Model Image
Manufacturer

GE

Model Number

TBX10SNSBLAD

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
WR2X8879 WR2X8879 BAFF FAN MTR
WR02X8879 WR02X8879 BAFFLE FAN MOTOR
WR17X3386 WR17X3386 BASE PLATE
WR50X0128 WR50X0128 BI-METAL THERMO ASM
WR01X5674 WR01X5674 BOLT
WR01X1923 WR01X1923 BOLT
WR1X1923 WR1X1923 BOLT
WR1X5671 WR1X5671 BOLT
WR1X5674 WR1X5674 BOLT
WR01X1916 WR01X1916 BRACKET CONDENSER
WR02X8876 WR02X8876 BRACKET FAN MOTOR (BACK)
WR02X8878 WR02X8878 BRACKET FAN MOTOR(FRONT)
WR1X1916 WR1X1916 BRKT CONDSER
WR2X8878 WR2X8878 BRKT FAN MTR
WR2X8876 WR2X8876 BRKT FAN MTR
WR02X10119 WR02X10119 CAP GROMMET WHITE
WR38X2063 WR38X2063 CAP HANDLE
WR62X0076 WR62X0076 CAPACITOR
WR62X76 WR62X76 CAPACITOR
WR02X8896 WR02X8896 CLAMP
WR2X9269 WR2X9269 CLAMP
WR2X8894 WR2X8894 CLIP REL CVR
WR02X8894 WR02X8894 CLIP RELAY COVER
WR84X0184 WR84X0184 CONDENSER ASM
WR84X184 WR84X184 CONDENSR ASM
WR09X0528 WR09X0528 CONTROL DEFROST
WR9X529 WR9X529 CONTROL TEMP
WR09X0529 WR09X0529 CONTROL TEMPERATURE
WR02X8880 WR02X8880 COVER
WR2X8880 WR2X8880 COVER
WR02X9230 WR02X9230 COVER HINGE MIDDLE AD
WR02X9229 WR02X9229 COVER HINGE TOP AD
WR02X8891 WR02X8891 COVER RELAY
WR17X3384 WR17X3384 COVER VEG PAN
WR32X1410 WR32X1410 COVER VEG PAN
WR17X6391 WR17X6391 CVR CONTROL
WR2X9230 WR2X9230 CVR HINGE
WR02X8881 WR02X8881 DAMPER
WR2X8881 WR2X8881 DAMPER
WR9X502 WR9X502 DEF CONTROL
WR2X8890 WR2X8890 DEFROST DEFL
WR02X8890 WR02X8890 DEFROST DEFLECTOR
WR77X0629 WR77X0629 DOOR INNER FF
WR77X0699 WR77X0699 DOOR INNER FRZ
WR77X629 WR77X629 DOOR INNR FF
WR77X699 WR77X699 DOOR INNR FZ
WR71X2417 WR71X2417 DOOR SHELF BTM
WR2X8531 WR2X8531 DOOR STOP
WR02X8893 WR02X8893 DRAIN TRAP
WR2X8893 WR2X8893 DRAIN TRAP
WR17X10261 WR17X10261 DRAIN TRAY
WR02X8889 WR02X8889 DRAIN WIRE
WR2X8889 WR2X8889 DRAIN WIRE
WR14X0439 WR14X0439 DUCT SHEET
WR14X439 WR14X439 DUCT SHEET
WR17X3380 WR17X3380 EVAP COVER
WR60X215 WR60X215 EVAP FAN MTR
WR1X1921 WR1X1921 EVAP MT STUD
WR85X0302 WR85X0302 EVAPORATOR ASM
WR85X10003 WR85X10003 EVAPORATOR ASSEMBLY
WR01X1921 WR01X1921 EVAPORATOR MOUNTING STUD
WR60X0216 WR60X0216 FAN BLADE EVAP
WR60X216 WR60X216 FAN BLD EVAP
WR78X8700 WR78X8700 FF 0 DOOR AD
WR78X8699 WR78X8699 FZ O DOOR AD
WR14X0440 WR14X0440 GASKET
WR14X440 WR14X440 GASKET
WR24X0545 WR24X0545 GASKET DOOR FF
WR24X0546 WR24X0546 GASKET DOOR FZ
WR24X582 WR24X582 GASKET DR FF
WR24X581 WR24X581 GASKET DR FZ
WR2X7800 WR2X7800 GROMMET
WR2X8877 WR2X8877 GROMMET
WR02X7800 WR02X7800 GROMMET COMPRESSOR MT
WR02X8877 WR02X8877 GROMMET FAN MOTOR
WR12X0992 WR12X0992 HANDLE ASM AD
WR51X0365 WR51X0365 HEATER DEFROST
WR87X0443 WR87X0443 HI-SIDE
WR87X443 WR87X443 HI-SIDE KIT
WR13X666 WR13X666 HINGE MIDASM
