Model Image
Manufacturer

GE

Model Number

ZISS420NRBSS

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
WD02X0295 WD02X0295 GE #10X1\2 PH SMS
WR01X5645 WR01X5645 GE #10X1\2 PH SMS
WH2X1211 WH2X1211 GE #6-32 X 3/16 MACH SCR.
WR01X1826 WR01X1826 GE #8-18 TYPE AB X 3/8 PH P
WR72X10191 WR72X10191 GE 10 SLIDE QUICK CHILL
WR01X10051 WR01X10051 GE 10-24X1 PHIL P-HD TAP
WR01X10313 WR01X10313 GE 36 VAPORIZER PAN BOLT
WR78X20988 WR78X20988 GE 36FZ/42FZ DOOR GASKET
WR02X11200 WR02X11200 GE 4-40 X 1/4 PH SMS
WR78X12746 WR78X12746 GE 42 SS ND FZ WRAP ASSEMBLY
WR01X10449 WR01X10449 GE 6-20 X 1\2 S\S PH PHIL
WR01X10065 WR01X10065 GE 8-32 X 3/8 PHIL PH TY C
WR85X10041 WR85X10041 GE ACCUMULATOR
WR31X10021 WR31X10021 GE AIR HANDLER ASM QC
WR17X11175 WR17X11175 GE AIR TOWER FF
WR02X11453 WR02X11453 GE AMP J10 CONNECTOR
WR21X25723 WR21X25723 GE BASKET ASM FZ
WR02X10951 WR02X10951 GE BHNG ARM NYLON FF DR CL
WR60X24484 WR60X24484 GE BLADE CONF FAN ASSEMBLY
WR60X26667 WR60X26667 GE BLADE FAN MOTOR
WR60X41627 WR60X41627 GE BLADE FAN MOTOR
WR55X10159 WR55X10159 GE BOARD HMI CONTRL
WR01X10302 WR01X10302 GE BOLT 1/4-20X1.5
WR02X11207 WR02X11207 GE BOLT SHOULDER
WR02X11130 WR02X11130 GE BRACKET ANTI-TIP
WR02X11863 WR02X11863 GE BRACKET COND FAN (MTG)
WR01X10287 WR01X10287 GE BRACKET EVAPORATOR FAN BTM
WR02X10653 WR02X10653 GE BRACKET ORIFICE FAN
WR02X12768 WR02X12768 GE BRACKET WATER VAVLE
WR02X12486 WR02X12486 GE BRKT COND FAN MOTOR LG
WR02X11565 WR02X11565 GE BRKT LIGHT COLUMN MT
WR32X1435 WR32X1435 GE BUCKET EGG
WR30X10033 WR30X10033 GE BUCKET ICE DISP
WR72X10104 WR72X10104 GE BUCKET SLIDE
WB01X10239 WB01X10239 GE BULB HALOGEN LAMP QC/CEI
WR17X11202 WR17X11202 GE BULB HOUSING COVER
WR02X10540 WR02X10540 GE BUMPER LID
WR02X10953 WR02X10953 GE BUSHING HINGE BOTTOM
WR02X10954 WR02X10954 GE BUSHING HINGE TOP
WR19X10005 WR19X10005 GE BUTTER DISH
WR01X10047 WR01X10047 GE BUTTON GLIDE
WR71X10440 WR71X10440 GE CAN RACK FZ
WR86X10021 WR86X10021 GE CAP SUCTION TUBE ASM
WR17X12831 WR17X12831 GE CASE TRIM FF SIDE
WR17X11181 WR17X11181 GE CASE TRIM FZ SIDE
WR17X11353 WR17X11353 GE CASE TRIM TOP
WR17X11212 WR17X11212 GE CEILING LIGHT BRACKET
WR02X11240 WR02X11240 GE CEILING LIGHT SHIELD 42
WR13X30112 WR13X30112 GE CHANNEL BASE ASSEMBLY (LH)
WR13X30113 WR13X30113 GE CHANNEL BASE ASSEMBLY (RH)
WR01X10300 WR01X10300 GE CLIP LOGO
WR1X1779 WR1X1779 GE CLIP MT COMP
WR02X9501 WR02X9501 GE CLIP TUBE
WR2X9501 WR2X9501 GE CLIP TUBE
WR87X10111 WR87X10111 GE COMPRESSOR REPL KIT VSC
WR17X11434 WR17X11434 GE COND BAFFLE RH
WR17X11433 WR17X11433 GE COND. SHROUD TOP
WR84X10048 WR84X10048 GE CONDENSER REPL. ASM.
