Manufacturer
GE
Model Number
PYE22KSKFSS
Description
Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
13.4 SCREW 8-32 D HXW 3/8 S |
|
|
ARC HANDLE ASSEMBLY FF |
|
|
ARC HANDLE ASSEMBLY FZ |
|
|
ARM FEELER IM |
|
|
ART FRAME VP ASSEMBLY |
|
|
AUGER MOTOR ASSEMBLY |
|
|
AXLE WHEEL |
|
|
BAFFLE COND AIR |
|
|
BAR REINFORCEMENT |
|
|
BASKET BOTTOM ASSEMBLY |
|
|
BASKET UPPER ASM |
|
|
BIN COND RH FF ASSEMBLY |
|
|
BIN DAIRY RH FF ASSEMBLY |
|
|
BIN FREEZER |
|
|
BIN GAL RH FF ASSEMBLY |
|
|
BIN ICE DOOR MID LH |
|
|
BIN ICE DOOR TOP LH |
|
|
BLOCK EVAPORATOR SEAL |
|
|
BRACKET CONDENSER |
|
|
BRACKET DOOR FZ LH |
|
|
BRACKET DOOR FZ RH |
|
|
BRACKET FILTER MANIFOLD |
|
|
BRACKET SLIDE FZ LH |
|
|
BRACKET SLIDE FZ RH |
|
|
BUCKET ICE ASSEMBLY |
|
|
CAM VERT ADJUSTMENT |
|
|
CAP CASE CORNER ASSEMBLY DGY |
|
|
CAP TOUCH AUTOFILL STAINLESS |
|
|
CLAMP TUBE |
|
|
CLIP EVAPORATOR THERMISTOR |
|
|
CLIP PHGL |
|
|
CLOSURE DOOR ASSEMBLY LH |
|
|
CLOSURE DOOR ASSEMBLY RH |
|
|
CLUTCH COUPLING AM |
|
|
COLLAR PORT |
|
|
COMPRESSOR DISCHARGE JUMPER TUBE |
|
|
COMPRESSOR MOUNTING CLIP |
|
|
CONDENSER ASSEMBLY FORMED |
|
|
CONNECTOR 90 DEG 5/16 |
|
|
CONNNECTOR GEAR PINION |
|
|
COUPLER 1/4 Y |
|
|
COVER ACCESS |
|
|
COVER AM IM HARNESS |
|
|
COVER CONNECTOR FF FAN |
|
|
COVER FAN FZ |
|
|
COVER FILTER RFID |
|
|
COVER LATCH |
|
|
COVER LED FZ ASSEMBLY |
|
|
COVER MAINBOARD |
|
|
COVER MP FRONT ASSEMBLY |
|
|
COVER WATER FILTER ASSEMBLY |
|
|
CROSSBAR PINION |
|
|
CUP FILL FZ IM |
|
|
DAMPER VEGETABLE PAN |
|
|
DELI PAN TOP REAR COVER |
|
|
DISHWASHER 6-19X1/4 TORX PAN HEAD SCREW |
|
|
DISPLAY BOARD AUTOFILL |
|
|
DIVERTER AND BADGE ASSEMBLY |
|
|
DIVIDER BASKET BOTTOM |
|
|
DIVIDER BASKET UPPER |
|
|
DIVIDER MEAT PAN |
|
|
DOOR DISP FF LH SS |
|
|
DOOR FOAM ASM FZ BOWED |
|
|
DOOR FOAM FF RH ASM SS |
|
|
DOOR ICEBOX FOAM ASSEMBLY |
|
|
DORIAN GRAY ARTICULATING MULLION |
|
|
DRIP TRAY AUTOFILL STAIN |
|
|
DRYER FILTER |
|
|
DUCT DOOR ASSEMBLY |
|
|
DUCT TOWER ASSEMBLY FF |
|
|
E CLIP |
|
|
EVAP COVER ASM FZ |
|
|
EVAPORATOR AND TUBE ASSEMBLY FF |
|
|
EVAPORATOR AND TUBE ASSEMBLY FZ |
|
|
FAN DC FF EVAP |
|
|
FAN GASKET ASSEMBLY |
|
|
FAN MOTOR DC FZ EVAP |
|
|
FAN MOTOR IM ASSEMBLY / SENSOR |
