Model Image
Manufacturer

GE

Model Number

ZIWD24PWBII

Description

Monogram 24-inch Panel-ready Wine Reserve

Interactive Exploded View
Exploded View

Parts List

Part Number Description
WR97X33925 WR97X33925 5MM X 4MM LOKRING
WR97X10085 WR97X10085 6MM X 1.8MM LOKRING
WR97X32111 WR97X32111 6MM X 3.5MM BRASS CONNECTOR
WR97X10033 WR97X10033 6MM X 4MM LOKRING
WR97X10031 WR97X10031 6MM X 6MM LOKRING
WR97X10036 WR97X10036 8MM X 6MM LOKRING
WR87X34745 WR87X34745 COMPRESSOR
WR87X34746 WR87X34746 COMPRESSOR ELECTRICALS
WR87X47727 WR87X47727 CONDENSER
WR87X34926 WR87X34926 CONDENSER FAN & BRACKET ASM
WR13X47731 WR13X47731 CONTROL BOX
WR13X47733 WR13X47733 CONTROL BOX COVER
WR55X29875 WR55X29875 DEFROST THERMISTOR
WR55X47712 WR55X47712 DISPLAY BOARD
WR09X47711 WR09X47711 DISPLAY OVERLAY
WR13X47740 WR13X47740 DOOR COVER PLATE FIXTURES
WR14X34523 WR14X34523 DOOR GASKET
WR01X34508 WR01X34508 DRAIN TUBE
WR02X47726 WR02X47726 DRIP PAN
WR02X47925 WR02X47925 END COVER BRACKET
WR87X34512 WR87X34512 EVAPORATOR
WR14X47715 WR14X47715 EVAPORATOR COVER ASSEMBLY
WR72X47747 WR72X47747 FULL LENGTH SLIDE RAIL
WR78X47736 WR78X47736 GLASS DOOR
WR72X47748 WR72X47748 HALF LENGTH SLIDE RAIL
WR71X47752 WR71X47752 HALF WINE RACK
WR01X34948 WR01X34948 HINGE SCREW
WR49X34671 WR49X34671 INSTALL BRACKETS
WR13X47707 WR13X47707 LARGE HINGE COVER
WR71X47749 WR71X47749 LARGE WINE RACK
WR13X34530 WR13X34530 LED COVER
WR55X34529 WR55X34529 LED LIGHT
WR01X47723 WR01X47723 LEFT FRONT ADJUSTMENT
WR60X47728 WR60X47728 LEFT REAR ROLLER ADJUSTMENT
WR01X47725 WR01X47725 LEVELING LEG
WR01X47743 WR01X47743 LOWER DOOR ADJUSTMENT BRACKETS
WR02X47926 WR02X47926 LOWER DOOR BRACKET
WR01X47745 WR01X47745 LOWER DOOR CENTER BRACKET
WR02X47719 WR02X47719 LOWER FRONT TRIM
WR13X47738 WR13X47738 LOWER HINGE
WR14X47713 WR14X47713 LOWER LED PANEL
WR09X35225 WR09X35225 LOWER ZONE THERMISTOR
WR13X47734 WR13X47734 MACHINE ACCESS COVER
WR55X47732 WR55X47732 MAIN CONTROL BOARD
WR02X47730 WR02X47730 MAIN CONTROL BOARD SHIELD COVER
WR13X47741 WR13X47741 MIDDLE DOOR COVER PLATE FIXTURE
WR71X47751 WR71X47751 MONOGRAM LOGO WINE RACK
WR55X34947 WR55X34947 MOTION SENSE MODULE
WR01X36672 WR01X36672 MOUNTING BRACKET SCREW
WR09X47710 WR09X47710 MULLION
WR14X34946 WR14X34946 MULLION GASKET
WR55X47985 WR55X47985 POWER CORD
31-1000772 31-1000772 PRINTED AND ONLINEMINI MANUAL AND WIRING
49-1000775 49-1000775 PRINTED AND ONLINEOWNERS AND INSTALL
WR98X25 WR98X25 R600A CHARGE CAN 25 GRAMS
WR55X31994 WR55X31994 REED SWITCH
WR13X47720 WR13X47720 REED SWITCH COVER
WR60X32071 WR60X32071 REFRIGERATOR EVAPORATOR FAN
WR55X46167 WR55X46167 REFRIGERATOR POWER SUPPLY BOARD
WR13X47865 WR13X47865 REVERSIBLE UPPER DOOR COVER
WR01X47724 WR01X47724 RIGHT FRONT ADJUSTMENT
WR60X47729 WR60X47729 RIGHT REAR ROLLER ADJUSTMENT
WR01X47735 WR01X47735 SCREW
WR01X47744 WR01X47744 SCREW
WR01X47722 WR01X47722 SCREW
WR01X47705 WR01X47705 SCREW
WR01X28375 WR01X28375 SCREW M5 X 16
WR01X21624 WR01X21624 SCREW ST3.5 X 13
WR01X28030 WR01X28030 SCREW ST3.5 X 13
WR01X28345 WR01X28345 SCREW ST3.9 X 16
WR02X47867 WR02X47867 SIDE DOOR TRIM
WR13X47708 WR13X47708 SMALL HINGE COVER
WR71X47750 WR71X47750 STANDARD WINE RACK
WR09X34528 WR09X34528 THERMISTOR
WR55X47718 WR55X47718 THERMISTOR
WR74X47721 WR74X47721 TOE KICK BRACKET
WR01X28248 WR01X28248 TOP SCREW HOLE COVER
WR02X47866 WR02X47866 UPPER & LOWER DOOR TRIM
WR14X47709 WR14X47709 UPPER AIR DUCT
WR01X47739 WR01X47739 UPPER DOOR ADJUSTMENT BRACKET
WR13X47742 WR13X47742 UPPER DOOR COVER
WR02X47706 WR02X47706 UPPER FRONT TRIM
WR13X47737 WR13X47737 UPPER HINGE
WR14X47714 WR14X47714 UPPER LED PANEL
WR13X47716 WR13X47716 WIFI & MOTION SENSE BOX
WR13X47717 WR13X47717 WIFI & MOTION SENSE COVER
WR55X47027 WR55X47027 WIFI BOARD