WR02X11262 WR02X11262 GE COVER RELAY (EMB)
WR17X13124 WR17X13124 GE COVER WATER LINE
WR02X11449 WR02X11449 GE COVER WATER LINE
WR29X10092 WR29X10092 GE CUP FILL IM
49-60139 49-60139 GE CUSTOM OPTIONS GUIDE
WR71X33505 WR71X33505 GE DAIRY BIN 42
WR71X26790 WR71X26790 GE DAIRY BIN ASM
WR14X10132 WR14X10132 GE DAIRY BIN CENTER GASKET
WR22X10035 WR22X10035 GE DAIRY BIN DOOR W/TRIM
WR14X10137 WR14X10137 GE DAIRY SQ GASKET
WR60X10063 WR60X10063 GE DAMPER ASM DESUPPLY
WR31X10018 WR31X10018 GE DIFFUSOR CASE ASM
WR19X0035 WR19X0035 GE DISH BUTTER ASM
WR78X10879 WR78X10879 GE DOOR FOAMED ASM FF 42
WR49X10021 WR49X10021 GE DRAIN PAN ASSEMBLY W/HTR
WR02X11257 WR02X11257 GE DRAIN TUBE CHECK VALVE
WR38X10190 WR38X10190 GE EDGE TRIM
WR02X9228 WR02X9228 GE ELUT BLOCK
WR71X10429 WR71X10429 GE ENCAP SHELF ASM
WR17X11174 WR17X11174 GE END CAP LIGHT COLUMN TOP
WR17X11201 WR17X11201 GE ENDCAP LIGHT COLUMN BTM
WR17X11200 WR17X11200 GE ENDCAP LIGHT COLUMN FZ
WR84X10038 WR84X10038 GE EVAP ASM W/HEATER
WR2X9228 WR2X9228 GE EVAP BLOCK SMALL
WR17X12615 WR17X12615 GE EVAP FAN ORFICE COVER
WR74X10112 WR74X10112 GE EYEBROW SWITCH COVER
WR17X11214 WR17X11214 GE EYEBROW SWITCH PLATE
WR17X13035 WR17X13035 GE FAN CHILL
WR71X10325 WR71X10325 GE FF AIR DIFFUSER
WR24X10145 WR24X10145 GE FF DOOR GASKET 42
WR13X10251 WR13X10251 GE FF HINGE DOOR BTM
WR13X23372 WR13X23372 GE FF HINGE SXS LOWER CASE
WR13X10245 WR13X10245 GE FF HINGE UPPER CASE
WR17X11193 WR17X11193 GE FF RETURN AIR BAFFLE
WR17X11179 WR17X11179 GE FF SHELF TRACK
WR78X12744 WR78X12744 GE FF SS WRAP ASM
WR13X10240 WR13X10240 GE FF TOP DOOR HINGE ASM
WR49X10094 WR49X10094 GE FILL TUBE KIT SD/SXS(N)
WH12X10192 WH12X10192 GE FILTER
WR17X22065 WR17X22065 GE FILTER MNT & TUBE ASM
WR17X3039 WR17X3039 GE FOAM BLOCK
WR49X10107 WR49X10107 GE FOAM DUCT
WR02X11197 WR02X11197 GE FOAM INSERT AIR TOWER
WR71X25600 WR71X25600 GE FRONT FZ BASKET
WR02X11210 WR02X11210 GE FRONT ROLLER ASM
WR23X10269 WR23X10269 GE FUSE 2 AMP
WR21X10057 WR21X10057 GE FZ BASKET ASM
WR01X10297 WR01X10297 GE FZ BOTTOM HINGE BUSHING
WR78X10881 WR78X10881 GE FZ FOAMED DOOR ASM 36/42
WR13X10250 WR13X10250 GE FZ HINGE DOOR BTM
