Model Image
Manufacturer

Panasonic

Model Number

DCGX9MK

Description

Lumix Gx9 With 12-60mm Lens

Interactive Exploded View

Parts List

Part Number Description
K1MY16BA0641 K1MY16BA0641 16P CONNECTOR
SAE0012AC SAE0012AC ADAPTER
VMS8278 VMS8278 ADJUST PIN
VMS8262-A VMS8262-A BATTERY DOOR SHAFT
VKF4971 VKF4971 BODY CAP
F1KZZ473A002 F1KZZ473A002 CAPACITOR
F1H1A105A025 F1H1A105A025 CAPACITOR
F1G1H103B014 F1G1H103B014 CAPACITOR
F1J1C1060001 F1J1C1060001 CAPACITOR 16V 10U
F1G1H470A834 F1G1H470A834 CAPACITOR 47PF, 50V
F1J1A106A043 F1J1A106A043 CER CAPACITOR 10U 10V
F1H0J4750004 F1H0J4750004 CER CAPACITOR 4.7U 6.3V
F1G1H471A830 F1G1H471A830 CERAMIC CAPACITOR
F1G1H102A830 F1G1H102A830 CERAMIC CAPACITOR
F1G1C104A146 F1G1C104A146 CERAMIC CAPACITOR
F1G0J1050007 F1G0J1050007 CERAMIC CAPACITOR
F1H0J1060006 F1H0J1060006 CERAMIC CAPACITOR MULTIL
G1C1R5MA0943 G1C1R5MA0943 CHIP INDUCTOR
G1C2R2MA0392 G1C2R2MA0392 CHIP INDUCTOR 2.2UH
G1C2R2KA0096 G1C2R2KA0096 CHIP INDUCTOR 2.2UH
G1C330MA0477 G1C330MA0477 CHIP INDUCTOR 33UH
D1H84734A042 D1H84734A042 CHIP RESISTOR
D0GA183JA023 D0GA183JA023 CHIP RESISTOR
B1GFCFJJ0016 B1GFCFJJ0016 CHIP TRANSISTOR SI 0 1W
EXC24CE900U EXC24CE900U COIL CAPACITOR
VQL2T97 VQL2T97 COLOR LABEL - S
K1MY15BA0585 K1MY15BA0585 CONNECTOR 15P
K1MY25BA0585 K1MY25BA0585 CONNECTOR 25P
K1MY25BA0556 K1MY25BA0556 CONNECTOR 25P
K1MY45BA0667 K1MY45BA0667 CONNECTOR 45P
K4ZZ04000064 K4ZZ04000064 CONNECTOR 4P
K1MY04BA0633 K1MY04BA0633 CONNECTOR 4P
K1MY51BA0647 K1MY51BA0647 CONNECTOR 51P
K1MY61BA0667 K1MY61BA0667 CONNECTOR 61P
K1MY61BA0647 K1MY61BA0647 CONNECTOR 61P
K1MY06BA0557 K1MY06BA0557 CONNECTOR 6P
K1MY08BA0557 K1MY08BA0557 CONNECTOR 8P
H0J327200230 H0J327200230 CRYSTAL OSCILLATOR
H0J240500053 H0J240500053 CRYSTAL OSCILLATOR
SDW0373K SDW0373K DECORATION RING
VYC1134 VYC1134 DECORATION RING UNIT
B1GBCFYY0222 B1GBCFYY0222 DIGITAL TRANSISTOR
B1GBCFYY0217 B1GBCFYY0217 DIGITAL TRANSISTOR
DZ5S068D0R DZ5S068D0R DIODE
DB3S308F0L DB3S308F0L DIODE
B3ADB0000244 B3ADB0000244 DIODE
B2ABAP000007 B2ABAP000007 DIODE
B0JCMD000066 B0JCMD000066 DIODE
B0JCDD000019 B0JCDD000019 DIODE
B0ADEJ000054 B0ADEJ000054 DIODE
1KE8DCGX9EGKZ 1KE8DCGX9EGKZ EYE CUP UNIT
B1CFJD000007 B1CFJD000007 FIELD EFFECT TRANSISTORS
EXC28CH900U EXC28CH900U FILTER
SDW0372K SDW0372K FILTER RING
VMG2117 VMG2117 FLOATING RUBBER
VMG1855 VMG1855 FLOATING RUBBER
