WH
WR17X11281 WR17X11281 GE CAP TRIM BTM FZ BK
WR17X11285 WR17X11285 GE CAP TRIM BTM FZ BQ
WR17X11272 WR17X11272 GE CAP TRIM BTM FZ WH
WR62X0079 WR62X0079 GE CAPACITOR
WR55X24064 WR55X24064 GE CAPACITOR
WR01X5278 WR01X5278 GE CLAMP CABLE
WR02X10522 WR02X10522 GE CLAMP TUBE
WR02X8203 WR02X8203 GE CLIP COMPRESSOR MOUNT
WR02X10552 WR02X10552 GE CLIP EVAP THERMISTOR
WR02X10738 WR02X10738 GE CLIP GRILLE
WR22X10021 WR22X10021 GE COMPARTMENT DAIRY
WR84X10022 WR84X10022 GE COND ASSEMBLY FORMED
WR17X35527 WR17X35527 GE CONDENSER FAN SHROUD
WR82X10109 WR82X10109 GE COVER ACCESS ASSEMBLY
WR17X11336 WR17X11336 GE COVER DUCT
WR17X10795 WR17X10795 GE COVER EVAPORATORORATOR FRONT
WR17X10802 WR17X10802 GE COVER FF TOWER
WR32X10146 WR32X10146 GE COVER FRONT CHILL
WR32X10885 WR32X10885 GE COVER FRONT CHILL
WR02X10834 WR02X10834 GE COVER HINGE FF BISQUE
WR02X10832 WR02X10832 GE COVER HINGE FF BLACK
WR02X10831 WR02X10831 GE COVER HINGE FF BLACK
WR02X10658 WR02X10658 GE COVER HINGE FF WHITE
WR02X10835 WR02X10835 GE COVER HINGE FZ BISQUE
WR02X10657 WR02X10657 GE COVER HINGE FZ WHITE
WR02X10810 WR02X10810 GE COVER L.H.
WR31X10043 WR31X10043 GE COVER LOWER
WR32X26245 WR32X26245 GE COVER MIDDLE PAN
WR32X10200 WR32X10200 GE COVER PAN GLASS
WR02X10811 WR02X10811 GE COVER R.H.
WR02X10556 WR02X10556 GE COVER RELAY SNAP (MEI)
WR32X10579 WR32X10579 GE COVER TOP PAN ASSEMBLY
WR31X10008 WR31X10008 GE COVER UPPER
WR29X10092 WR29X10092 GE CUP FILL IM
WR29X10109 WR29X10109 GE CUP FILL IM
WR60X10063 WR60X10063 GE DAMPER ASM DESUPPLY
WR60X10062 WR60X10062 GE DAMPER ASM SUPPLY
WR50X10068 WR50X10068 GE DEFROST THERMOSTAT
WR32X10154 WR32X10154 GE DIAL PAN CHILL
WR02X10641 WR02X10641 GE DISCHARGE PAN CHILL
WR22X10058 WR22X10058 GE DISH BUTTER
WR17X11609 WR17X11609 GE DIVERTER FF AIRFLOW
WR22X10022 WR22X10022 GE DOOR DAIRY CLEAR
WR78X10604 WR78X10604 GE DOOR FOAM ASM FF BK
WR78X10602 WR78X10602 GE DOOR FOAM ASM FF BQ
WR78X10600 WR78X10600 GE DOOR FOAM ASM FF WH
WR78X10634 WR78X10634 GE DOOR FOAM ASM FZ BK
WR78X10633 WR78X10633 GE DOOR FOAM ASM FZ WH
WR31X10009 WR31X10009 GE DUCT CAVITY CHILL
WR17X10803 WR17X10803 GE EPS FF TOWER
WR02X10644 WR02X10644 GE EPS PAN CHILL
WR60X30922 WR60X30922 GE EVAPORATOR FAN BLADE
WR17X13035 WR17X13035 GE FAN CHILL
WR02X10562 WR02X10562 GE FASTENER PUSH
WR14X10068 WR14X10068 GE FOAM STRIP SE ADH
WR14X10067 WR14X10067 GE FOAM STRIP SE ADH
WR14X10069 WR14X10069 GE FOAM STRIP SE ADH
WR14X10053 WR14X10053 GE FOAM STRIP SE ADH
WR31X10027 WR31X10027 GE FRAME 23 CHILL
WR49X10135 WR49X10135 GE FRAME SUPPORT PINS