WR13X10246 WR13X10246 GE FZ HINGE SXS CASE UPPER
WR13X10241 WR13X10241 GE FZ HINGE SXS LOWER CASE
WR71X10438 WR71X10438 GE FZ SHELF ASM
WR71X10439 WR71X10439 GE FZ SHELF ASM
WR17X11205 WR17X11205 GE FZ SHELF TRACK
WR72X10190 WR72X10190 GE FZ SLIDE ASSEMBLY LH
WR72X10189 WR72X10189 GE FZ SLIDE ASSEMBLY RH
WR71X10427 WR71X10427 GE GAL BIN FF ASM
WR24X10111 WR24X10111 GE GASKET DAIRY BTM
WR14X10140 WR14X10140 GE GASKET LID SHOWCASE
WR13X10244 WR13X10244 GE GRILL HINGE MOUNT
WR74X10341 WR74X10341 GE GRILLE PANEL ASM
WR02X10647 WR02X10647 GE GRILLE SENSOR
WR02X22869 WR02X22869 GE GROMMET COMP. MTG.
WR02X12008 WR02X12008 GE GROMMET EVAPORATOR FAN
WR02X10520 WR02X10520 GE GROMMET FAN MOTOR
WR02X11183 WR02X11183 GE HALOGEN BULB LIGHT COLUM
WR12X27601 WR12X27601 GE HANDLE TUBULAR SS
WR01X10304 WR01X10304 GE HARDWARE PACK
WR23X10607 WR23X10607 GE HARNESS HMI TE
WR23X10491 WR23X10491 GE HARNESS INVERTER COMM
WR23X10267 WR23X10267 GE HARNESS QC
WR23X10268 WR23X10268 GE HARNESS QC LIGHTS
WR51X322 WR51X322 GE HEATER DEFROST
WR51X10138 WR51X10138 GE HEATER THAW
WR13X10691 WR13X10691 GE HINGE ASSEMBLY GRILLE LEFT
WR13X10204 WR13X10204 GE HINGE ASSEMBLY GRILLE RIGHT
WR01X10177 WR01X10177 GE HINGE SCREW DOOR BTM
WR55X10915 WR55X10915 GE HMI CONTROL ASM
WR02X11202 WR02X11202 GE HOCKEY PUCK W/LAMP &HARN
WR13X10243 WR13X10243 GE HOOD HINGE MOUNT
WR32X10329 WR32X10329 GE HUMIDITY SLIDE 42
WR02X11218 WR02X11218 GE HUMIDITY SLIDER CONTROL
WR17X12547 WR17X12547 GE ICE BIN DOOR
WR71X10420 WR71X10420 GE ICE BIN DOOR TRACK
WR17X11218 WR17X11218 GE ICE BIN FRT
WR30X10093 WR30X10093 GE ICE MAKER ASSEMBLY
WR55X20817 WR55X20817 GE INVERTER ASSEMBLY
WR01X22266 WR01X22266 GE LATCH LIGHT SHIELD
WR2X4978 WR2X4978 GE LEVELING LEG
WR17X11698 WR17X11698 GE LH CONDENSER BAFFLE
WR02X11292 WR02X11292 GE LH HMI ENDCAP
WR17X11207 WR17X11207 GE LIGHT COLUMN ASM
WR02X11211 WR02X11211 GE LINK AUCATOR FF
WR02X11208 WR02X11208 GE LINK AUCTUATOR FZ
WR13X10239 WR13X10239 GE LOWER FF ADJ HINGE PIN
WR55X10560 WR55X10560 GE MAIN BOARD
WR02X11838 WR02X11838 GE MAIN BOARD COVER
WR01X10301 WR01X10301 GE MAIN BOARD STAND OFFS
WR49X10070 WR49X10070 GE MASTER LIGHT SW. KIT
