Model Image
Manufacturer

Panasonic

Model Number

AJVF20W

Description

No description available

Interactive Exploded View

Parts List

Part Number Description
VEE1C85 VEE1C85 10P CABLE
VEE0J46 VEE0J46 13P CABLE
VYK9295 VYK9295 BOTTOM CASE ASS
VCEV1HBH4R7 VCEV1HBH4R7 CAPACITOR
VCEV1CBL471 VCEV1CBL471 CAPACITOR
VCEV1CBJ101 VCEV1CBJ101 CAPACITOR
VCEA1JBK270 VCEA1JBK270 CAPACITOR
VCEA1CBG101 VCEA1CBG101 CAPACITOR
VMG1217 VMG1217 CASE PACKING (1
VMG1218 VMG1218 CASE PACKING (2
VJS4337 VJS4337 CRT CABLE/YOKE (DISCONTINUED)
VEK8805 VEK8805 CRT/DY ASS'Y
VEK8804 VEK8804 CRT/DY ASS'Y (DISCONTINUED)
VGH4300 VGH4300 DISPLAY PLATE
VGM1266 VGM1266 EVF ATTACHMENT
VMG1773-S VMG1773-S EYE CAP
VLT0949 VLT0949 FLYBACK TRANSFO
VKH0389 VKH0389 GUARD BAR
TC4S01F TC4S01F IC CMOS STANDAR
LM4041E1M312 LM4041E1M312 IC LINEAR
VMZ2914 VMZ2914 INSULATION
VYC0950 VYC0950 LENS CASE
VMG1221 VMG1221 LENS LOCK PACKI
VGM1655 VGM1655 LOCK TABLE
VMX2890 VMX2890 MASK SHEET
VMZ2915 VMZ2915 MASK SHEET
VDL0965 VDL0965 MC PROJECTOR
VGP5040 VGP5040 OUT SIDE HOLDER
VEP29173A VEP29173A PCB
VEP20781A VEP20781A PCB
VEP20782A VEP20782A PCB
VEP20783 VEP20783 PCB
VMC1513 VMC1513 PLATE SPRING
VMX2886 VMX2886 RING
VHD1265 VHD1265 SCREW
AJVF20WSM AJVF20WSM SERVICE MANUAL
AJVF20WCD AJVF20WCD SERVICE MANUAL
AJVF20WBSM AJVF20WBSM SERVICE MANUAL
VMG1225 VMG1225 SWITCH PACKING
VGQ5321 VGQ5321 TALLEY BASE
VGU8170 VGU8170 TALLY KNOB
VMG1219 VMG1219 TALLY SHEET
VST0332 VST0332 TOGGLE SWITCH
VST0333 VST0333 TOGGLE SWITCH
VYK9294 VYK9294 TOP CASE ASS'Y
2SK1254L 2SK1254L TRANSISTOR
VEE1C83 VEE1C83 VF CABLE
VGL0837 VGL0837 VGL0837
VGU0A67 VGU0A67 VR KNOB
VHD1884 VHD1884 VR NUT
VMX2885 VMX2885 WASHER
VMX3472 VMX3472 WASHER
