GE

Model Number

ZISS42NCASS

Description

Refrigerator

Interactive Exploded View

Parts List

Part Number Description
WR01X5645 WR01X5645 #10X1\2 PH SMS
WR2X7226 WR2X7226 *NLA*CLIP COVER
WR78X10877 WR78X10877 36/42 FZ ND FOAMED DR
WR87X20798 WR87X20798 AASM HI SIDE
WR2X8925 WR2X8925 ACT ARM-FF
WR2X8926 WR2X8926 ACTUR ARM FZ
WR02X8925 WR02X8925 ARM ACTUATOR
WR02X8926 WR02X8926 ARM ACTUATOR
WR29X5129 WR29X5129 ARM SHUT OFF
WR17X3039 WR17X3039 BAFFLE EVAP
WR17X3037 WR17X3037 BAFFLE EVAP FOAM
WR17X3045 WR17X3045 BAFFLE FRONT W/FG
WR17X11193 WR17X11193 BAFFLE FZ
WR17X3044 WR17X3044 BAFFLE LH W/FG
WR02X8970 WR02X8970 BAR SUPPORT
WR2X8970 WR2X8970 BAR SUPPORT
WR13X0670 WR13X0670 BASE ASM (LH)
WR13X0671 WR13X0671 BASE ASM (RH)
WR13X670 WR13X670 BASE ASM LH
WR13X671 WR13X671 BASE ASM-RH
WR01X1851 WR01X1851 BASE SHAFT
WR01X10256 WR01X10256 BASE SHAFT
WR29X5111 WR29X5111 BC00173-1
WR29X5117 WR29X5117 BE03687-01
WR71X2655 WR71X2655 BIN DOOR DEEP FF
WR71X2276 WR71X2276 BIN FZ DOOR
WR60X220 WR60X220 BLADE COND F
WR60X0167 WR60X0167 BLADE COND FAN
WR01X1838 WR01X1838 BOLT ADJ HINGE
WR01X1899 WR01X1899 BOLT COMP PAN
WR1X1838 WR1X1838 BOLT-HINGE
WR2X8610 WR2X8610 BRACKET
WR57X10026 WR57X10026 BRACKET & VALVE ASM
WR02X8619 WR02X8619 BRACKET DEFROST HEATER
WR02X8806 WR02X8806 BRACKET EVAP. FAN LARGE
WR02X8805 WR02X8805 BRACKET EVAP. FAN SMALL
WR2X7137 WR2X7137 BRACKET FAN
WR2X8806 WR2X8806 BRACKET FAN
WR2X8619 WR2X8619 BRACKET HTR.
WR02X10370 WR02X10370 BRACKET WATER VALVE
WR02X10425 WR02X10425 BRACKET WATER VALVE
WR32X1435 WR32X1435 BUCKET EGG
WR30X10154 WR30X10154 BUCKET ICE
WR2X8587 WR2X8587 BUSHING
WR1X1839 WR1X1839 BUSHING
WR1X1836 WR1X1836 BUSHING
WR2X8588 WR2X8588 BUSHING
WR01X1836 WR01X1836 BUSHING ACTUATOR ARM
WR02X8588 WR02X8588 BUSHING BTM HINGE
WR02X8587 WR02X8587 BUSHING HINGE
WR01X1839 WR01X1839 BUSHING HINGE SPRING ASM
WR19X10005 WR19X10005 BUTTER DISH
MXRC MXRC CANISTER WATER FILTER
WR62X0079 WR62X0079 CAPACITOR
WR55X24064 WR55X24064 CAPACITOR
WR23X0474 WR23X0474 CAPACITOR HARNESS
WR86X105 WR86X105 CAPILLARY TB
WR01X1843 WR01X1843 CLAMP
WR02X7226 WR02X7226 CLAMP COVER
WR29X0158 WR29X0158 CLAMP THERMOSTAT
WR1X1843 WR1X1843 CLAMP TRI325006
WR2X8606 WR2X8606 CLOSURE DOOR
WR2X8607 WR2X8607 CLOSURE DOOR
WR02X9467 WR02X9467 CLOSURE FF DOOR RH
WR02X9468 WR02X9468 CLOSURE FZ DOOR ASM LH
WR17X3048 WR17X3048 COND SHROUD
WR14X0313 WR14X0313 COND TOP BAFFLE FOAM
WR84X212 WR84X212 CONDENSER
WR84X0212 WR84X0212 CONDENSER ASM 36 SD
WR2X8601 WR2X8601 CONT KNOB FF
WR2X8600 WR2X8600 CONT KNOB FZ
WR02X9412 WR02X9412 CONTROL PANEL FF 42""
WR2X9412 WR2X9412 CONTROL PNL
WR02X10426 WR02X10426 COPPER TUBE
WR02X7834 WR02X7834 COVER
WR13X0638 WR13X0638 COVER FZ HINGE
WR13X639 WR13X639 COVER HINGE
WR2X7834 WR2X7834 COVER RELAY
WR2X8604 WR2X8604 COVER VALVE
WR17X13124 WR17X13124 COVER WATER LINE
WR02X8604 WR02X8604 COVER WATER VALVE
WR29X0182 WR29X0182 COVER WH
WR29X182 WR29X182 CVR ICEMAKR
WR2X9401 WR2X9401 DAIRY UTIL.
