Manufacturer
International Comfort Products
Model Number
PHD460000LLC0F1
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
| 1173719 | ACCUMULATOR |
| 1178403 | BASE RAIL |
| 1178402 | BASE RAIL |
| 1178014 | BASE RAIL |
| 1177927 | BOARD DEFROST CONTROL |
| 1176085 | BRACKET BLOWER SUPPORT |
| 1176023 | BRACKET SUPPORT 10-INCH |
| 1178001 | CIRCUIT BOARD |
| 1188221 | COIL CONDENSER AL/CU |
| 1188220 | COIL CONDENSER AL/CU |
| 1188305 | COIL EVAPORATOR TIN PLATE |
| 1172619 | COIL REV VALVE 24V |
| ZP51K6E-TFD-830 | COMPRESSOR |
| 1178391 | CONDENSER MOTOR 1/460 1/5 825 |
| 1173177 | CORE VALVE |
| 1176139 | COVER |
| 1176062 | COVER ASSEMBLY DUCT |
| 1178480 | COVER TOP COND |
| 1173661 | FAN BLADE |
| 1172311 | FILTER DRIER |
| 1178467 | GRILLE ASSEMBLY 18-INCH |
| 1178466 | GRILLE ASSEMBLY 18-INCH |
| 1178437 | GRILLE ASSEMBLY; 18 IN. FR/RT HG |
| 1178481 | GRILLE OUTLET |
| 1176613 | GROMMET |
| 1171270 | GROMMET COMPRESSOR |
| 1187321 | HARNESS ASSEMBLY, CONTROL ECONO |
| 1188410 | INSUL ASSEMBLY BLOWER PANEL LG |
| 1178612 | INSUL ASSEMBLY ELEC PANEL LG |
| 1188408 | INSUL ASSEMBLY PANEL COIL LG |
| 1188412 | INSUL ASSEMBLY SIDE PANEL LG |
| 1176140 | INSUL CONTROL PLATE |
| 1176087 | INSUL PANEL RET DUCT |
| 1188402 | INSULATION ASSEMBLY EVAPORATOR TOP LG |
| 1176088 | KIT BLW MTR MTG LG CHAS |
| 1172300 | LUG GROUND |
| 1174060 | METERING DEVICE .052 |
| 1187970 | MOTOR, ECM. 1 HP X13 |
| 1171357 | PAINT HAZ -HAZ- |
| 1178463 | PANEL COMP ACCESS LG |
| 1177347 | PANEL CORNER 18-INCH COND |
| 1177349 | PANEL CORNER 18-INCH HDR |
| 1177348 | PANEL CORNER 18-INCH HDR |
| 1176066 | PANEL DUCT |
| 1176112 | PARTITION COIL EVAP |
| 1177021 | PLATE ASY |
| 1176143 | PLATE CONTROL |
| 1176076 | PLATE FAN TOP |
| 1177022 | PLUG COMPRESSOR |
| 1178479 | RACEWAY OFM 14-INCH |
| 1176074 | SCROLL |
| 1178677 | SWITCH TEMP |
| 1171496 | TRANSFORMER |
| 1175622 | VALVE REVERSING |
| 1177025 | WHEEL 11-10DD CCW |
