Model Image
Manufacturer

Midea

Model Number

M30D27HRDN1M

Description

Mini-split

Interactive Exploded View

Parts List

Part Number Description
15111600000083 15111600000083 1/2-INCH --3/8-INCH ADAPTER
15111600000073 15111600000073 1/2-INCH --5/8-INCH ADAPTER
15111600000081 15111600000081 1/4-INCH --3/8-INCH ADAPTER
15500307000001 15500307000001 3/8-INCH --1/2-INCH ADAPTER
15500405000008 15500405000008 3/8-INCH --1/2-INCH ADAPTER
15500216000003 15500216000003 4-WAYS VALVE
15422300000099 15422300000099 4-WAYS VALVE ASSEMBLY
12222000001858 12222000001858 AIR OUTLET GRILLE
11002012005083 11002012005083 ASYNCHRONOUS MOTOR
12100105000060 12100105000060 AXIAL FLOW FAN
12222300000169 12222300000169 BIG HANDLE
12222300000134 12222300000134 CHASSIS ASSEMBLY
12222300000215 12222300000215 CHASSIS ASSEMBLY
12122000006844 12122000006844 CLAMP OF FRONT NET
11103020000201 11103020000201 COMPRESSOR
15822000001101 15822000001101 CONDENSER
15822000001856 15822000001856 CONDENSER ASSEMBLY
15822000A01724 15822000A01724 CONDENSER ASSEMBLY
15500406000016 15500406000016 COPPER NUT
12122300000044 12122300000044 COVER OF ELECTRONIC CONTROL BOX
12222200001792 12222200001792 COVER OF INDUCTANCE
17402001000014 17402001000014 CRANKCASE ELECTRIC HEATER
11201007000246 11201007000246 DISCHARGE TEMPERATURE SENSOR ASSEMBLY
17222300000194 17222300000194 ELECTRONIC CONTROL BOX ASSEMBLY
17222300A00009 17222300A00009 ELECTRONIC CONTROL BOX ASSEMBLY
17222300A00021 17222300A00021 ELECTRONIC CONTROL BOX ASSEMBLY
17222300A00295 17222300A00295 ELECTRONIC CONTROL BOX ASSEMBLY
15500213000046 15500213000046 ELECTRONIC EXPANSION VALVE ASSEMBLY
15500213000049 15500213000049 ELECTRONIC EXPANSION VALVE ASSEMBLY
17400101000019 17400101000019 FAN MOTOR CAPACITOR
12222200001814 12222200001814 FRONT PANEL
12222200001825 12222200001825 FRONT PANEL
12222200001662 12222200001662 FRONT RIGHT CLAPBOARD ASSEMBLY
15500204000008 15500204000008 GAS VALVE
15122000000802 15122000000802 INPUT PIPE ASSEMBLY
12122300000041 12122300000041 INSTALLATION PLATE OF ELECTRIC PARTS
17122300000627 17122300000627 INVERTER CONTROL BOARD ASSEMBLY
17122300000734 17122300000734 INVERTER CONTROL BOARD ASSEMBLY
12222200001643 12222200001643 LEFT SUPPORTER
12222200001875 12222200001875 LEFT SUPPORTER
22011600000033 22011600000033 LINE SET (1/4-INCH - 1/2-INCH ) 16 FT
22011600000016 22011600000016 LINE SET (1/4-INCH - 1/2-INCH ) 24.5 FT
22011600000147 22011600000147 LINE SET (1/4-INCH - 3/8-INCH ) 16 FT
22011600000030 22011600000030 LINE SET (1/4-INCH - 3/8-INCH ) 24.5 FT
22011600000149 22011600000149 LINE SET (3/8-INCH - 5/8-INCH ) 16 FT
22011600000066 22011600000066 LINE SET (3/8-INCH - 5/8-INCH ) 24.5 FT
15500208000031 15500208000031 LIQUID VALVE
15422300000025 15422300000025 LIQUID VALVE ASSEMBLY
15422300000028 15422300000028 LIQUID VALVE ASSEMBLY
17122300A00521 17122300A00521 MAIN CONTROL BOARD (WHISTLING)
17122300A00065 17122300A00065 MAIN CONTROL BOARD ASSEMBLY
17122300000482 17122300000482 OUTDOOR MAIN CONTROL BOARD ASSEMBLY
17122300A00115 17122300A00115 OUTDOOR MAIN CONTROL BOARD ASSEMBLY
17122300A00500 17122300A00500 OUTDOOR MAIN CONTROL BOARD ASSEMBLY
15122000000414 15122000000414 OUTPUT PIPE
12222300000172 12222300000172 PARTITION BOARD ASSEMBLY
11203803000085 11203803000085 RADIATOR
17400306000058 17400306000058 REACTOR
12122200002801 12122200002801 REAR NET
12222200001554 12222200001554 REAR NET
12222300000071 12222300000071 REAR RIGHT CLAPBOARD ASSEMBLY
12222200001553 12222200001553 REAR SUPPORTER
11201007000044 11201007000044 SENSOR (T2B PIPE TEMP)
11201007000136 11201007000136 SENSOR (T3 PIPE TEMP)
11201007000143 11201007000143 SENSOR (T4 AMBIENT TEMP)
12222200001791 12222200001791 SUPPORTER ASSEMBLY OF FAN MOTOR
12222300000226 12222300000226 TERMINAL BOARD
17222300000161 17222300000161 TERMINAL BOARD ASSEMBLY
12222300000199 12222300000199 TOP COVER ASSEMBLY
12222300000209 12222300000209 VALVE PLATE
12122000007147 12122000007147 WATER COLLECTOR
12122300000015 12122300000015 WATER COLLECTOR
17400401000135 17400401000135 WIRE JOINT