WR22X0510 WR22X0510 DAIRY/UTIL. DOOR W/TRIM
WR17X4139 WR17X4139 DAIRY/UTILITY COMP
WR09X0513 WR09X0513 DAMPER FF
WR9X513 WR9X513 DAMPER FF
WR9X502 WR9X502 DEF CONTROL
WR51X0322 WR51X0322 DEFROST HEATER
WR50X0109 WR50X0109 DEFROST THERMOSTAT
WR09X0587 WR09X0587 DEFROST TIMER 3001-58
WR19X0035 WR19X0035 DISH BUTTER ASM
WR02X9401 WR02X9401 DIVIDER DAIRY/UTIL.42/48
WR2X9400 WR2X9400 DIVIDER MODU
WR02X9400 WR02X9400 DIVIDER MODULE
WR78X10002 WR78X10002 DOOR FOAMED ASM 36/42 FZ
WR78X20988 WR78X20988 DOOR GASKET
WR38X2093 WR38X2093 EDGE TRIM FF REAR DUC
WR38X2239 WR38X2239 EDGE TRIM FF REAR DUCT
WR02X10445 WR02X10445 ELBOW PLUG IN 1/4
WR02X10446 WR02X10446 ELBOW PLUG IN 5/16
WR02X9301 WR02X9301 ELUT EXTENSION
WR32X10299 WR32X10299 ENCAP GLASS SHELVES
WR2X9228 WR2X9228 EVAP BLOCK SMALL
WR60X30349 WR60X30349 EVAP FAN MOTOR KIT
WR85X0223 WR85X0223 EVAPORATOR
WR85X223 WR85X223 EVAPORATOR
WR60X123 WR60X123 FAN BLADE
WR60X0123 WR60X0123 FAN BLADE EVAP MOTOR
WR60X187 WR60X187 FAN MOTOR
WR17X3047 WR17X3047 FAN ORIFICE
WR14X0449 WR14X0449 FF CONTROL PANEL GASKET
WR14X449 WR14X449 FF CTRL PL G
WR71X2449 WR71X2449 FF DOOR BIN ASSEMBLY
WR14X0457 WR14X0457 FF DOOR GASKET
WR24X10145 WR24X10145 FF DOOR GASKET 42
WR78X8836 WR78X8836 FF DOOR PANEL W/FOAM
WR78X10862 WR78X10862 FF FOAMED DOOR ASM 42
WR17X10011 WR17X10011 FF LOWER LIGHT HSG 42
WR02X10427 WR02X10427 FF REAR DUCT 42
WR17X10383 WR17X10383 FF WRAP ASSEMBLY SS 42
WR51X369 WR51X369 FIL TUBE HTR
WR29X0153 WR29X0153 FILL CUP
WR29X10063 WR29X10063 FILL CUP
WR2X8612 WR2X8612 FILL TUBE
WR51X0369 WR51X0369 FILL TUBE HEATER
WR02X8612 WR02X8612 FILL TUBE ICEMAKER
WR86X25269 WR86X25269 FILTER AND DRYER ASSEMBLY
WR17X10521 WR17X10521 FILTER HEAD & BRKT ASSEMBLY
WR02X10173 WR02X10173 FILTER PLUG ASM
WR01X10308 WR01X10308 FLAT WASHER 3/8X 7/8
WR2X9470 WR2X9470 FRONT WHEEL
WR71X2668 WR71X2668 FRZ BASKET FRONT ASSEMBLY
WR02X9470 WR02X9470 FT WHEEL BKT
WR21X0205 WR21X0205 FZ BASKET REAR 36"" & 42""
WR21X205 WR21X205 FZ BASKET RR
WR17X3499 WR17X3499 FZ LIGHT SHIELD
WR17X10385 WR17X10385 FZ ND WRAP ASSEMBLY SS 36/42
WR17X10014 WR17X10014 FZ REAR DUCT ND 36/42
WR71X2278 WR71X2278 FZ SHELF ASSEMBLY ND 36/42
