Model Image
Manufacturer

GE

Model Number

RB758DP1BB

Description

Electric Range

Interactive Exploded View

Parts List

Part Number Description
40A15 40A15 40WATT 15AMP INC AND ESCENT BULB
WB24T10025 WB24T10025 500W ELEC RNGE SRFCE BRNER CONTROL SWTCH2
WB02K0027 WB02K0027 BAIL
WB2K27 WB2K27 BAIL
WB07K10339 WB07K10339 BARRIER DOOR
WB56X31458 WB56X31458 BLACK DRAWER PANEL
WB64K10011 WB64K10011 BOX COOKTOP
WB02K10254 WB02K10254 BRACKET ANTI-TIP ASM
WB02K10384 WB02K10384 BRACKET ASSEMBLY ANTI-TIP
WB02K10076 WB02K10076 BRACKET CONTROL
WB37K10004 WB37K10004 BRACKET COOK TOP LF
WB37K10003 WB37K10003 BRACKET COOK TOP RG
WB02K10029 WB02K10029 BRACKET MTG TERMINAL
WB30X46986 WB30X46986 BROIL ELEMENT
WB02K10178 WB02K10178 BUMPER
WB25K0002 WB25K0002 CAMERA LENS
WB7K263 WB7K263 CAP END DR
WB7K264 WB7K264 CAP END DR
WB02K10133 WB02K10133 CLIP RECEPTICAL
WB02X8115 WB02X8115 CLIP WIRE
WB2X8115 WB2X8115 CLIP WIRE
WB2K22 WB2K22 CLIP WIRE
WB02K0022 WB02K0022 CLIP WIRE
WB01X0119 WB01X0119 CONTOURED WASHER
WB27K10358 WB27K10358 CONTROL T09
WB27X45466 WB27X45466 CONTROL T09
WB62K10085 WB62K10085 COOKTOP BLACK
WB34K10066 WB34K10066 COVER BACK
WB56K5 WB56K5 CRYSTAL WIND
WB56K0019 WB56K0019 CRYSTAL WINDOW
WB56K0005 WB56K0005 CRYSTAL WINDOW
WB34K10083 WB34K10083 DIVIDER WIRING
WB35K10105 WB35K10105 DOOR INSULATION
WB58K10007 WB58K10007 DRAWER BODY
WB17T10006 WB17T10006 ELEC RANGE SURFACE BURNER TERMINAL BLOCK
WB07K0264 WB07K0264 END CAP DOOR LFT (BK)
WB07K0263 WB07K0263 END CAP DOOR RT (BK)
WB63K10148 WB63K10148 FRAME WELD ASM
WB35X29722 WB35X29722 GASKET ASSEMBLY. DOOR
WB32K0005 WB32K0005 GASKET OVEN LIGHT
WB2K66 WB2K66 GD SUPT RGTP
WB57K2 WB57K2 GL DOOR BLK
WB57K0002 WB57K0002 GLASS DOOR (BLK)
WB08K0005 WB08K0005 GLASS OVEN LAMP
WB02K10062 WB02K10062 GLIDER DRAWER LEFT
WB02K10061 WB02K10061 GLIDER DRAWER RIGHT
WB2K8 WB2K8 GROMMET
WB2X646 WB2X646 GROUND PLATE
WB56K8 WB56K8 GUARD INSUL
WB63K10009 WB63K10009 GUARD INSULATION BOTTOM
WB56K0008 WB56K0008 GUARD INSULATION DOOR
WB34K0031 WB34K0031 GUARD RADIATION LFT
WB34K0030 WB34K0030 GUARD RADIATION RT
WB34K10029 WB34K10029 GUARD TERMINAL
WB02K0066 WB02K0066 GUIDE SUPPORT RGTP
WB10K0012 WB10K0012 HINGE ASM GUIDE
WB34K0004 WB34K0004 HINGE GUARD LEFT
WB34K0003 WB34K0003 HINGE GUARD RIGHT
