Manufacturer
GE
Model Number
ZET3058BH1BB
Description
Electric Range
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
340531 |
|
|
35W RANGE HALOGEN BULB |
|
|
BADGE MONOGRAM SMALL |
|
|
BAKE ELEMENT |
|
|
BAKE TCO |
|
|
BASE RAIL |
|
|
BLOWER ASSEMBLY |
|
|
BOARD EMI FILTER |
|
|
BOARD QUANTUM |
|
|
BODY OVEN VENT TOP |
|
|
BOX VENT ASSEMBLY |
|
|
BRACKET CONVECT MOUNT |
|
|
BRACKET QUANTUM WO |
|
|
BRACKET SAIL LEFT |
|
|
BRACKET SAIL RIGHT |
|
|
BRACKET-H V C |
|
|
BROIL ELEMENT 2500W |
|
|
C-OIL |
|
|
CAPACITOR MOTOR |
|
|
CLEAN TCO |
|
|
CONDUIT WIRE ASSEMBLY |
|
|
COOKING GUIDE |
|
|
COVER |
|
|
COVER |
|
|
COVER FAN (CONVEX) UPPER |
|
|
COVER FAN (CONVX) |
|
|
COVER FAN LEFT |
|
|
COVER FAN RIGHT |
|
|
COVER FRT FAN HSG |
|
|
COVER INTERLOCK |
|
|
COVER REAR FAN HSG |
|
|
COVER WIRE LWR |
|
|
COVER WIRE MDL |
|
|
COVER WIRE UPR RR |
|
|
COVER. |
|
|
DIODE-H.V ASSEMBLY |
|
|
DISPLAY VFD1 |
|
|
DISPLAY VFD2 WO |
|
|
DOOR BUMPER |
|
|
DOOR INNER ASSEMBLY |
|
|
DOOR OUTER ASSEMBLY UPPER |
|
|
DUAL BAKE ELEMENT |
|
|
DUCT CONVECTION |
|
|
DUCT MAG WO |
|
|
E-CLIP |
|
|
ELEMENT CONVEX UPPER |
|
|
FAN ASSEMBLY MAGNETRON |
|
|
FAN ASSEMBLY TRANSFORMER |
|
|
FAN SUPPORT |
|
|
FAN SUPPORT |
|
|
FILLER PNL ASSEMBLY (SS-BLK) |
|
|
FOAM TAPE/SEAL |
|
|
FRAME FRT LOWER |
|
|
FUSE 250V 15A. |
|
|
GASKET BAKE ELEMENT |
|
|
GASKET BROIL ELEMENT |
|
|
GASKET OVN DR |
|
|
GLASS OVN DR INR |
|
|
HALOGEN LAMP ASSEMBLY LWR |
|
|
HANDLE ASSEMBLY 30 (BLK) |
|
|
HARNESS GND HINGE RECEIV |
|
|
HARNESS INTERFACE DWO |
|
|
HARNESS MAIN LWR DWO |
|
|
HARNESS RIBBON CABLE |
|
|
HARNESS SAIL FAD RT |
|
|
HARNESS SHIELDED DISPLAY |
|
|
HARNESS W/ACCESSORIES |
|
|
HARNESS WIRE LCK MTR |
|
|
HEX NUT |
|
|
HINGE DOOR |
|
|
HINGE DOOR |
|
|
HOLDER FUSE MWA |
|
|
HOOK INTERLOCK ASSEMBLY |
|
|
HOUSING FAN LEFT |
|
|
HOUSING FAN RIGHT |
|
|
HUB BLADE ASSEMBLY |
|
|
INSULATION (INR) LWR |
|
|
INSULATION (OUT) LWR |
|
|
INSULATION BACK AND BOTTOM |
|
|
INSULATION BACK AND BTM |
|
|
INSULATION OVEN DR SDE |
|
|
INSULATION OVN DR SDE |
|
|
INSULATION OVN DR TOP |
|
|
INSULATION STIRRER MOTOR |
|
|
INSULATION TOP AND SDS OTR |
|
|
INSULATION TOP SDS INR |
|
|
INTERLOCK ASSEMBLY RT |
|
|
KEPS NUT 6-32 |
|
|
LAMP HALOGEN ASSEMBLY |
|
|
LAMP HALOGEN UPR |
|
|
LATCH OVN |
|
|
LEFT INTERLOCK ASSEMBLY |
|
|
LEFT SWITCH SAIL ASSEMBLY |
|
|
LENS OVEN LAMP |
|
|
LINER OVN DR ASSEMBLY |
|
|
LOCKWASHER |
|
|
LOWER OVN INSLN RETAINER |
|
|
