Model Image
Manufacturer

GE

Model Number

RBS330DR1WW

Description

Electric Range

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB31X46067 WB31X46067 "6"" SURFACE BURNER WITH SENSOR"
WB31X46066 WB31X46066 "8"" SURFACE BURNER WITH SENSOR"
40A15 40A15 40A15
WB02K0027 WB02K0027 BAIL
WB30X46987 WB30X46987 BAKE ELEMENT
WB07X20288 WB07X20288 BARRIER DOOR
WB17T10006 WB17T10006 BLOCK INSULATOR
WB27X31509 WB27X31509 BLOCK TERMINAL ASM
WB63K10105 WB63K10105 BOTTOM OVEN
WB31K10265 WB31K10265 BOWL BURNER 6 (CH)
WB31K10266 WB31K10266 BOWL BURNER 8 (CH)
WB64K10009 WB64K10009 BOX COOKTOP
WB02X42793 WB02X42793 BRACKET ASM ANTI-TIP
WB34X29134 WB34X29134 BRACKET BASE
WB37X20193 WB37X20193 BRACKET COOK TOP
WB37X20196 WB37X20196 BRACKET COOK TOP
WB02K10398 WB02K10398 BRACKET MOUNTING DRAWER
WB02K10029 WB02K10029 BRACKET MTG TERMINAL
WB30X46986 WB30X46986 BROIL ELEMENT
WB25K0002 WB25K0002 CAMERA LENS
WB02X21087 WB02X21087 CARTON COVER THERMOSTAT
WB02K0010 WB02K0010 CLIP CAPILLARY
WB02K0050 WB02K0050 CLIP CRYSTAL
WB02K10133 WB02K10133 CLIP RECEPTICAL
WB34X21585 WB34X21585 COVER BACK
WB02X33816 WB02X33816 COVER THERMOSTAT
WB56K0005 WB56K0005 CRYSTAL WINDOW
WB57K0018 WB57K0018 CRYSTAL WINDOW
WB34X21602 WB34X21602 DIVIDER WIRING
WB35K10114 WB35K10114 DOOR INSULATION
WB58K10015 WB58K10015 DRAWER BODY
WB02K10158 WB02K10158 DRAWER SUPPORT
WB07X20278 WB07X20278 END SUPPORT LEFT
WB07X20277 WB07X20277 END SUPPORT RIGHT
WB02X28738 WB02X28738 FRAME FRONT BUMPER
WB35X29720 WB35X29720 GASKET DOOR ASM
WB08K0005 WB08K0005 GLASS OVEN LAMP
WB02K10062 WB02K10062 GLIDER DRAWER LEFT
WB02K10061 WB02K10061 GLIDER DRAWER RIGHT
WB2K8 WB2K8 GROMMET
WB56K10032 WB56K10032 GUARD INSULATION
WB63K10241 WB63K10241 GUARD INSULATION BOTTOM
WB34X21584 WB34X21584 GUARD TERMINAL
WB02K0066 WB02K0066 GUIDE SUPPORT RGTP
WB18X32878 WB18X32878 HARNESS MAIN
WB18X48306 WB18X48306 HARNESS SURFACE UNIT LF
WB18X27488 WB18X27488 HARNESS SURFACE UNIT RF
WB18X48307 WB18X48307 HARNESS SURFACE UNIT RR
WB10X21978 WB10X21978 HINGE DOOR
WB34K0004 WB34K0004 HINGE GUARD LEFT
WB34K0003 WB34K0003 HINGE GUARD RIGHT
WB08K0001 WB08K0001 HOUSING RECEPTACLE
WB24T10025 WB24T10025 INF SW CONTROL (2500W)
WB24T10022 WB24T10022 INF SWITCH CONTROL 1250W
WB35K10107 WB35K10107 INSULATION OVEN BACK
WB03X21365 WB03X21365 KNOB THERMOSTAT ASM
WB03X21352 WB03X21352 KNOB VALVE
WB25K10002 WB25K10002 LAMP PILOT
WB02K10182 WB02K10182 LEG LEVELER
WB02X29030 WB02X29030 LEG LEVELING
WB56X21217 WB56X21217 LINER ASM WELD DOOR
WB01K0003 WB01K0003 NUT SPEED
WB48X20249 WB48X20249 OVEN RACK
WB56K10047 WB56K10047 PANEL DOOR
WB56X29129 WB56X29129 PANEL SIDE
WB14K0005 WB14K0005 PIN HINGE
WB02K0017 WB02K0017 PIN LOCATOR FRONT
WB02K10075 WB02K10075 PIN LOCATOR REAR
WB02X0646 WB02X0646 PLATE-GROUND
49-88076 49-88076 PM GAS QUICK GUIDE
49-2000686 49-2000686 PM INSERT INSTRUCTIONS
31-2000872 31-2000872 PM MINI MANUAL AND WIRING
49-88075 49-88075 PM QUICK GUIDE
WB39K0016 WB39K0016 RAIL DRAWER
WB63K10273 WB63K10273 RANGE BACK
WB62X21353 WB62X21353 RANGE TOP
WB10X20220 WB10X20220 RECEIVER HINGE
WB08T10026 WB08T10026 RECEPTACLE PUSH-IN
WB55K0001 WB55K0001 REFLECTOR LG
WB02K10026 WB02K10026 ROD SUPPORT
WB01X26995 WB01X26995 SCR 8-18 AB X 5/16S
WB01K10057 WB01K10057 SCREW
WB01K10091 WB01K10091 SCREW
WB01X31119 WB01X31119 SCREW #8-18
WB01K0042 WB01K0042 SCREW (BLK)
WB01X37565 WB01X37565 SCREW 10-32
WB01T10008 WB01T10008 SCREW 10-32 TR T
WZ4X345D WZ4X345D SCREW 8-18X5/8 HXW
WB01K10012 WB01K10012 SCREW 8-22 PL 1HX 71
WB01X23501 WB01X23501 SCREW 8-32 TPT FLR 215 S
WB01X1261 WB01X1261 SCREW GROUND
WB01X5874 WB01X5874 SCREW WH
WB02K10156 WB02K10156 SPACER
WB01K10093 WB01K10093 SPEEDNUT
WB01K0002 WB01K0002 SPEEDNUT
WB63K10233 WB63K10233 SUPPORT BASE LEFT
WB63K10232 WB63K10232 SUPPORT BASE RIGHT
WB02K10028 WB02K10028 SUPPORT BROIL
WB24X20459 WB24X20459 SWITCH ROCKER SEALED
WB24X21192 WB24X21192 THERMOSTAT ELECTRIC
WB38K10002 WB38K10002 TUBE-VENT
WB04K10002 WB04K10002 VENT COVER
WB56X31459 WB56X31459 WHITE DRAWER PANEL
WB15X35075 WB15X35075 WHITE HANDLE AND ENDCAP
WB36X42792 WB36X42792 WHITE TRIM CONTROL
