Manufacturer
GE
Model Number
ZISS480NPESS
Description
Refrigerator
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
"48"" GRILL KIT" |
|
|
"8-32 X 5/8"" PH SS TCS" |
|
|
"AIR TOWER COVER 42/48""" |
|
|
"CPLG. 5/16""- .079""" |
|
|
"DAIRY BIN 48""" |
|
|
"FREEZER BASKET 48""" |
|
|
"LIGHT GUIDE 48""" |
|
|
"QUICK CHILL MULLION 48""" |
|
|
"QUICK CHILL PAN 48""" |
|
|
"REFRIGERATOR LED SHELF 48""" |
|
|
"SCREW, 1/4-20 TT BHT .87" |
|
|
"SNACK PAN 48""" |
|
|
"STAINLESS FREEZER DOOR WRAP 48""" |
|
|
"STAINLESS REFRIGERATOR DOOR WRAP 48""" |
|
|
"TOE KICK 48""" |
|
|
"TOE KICK SKIRT 48""" |
|
|
"VEGETABLE PAN 48""" |
|
|
#10X1\2 PH SMS |
|
|
1/4-20 HEX NUT |
|
|
10.5MM X 8MM LOKRING |
|
|
10MM X 8MM LOKRING |
|
|
4-40 X 1/4 PH SMS |
|
|
48-INCH DRAIN PAN AND EVAPORATOR COVER KIT |
|
|
4MM X 2MM LOKRING |
|
|
6MM X 2MM LOKRING |
|
|
6MM X 4MM LOKRING |
|
|
6MM X 5MM LOKRING |
|
|
8.5MM X 6MM LOKRING |
|
|
8MM X 8MM LOKRING AL |
|
|
ACTUATOR ARM |
|
|
ACTUATOR ARM |
|
|
BAFFLE COND AIR |
|
|
BASE CHANNEL LH |
|
|
BASE CHANNEL RH |
|
|
BASE SHAFT |
|
|
BHNG ARM NYLON FF DR CL |
|
|
BIN ASM GALLON 48 |
|
|
BIN DOOR ASM 36/48 |
|
|
BIN DOOR ASM 48 |
|
|
BLADE CONF FAN ASM |
|
|
BOLT SHOULDER |
|
|
BRACKET AND VALVE ASM |
|
|
BRACKET ANTI-TIP |
|
|
BRACKET COND FAN (MTG) |
|
|
BRACKET COND FAN (REAR) |
|
|
BRACKET EVAP FAN BTM |
|
|
BRACKET ORIFICE FAN |
|
|
BRACKET WATER VALVE |
|
|
BUCKET ICE DISP |
|
|
BUCKET SLIDE |
|
|
BUMPER |
|
|
BUSHING HINGE BOTTOM |
|
|
BUSHING HINGE TOP |
|
|
CEILING LIGHT SHIELD |
|
|
COMPRESSOR |
|
|
CONDENSER AND BRACKET |
|
|
CONDENSER STRAP |
|
|
COVER QC |
|
|
COVER QC DAMPER |
|
|
COVER WATER LINES |
|
|
COVER WATER TANK |
|
|
DAMPER ASM |
|
|
DAMPER FOAM ASM 48 |
|
|
DEFROST HEATER |
|
|
DISCHARGE TUBE |
|
|
DOOR ICE BIN |
|
|
DOOR LATCH LIGHT WH (PAIR) |
|
|
DRAIN PAN AND HEATER |
|
|
DUCT GRILL |
|
|
EDGE TRIM |
|
|
EVAPORATOR |
|
|
EVAPORATOR HARNESS AC |
|
|
EVAPORATOR HARNESS DC |
|
|
FAN BLADE ASM |
|
|
FLAT WASHER 3/8X 7/8 |
|
|
FOAM BAFFLE |
|
|
FOAM BLOCK EVAP |
|
|
FOAM STRIP FRONT |
|
|
FREEZER NON DISPENSER DOOR 48"" |
|
|
FZ BOTTOM HINGE BUSHING |
|
|
FZ HINGE SXS CASE UPPER |
|
|
FZ SLIDE ASM LH |
|
|
FZ SLIDE ASM RH |
|
|
GASKET DOOR |
|
|
GASKET DOOR |
|
|
GLIDER |
|
|
GRILLE SENSOR |
|
|
GRILLE SENSOR |
|
|
GROMMET |
|
|
GROMMET EVAP FAN |
|
|
GROMMET FAN MOTOR |