|
|
FF COVER LED ASSEMBLY |
|
|
FILTER MANIFOLD |
|
|
FRESH FOOD LED CHROME |
|
|
FRIDGE DEFROST DRAIN TUBE CHECK VALVE |
|
|
FRONT/REAR WHEEL AND AXLE |
|
|
FZ FAN AND FELT ASSEMBLY |
|
|
GASKET DUCT FAN IM |
|
|
GASKET FF DGY |
|
|
GASKET FF FAN FRONT |
|
|
GASKET FZ DGY ES |
|
|
GE BADGE |
|
|
GEAR LWR DRW LH |
|
|
GEAR LWR DRW RH |
|
|
GLASS VEGETABLE PAN |
|
|
GLIDE SUPPORT LH AND RH BIS |
|
|
GRILLE THERMISTOR |
|
|
GROMMET COMPRESSOR |
|
|
GROMMET TUBING SLIT. |
|
|
GUIDE ROLLER VEGETABLE PAN |
|
|
HARNESS DOOR CASE |
|
|
HARNESS DOOR SWITCH AC |
|
|
HARNESS GROUND |
|
|
HARNESS POWER CORD |
|
|
HEATER CONDUCTION FF |
|
|
HEATER CONDUCTION FZ |
|
|
HEATER DEF ASSEMBLY FF |
|
|
HEATER DEF ASSEMBLY FZ |
|
|
HEATER HARNESS FF |
|
|
HEATER HARNESS FZ W/TCO |
|
|
HINGE CAP |
|
|
HINGE CENTER ASSEMBLY LH |
|
|
HINGE CENTER ASSEMBLY RH |
|
|
HINGE CENTER MULLION |
|
|
HINGE ENDCAP ASSEMBLY DGY (2PK) |
|
|
HINGE MULLION |
|
|
HINGE TOP DOOR ICEBOX |
|
|
HINGE TOP PIN ASSEMBLY LH |
|
|
HINGE TOP PIN ASSEMBLY RH |
|
|
HOLDER ELEMENT |
|
|
HOLDER ELEMENT ASSEMBLY |
|
|
HOUSING TRAY VALVE TANK |
|
|
HOUSING WIRE IM FZ |
|
|
HSNG INSUL. |
|
|
ICE BUCKET AND CRUSHER. |
|
|
ICE MAKER ASSEMBLY #2 |
|
|
INSERT FUNNEL |
|
|
INSULATOR HSNG TERM |
|
|
KIT ANTI TIP ASSEMBLY |
|
|
KIT CAPACITOR 12 UF |
|
|
LATCH ICEBOX DOOR |
|
|
LOUVER DUCT IM RETURN FZ |
|
|
MASTIC SOUND DEADENING |
|
|
MAT MODULE |
|
|
MINI MANUAL SERVICE |
|
|
MOTOR DUCT DOOR |
|
|
OVERLAY MEAT PAN ASSEMBLY |
|
|
OVERLOAD PTCR COMBO |
|
|
PADDLE AND SWITCH AUTOFILL |
|
|
PAN MEAT ASSEMBLY |
|
|
PAN VEGETABLE RH ASSEMBLY |
|
|
PCB ASM DOOR CONTROL |
|
|
PCB ASSEMBLY HUMIDITY BOARD |
|
|
PCB BOARD DELI W/ OVRLY |
|
|
PCB COVER ASSEMBLY DGY |
|
|
PIN CROSS BAR |
|
|
PLUG BUTTON |
|
|
PLUG BUTTON WATER FILL |
|
|
PM QUICK USE & CARE |
|
|
PORT GASKET |
|
|
QUICK CLIP CONN 5/16 |
|
|
QUICK CLIP CONNECTOR 1/4 |
|
|
REFRIGERATOR COILED COLD WATER TANK |
|
|
REFRIGERATOR COMPRESSOR |
|
|
REFRIGERATOR DOOR HANDLE FASTENER |
|
|
REFRIGERATOR DOOR ICE BIN |
|
|
REFRIGERATOR EVAPORATOR COVER |
|
|
REFRIGERATOR FRESH FOOD FAN BOOT |
|
|
REFRIGERATOR ICEMAKER |
|
|
REFRIGERATOR MAIN CONTROL BOARD |
|
|