WR14X10096 WR14X10096 GE GASKET DAMPER CHILL
WR24X20456 WR24X20456 GE GASKET DOOR FF BLACK
WR24X20455 WR24X20455 GE GASKET DOOR FZ BLACK
WR14X10061 WR14X10061 GE GASKET EVAP COVER
WR49X10091 WR49X10091 GE GASKET FF INLET
WR14X10062 WR14X10062 GE GASKET FF TOWER
WR14X10093 WR14X10093 GE GASKET LC
WR14X10095 WR14X10095 GE GASKET MULLION DUCT
WR14X10059 WR14X10059 GE GASKET PAN CRV FRONT
WR14X10102 WR14X10102 GE GASKET PAN CRV REAR
WR14X10058 WR14X10058 GE GASKET PAN CRV REAR
WR14X10066 WR14X10066 GE GASKET PLENUM
WR14X10065 WR14X10065 GE GASKET PLENUM
WR14X10064 WR14X10064 GE GASKET PLENUM
WR14X10063 WR14X10063 GE GASKET PLENUM
WR14X10094 WR14X10094 GE GASKET UC
WR72X10169 WR72X10169 GE GLIDE BUCKET LH DISPLAY
WR72X10145 WR72X10145 GE GLIDE BUCKET RH DISPLAY
WR31X10010 WR31X10010 GE GRILL BULB CHILL
WR02X10829 WR02X10829 GE GRILL MULLION
WR02X10671 WR02X10671 GE GRILLE AIR RETURN
WR74X10270 WR74X10270 GE GRILLE BASE
WR02X10647 WR02X10647 GE GRILLE SENSOR
WR02X10678 WR02X10678 GE GROMMET
WR02X22869 WR02X22869 GE GROMMET
WR17X11168 WR17X11168 GE GROMMET AND TUBE ASM
WR02X10689 WR02X10689 GE GROMMET BASE GRILL
WR02X11331 WR02X11331 GE GROMMET EVAP FAN
WR02X10520 WR02X10520 GE GROMMET FAN MOTOR
WR14X10055 WR14X10055 GE GROMMET TUBING SLIT
WR74X10131 WR74X10131 GE GUARD WIRING
WR12X10625 WR12X10625 GE HANDLE
WR12X10626 WR12X10626 GE HANDLE
WR12X10543 WR12X10543 GE HANDLE ASM TRIM FF BK
WR12X10541 WR12X10541 GE HANDLE ASM TRIM FF BQ
WR12X10539 WR12X10539 GE HANDLE ASM TRIM FF WH
WR12X10542 WR12X10542 GE HANDLE ASM TRIM FZ BK
WR12X10540 WR12X10540 GE HANDLE ASM TRIM FZ BQ
WR12X10538 WR12X10538 GE HANDLE ASM TRIM FZ WH
WR12X10974 WR12X10974 GE HANDLE SOFT TOUCH INSERT
WR23X10504 WR23X10504 GE HARNESS BOARD INDIV
WR23X10284 WR23X10284 GE HARNESS CHILL AC
WR23X10485 WR23X10485 GE HARNESS CHILL DC
WR23X10290 WR23X10290 GE HARNESS DEF HEATER
WR23X10209 WR23X10209 GE HARNESS/TSTAT FF LT
WR51X10055 WR51X10055 GE HEATER & BRACKET ASM
WR51X10138 WR51X10138 GE HEATER THAW
WR13X10170 WR13X10170 GE HINGE BTM & PIN ASSEMBLY BISQU
WR13X10168 WR13X10168 GE HINGE BTM & PIN ASSEMBLY BLACK
WR13X10129 WR13X10129 GE HINGE BTM & PIN ASSEMBLY WHITE
WR13X10126 WR13X10126 GE HINGE BTM ADJ WHITE
WR13X10167 WR13X10167 GE HINGE BTM BK
WR13X10169 WR13X10169 GE HINGE BTM BQ
WR13X10214 WR13X10214 GE HINGE TOP & PIN ASSEMBLY FZ
WR13X10215 WR13X10215 GE HINGE TOP & PIN FF
WR02X10821 WR02X10821 GE HUMIDITY CONTROL
WR30X10093 WR30X10093 GE ICE MAKER ASSEMBLY
WR71X10788 WR71X10788 GE INSERT MODULE FF FIXED
WR55X10389 WR55X10389 GE INTERFACE CUSTONER ASSEMBLY