LWR OVEN RELAY BRD |
|
|
MAIN LOGIC BRD |
|
|
MAIN POWER BRD |
|
|
MANUAL MINI & WD ASM |
|
|
MANUAL USE & CARE |
|
|
MATCH PLATE ENAMEL |
|
|
MICROWAVE CAPACITOR MOTOR BRACKET |
|
|
MICROWAVE MAGNETRON |
|
|
MICROWAVE MAGNETRON COVER |
|
|
MOTOR PSC CONV |
|
|
MOTOR STIRRER |
|
|
MOTOR VENT |
|
|
NUT |
|
|
OUTER DR ASSEMBLY |
|
|
OUTER DR ASSEMBLY LWR |
|
|
OV LAMP LENS |
|
|
OVEN DOOR GLASS RETAINER |
|
|
PACK WINDOW ASM |
|
|
PACK WINDOW ASSEMBLY |
|
|
PANEL CONTROL ASSEMBLY MGM |
|
|
PCB ST AND OFF |
|
|
PCB ST AND OFF |
|
|
PSC CONV MOTOR LOWER |
|
|
RACK OVEN TRIVECTION |
|
|
RACK OVEN UPR |
|
|
RANGE BOTTOM VENT BODY |
|
|
RANGE CONVECTION ELEMENT |
|
|
RANGE INSULATION RETAINER - LOWER TOP |
|
|
RANGE OVEN DOOR BUMPER |
|
|
RANGE OVEN DOOR CLIP |
|
|
RANGE UPPER OVEN DOOR GASKET |
|
|
RANGE VENT FAN BLADE |
|
|
RELAY |
|
|
RETAINER GLASS OVEN DR |
|
|
RETAINER INSLN BACK |
|
|
RETAINER INSLN BACK |
|
|
RETAINER INSLN BACK LOW |
|
|
RETAINER INSLN BTM |
|
|
RETAINER INSLN OVN DR |
|
|
RETAINER INSLN SDE LEFT |
|
|
RETAINER INSLN SDE RT |
|
|
RETAINER INSLN TOP |
|
|
RETAINER OVN DR EXT |
|
|
RIGHT SWITCH SAIL ASSEMBLY |
|
|
ROAST RACK |
|
|
ROD BRACKET REINF |
|
|
SCR 8 - 32 X .343 TRS S |
|
|
SCR 8-15 A HXW 7/8 S |
|
|
SCREEN FAN |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW |
|
|
SCREW 1/4-TPI FL HX 9/10 |
|
|
SCREW 10-16 AB HXW 750 S N |
|
|
SCREW 10-16 SHLDR TYPE A |
|
|
SCREW 10-16 TRT20 7/16 S NI |
|
|
SCREW 10-32 TR T |
|
|
SCREW 8-32 , 13-32 |
|
|
SCREW MAGNETRON |
|
|
SCREW ST 8-18 X 3/4 BLK |
|
|
SCREW ST10-16 X 7/16"" |
|
|
SCREW, TRANSFORMER |
|
|
SCREW-10-32 |
|
|
SCREW-10AB |
|
|
SCREW-BLACK |
|
|
SCREW-BLK |
|
|
SCREW-PKG 12 |
|
|
SCREW-PKG 12 |
|
|
SCREW-PKG 12 |
|
|
SD INSUL RET |
|
|
SENSOR ASSEMBLY |
|
|
SHIELD GLASS |
|
|
SIDE EXTENSION-LT |
|
|
SIDE EXTENSION-RT |
|
|
ST AND OFF |
|
|
STIRRER MOTOR SCREW |
|
|
STUD |
|
|
SUPPORT OVEN CAVITY |
|
|
SWITCH LIGHT SPOT |
|
|
TAPE FOAM |
|
|
TCO RUNAWAY |
|
|
THERMOSTAT |
|
|
TRANSFORMER |
|
|
TRIM BTM ASSEMBLY 30 (BLK) |
|
|
TRIM BTM CAB ASSEMBLY |
|
|
TRIM SCREW-BLK |
|
|
TRIM VENT INR (BLACK) LWR |
|
|
TRIM VERT SDE ASSEMBLY LEFT |
|
|
TRIM VERT SDE ASSEMBLY RT |
|
|
TRIM VNT ASSEMBLY |
|
|
TUBE VENT |
|
|
UNIT BROIL ASSEMBLY (DLX) LWR |
|
|
UNIVERSAL RANGE BROILER PAN |
|
|
VENT INLET DUCT |
|
|
WASHER |
|
|
WASHER |
|
|
WASHER |
|
|
WASHER |
|
|
WASHER .250 ID X .812 OD |
|
|
WB01X0681 |
|
|
WRAPPER OVEN CAV ASSEMBLY LO |
