Model Image
Manufacturer

Lenovo

Model Number

20ARZ02YUS

Description

Thinkpad-t440s

Interactive Exploded View

Parts List

Part Number Description
45N0264 45N0264 65W,20VDC,2P,WW,CHY
45N0480 45N0480 65W,20VDC,2P,WW,CHY
45N0260 45N0260 65W,20VDC,2P,WW,LTN
00HM077 00HM077 AL FOIL,CAMERA
04X3862 04X3862 ASM
04X3865 04X3865 ASM,USB SUB CARD
04X0436 04X0436 AUO 14.0"FHD AG
04X3989 04X3989 BASE,BLACK,METAL
04X5343 04X5343 BRACKET,DC IN
04X5342 04X5342 BRACKET,LCD,CONNECTOR
00HN683 00HN683 CABLE,EDP
04X5344 04X5344 CABLE,GASCKET,KBD
04X3869 04X3869 CAMERA
04X0298 04X0298 CAMERA,720P,HD,FRONT,MIC,BISON
04X0295 04X0295 CAMERA,720P,HD,FRONT,MIC,CHICONY
04X0300 04X0300 CAMERA,720P,HD,FRONT,MIC,LITEON
04Y0862 04Y0862 CS13T,US,LTN
04X0264 04X0264 CS13T,US,PRIMAX
04X3863 04X3863 DC IN
04X3868 04X3868 EDP
45N1125 45N1125 EXTERNAL,3C,23WH,LIION,PAN
45N1127 45N1127 EXTERNAL,3C,23WH,LIION,PAN
04X5341 04X5341 FRU CABEL USB SUBCARD FORUMA
04X0274 04X0274 FRU CS13 HD CAMERA JAE BSN
04X0276 04X0276 FRU CS13 HD CAMERA JAE CNY
04W3823 04W3823 FRU ERICSSON N5321 MA
04W3800 04W3800 FRU FXN NFC NO ANTENNA
04X3864 04X3864 FRU POWER SWITCH ASM
03T7290 03T7290 FRU Q85 ATX MB WIN8.1
03T7291 03T7291 FRU Q85 ATX MB WIN8.1 PRO
04X3985 04X3985 FRU SMART CARD READER CABLE
04X5475 04X5475 FRU SMART CARD READER KIT
03T6784 03T6784 FRU, P500 RONALDO PLANAR - W
03T6783 03T6783 FRU, P500 RONALDO PLANAR - W
03T6787 03T6787 FRU, P700 MESSI PLANAR - WIN
03T6786 03T6786 FRU, P700 MESSI PLANAR - WIN
03T6790 03T6790 FRU, P900 PELE PLANAR - WIN8
03T6789 03T6789 FRU, P900 PELE PLANAR - WIN8
04X0544 04X0544 HDD,500G,7200,7MM,HGST,SATA,STD
00HM715 00HM715 HDD,500G,7200,7MM,HGST,SATA,STD
00HM717 00HM717 HDD,500G,7200,7MM,SEAG,SATA,STD
04X3809 04X3809 HDD,500G,7200,7MM,TOS,SATA,STD
04X3952 04X3952 I5-4300,SWG,W8P,AMT,TPM,VPRO
45N1109 45N1109 INTERNAL,3C,23WH,LIION,PAN
45N1113 45N1113 INTERNAL,3C,23WH,LIION,PAN
45N1111 45N1111 INTERNAL,3C,23WH,LIION,SON
04X3885 04X3885 KBD,SWG
00HM813 00HM813 KBD,SWG
04X5377 04X5377 KIT
04X5444 04X5444 KIT
04X3871 04X3871 KIT,LH
04X3870 04X3870 KIT,SZS
04X3893 04X3893 KIT,WWAN+WLAN,AMP
04X3894 04X3894 KIT,WWAN+WLAN,LUX
04X3867 04X3867 LCD
04X3866 04X3866 LCD,ASM
00HM049 00HM049 LCD,SHEET,CAM
00HM187 00HM187 LCD,SHEET,CAMERA
00HN825 00HN825 LGD 14.0 FHD IPS AG
04X5347 04X5347 MIC,CAM
45N5864 45N5864 RTC BATTERY LH
02K7078 02K7078 RTC,1C,3V,LION,CR2032
04X5345 04X5345 SIM TRAY
04X5393 04X5393 SMART CARD, TAI
00HM042 00HM042 SMART CARD,CABLE
04X3984 04X3984 SMARTCARD,JAE
04X1849 04X1849 SWG,FURUKAWA
04X0444 04X0444 SWG,TOSHIBA
04X6481 04X6481 SYSTEM MISC KIT
45N0399 45N0399 US/CANADA 1.0M 2PINS LINETEK
42T5008 42T5008 US/CANADA 1.0M 2PINS LONGWELL
45N0130 45N0130 US/CANADA 1.0M 2PINS LUXSHARE
00HM069 00HM069 USB,SUBCARD,SWG
04X6008 04X6008 WIRELESS,CMB,IN,WP2AN M.2
04W3842 04W3842 WIRELESS,WWAN,ERC,N5321 M.2