WR13X0666 WR13X0666 HINGE MIDDLE ASM
WR13X0627 WR13X0627 HINGE TOP
WR13X5227 WR13X5227 HINGE TOP
WR51X365 WR51X365 HTR DEFROST
WR14X437 WR14X437 INSUL MULL
WR14X0437 WR14X0437 INSULATION MULLION
WR17X3381 WR17X3381 INSULATION MULLION
WR17X3382 WR17X3382 INSULATION MULLION
WR02X8895 WR02X8895 JUNCTION BOX
WR2X8895 WR2X8895 JUNCTION BOX
WR2X8887 WR2X8887 KNOB
WR02X8887 WR02X8887 KNOB THERMOSTAT
WR02X8874 WR02X8874 LEG
WR02X11131 WR02X11131 LEG
WR01X5692 WR01X5692 LEG SPACER
WR23X5167 WR23X5167 LIGHT SOCKET
31-5878 31-5878 MINI MANUAL
WR60X0215 WR60X0215 MOTOR EVAP FAN
WR17X3829 WR17X3829 MULLION CASE
WR04X0215 WR04X0215 NAMEPLATE
WR4X215 WR4X215 NAMEPLATE
WR02X8892 WR02X8892 NYLON CLAMP
WR2X8892 WR2X8892 NYLON CLAMP
WR08X0135 WR08X0135 OVERLOAD
WR8X135 WR8X135 OVERLOAD
49-6750 49-6750 OWNERS GUIDE
WR17X3379 WR17X3379 PLATE COVER BOTTOM
WR17X4334 WR17X4334 PLATE COVER BOTTOM
WR17X3385 WR17X3385 PLATE FRONT COVER
WR02X8883 WR02X8883 PLATE MOUNTING LF SIDE
WR02X8882 WR02X8882 PLATE MOUNTING RT SIDE
WR2X8883 WR2X8883 PLATE MTG LF
WR2X8882 WR2X8882 PLATE MTG RT
WR2X9231 WR2X9231 PLUG BUTTON
WR02X9231 WR02X9231 PLUG BUTTON AD
WR23X0108 WR23X0108 POWER CORD
WR23X10300 WR23X10300 POWER CORD
WR07X0231 WR07X0231 PTC RELAY
WR7X231 WR7X231 PTC RELAY
WR86X25269 WR86X25269 R134 DRIER
WR01X1924 WR01X1924 SCREW
WR01X1817 WR01X1817 SCREW
WR01X1926 WR01X1926 SCREW
WR2X8904 WR2X8904 SCREW
WR1X5668 WR1X5668 SCREW
WR1X2065 WR1X2065 SCREW
WR1X5189 WR1X5189 SCREW **NLA*
WR01X1925 WR01X1925 SCREW CAP
WR02X8904 WR02X8904 SCREW HANDLE TO DOOR
WR01X1922 WR01X1922 SCREW TAPPING
WR01X5668 WR01X5668 SCREW TAPPING
WR1X1922 WR1X1922 SCREW TAPPNG
WR14X0436 WR14X0436 SEAL
WR14X436 WR14X436 SEAL
WR14X0438 WR14X0438 SEAL EVAP COVER
WR14X438 WR14X438 SEAL EVAP CV
WR14X0441 WR14X0441 SEAL MULLION
WR14X441 WR14X441 SEAL MULLION
WR02X8900 WR02X8900 SHELF BUSHING LEFT
WR02X8901 WR02X8901 SHELF BUSHING RIGHT
WR2X8901 WR2X8901 SHELF BUSHNG
WR2X8900 WR2X8900 SHELF BUSHNG
WR17X3369 WR17X3369 SHELF FRONT
WR71X2416 WR71X2416 SHELF STATIONARY
WR2X8884 WR2X8884 SHIM HINGE
WR02X8884 WR02X8884 SHIM HINGE MIDDLE
WR2X8888 WR2X8888 SLEEVE CAPIL
WR02X8888 WR02X8888 SLEEVE CAPILLARY
WR1X5692 WR1X5692 SPACER
WR02X8902 WR02X8902 STOP DOOR
WR02X8899 WR02X8899 STOP DOOR
WR2X8902 WR2X8902 STOP DOOR
WR23X0412 WR23X0412 SWITCH LIGHT
WR23X412 WR23X412 SWITCH LIGHT
WR2X8886 WR2X8886 THERMO CAPIL
WR02X8886 WR02X8886 THERMO CAPILLARY SUPPORT
WR50X122 WR50X122 THERMO DEF
WR30X10009 WR30X10009 TRAY ICE CUBE
WR38X2001 WR38X2001 TRIM SHELF FF & FZ
WR32X1411 WR32X1411 VEG PAN
WR23X0392 WR23X0392 WIRE HARNESS
WR23X392 WR23X392 WIRE HARNESS
WR13X10234 WR13X10234 WR13X10019
WR71X2736 WR71X2736 WR71X2736
WR86X0093 WR86X0093 WR86X0093