WR02X10666 WR02X10666 GE KNOB PAN CHILL
WR02X10812 WR02X10812 GE LAMP 40W CHILL
WR11X10009 WR11X10009 GE LEVER ASM FF SIDE BK
WR11X10007 WR11X10007 GE LEVER ASM FF SIDE WH
WR11X10010 WR11X10010 GE LEVER ASM FZ SIDE BK
WR11X10011 WR11X10011 GE LEVER ASSEMBLY FF SIDE BISQUE
WR11X10008 WR11X10008 GE LEVER ASSEMBLY FZ SIDE BISQUE
WR22X10059 WR22X10059 GE LID DISH BUTTER
WR17X10801 WR17X10801 GE LIGHT SHIELD BTM FF
WR31X10079 WR31X10079 GE LIGHT SOCKET CHILL
WR02X10665 WR02X10665 GE LINKAGE PAN CHILL
WR02X10818 WR02X10818 GE LINKAGE PAN CHILL L.H.
WR02X10819 WR02X10819 GE LINKAGE PAN CHILL R.H.
WR87X29147 WR87X29147 GE LOW SIDE ASM
WR02X12275 WR02X12275 GE MOBILITY ASSEMBLY BACK-BIS
WR02X12274 WR02X12274 GE MOBILITY FRONT ASSEMBLY
WR71X10979 WR71X10979 GE MODULE SHELF FF
WR71X10973 WR71X10973 GE MODULE SHELF FF
WR71X10297 WR71X10297 GE MODULE SHELF FIXED FF
WR71X10254 WR71X10254 GE MODULE SHELF FZ FIXED
WR71X10764 WR71X10764 GE MODULE SHELF INSERT
WR71X10255 WR71X10255 GE MODULE SUPPORT FZ
WR71X10256 WR71X10256 GE MODULE SUPPORT FZ
WR60X10307 WR60X10307 GE MOTOR DC EVAP FAN ASM
WR60X10185 WR60X10185 GE MOTOR DC EVAPORATOR FAN ASSEMBLY
WR31X10013 WR31X10013 GE NOISE WALL CHILL
WR01X10212 WR01X10212 GE NUT 8-32
WR17X10812 WR17X10812 GE ORIFICE FAN ASSEMBLY
WR08X10025 WR08X10025 GE OVERLOAD
WR86X96 WR86X96 GE P/S DRYER KIT R134A
WR86X25269 WR86X25269 GE P/S DRYER KIT R134A
WR32X10337 WR32X10337 GE PAN ASM CHILL
WR32X26198 WR32X26198 GE PAN ASM TOP
WR32X26235 WR32X26235 GE PAN MIDDLE CHILL ASSEMBLY
WR02X12263 WR02X12263 GE PIN HINGE BTM ADJ HOLLOW
WR17X10918 WR17X10918 GE PLATE SEAL CHILL
WR17X11122 WR17X11122 GE PLENUM FAN EVAPORATOR
WR31X10007 WR31X10007 GE PLENUM TOP
49-60195 49-60195 GE PM GUIDE OWNERS
31-51418 31-51418 GE PM MINI MANUAL WIRING
WR23X0108 WR23X0108 GE POWER CORD
WR23X10300 WR23X10300 GE POWER CORD
WR02X11557 WR02X11557 GE PROTECTOR CAP
WR07X10057 WR07X10057 GE PTCR
WR17X11078 WR17X11078 GE RACK CHILL
WR02X10809 WR02X10809 GE REFLECTOR
WR2X8203 WR2X8203 GE REFRIGERATOR CLIP
WR17X12713 WR17X12713 GE REFRIGERATOR CONDENSER
WR2X9000 WR2X9000 GE REFRIGERATOR CONDENSER CLIP
WR60X10209 WR60X10209 GE REFRIGERATOR CONDENSER FAN MOTOR
WR23X31507 WR23X31507 GE REFRIGERATOR DOOR LIGHT SWITCH
WR71X10966 WR71X10966 GE REFRIGERATOR FREEZER SLIDE-OUT SHELF
WR55X10942C WR55X10942C GE REFRIGERATOR MAIN CONTROL BOARD
WR02X11253 WR02X11253 GE RETAINER SNUGGER
WR02X11252 WR02X11252 GE RETAINER SNUGGER
WR02X12149 WR02X12149 GE RING COMPRESSION
WR01X10611 WR01X10611 GE SCR 10-16.