REFRIGERATOR TEMPERATURE SENSOR |
|
|
REFRIGERATOR UNION CONNECTOR - 1/4-INCH |
|
|
REFRIGERATOR WATER FILTER BYPASS PLUG |
|
|
REFRIGERTATOR VALVE AND TANK COVER |
|
|
RFID WATER FILTER BOARD |
|
|
ROLLER ASSEMBLY |
|
|
SCR 1/4-20 GX TRT 7/8 S |
|
|
SCR 1/4-20 HXW 7/8 S |
|
|
SCR 10-18 FLT20 3/4 S |
|
|
SCR 10-24 AB RNT 20 5/8 |
|
|
SCR 10-32 B RNS .353 S |
|
|
SCR 10-32 TR 1/2 |
|
|
SCR 8-10 PL PNP 1/2 S |
|
|
SCR 8-18 AB FLP 3/4 S ZN |
|
|
SCR 8-18 AB HXW 3/4 WH |
|
|
SCR 8-18 AB HXW 5/4 S |
|
|
SCR 8-18 AB HXW 9/16 S |
|
|
SCR 8-18 AB HXWP 9/16S |
|
|
SCR 8-18 AB IHXW 3/4 S |
|
|
SCR 8-18 AB IHXW 9/16 S |
|
|
SCR 8-18 AB IHXW 9/16 S |
|
|
SCR 8-18 FLP 1/2 S |
|
|
SCR 8-18 FLP 1/2 S |
|
|
SCR 8-18 FLP 1/2 S |
|
|
SCR 8-18 HI/LO HWX 3/4 |
|
|
SCR 8-18 HXW 1 1/4S |
|
|
SCR 8-18 TPT 1/4 |
|
|
SCR 8-32 AB IHWS 3/8 S |
|
|
SCR 8-32 CA IHXW .625 S |
|
|
SCR 8-32 HXW 3/4 S |
|
|
SCR M4X1.59 MCH P 10MM S |
|
|
SCREW |
|
|
SCREW (CR) |
|
|
SCREW 1/4-20 HXW 3/4S |
|
|
SCREW 8-16 HXW 1/2 SS |
|
|
SCREW 8-18 HI/LO 5/8 |
|
|
SCREW HINGE CTR ADJ |
|
|
SCREW LEVELING ASSEMBLY |
|
|
SCREW MTG |
|
|
SCREW SET DOOR FZ |
|
|
SET SCREW |
|
|
SHELF ASSEMBLY |
|
|
SHELF ASSEMBLY TUCKAWAY |
|
|
SHIELD LED LIGHT |
|
|
SHUNT SENSOR |
|
|
SLEEVE SPRING MULLION |
|
|
SLIDE ASSEMBLY MEAT PAN |
|
|
SLIDE HOLDER FZ LH |
|
|
SLIDE HOLDER FZ RH |
|
|
SLIDE LOWER FZ LH |
|
|
SLIDE LOWER FZ RH |
|
|
SPACER TRACK |
|
|
SPRING |
|
|
SPRING CLUTCH AM |
|
|
SPRING DUCT DOOR |
|
|
SPRING FEELER ARM |
|
|
SPRING HINGE MULLION |
|
|
STOP DOOR RH/LH ASSEMBLY |
|
|
STOPPER DIVIDER FZ UPPER |
|
|
STRIKER TOP MULLION |
|
|
SUPPORT BIN FZ |
|
|
SUPPORT CONDENSER |
|
|
SUPPORT SIDE LH |
|
|
SUPPORT SIDE RH |
|
|
SUPPORT SLIDE FZ |
|
|
SWITCH LIGHT |
|
|
SWITCH LIGHT FF |
|
|
TAPE FELT |
|
|
THERMOSTAT DEFROST FZ |
|
|
TOP COVER MIDDLE DGY |
|
|
TRACK CENTER FF |
|
|
TRACK SIDE FF |
|
|
TROUGH DRAIN FF |
|
|
TROUGH DRAIN FZ |
|
|
TUBE FZ REPAIR ASSEMBLY |
|
|
TUBE PEX LH DOOR |
|
|
TUBE SUCTION JUMPER |
|
|
TUBING PEX 55.3 IN |
|
|
TUBING PEX 55.3 IN |
|
|
VALVE BODY ASSEMBLY |
|
|
VALVE DOUBLE IM ASSEMBLY |
|
|
VALVE DUAL WATER W FM |
|
|
WATER FILTER |
|
|
WHEEL |
|
|
WHEEL OVERMOLD ASM REAR |
|
|
WZ04X0408 |
