Manufacturer
GE
Model Number
RE2H50R61NCWW
Description
Hybrid Water Heater
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
"GROMMET INLET, BLUE" |
|
|
"GROMMET OUTLET, RED" |
|
|
"TUBE INSULATION, PIPE" |
|
|
1/4-20 HEX NUT - LOCKING |
|
|
BARRIER DIELECTRIC |
|
|
BLADE FAN |
|
|
BRACKET THERMISTOR T2 |
|
|
BRKT OVERLOAD |
|
|
CAPACITOR RUN |
|
|
CAVITY JUNCTION BOX |
|
|
CLIP SENSOR (T3A/T4) |
|
|
CLIP SENSOR (T3B) |
|
|
CLIP SPRING TCO |
|
|
COMP PROCESS TUBE 5/16 |
|
|
COMPRESSOR |
|
|
COVER ACCESS J- BOX |
|
|
COVER AIR FILTER SNAP |
|
|
COVER ELMNT (UPPER) EPS |
|
|
COVER ELMNT METAL L. RED |
|
|
COVER ELMNT METAL U. RED |
|
|
COVER FIXED J- BOX |
|
|
COVER TERMINAL |
|
|
DIPTUBE ASM |
|
|
DISCHARGE TUBE ASM |
|
|
EEV VALVE |
|
|
EEV VALVE ASM KIT |
|
|
ELEMENT HEATING W/GASKET |
|
|
EVAPORATOR KIT |
|
|
FAN MOTOR EC |
|
|
FAN SHROUD ASM |
|
|
FILTER AIR |
|
|
FILTER DRYER ASM |
|
|
GROMMET |
|
|
GROMMET DC (J-BOX) |
|
|
GROUND WIRE TO J-BOX |
|
|
HYBRID WATER HEATER |
|
|
MASTIC THERMAL SENSOR |
|
|
NUT 5/16-18 HEX |
|
|
NUT KEPS 10-32 SPECIAL |
|
|
OVERLOAD COMP |
|
|
OVERLOAD COMP |
|
|
PM USE & CARE |
|
|
REAR CONTROL COVER |
|
|
REAR SHROUD ASM |
|
|
ROD ANODE |
|
|
ROD ANODE ISOLATED |
|
|
SCR 10-32 HXW 2 1/2 S |
|
|
SCR 10-32 PNUP 13/32 S |
|
|
SCR 10-32 PNUP 3/8 S |
|
|
SCR 1032 GX HXW 7/16 S |
|
|
SCR 1032 GX PNT25 1/2 S |
|
|
SCR 8-18 B PNT 3/4 S RED |
|
|
SCR 8-32 GX IHX 3/8 SCA |
|
|
SCR 818 AB PNT20 7/16 S |
|
|
SEAL FOAM BARRIER |
|
|
SEAL FOAM EVAP |
|
|
SENSOR (T3A/T3B/T4) |
|
|
SENSOR T5 |
|
|
SERVICE KIT CONTROL ASM |
|
|
SERVICE KIT DRAIN PAN |
|
|
T2 TANK THERMISTOR ASM |
|
|
T2 WIRE REPAIR KIT |
|
|
TANK THERMISTOR T2 |
|
|
TCO |
|
|
TCO DLB SCREWS |
|
|
TRIM RING |
|
|
TUBE DRYER |
|
|
VALVE DRAIN STRAIGHT |
|
|
VALVE TP |
|
|
WASHER FLAT |
|
|
WATER EXTENSION PIPE |
|
|
WIRE (G-B) GRD COMPRESSO |
|
|
WIRE ED |
|
|
WIRE L1-L2 REPAIR KIT |
|
|
WIRE TIE |
|
|
WIRE TIE BALL |
|
|
WIRE TIE/PLUG |