WR14X0477 WR14X0477 GASKET DAIRY/UTIL. 42""
WR24X0516 WR24X0516 GASKET DOOR FZ 36""/42""
WR14X10001 WR14X10001 GASKET REAR DUCT
WR49X360 WR49X360 GASKET VENT
WR49X0360 WR49X0360 GASKET VENT KIT
WR2X4978 WR2X4978 GLIDER
WR74X242 WR74X242 GRILL FRAME
WR17X10386 WR17X10386 GRILLE BASE ND SS 42
WR74X10003 WR74X10003 GRILLE PANEL ASSEMBLY 42 DISPLAY
WR2X7391 WR2X7391 GROMMET
WR2X8474 WR2X8474 GROMMET
WR02X7238 WR02X7238 GROMMET COMP MTG
WR02X7391 WR02X7391 GROMMET EVAP FAN
WR2X7238 WR2X7238 GROMMET MTG.
WR02X9466 WR02X9466 GROMMET WATERFILL
WR14X477 WR14X477 GSKT DAIRY
WR02X10166 WR02X10166 HANDLE PLUG SS
WR12X27601 WR12X27601 HANDLE TUBULAR SS
WR23X10108 WR23X10108 HARNESS
WR23X474 WR23X474 HARNESS CAPT
WR51X322 WR51X322 HEATER DEF
WR51X0321 WR51X0321 HEATER-PAN
WR87X0471 WR87X0471 HIGH SIDE ASM
WR1X2164 WR1X2164 HINGE BOLT
WR13X636 WR13X636 HINGE BTM
WR13X10080 WR13X10080 HINGE COVER LH
WR13X0639 WR13X0639 HINGE COVER RH
WR13X0766 WR13X0766 HINGE DOOR BTM. F.F.
WR13X10082 WR13X10082 HINGE DOOR TOP 36SD LH
WR13X766 WR13X766 HINGE DR ASM
WR13X0643 WR13X0643 HINGE FF BTM
WR13X643 WR13X643 HINGE FF BTM
WR13X0642 WR13X0642 HINGE FF TOP
WR13X642 WR13X642 HINGE FF TOP
WR13X0641 WR13X0641 HINGE FZ BTM
WR13X641 WR13X641 HINGE FZ BTM
WR13X0640 WR13X0640 HINGE FZ TOP
WR13X640 WR13X640 HINGE FZ TOP
WR13X0633 WR13X0633 HINGE TOP FF
WR13X633 WR13X633 HINGE TOP FF
WR13X0636 WR13X0636 HINGE TOP FZ
WR13X0635 WR13X0635 HINGE TOP FZ
WR17X3498 WR17X3498 HOOD ASM
WR02X8919 WR02X8919 HOUSING FRONT PSS
WR02X8918 WR02X8918 HOUSING PSS
WR2X8918 WR2X8918 HOUSING PSS
WR2X8919 WR2X8919 HSG FRT PSS
WR30X0291 WR30X0291 ICE BUCKET
WR30X30972 WR30X30972 ICEMAKER REPLACEMENT KIT
49-6963 49-6963 INSTALL & OPTIONS GUIDE
WR02X8800 WR02X8800 KEY PIVOT
WR1X1733 WR1X1733 KEY PIVOT
WR02X8601 WR02X8601 KNOB CONTROL FF
WR02X8600 WR02X8600 KNOB CONTROL FZ
WR02X11626 WR02X11626 LAMP HOLDER FF
WR02X7560 WR02X7560 LEVELING LEG
WR02X10428 WR02X10428 LIGHT SHIELD FF 42
WR02X8928 WR02X8928 LIGHT SOCKET #3407B
WR29X204 WR29X204 MOLD BODY AS
WR29X0204 WR29X0204 MOLD/HEATER ASM
WR29X10001 WR29X10001 MOTOR
WR60X0179 WR60X0179 MOTOR COND FAN