WR01X10631 WR01X10631 GE SCR 12-24 TT OVT .900 S
WR01X10065 WR01X10065 GE SCR 8-18 BA POR 5/8 SS
WR1X1466 WR1X1466 GE SCR 8-32 T HXW 3/8 S
WZ5X158D WZ5X158D GE SCR 8-32 T HXW 3/8 S
WR01X2022 WR01X2022 GE SCREW
WR1X1786 WR1X1786 GE SCREW
WR01X10615 WR01X10615 GE SCREW 10-16 PL PNP 5/8 SZN
WR01X10654 WR01X10654 GE SCREW 10-32 TT HXW 5/16 S
WR01X10194 WR01X10194 GE SCREW 10-32 TT HXW 5/16 S
WR01X10652 WR01X10652 GE SCREW 8-18 AB IHW 5/8 S
WD02X0323 WD02X0323 GE SCREW 8-32 X 3/8 SPH
WR01X10314 WR01X10314 GE SCREW HANDLE MTG
WR01X10210 WR01X10210 GE SCREW MOBILITY
WR02X12271 WR02X12271 GE SCREW MOBILITY 23
WD2X323D WD2X323D GE SCREW-PKG 12
WR14X10092 WR14X10092 GE SEAL AHU CHILL
WR14X10091 WR14X10091 GE SEAL AHU CHILL
WR14X10090 WR14X10090 GE SEAL AHU CHILL
WR14X10100 WR14X10100 GE SEAL FRAME & AHU CHILL
WR14X10105 WR14X10105 GE SEAL FRONT CHILL
WR14X10104 WR14X10104 GE SEAL MIDDLE CHILL
WR14X10106 WR14X10106 GE SEAL REAR CHILL
WR14X10103 WR14X10103 GE SEAL SIDES CHILL
WR55X10025 WR55X10025 GE SENSOR TEMPERATURE FF
WR17X10820 WR17X10820 GE SEPARATOR AIR HISIDE
WR17X10926 WR17X10926 GE SEPARATOR AIR HISIDE
WR71X10313 WR71X10313 GE SHELF CHILLER
WR71X10527 WR71X10527 GE SHELF FIXED FZ
WR71X10296 WR71X10296 GE SHELF SLIDEOUT ASSEMBLY
WR71X10615 WR71X10615 GE SHELF TUCKAWAY ASSEMBLY
WR17X10811 WR17X10811 GE SHIELD ASSEMBLY TROUGH
WR17X10839 WR17X10839 GE SHIELD LIGHT FF
WR17X10792 WR17X10792 GE SHIELD LIGHT FZ
WR02X10668 WR02X10668 GE SHUNT SENSOR
WR02X10664 WR02X10664 GE SHUTTER PAN CHILL
WR72X10069 WR72X10069 GE SLIDE & BRACKET ASSEMBLY
WR72X10068 WR72X10068 GE SLIDE & BRACKET ASSEMBLY L H
WR72X10070 WR72X10070 GE SLIDE LINER
WR02X10633 WR02X10633 GE SLIDE MIDDLE PAN COVER
WR02X10582 WR02X10582 GE SNUGGER
WR21X10058 WR21X10058 GE SNUGGER WIRE BASKET
WR02X9391 WR02X9391 GE SOCKET & TERMINAL ASM
WR2X9391 WR2X9391 GE SOCKET AND TERM
WR02X10645 WR02X10645 GE SOCKET LAMP
WR17X10945 WR17X10945 GE SPACER
WR1X2027 WR1X2027 GE SPRING CLOSU
WR02X10663 WR02X10663 GE STAND OFF
WR02X13426 WR02X13426 GE STOP DOOR BISQUE
