Manufacturer
Midea
Model Number
MEHS36PSH2
Description
Indoor Unit Of Split
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
AIR FILTER |
|
|
AIR FRESHENING FILTER |
|
|
AIR OUTLET ASSEMBLY |
|
|
AMBIENT TEMPERATURE SENSOR ASSEMBLY |
|
|
AMBIENT TEMPERATURE SENSOR ASSEMBLY |
|
|
BEARING BASE |
|
|
BEARING HOLDER |
|
|
BRACKET OF REMOTE CONTROLLER |
|
|
BRACKET OF REMOTE CONTROLLER |
|
|
CHASSIS ASSEMBLY |
|
|
COVER OF ELECTRICAL EQUIPMENT |
|
|
COVER OF ELECTRONIC CONTROL BOX |
|
|
CROSS FLOW FAN |
|
|
DISPLAY BOARD |
|
|
DISPLAY BOARD ASSEMBLY |
|
|
DISPLAY BOX SUBASSEMBLY |
|
|
DRAIN HOSE |
|
|
DRAIN JOINT |
|
|
ELECTRONIC CONTROL BOX |
|
|
ELECTRONIC CONTROL BOX ASSEMBLY |
|
|
EVAPORATOR ASSEMBLY |
|
|
FAN MOTOR |
|
|
FAN MOTOR COVER |
|
|
FRONT COVER OF CHASSIS(RIGHT) |
|
|
HORIZONTAL LOUVER |
|
|
HORIZONTAL LOUVER (ABOVE) |
|
|
HORIZONTAL LOUVER (BELOW) |
|
|
INCLUDES (DISPLAY BOARD, CONTROL BOX, WIFI MODULE) |
|
|
INCLUDES (WIRED CONTROLLER, INTERFACE KIT, & DISPLAY BOARD) |
|
|
INDOOR MAIN CONTROL BOARD ASSEMBLY |
|
|
INSTALLATION PLATE |
|
|
INTERFACE KIT |
|
|
LOUVER MOTOR |
|
|
PANEL ASSEMBLY |
|
|
PANEL FRAME ASSEMBLY |
|
|
PIPE CLAMP BOARD |
|
|
PIPE NUT OR COPPER NUT |
|
|
PIPE NUT OR COPPER NUT |
|
|
PIPE TEMPERATURE SENSOR |
|
|
PIPE TEMPERATURE SENSOR ASSEMBLY |
|
|
REMOTE CONTROLLER |
|
|
SCREW CAP |
|
|
SEAL RING |
|
|
WIFI KIT (CONTROL BOX) |
|
|
WIFI KIT (WIFI MODULE) |
|
|
WIRE JOINT |
|
|
WIRED CONTROLLER (120G1 - NEEDS INTERFACE/DISPLAY BOARD) |