WR60X0182 WR60X0182 MOTOR EVAP FAN
WR23X5146 WR23X5146 N/L/A 03/09/05
WR29X0160 WR29X0160 NO ITEM DESCRIPTION
WR02X8592 WR02X8592 NO ITEM DESCRIPTION
WR30X0327 WR30X0327 NO MODEL DESCRIPTION
WR01X1715 WR01X1715 NUT
WR1X1715 WR1X1715 NUT
WR57X57 WR57X57 NUT
WR57X97 WR57X97 NUT & FERRUL
WR57X0097 WR57X0097 NUT FERRUL
WR08X0170 WR08X0170 OVERLOAD
WR8X170 WR8X170 OVERLOAD
WR86X96 WR86X96 P/S DRYER KIT R134A
WR02X9404 WR02X9404 PAN COVER RETAINER
WR2X9405 WR2X9405 PAN COVR SPT
WR2X9406 WR2X9406 PAN COVR SPT
WR17X3043 WR17X3043 PAN EVAPORATION
WR49X10021 WR49X10021 PAN EVAPORATOR DRAIN
WR17X3041 WR17X3041 PAN REFRIGERATOR
WR17X10526 WR17X10526 PAN UMBILICAL LARGE
WR17X3424 WR17X3424 PAN UMBILICAL LARGE
WR74X10029 WR74X10029 PANEL FRAME ASSEMBLY SS 42
WR17X4142 WR17X4142 PICT WINDOW LT
WR17X4143 WR17X4143 PICT WINDOW RT
WR23X0108 WR23X0108 POWER CORD
WR23X10300 WR23X10300 POWER CORD
WR2X9413 WR2X9413 QUICK SHELF
WR32X1540 WR32X1540 QUICK SHELF
WR32X1539 WR32X1539 QUICK SHELF GLASS ENCAP
WR02X9413 WR02X9413 QUICK SHELF LINK
WR72X0258 WR72X0258 QUICK SHELF SLIDE (LT)
WR72X0259 WR72X0259 QUICK SHELF SLIDE (RT)
WR02X9403 WR02X9403 QUICK SHELF WIRE FRAME
WR71X2657 WR71X2657 QUICK SPACE FRAME
WR32X1556 WR32X1556 QUICK SPACE GLASS FRAME
WR32X1542 WR32X1542 QUICK SPACE GLASS FRAME
WR32X1541 WR32X1541 QUICK SPACE GLASS SLIDE
WR71X2656 WR71X2656 QUICK SPACE SHELF CANT
WR72X0261 WR72X0261 QUICK SPACE SLIDE (LH)
WR72X0260 WR72X0260 QUICK SPACE SLIDE (RH)
WR17X3617 WR17X3617 R-HAND BAFFLE W/FG
WR32X1573 WR32X1573 REFLECTOR QUICK SPACE
WR14X313 WR14X313 REFRIGERATOR GASKET COVER
WR07X0240 WR07X0240 RELAY (PTCR)
WR07X10055 WR07X10055 RELAY PTCR (8EA16C3)
WR17X3438 WR17X3438 RETAINER GLASS SHELF
WR1X1933 WR1X1933 SCR HGE COVR
WR1X5653 WR1X5653 SCR HINGE
WR01X1840 WR01X1840 SCREW
WR01X5635 WR01X5635 SCREW
WR1X5645 WR1X5645 SCREW
WR1X2130 WR1X2130 SCREW
WR1X5644 WR1X5644 SCREW
WR1X1737 WR1X1737 SCREW
WR1X1840 WR1X1840 SCREW
WR1X1716 WR1X1716 SCREW
WR1X5686 WR1X5686 SCREW
WR01X10057 WR01X10057 SCREW #10-32X3/4 CR TR H
WR01X1845 WR01X1845 SCREW 12-24TT OHT .900
WZ06X0133 WZ06X0133 SCREW BRKT. EVAP. FAN
WR01X1831 WR01X1831 SCREW GRILLE MTG.