13-51558 13-51558 GE MINI MANUAL
WB02X26123 WB02X26123 GE MONOGRAM BADGE
WR60X10209 WR60X10209 GE MOTOR DC COND FAN
WR13X10027 WR13X10027 GE MULTIPLE SUPERCEDURES
WR02X10764 WR02X10764 GE MULTIPLE SUPERCEDURES
WH02X10124 WH02X10124 GE NUT
WR86X96 WR86X96 GE P/S DRYER KIT R134A
WR86X25269 WR86X25269 GE P/S DRYER KIT R134A
WR17X11924 WR17X11924 GE PAN SLEEVE
WR72X10102 WR72X10102 GE PAN SLIDE SUPPORT LH
WR72X10101 WR72X10101 GE PAN SLIDE SUPPORT RH
WR17X11984 WR17X11984 GE PAN SYSTEM
WR40X10039 WR40X10039 GE PANREAR SEAL
WR17X22070 WR17X22070 GE PLUG BYPASS FILTER
WR23X0420 WR23X0420 GE POWER CORD
WR23X10300 WR23X10300 GE POWER CORD
WR14X10139 WR14X10139 GE QC FRONT SEAL ASM
WR02X11198 WR02X11198 GE QC HALOGEN LAMP ASM
WR02X11199 WR02X11199 GE QC INLET DUCT FZ
WR60X10269 WR60X10269 GE QC MULLION ASSEMBLY
WR32X25933 WR32X25933 GE QC PAN MODIFIED
WR60X10116 WR60X10116 GE QC SEAL DAMPER
WR17X11177 WR17X11177 GE QC TRAY
WR02X12946 WR02X12946 GE RAIN HAT
WR74X10274 WR74X10274 GE REAR DUCT FZ
WR02X12948 WR02X12948 GE RED SPRING CLOSURE
WR60X10185 WR60X10185 GE REFER DC EVAPORATOR FAN MOTOR
WR02X11451 WR02X11451 GE REFLECTIVE FILM FF
WR71X25605 WR71X25605 GE REG BIN ASM
WR71X25603 WR71X25603 GE REG BIN FF ASM
WR02X11221 WR02X11221 GE RETAINER SYSTEM PAN
WR02X11291 WR02X11291 GE RH HMI ENDCAP
WR02X10323 WR02X10323 GE RING COMP COND FAN BLADE
WR1X1466 WR1X1466 GE SCR 8-32 T HXW 3/8 S
WZ5X158D WZ5X158D GE SCR 8-32 T HXW 3/8 S
WD2X295 WD2X295 GE SCREW
WR1X5645 WR1X5645 GE SCREW
WR1X2129 WR1X2129 GE SCREW
WR1X1826 WR1X1826 GE SCREW
WR01X10057 WR01X10057 GE SCREW #10-32X3/4 CR TR H
WR01X1845 WR01X1845 GE SCREW 12-24TT OHT .900
WR01X10652 WR01X10652 GE SCREW 8-18 AB IHW 5/8 S
WR01X10383 WR01X10383 GE SCREW MTG STUD
WR01X10026 WR01X10026 GE SCREW SET 10-32
WR01X10188 WR01X10188 GE SCREW TRIM (SELF DRIL
WR01X2129 WR01X2129 GE SCREW, #8-15 X 1/2 CR PA
WR1X1754D WR1X1754D GE SCREW-PKG 12
WR40X10040 WR40X10040 GE SEAL PAN FRONT
WR55X10025 WR55X10025 GE SENSOR TEMPERATURE FF
WR02X11209 WR02X11209 GE SHEAR PIN
WR32X10330 WR32X10330 GE SHOWCASE FLIP LID WINDOW
WR32X10327 WR32X10327 GE SHOWCASE PAN ASM
WR71X10436 WR71X10436 GE SHOWCASE PAN SHELF ASM