WR02X13425 WR02X13425 GE STOP DOOR BLACK
WR02X10662 WR02X10662 GE STOP SHELF
WR02X3736 WR02X3736 GE STR RELIEF
WR1X1779 WR1X1779 GE STUD MTGCOMP
WR72X10066 WR72X10066 GE SUPPORT SLIDE BASKET
WR72X10067 WR72X10067 GE SUPPORT SLIDE BASKET
WR23X23343 WR23X23343 GE SWITCH LIGHT
WR23X21444 WR23X21444 GE SWITCH LIGHT FZ
WR01X10235 WR01X10235 GE THIMBLE DOOR BOT BISQUE
WR01X10206 WR01X10206 GE THIMBLE DOOR BOT WHITE
WR01X10232 WR01X10232 GE THIMBLE DOOR BTM BK
WR01X10237 WR01X10237 GE THIMBLE DOOR BTM FZ BISQUE
WR01X10234 WR01X10234 GE THIMBLE DOOR BTM FZ BLACK
WR01X10208 WR01X10208 GE THIMBLE DOOR BTM FZ WHITE
WR01X10957 WR01X10957 GE THIMBLE DOOR TOP BISQUE
WR01X10956 WR01X10956 GE THIMBLE DOOR TOP BK
WR17X11079 WR17X11079 GE TRAY DRIP CHILL
WR22X10023 WR22X10023 GE TRIM DAIRY COMPARTMENT
WR17X10953 WR17X10953 GE TRIM DOOR BTM BLACK
WR17X10963 WR17X10963 GE TRIM DOOR BTM FF BISQUE
WR17X10954 WR17X10954 GE TRIM DOOR BTM FF BLACK
WR17X10973 WR17X10973 GE TRIM DOOR BTM FF WHITE
WR17X10962 WR17X10962 GE TRIM DOOR BTM FZ BISQUE
WR17X10972 WR17X10972 GE TRIM DOOR BTM FZ WHITE
WR17X11283 WR17X11283 GE TRIM DOOR SIDE FF BK
WR17X11287 WR17X11287 GE TRIM DOOR SIDE FF BQ
WR17X11274 WR17X11274 GE TRIM DOOR SIDE FF WH
WR17X11282 WR17X11282 GE TRIM DOOR SIDE FZ BK
WR17X11286 WR17X11286 GE TRIM DOOR SIDE FZ BQ
WR17X11273 WR17X11273 GE TRIM DOOR SIDE FZ WH
WR17X10965 WR17X10965 GE TRIM DOOR TOP FF BISQUE
WR17X10958 WR17X10958 GE TRIM DOOR TOP FF BLACK
WR17X10975 WR17X10975 GE TRIM DOOR TOP FF WHITE
WR17X10964 WR17X10964 GE TRIM DOOR TOP FZ BISQ
WR17X10957 WR17X10957 GE TRIM DOOR TOP FZ BLACK
WR17X10974 WR17X10974 GE TRIM DOOR TOP FZ WHITE
WR38X10456 WR38X10456 GE TRIM SHELF FZ
WR02X11426 WR02X11426 GE TUBE DRAIN
WR17X11625 WR17X11625 GE TUBE PLASTIC
WR01X10239 WR01X10239 GE WASHER RETAINER CHILL
WR57X33326 WR57X33326 GE WATER VALVE WITH GUARD
WR02X10807 WR02X10807 GE WHEEL AND RING ASM
WR02X10861 WR02X10861 GE WHEEL FRAME FRONT
WR01X10209 WR01X10209 GE WHEEL PAN COVER
WR17X10793 WR17X10793 GE WINE RACK
Main Menu x