WB2X6195 WB2X6195 HINGE PIN
WB34K4 WB34K4 HNGE GRD LFT
WB34K3 WB34K3 HNGE GRD RGT
WB09K10001 WB09K10001 HOOK DOOR SPRING
WB8K1 WB8K1 HOUS RECEPTL
WB08K0001 WB08K0001 HOUSING RECEPTACLE
31-10831 31-10831 INSTALL INSTRUCTIONS
WB35K10104 WB35K10104 INSULATION OVEN BACK
WB35K10103 WB35K10103 INSULATION OVEN WRAP
WB02K10144 WB02K10144 LATCH ASSEMBLY
WB02T10021 WB02T10021 LATCH COVER
WB25T10041 WB25T10041 LENS
WB55K10042 WB55K10042 LINER ASSEMBLY WELD DOOR
WB01K0003 WB01K0003 NUT SPEED
WB1K3 WB1K3 NUT SPEED
WB53K10007 WB53K10007 OVEN BACK
WB63K10006 WB63K10006 OVEN BOTTOM
WB63K10245 WB63K10245 OVEN SIDE LF
WB63K10146 WB63K10146 OVEN SIDE RT
WB63K10021 WB63K10021 OVEN TOP
WB27K10314 WB27K10314 OVERLAY T09-B HP
WB02K0062 WB02K0062 PAD FELT (2"")
WB2K62 WB2K62 PAD FELT 2
WB55K0020 WB55K0020 PANEL ASM WELD INNER
WB56K10006 WB56K10006 PANEL DRAWER (BLACK)
WB63K10142 WB63K10142 PANEL SIDE
WB63K10144 WB63K10144 PANEL SIDE
WB63K10141 WB63K10141 PANEL SIDE
WB14K0005 WB14K0005 PIN HINGE
WB14K5 WB14K5 PIN HINGE
WB02X6195 WB02X6195 PIN HINGE DOOR
WB2K17 WB2K17 PIN LOCATOR
WB02K0017 WB02K0017 PIN LOCATOR FRONT
WB02K10075 WB02K10075 PLASTIC NAIL
WB02X0646 WB02X0646 PLATE-GROUND
31-10781 31-10781 PM INSTALL INSTRUCTIONS
31-21270 31-21270 PM MINI-MANUAL
49-88045-2 49-88045-2 PM OWNERS AND INSTALL
WB55K20 WB55K20 PNL ASM WELD
WB48T10095 WB48T10095 RACK OVEN
WB39K0016 WB39K0016 RAIL DRAWER
WB30K10016 WB30K10016 RANGE 6-INCH SURFACE ELEMENT
WB30K10018 WB30K10018 RANGE 8-INCH SURFACE ELEMENT
WB63K10005 WB63K10005 RANGE BACK
WB63K10233 WB63K10233 RANGE BASE SUPPORT
WB31T10014 WB31T10014 RANGE BURNER BOWL - BLACK PORCELAIN - 6-INCH
WB31T10015 WB31T10015 RANGE BURNER BOWL - BLACK PORCELAIN - 8-INCH
WB03T10072 WB03T10072 RANGE CONTROL KNOB - BLACK
WB02K10245 WB02K10245 RANGE DOOR BRACKET
WB15X10047 WB15X10047 RANGE DOOR HANDLE - BLACK
WB10K12 WB10K12 RANGE DOOR HINGE ASSEMBLY
WB02K10162 WB02K10162 RANGE DOOR SPACER
WB02K10025 WB02K10025 RANGE DRAWER MOUNTING BRACKET
WB39K16 WB39K16 RANGE DRAWER RAIL
WB02K10158 WB02K10158 RANGE DRAWER SUPPORT
WB07K10194 WB07K10194 RANGE END SUPPORT - LEFT - BLACK
WB07K10193 WB07K10193 RANGE END SUPPORT - RIGHT - BLACK
WB25K10002 WB25K10002 RANGE INDICATOR LIGHT
WB02K10182 WB02K10182 RANGE LEVELING LEG
