Manufacturer
Lenovo
Model Number
20C60059US
Description
Thinkpad-edge-e540
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
128G,2.5",7MM,SATA6G,LTON,STD |
|
|
128G,2.5",7MM,SATA6G,LTON,STD |
|
|
128G,2.5",7MM,SATA6G,SAMSG,STD |
|
|
128G,2.5",7MM,SATA6G,SAMSG,STD |
|
|
128G,2.5",7MM,SATA6G,SAMSG,STD |
|
|
128G,2.5",7MM,SATA6G,SDISK,STD |
|
|
128G,2.5",7MM,SATA6G,TOS,STD |
|
|
128G,2.5",7MM,SATA6G,TOS,STD |
|
|
128G,2.5",7MM,SATA6G,TOS,STD |
|
|
65W,20VDC,2P,WW,CHY |
|
|
65W,20VDC,2P,WW,DEL |
|
|
65W,20VDC,2P,WW,LTN |
|
|
8GB DDR3L 1600 SODIMM |
|
|
AUO 15.6"HD AG SLIM FLAT |
|
|
CABLE,LCD EDP |
|
|
CABLE,LCD EDP,W/O WEDGE |
|
|
CMI 15.6"HD AG SLIM FLAT |
|
|
E531/E540,US,LTN |
|
|
FRU 15W SB CARD READER&USB |
|
|
FRU 15W SB DCIN&RJ45 SUB CARD |
|
|
FRU ANTENNA WLAN SET-15 AMP |
|
|
FRU ANTENNA WLAN SET-15 ICT |
|
|
FRU BSCOVASM 15W SB ROW,NT |
|
|
FRU BSCOVASM 15W SB ROW,YT |
|
|
FRU CPU DUAL CORE I7-4702MQ |
|
|
FRU DC-IN BRACKET 15W |
|
|
FRU HD720P CAMERA W/MICS(BISON) |
|
|
FRU LCD COVER 15W BLACK PL |
|
|
FRU LCD COVER KIT 15W,BLACK |
|
|
FRU ODD SUB CARD 15W |
|
|
FRU PALMREST W/FPR,N/EDGE LOGO |
|
|
FRU PALMREST W/FPR,N/EDGE LOGO |
|
|
FRU PLN W8P,INTEG ,YTPM |
|
|
FRU POWER BUTTON SUB CARD15W |
|
|
FRU Q85 ATX MB WIN8.1 |
|
|
FRU Q85 ATX MB WIN8.1 PRO |
|
|
FRU SCREW KIT FOR E531_E540 |
|
|
FRU WP2 22BGN HMC |
|
|
FRU, P500 RONALDO PLANAR - W |
|
|
FRU, P500 RONALDO PLANAR - W |
|
|
FRU, P700 MESSI PLANAR - WIN |
|
|
FRU, P700 MESSI PLANAR - WIN |
|
|
FRU, P900 PELE PLANAR - WIN8 |
|
|
FRU, P900 PELE PLANAR - WIN8 |
|
|
FRU,15W,SCREW,MYLAR,LCD(2),NT |
|
|
FRU,15W,SCREW,MYLAR,LCD(500),NT |
|
|
FRU,720P,HD,CAMERA,W/MIC-CCY |
|
|
FRU,720P,HD,CAMERA,W/MIC-LTN |
|
|
FRU,CONNECTER COVER |
|
|
FRU,HINGE,15W |
|
|
FRU,INT,UMA,SB THERMAL,DELTA |
|
|
FRU,INTEL,UMA,SB THERMAL,AVC |
|
|
FRU,LCD,BEZEL,15W |
|
|
FRU,MINI DOOR,W/ SCREW,15W |
|
|
FRU,SPEAKER ASM,15W |
|
|
FRU,THERMAL DOOR,W/SCREW,15W |
|
|
FRU15W,SB,LCD CABLE,FOR MS |
|
|
HEATSINK,INTEL,UMA,HSW,SUNON |
|
|
LGD 15.6"HD AG SLIM FLAT |
|
|
PALM W/FPR,N/EDGE LOGO-CHY,E531 |
|
|
PALMREST W/FPR,N/EDGE LOGO,E540 |
|
|
RTC BATTERY |
|
|
SAMSUNG 15.6"HD AG SLIM FLAT |
|
|
SCREW, SCREW KIT |
|
|
SMB C01 LGC 6CELL 2.2AH |
|
|
SMB C01 SANYO 6CELL 2.2AH |
|
|
SMB C01 SIMPLO 6CELL 2.2AH |
|
|
SMB C01 SONY 6CELL 2.2AH |
|
|
SMD,HLDS,SATA,9.5MM,X8,SBGNT |
|
|
SMD,PLDS,SATA,9.5MM,X8,SBGNT |
|
|
SMD,PPRD,SATA,9.5MM,X8,SBGNT |
|
|
TRACKPOINT,RED |
|
|
US/CANADA 1.0M 2PINS LINETEK |
|
|
US/CANADA 1.0M 2PINS LUXSHARE |
|
|
US/CANADA 1.0M 2PINS VOLEX |
|
|
WIRELESS,CMB,IN,WP2BN HMC |
