Manufacturer
Lenovo
Model Number
4334DBU
Description
G570 - Laptop Computer
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
CPT CLAA156WB11A HD G W LED1 NB LCD |
|
|
PIWG1 CAMERA 0.3M PK400009V00 |
|
|
PIWG1 FAN W/CABLE DC280009BA/D/N/S0 |
|
|
PIWG1 HDD BRACKET AM0GL000600 |
|
|
PIWG1 LCD SCREW RUBBER UP FH0GL000900 |
|
|
PIWG1 MB LED SPONGE |
|
|
PIWG1 ODD BEZEL-RAMBO AP0GL000A00 |
|
|
PIWG1 ODD BRACKET EC0GL000A00 |
|
|
PIWG1 POWER BOARD UMA W/FFC 455NI738L21 |
|
|
PIWG1 SCREW-BATTERY CONN TO MB |
|
|
PIWG1 SCREW-BEZEL TO LCD COVER |
|
|
PIWG1 SCREW-FAN TO UP |
|
|
PIWG1 SCREW-HDD BRK TO LOW |
|
|
PIWG1 SCREW-HDD_BRK TO HDD |
|
|
PIWG1 SCREW-LOW TO UP(BATTERY) |
|
|
PIWG1 SCREW-POWER PCB TO UPPER |
|
|
PIWG1 SCREW-SPEAKER R/L TO LOWER |
|
|
PIWG1 SCREW-THERMAL DOOR TO LOWER |
|
|
PIWG1 SCREW-UP TO LOW |
|
|
PIWG1 SD DUMMY CARD-5IN1 FA0GL000V00 |
|
|
PIWG1 THERMAL MODULE-UMA AT0GL0020ACRU0 |
|
|
PIWG1 THERMAL PAD-PCH ET0540002/300 |
|
|
PIWG2 BT CABLE |
|
|
PIWG2 CARD READER-15.6 S6751 |
|
|
PIWG2 DC-IN CABLE-15.6 |
|
|
PIWG2 LCD BEZEL FOR W/CAMERA-HTM |
|
|
PIWG2 LCD BRACKET 15.6 R+L |
|
|
PIWG2 LED BOARD |
|
|
PIWG2 LOGIC LOWER 15.6 FOR W/HDMI |
|
|
PIWG2 LOGIC UPPER-AL W/TP FOR W/HDMI |
|
|
PIWG2 LVDS CABLE W/CMOS-15.6 |
|
|
PIWG2 ODD BOARD |
|
|
PIWG2 SPEAKER SET-15.6 2W 4OHM |
|
|
PIWG2 THERMAL DOOR-15.6 |
|
|
PIWG2 TP FFC-15.6 6P 134MM |
|
|
PIWG2 USB CABLE-15.6 M/B-USB_WIRE |
|
|
PIWG2 WLAN ANTENNA 15.6 R+L |
|
|
PSN UJ8A0 TRAY IN RAMBO ODD |
|
|
SCREW C G570 THML TO MB |
|
|
VOLEX US15S3+SPT-2 VAC5S 1M CORD |