|
|
HARNESS FF LOWER |
|
|
HEATER THAW |
|
|
HINGE ASM DOOR TOP RH |
|
|
HINGE CASE BOTTOM |
|
|
HINGE CASE BOTTOM FZ |
|
|
HINGE CASE FF UPPER |
|
|
HINGE DOOR BTM |
|
|
HINGE SCREW DOOR BTM |
|
|
HOUSING WIFI |
|
|
ICE BIN DOOR TRACK |
|
|
ICE BIN FRT |
|
|
ICE MAKER FILL TUBE AND HEATER |
|
|
ICEMAKER FAN |
|
|
ICEMAKER SPACER |
|
|
ICEMAKER WITH 2 PIECE FILL CUP |
|
|
INVERTER |
|
|
KEY PIVOT |
|
|
LED BOARD |
|
|
LED JUMPER HARNESS |
|
|
LED TRANSFORMER |
|
|
LIGHT GUIDE ACRYLIC FF 4 |
|
|
LIGHT SWITCH |
|
|
LIGHT SWITCH |
|
|
LINK ACTUATOR FZ |
|
|
LINK AUCATOR FF |
|
|
LOWER FF ADJ HINGE PIN |
|
|
MAIN BOARD COVER |
|
|
MAIN BOARD STAND OFF |
|
|
MAIN HARNESS AC |
|
|
MAIN HARNESS DC |
|
|
MINIMALIST DOOR HANDLE |
|
|
MOTOR DC COND FAN |
|
|
MOTOR EVAP DC |
|
|
MOUNT HOOD GRILL HINGE |
|
|
MWF BYPASS |
|
|
MWF MANIFOLD |
|
|
PAN REAR SEAL 48 |
|
|
PAN SIDE SUPPORT LH |
|
|
PAN SIDE SUPPORT RH |
|
|
PM INSTALL INSTRUCTIONS |
|
|
PM MINI MANUAL AND WIRING |
|
|
POWER CORD |
|
|
POWER SUPPLY POWER CONTROL BOARD |
|
|
QC HOUSING ASM KIT |
|
|
R600 DRIER W/ RED CAP |
|
|
R600A CHARGE CAN 60 GRAMS |
|
|
REFRIGERATOR DOOR 48"" |
|
|
REFRIGERATOR DRAIN VACUUM BREAK VALVE |
|
|
REFRIGERATOR MAIN CONTROL BOARD |
|
|
RETURN BAFFLE |
|
|
RING COMPRESSION |
|
|
SCREW |
|
|
SCREW 6X1/2 PAN PHIL H/L |
|
|
SCREW TRIM (SELF DRILLIN |
|
|
SEAL PAN FRONT |
|
|
SHEAR PIN |
|
|
SHELF FF 48 |
|
|
SHROUD CONDENSER |
|
|
SLIDE INNER |
|
|
SLIDE OUTER |
|
|
SLIDE OUTER |
|
|
SLIDE SUPPORT RH ASM |
|
|
SNACK PAN WIRE SPT ASM48 |
|
|
SPACER FF DOOR CLOSURE |
|
|
SPRING CLOSURE |
|
|
SPRING WHEEL #LE022C4 |
|
|
STATEMENT DOOR HANDLE |
|
|
STEEL COLLAR |
|
|
SUCTION TUBE |
|
|
SUPPORT SHELF LH |
|
|
SYSTEM PAN BRACKET |
|
|
TEMPERATUR SENSOR FF |
|
|
TEMPERATURE CONTROL BOARD AND HOUSING |
|
|
THERMOSTAT CUTOFF |
|
|
TOP SXS FZ DOOR HINGE AS |
|
|
TOWER LED |
|
|
TRACK FF SHELF |
|
|
TRACK FZ SHELF |
|
|
TRANSFORMER TRAY |
|
|
TRIM CASE SIDE FF CAFE P |
|
|
TRIM CASE SIDE FZ CAFE/P |
|
|
TRIM CASE TOP SXS 48 |
|
|
TRIM CEILING BRACKET LH |
|
|
TRIM CEILING BRACKET RH |
|
|
TUBE DRAIN FLEXIBLE |
|
|
VEG PAN WIRE SUPPORT |
|
|
VEG WIRE FRAME MODIFIED |
|
|
WATER FILTER BRACKET |
|
|
WATER FILTER CANISTER |
|
|
WATER VALVE BRACKET |
|
|
WHEEL ASM. |
|
|
WIFI AND HUMIDITY BOARD |
|
|
WIFI JUMPER HARNESS |
|
|
WIRE SHELF FZ 48 |