WR01X1933 WR01X1933 SCREW HINGE COVER
WR01X1737 WR01X1737 SCREW HSG.
WR01X10026 WR01X10026 SCREW SET 10-32
WR29X5175 WR29X5175 SCREW SHROUD COND
WR1X5635 WR1X5635 SCREW TRACK
WZ6X133 WZ6X133 SCREW&WASHER
WR01X1716 WR01X1716 SCREW, FAN MOTOR
WR01X5644 WR01X5644 SCREW-CONTROL
WR1X1754D WR1X1754D SCREW-PKG 12
WR2X8603 WR2X8603 SHAFT C KNOB
WR2X8602 WR2X8602 SHAFT C KNOB
WR02X8602 WR02X8602 SHAFT CONT KNOB FF
WR02X8603 WR02X8603 SHAFT CONT KNOB FZ
WR02X11209 WR02X11209 SHEAR PIN
WR72X258 WR72X258 SHELF SLIDE
WR72X259 WR72X259 SHELF SLIDE
WR72X260 WR72X260 SHELF SLIDE
WR17X3300 WR17X3300 SHELF TRACK FZ
WR02X8590 WR02X8590 SHIM
WR02X8589 WR02X8589 SHIM
WR2X8590 WR2X8590 SHIM .030
WR2X8589 WR2X8589 SHIM .060
WR02X8593 WR02X8593 SHIM HINGE
WR2X8585 WR2X8585 SHIM HINGE
WR2X8593 WR2X8593 SHIM HINGE
WR2X8586 WR2X8586 SHIM HINGE
WR2X8592 WR2X8592 SHIM HINGE
WR02X8586 WR02X8586 SHIM HINGE BTM FF
WR02X8585 WR02X8585 SHIM HINGE TOP FF
WR01X2164 WR01X2164 SHOULDER BOLT, DOOR
WR72X10191 WR72X10191 SLIDE ASM 10
WR72X0285 WR72X0285 SLIDE FRZ ASM LH
WR72X0284 WR72X0284 SLIDE FRZ ASM RH
WR72X285 WR72X285 SLIDE FRZ LH
WR72X284 WR72X284 SLIDE FRZ RH
WR72X0269 WR72X0269 SLIDE FULL EXT10
WR02X8610 WR02X8610 SLIDE MOUNT REFRIG
WR72X0268 WR72X0268 SLIDE SUPPORT FZ
WR72X268 WR72X268 SLIDE SUPPORT FZ
WR32X1543 WR32X1543 SNACK PAN COVER
WR02X9406 WR02X9406 SNACK PAN COVER SPPT LT
WR02X9405 WR02X9405 SNACK PAN COVER SPPT RT
WR71X2663 WR71X2663 SNACK PAN FRONT ASSEMBLY
WR32X1564 WR32X1564 SNACK PAN REAR 42
WR72X0263 WR72X0263 SNACK PAN SUPPORT ASM
WR72X263 WR72X263 SNCK PAN SUP
WR02X8972 WR02X8972 SOFFIT GASKET FRNT EXTR.