WB30X46987 WB30X46987 RANGE OVEN BAKE ELEMENT
WB36X192 WB36X192 RANGE OVEN BULB COVER
WB32K5 WB32K5 RANGE OVEN GASKET
WB34K31 WB34K31 RANGE RADIATION GUARD
WB34K30 WB34K30 RANGE RADIATION GUARD
WB24T10029 WB24T10029 RANGE SURFACE BURNER CONTROL SWITCH
WB08T10026 WB08T10026 RECEPTACLE PUSH-IN
WB35K10041 WB35K10041 REFLECTOR
WB35K33 WB35K33 REFLECTOR
WB35K0022 WB35K0022 REFLECTOR 9.5 INCH
WB2X1082 WB2X1082 RETAINER
WB02X1082 WB02X1082 RING RETAINING
WB02K10026 WB02K10026 ROD SUPPORT
WB1K44 WB1K44 SCEW LATCH
WB01K10042 WB01K10042 SCR 8-18 AB IHW 3/8 SN
WB01K0001 WB01K0001 SCREW
WB1K5119 WB1K5119 SCREW
WB1X536 WB1X536 SCREW
WB1X5716 WB1X5716 SCREW
WB1X1261 WB1X1261 SCREW
WB1K5062 WB1K5062 SCREW
WB01K10091 WB01K10091 SCREW
WB01K0042 WB01K0042 SCREW (BLK)
WB01X5716 WB01X5716 SCREW (BLK)
WB01X5364 WB01X5364 SCREW (CR)
WB01X0593 WB01X0593 SCREW - DOOR ASM (4 PER)
WB01K0065 WB01K0065 SCREW 10-16
WB01K0070 WB01K0070 SCREW 7-19
WZ04X0345 WZ04X0345 SCREW 8-18X5/8 HXW
WB1K67 WB1K67 SCREW 8-22
WB01K10012 WB01K10012 SCREW 8-22 PL 1HX 71
WB01X23501 WB01X23501 SCREW 8-32 TT FLP .270
WB01K0044 WB01K0044 SCREW DOOR LATCH
WB01X1261 WB01X1261 SCREW GROUND
WB1K62 WB1K62 SCREW HEAD PAINTED BLACK
WB1K53 WB1K53 SCREW HINGE
WB1X5364 WB1X5364 SCREW MTG
WB01K0062 WB01K0062 SCREW MTG END CAP (BK)
WB01K0053 WB01K0053 SCREW MTG HINGE (TORX)
WB01X0558 WB01X0558 SCREW NAIL POINT
WZ4X423D WZ4X423D SCREW-PKG 12
WB1X558D WB1X558D SCREW-PKG 12
WZ4X345D WZ4X345D SCREWS - 12 PACK
WB23X5340 WB23X5340 SENSOR-OVEN
WB63K10244 WB63K10244 SIDE OVEN
WB09K0005 WB09K0005 SPRING DOOR
WB9K5 WB9K5 SPRING DOOR
WB10K10009 WB10K10009 SUPPORT ASSEMBLY RIVET LF
WB10K10010 WB10K10010 SUPPORT ASSEMBLY RIVET RT
WB63K10232 WB63K10232 SUPPORT BASE
WB02K10028 WB02K10028 SUPPORT BROIL
WB35K10028 WB35K10028 SUPPORT CATALYST
WB17T10011 WB17T10011 TERMINAL BLOCK ASSEMBLY
WB07K10232 WB07K10232 TRIM BOTTOM ASSEMBLY
WB36K10844 WB36K10844 TRIM CONTROL
WB07K10248 WB07K10248 TRIM POST LF
WB07K10249 WB07K10249 TRIM POST RT
WB07K10200 WB07K10200 TRIM VENT ASSEMBLY
WB38K10016 WB38K10016 TUBE VENT ASSEMBLY
WB38K10002 WB38K10002 TUBE-VENT
WB02X32440 WB02X32440 WASHER CONTOURED
WB1X119D WB1X119D WASHR-PKG 12
WB56K19 WB56K19 WIND PACK SM
WB34K10088 WB34K10088 WINDOW SPACER ASSEMBLY
