Model Image
Manufacturer

GE

Model Number

SCA1001KSS01

Description

No description available

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WB24X25397 WB24X25397 "SWITCH,MICRO"
WB36X10163 WB36X10163 10W MICROWAVE HALOGEN BULB 12V
WB25X10019 WB25X10019 120V MICROWAVE HALOGEN BULB; 20W
WB27X10471 WB27X10471 12A FUSE
WB49X10240 WB49X10240 13-INCH DIA ADVANTIUM METAL TRAY
WB56X10422 WB56X10422 BASE PLATE ASSEMBLY
WB38X10054 WB38X10054 BLOWER ASSEMBLY
WB27X10808 WB27X10808 CAPACITOR
WB27X10233 WB27X10233 CAPACITOR HIGH VOLT
WB55X10428 WB55X10428 CHOKE COVER
WB06X10668 WB06X10668 DAMPER INLET ASSEMBLY
WB06X10318 WB06X10318 DAMPER OUTLET ASSEMBLY
WB56X10658 WB56X10658 DOOR ASSEMBLY SS
WB55X10707 WB55X10707 DOOR GROSS SUB ASSEMBLY SS
WB38X10024 WB38X10024 FAN BLADE
WB38X10055 WB38X10055 FAN BLADE ASSEMBLY
WB27X10519 WB27X10519 FILTER ASSEMBLY NOISE
WB36X10248 WB36X10248 GLASS ASSEMBLY
WB06X10317 WB06X10317 GLASS OVEN LAMP
WB07X10774 WB07X10774 GRILLE ASSEMBLY SS
WB06X10320 WB06X10320 GRILLE CLIPS
WB27X10925 WB27X10925 H.V. TRANFORMER
WB15X10237 WB15X10237 HANDLE ASSEMBLY SS
WB21X10128 WB21X10128 HEATER
WB06X10554 WB06X10554 HOLDER ASSEMBLY
WB01X32574 WB01X32574 INSTALLATION HARDWARE
WB64X10003 WB64X10003 INSTALLATION KIT ASSEMBLY
49-40453 49-40453 INSTRUCTIONS INSTALL
WB27X10775 WB27X10775 KEY PCB ASSEMBLY
WB36X10253 WB36X10253 LAMP REFLECTOR ASSEMBLY
WB06X10216 WB06X10216 LATCH BRACKET
WB18X10310 WB18X10310 LEAD WIRE TOTAL ASSEMBLY
WB26X26221 WB26X26221 MAGNETRON ASSEMBLY
WB27X10309 WB27X10309 MAGNETRON ASSEMBLY
49-40401-1 49-40401-1 MANUAL,OWNERS
WB21X10054 WB21X10054 MGT THERMO ASSEMBLY
WB03X10215 WB03X10215 MICROWAVE BUTTON
WB07X10775 WB07X10775 MICROWAVE CONTROL PANEL - BLACK AND SS
WB27X10037 WB27X10037 MICROWAVE DIODE CABLE
WB10X10021 WB10X10021 MICROWAVE DOOR LATCH PAWL
WB49X10129 WB49X10129 MICROWAVE GLASS TRAY
WB06X10309 WB06X10309 MICROWAVE GREASE FILTERS - 2 PK
WB03X10216 WB03X10216 MICROWAVE KNOB - STAINLESS STEEL LOOK
WB06X10321 WB06X10321 MICROWAVE LED DISPLAY HOLDER
WB27X10928 WB27X10928 MICROWAVE LINE FUSE
WB2X9052 WB2X9052 MICROWAVE MOUNTING BOLTS
WB06X10316 WB06X10316 MICROWAVE MOUNTING BRACKET
WB06X10308 WB06X10308 MICROWAVE POWER CORD COVER
WB20X10048 WB20X10048 MICROWAVE THERMOSTAT
WB26X10188 WB26X10188 MICROWAVE TURNTABLE MOTOR ASSEMBLY
WB26X36106 WB26X36106 MICROWAVE VENTILATION MOTOR
WB06X10311 WB06X10311 MICROWAVE WAVE GUIDE COVER
31-40427 31-40427 MINI MANUAL
WB26X10189 WB26X10189 MOTOR FAN
WB02X32725 WB02X32725 MOUNT VENT MOTOR COVER
WB56X35363 WB56X35363 MOUNTING PLATE ASSEMBLY
WB01X10124 WB01X10124 NUT ASSEMBLY
WB56X10205 WB56X10205 OUTER CASE BLACK
WB18X10311 WB18X10311 POWER CORD ASSEMBLY
49-40159 49-40159 REAR WALL TEMPLATE
WB36X10180 WB36X10180 REFLECTOR ASSEMBLY
WB36X10182 WB36X10182 REFLECTOR ASSEMBLY
WB27X10777 WB27X10777 RELAY PCB
WB06X10315 WB06X10315 ROTATING RING ASSEMBLY
WB24X10044 WB24X10044 SENSOR ASSEMBLY
WB06X10312 WB06X10312 SHAFT ASSEMBLY
WB27X10776 WB27X10776 SMART BOARD
WB24X10047 WB24X10047 SW PRIM INTERLOCK AND DOOR
WB24X31473 WB24X31473 TCO BASE HOOD
49-40176 49-40176 TEMPLATE(TOP CAB)
WB27X10468 WB27X10468 THERMISTOR
WB20X10021 WB20X10021 TRANSFORMER POWER
WB20X10023 WB20X10023 TRANSFORMER POWER