WR72X261 WR72X261 SPACE SLIDE
WR29X5118 WR29X5118 SPACER HOLDING SWITCH
WR2X8916 WR2X8916 SPRG CLOSURE
WR2X8804 WR2X8804 SPRING
WR29X5181 WR29X5181 SPRING
WR29X10002 WR29X10002 SPRING BEAM
WR02X8916 WR02X8916 SPRING CLOSURE FF
WR02X8804 WR02X8804 SPRING CLOSURE FZ
WR12X27598 WR12X27598 STAND-OFF SS
WR01X5648 WR01X5648 STEEL COLLAR
WR1X5648 WR1X5648 STEEL COLLAR
WR13X0637 WR13X0637 STOP DOOR
WR02X3736 WR02X3736 STR RELIEF
WR1X5278 WR1X5278 STR RELIEF
WR2X8613 WR2X8613 STRAP
WR02X8613 WR02X8613 STRAP IM GROMMET
WR86X0105 WR86X0105 SUCTION CAPILLARY TUBE
WR23X309 WR23X309 SW POWER SAVER
WR23X26573 WR23X26573 SWITCH
WR29X5171 WR29X5171 SWITCH IM
WR23X10725 WR23X10725 SWITCH LIGHT
WR23X0411 WR23X0411 SWITCH LIGHT 200 WATT
WR23X0396 WR23X0396 SWITCH POWERSAVER
WR23X0192 WR23X0192 SWITCH-CRADLE-WATER SIDE
31-51306 31-51306 TECHNICAL DATA SHEET
WR9X509 WR9X509 TEMP CONTROL
WR09X0509 WR09X0509 TEMP CONTROL FZ
WR50X0108 WR50X0108 THEMODISC
WR29X0185 WR29X0185 THERMAL CUT-OFF
WR50X45 WR50X45 THERMO PKG
WR29X0157 WR29X0157 THERMOSTAT
WR74X276 WR74X276 TOE KICK ND
WR74X0276 WR74X0276 TOE KICK ND 42
WR17X3036 WR17X3036 TOP FZ
WR17X20773 WR17X20773 TRACK SHELF FF
WR17X4140 WR17X4140 TRACK SHELF FF
WR17X10150 WR17X10150 TRIM CASE FF SIDE SS
WR17X10151 WR17X10151 TRIM CASE FZ SIDE SS
WR38X1823 WR38X1823 TRIM FRZ REAR DUCT BTM
WR01X1903 WR01X1903 TRIM SCREW S/S
WR17X3030 WR17X3030 TUBE DRAIN
WR17X11349 WR17X11349 TUBE PLASTIC
49-60037 49-60037 USE & CARE MANUAL
WR22X510 WR22X510 UTIL. DOOR
WR57X10023 WR57X10023 VALVE ASM WATER
WR02X9408 WR02X9408 VEG PAN COVER SPPT LT
WR02X9407 WR02X9407 VEG PAN COVER SPPT RT
WR71X2666 WR71X2666 VEG PAN FRONT ASSEMBLY
WR32X1544 WR32X1544 VEG PAN GLASS 42
WR2X8965 WR2X8965 VEG PAN SEAL
WR2X8963 WR2X8963 VEG PAN SEAL
WR02X8965 WR02X8965 VEG PAN SEAL FRONT
WR02X8963 WR02X8963 VEG PAN SEAL REAR
WR72X0266 WR72X0266 VEG PAN SUPPORT ASM
WR72X266 WR72X266 VEG PAN SUPT
WR2X9408 WR2X9408 VEG PAN SUPT
WR2X9407 WR2X9407 VEG PAN SUPT
WR32X1565 WR32X1565 VEGETABLE PAN REAR 42 INCH
WR2X9426 WR2X9426 VENT GUARD
WR02X9426 WR02X9426 VENT GUARD 42""
WR74X10028 WR74X10028 VENT TOP ASSEMBLY SS 42
WR2X8972 WR2X8972 VENT TOP GAS
WR01X5649 WR01X5649 WASHER
WR01X1835 WR01X1835 WASHER
WR1X5702 WR1X5702 WASHER
WR1X1714 WR1X1714 WASHER
WR1X1835 WR1X1835 WASHER
WR01X1898 WR01X1898 WASHER COMP
WR01X2165 WR01X2165 WASHER HINGE BOLT LARGE
WR01X1714 WR01X1714 WASHER,CUSION
MWFP MWFP WATER FILTER
WR57X10024 WR57X10024 WATER VALVE ASM
WR2X8377 WR2X8377 WHEEL ASM.
WR02X8377 WR02X8377 WHEEL REAR ASM
WR17X3364 WR17X3364 WINE RACK
WR2X9403 WR2X9403 WIRE FRAME
WR17X10149 WR17X10149 WIRE GUARD SS 42
WR29X186 WR29X186 WIRE HARN
WR29X0186 WR29X0186 WIRE HARNESS
WR29X5128 WR29X5128 WR29X0191
WR30X10093 WR30X10093 WR29X5174
Main Menu x