WR71X10437 WR71X10437 GE SHOWCASE PAN SHELF FRONT
WR71X10435 WR71X10435 GE SHOWCASE PAN WIRE
WR84X10049 WR84X10049 GE SHROUD CONDENSER
WR17X11203 WR17X11203 GE SLIDE CAN RACK LH
WR17X11204 WR17X11204 GE SLIDE CAN RACK RH
WR72X0269 WR72X0269 GE SLIDE FULL EXT10
WR72X0268 WR72X0268 GE SLIDE SUPPORT FZ
WR72X268 WR72X268 GE SLIDE SUPPORT FZ
WR32X25591 WR32X25591 GE SNACK PAN ASM
WR71X10432 WR71X10432 GE SNACK PAN SHELF ASM
WR71X10431 WR71X10431 GE SNACK PAN WIRE SUPPORT
WR02X11231 WR02X11231 GE SPACER FF DOOR CLOSURE
WR02X12949 WR02X12949 GE SPRING CLOSURE BLUE
WR02X11233 WR02X11233 GE SPRING WHEEL #LE022C4
WR12X27598 WR12X27598 GE STAND-OFF SS
WR23X10725 WR23X10725 GE SWITCH LIGHT FF
WR23X21444 WR23X21444 GE SWITCH LIGHT FZ
WR31X10022 WR31X10022 GE TEMP CONTROL HOUSING
WR02X11228 WR02X11228 GE THERMISTOR GRILL KIT- AL
WR50X29776 WR50X29776 GE THERMODISC EVAP
WR50X10035 WR50X10035 GE THERMOSTAT LIGHT
WR74X26126 WR74X26126 GE TOE KICK -SS
WR14X10138 WR14X10138 GE TOP EDGE GUARD DAIRY BIN
WR13X10238 WR13X10238 GE TOP SXS FZ DOOR HINGE AS
WR62X10029 WR62X10029 GE TRANSFORMER FF LIGHTS
WR62X10030 WR62X10030 GE TRANSFORMER FZ LIGHTS
WR17X11184 WR17X11184 GE TRANSFORMER PAN
WR17X12060 WR17X12060 GE TRANSFORMER TRAY
WR02X11256 WR02X11256 GE TRIM CORNER KEY
WR02X8472 WR02X8472 GE TUBE
WR17X2891 WR17X2891 GE TUBE PLASTIC
49-60315 49-60315 GE USE & CARE MANUAL
WR32X25926 WR32X25926 GE VEG PAN ASM
WR17X11215 WR17X11215 GE VEG PAN FLIP WINDOW
WR71X10434 WR71X10434 GE VEG PAN FRONT ASM
WR02X11242 WR02X11242 GE VEG PAN REAR SEAL
WR02X11243 WR02X11243 GE VEG PAN SHELF FRONT SEAL
WR72X10105 WR72X10105 GE VEG PAN WIRE SUPPORT
WR71X10430 WR71X10430 GE VEG WIRE FRAME
WR32X10328 WR32X10328 GE VEGETABLE PAN GLASS SHELF
WR2X8472 WR2X8472 GE VENT TUBE
WR01X10046 WR01X10046 GE WASHER SHOWCASE PIVOT
MWFP MWFP GE WATER FILTER
WR17X1948 WR17X1948 GE WATER LINE 1/4
WR02X11219 WR02X11219 GE WATER VALVE BRACKET
WR57X33326 WR57X33326 GE WATER VALVE WITH GUARD
WR2X8377 WR2X8377 GE WHEEL REAR ASM
WR17X3364 WR17X3364 GE WINE RACK
WR01X10311 WR01X10311 GE WIRE COVER QC ASM
WR01X10298 WR01X10298 GE WIRE MESH QC HSG
WR01X10256 WR01X10256 GE WR01X10256
Main Menu x
