Manufacturer
Lenovo
Model Number
20EGS1E800
Description
Thinkpad-w541
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
170W,20VDC,2P,WW,DEL |
|
|
256G,2.5",7MM,SATA6G,SAMSG,EDRV |
|
|
4GB DDR3L 1600 SODIMM |
|
|
ASM |
|
|
AUO 15.6"FHD AG |
|
|
BASE,BLK,WS |
|
|
CAMERA,720P,HD,FRONT,MIC,CHICONY |
|
|
CAMERA,FLAT |
|
|
CHASSIS,WS |
|
|
CLEAR PLATE,CAMERA |
|
|
CS13KM,US,CHY,BACKLIT |
|
|
DC-IN |
|
|
DC-IN |
|
|
DUMMY,EXPRESS,CARD |
|
|
EDP,FLAT,FHD |
|
|
EM GASKET,CLICKPAD,CATERON |
|
|
EXTERNAL,9C,99WH,LIION,PAN |
|
|
EXTERNAL,9C,99WH,LIION,PAN |
|
|
FINGER PRINT READER |
|
|
FLAT,JARLLY |
|
|
FPR,CLICKPAD,W541 |
|
|
HDD,DOOR |
|
|
I/O,SUBCARD |
|
|
INTEL,I7-4800MQ |
|
|
KBD,BEZEL,FPR,W541 |
|
|
KIT |
|
|
KIT,WWAN,WLAN,AMPHENOL,FLAT |
|
|
LCD,FLAT,W541 |
|
|
LCD,REAR,FLAT,TW,FHD |
|
|
MIC,AI-FOIL |
|
|
MISC,KIT,BASE |
|
|
MISC,KIT,PLANAR |
|
|
MISC,KIT,SYSTEM |
|
|
MYLAR,SCREW HINGE,CAP |
|
|
NOK,NOCPU,Q3,AMT,YTPM,W541 |
|
|
POWER,BOARD |
|
|
RTC,1C,3V,LION,CR2032 |
|
|
SHEET,GRAPHITE |
|
|
SMART CARD READER,DUMMY |
|
|
SMD,HLDS,SATA,9.5MM,X8,SBS13 |
|
|
SUBCARD,POWER SWITCH,LED |
|
|
UPPER,CASE,FPR |
|
|
US/CA,1M,2P,NON-LH,LGW |
|
|
WIRELESS,CMB,IN,WP2ACM2ROM |
|
|
WLAN,DOOR |
|
|
WS,Q3,TOSHIBA |
