Manufacturer
GE
Model Number
WBVH5300K2WW
Description
Front-loading Washer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
3_WAY_PIPE_CLAMP |
|
|
AIR_CHAMBER |
|
|
BAFFLE ASSEMBLY |
|
|
BLEACH INLET WATER HOSE |
|
|
BOLT 8X58 |
|
|
BOLT M8*48 |
|
|
BOTTOM_VENT_HOSE_CLAMP |
|
|
CABINET_REAR_COVER |
|
|
CHILD LOCK BUTTON |
|
|
CONTROL BOARD ASSEMBLY |
|
|
CONTROL PANEL ASSEMBLY WW |
|
|
CONTROL_REAR_COVER |
|
|
CORNER BRACKET |
|
|
COUNTERWEIGHT FRONT LOWER |
|
|
COUNTERWEIGHT FRONT UPPER |
|
|
COUNTERWEIGHT REAR |
|
|
COVER - THERMISTOR |
|
|
DAMPER - SHOCK |
|
|
DAMPER_PIN |
|
|
DISPENSER DWR FRONT WW |
|
|
DISPENSER_SEAL |
|
|
DISPENSER_VENT_HOSE |
|
|
DISPENSER_VENT_HOSE_CLAM |
|
|
DOOR COVER ASSEMBLY |
|
|
DOOR FRAME - OUTER ASSEMBLY |
|
|
DOOR GLASS |
|
|
DOOR PLUNGER |
|
|
DRAIN HOSE GUIDE U-SHAPE |
|
|
DRAIN_HOSE |
|
|
DRAIN_HOSE_CLAMP |
|
|
DRAIN_HOSE_COUPLING |
|
|
DRAWER DISPENSER |
|
|
DRAWER LATCH LEVEL |
|
|
DRIVE PULLEY KIT |
|
|
DRIVING_BELT |
|
|
EMI_FILTER |
|
|
FLANGE_BOLT_M8*35 |
|
|
FRONT LOAD WASHER DOOR LOCK |
|
|
FRONT PANEL WW |
|
|
FRONT_PANEL_PIN |
|
|
FRONT_TOP_BRACKET |
|
|
FRONT_TUB |
|
|
GASKET INSIDE CLAMP |
|
|
GASKET OUTSIDE CLAMP |
|
|
GASKET_NOZZLE |
|
|
GASKET_NOZZLE_WASHER |
|
|
HEATER THERMISTOR |
|
|
HINGE |
|
|
HINGE COVER |
|
|
HINGE DOOR PLATE |
|
|
HINGE DOOR SHORT PIN |
|
|
HOSE - PRESSURE SWITCH |
|
|
HOT INLET WATER HOSE |
|
|
INSIDE_DRAIN_HOSE |
|
|
INSIDE_DRAIN_HOSE_CATCH |
|
|
INVERTER |
|
|
INVERTER CONNECTORS SHIE |
|
|
LEG |
|
|
LIQUID DETERGENT INSERT |
|
|
LOCK WASHER |
|
|
MAIN BOX DIVERTER ASSEMBLY |
|
|
MAIN INLET WATER HOSE |
|
|
MAIN_WATER_HOSE_COLD |
|
|
MAIN_WATER_HOSE_HOT |
|
|
MOTOR ASSEMBLY KIT |
|
|
MOTOR_SHIELD |
|
|
MOTOR_WASHER |
|
|
NUT_M16 |
|
|
NUT_M5 |
|
|
NUT_M8 |
|
|
OUTSIDE_DRAIN_HOSE |
|
|
OUTSIDE_DRAIN_HOSE_CATCH |
|
|
POWER BUTTON |
|
|
POWER_CORD |
|
|
PRESSURE SWITCH |
|
|
PRESSURE_HOSE_CLAMP |
|
|
PROTECT COVER AND RING |
|
|
PUMP ACCESS DOOR WW |
|
|
PUMP ACCESS SHROUD |
|
|
PUMP DRAIN CHANNEL |
|
|
PUMP FILTER |
|
|
PUMP_CLAMP |
|
|
REAR_TUB |
|
|
RINSE BUTTON SILVER GREY |
|
|
SCREW M4 X 8 |
|
|
SCREW M4*17 |
|
|
SCREW M5*12 |
|
|
SCREW ST4.2 X 13 |
|
|
SCREW ST4.2*11 |
|
|
SCREW ST4.4*9.5 |
|
|
SCREW ST4X11 |
|
|
SCREW ST8*45 |
|
|
SCREW_M5*12 |
|
|
SCREW_M5*12 |
|
|
SCREW_M5*6 |
|
|
SCREW_ST 4.2X14 |
|
|
SCREW_ST3.5 X 11 |
|
|
SCREW_ST3.5*9.5 |
|
|
SCREW_ST4*10 |
|
|
SCREW_ST4*20 |
|
|
SCREW_ST4*20 |
|
|
SCREW_ST4*25 |
|
|
SCREW_ST4.2*13 |
|
|
SCREW_ST4.2*13 |
|
|
SCREW_ST4.2*13 |
|
|
SCREW_ST4.2*13 |
|
|
SCREW_ST6*35 |
|
|
SCREW_WASHER_ST4*25 |
|
|
SELECT CYCLE KNOB ASSEMBLY |
|
|
SERVICE PANEL WW |
|
|
SHIPPING_SCREW_COVER |
|
|
SIPHON_PIPE |
|
|
SOFTENER BLEACH COVER |
|
|
SOIL_SPEED_TEMP_BUTTON |
|
|
SPRAY HOSE |
|
|
SPRING_HANGER |
|
|
START PAUSE BUTTON |
|
|
SUSPENSION_SPRING |
|
|
TOP DECOR COVER WW |
|
|
TOP PANEL ASSEMBLY WW |
|
|
TOP_PANEL_PIN |
|
|
TUB DRAIN HOSE CLAMP |
|
|
TUB_SEAL |
|
|
VENT_HOSE |
|
|
VENT_HOSE_CLAMP |
|
|
VENT_HOSE_COUPLING |
|
|
WASHER |
|
|
WASHER |
|
|
WASHER STAINLESS STEEL TUB ASSEMBLY |
|
|
WASHER/DRYER STACKING KIT - 27-INCH |
|
|
WASHING MACHINE 2-IN/3-OUT WATER VALVE |
|
|
WASHING MACHINE DOOR GASKET |
|
|
WASHING MACHINE FRONT PANEL HANGER |
|
|
WASHING MACHINE PUMP |
|
|
WASHING MACHINE WATER INLET HOSE CLAMP |
|
|
WATER_INLET_PIPE |
|
|
WIRE HARNESS |
|
|
WIRE_CATCH |
|
|
WIRE_CATCH |
|
|
WIRE_CATCH_1 |
|
|
WIRING_COVER |