SXQ0653 SXQ0653 FOCUS RING UNIT
SXQ0655 SXQ0655 FRONT FRAME UNIT
ERBRD1R50X ERBRD1R50X FUSE
ERBRD1R00X ERBRD1R00X FUSE
ERBRD2R00X ERBRD2R00X FUSE 32V 2.0A
ERBRE2R50V ERBRE2R50V FUSE 32V 2.5A
K5H1512A0024 K5H1512A0024 FUSE 50V 0.15A
VKF5259 VKF5259 HOT SHOE COVER
SKF0133H SKF0133H HOT SHOE COVER
SUBF000022 SUBF000022 IC
SUBF000017 SUBF000017 IC
L2EE00000038 L2EE00000038 IC
C1ZBZ0005562 C1ZBZ0005562 IC
C0ZBZ0002264 C0ZBZ0002264 IC
C0DBGYY06572 C0DBGYY06572 IC
C0DBGYY06165 C0DBGYY06165 IC
C0DBAYY02385 C0DBAYY02385 IC
B3NBB0000009 B3NBB0000009 IC
1SL1DVLB1219Z 1SL1DVLB1219Z IC
C0DBGYY06834 C0DBGYY06834 IC
C0DBGYY06737 C0DBGYY06737 IC
C1ZBZ0004906 C1ZBZ0004906 IC, LINEAR
C0ZBZ0002095 C0ZBZ0002095 IC, LINEAR
C0ZBZ0001817 C0ZBZ0001817 IC, LINEAR
C0DBGYY02523 C0DBGYY02523 IC, LINEAR
C0DBGYY02368 C0DBGYY02368 IC, LINEAR
C0DBAYY01798 C0DBAYY01798 IC, LINEAR
C0ABGA000035 C0ABGA000035 IC, LINEAR
J0JFC0000006 J0JFC0000006 INDUCTOR
K1FY119E0057 K1FY119E0057 JACK, HDMI
SXQ0649 SXQ0649 L MOUNT UNIT
SYF0059-M SYF0059-M LENS CAP
VYF3514 VYF3514 LENS FRONT CAP
SDW0355K SDW0355K LENS HOOD
VFC4605 VFC4605 LENS REAR CAP
SXW0282 SXW0282 LENS UNIT
VXS0266 VXS0266 LEVER ROTOR
ML-421S_DB ML-421S_DB LITHIUM COIN BATTERY
C0DBGYY00779 C0DBGYY00779 LOGIC IC
L5EDDYY00516 L5EDDYY00516 LVF MODULE
D1BA5601A022 D1BA5601A022 M.RESISTOR CH 1/16W 5.6K
D0GB121JA065 D0GB121JA065 METAL GLAZE FILM RESISTOR
D0GB104JA065 D0GB104JA065 METAL GLAZE RESISTOR
D0GBR00J0004 D0GBR00J0004 METAL GLAZE RESISTOR 0 06
D0GA680JA023 D0GA680JA023 METAL GLAZE RESISTOR 0 06
D0GA473JA023 D0GA473JA023 METAL GLAZE RESISTOR 0 06
D0GA151JA023 D0GA151JA023 METAL GLAZE RESISTOR 0 06
D0GA103JA023 D0GA103JA023 METAL GLAZE RESISTOR 0 06
D0GA102JA023 D0GA102JA023 METAL GLAZE RESISTOR 0 06
D0GA101JA023 D0GA101JA023 METAL GLAZE RESISTOR 0 06
SEJ0005 SEJ0005 MOUNT CONTACT UNIT
VEK0U87 VEK0U87 MOUNT CONTAT UNIT
D1H86804A042 D1H86804A042 NETWORK RESISTER
VDW2714 VDW2714 PC BOARD FRAME
DVGE1275Z DVGE1275Z PLATE
SXQ0648 SXQ0648 REAR FRAME UNIT
VXW1724 VXW1724 REAR FRAME UNIT - K
D1H81034A042 D1H81034A042 RESISTOR
D1BD4703A119 D1BD4703A119 RESISTOR
D1BA1621A022 D1BA1621A022 RESISTOR
D0GD514JA052 D0GD514JA052 RESISTOR
D0GD106JA052 D0GD106JA052 RESISTOR
D1BA1001A022 D1BA1001A022 RESISTOR 1K 1/16W
B1GBCFYY0284 B1GBCFYY0284 RESISTOR BUILT-IN TYPE TR
D1H81044A042 D1H81044A042 RESISTOR NETWORKS
D1H81014A042 D1H81014A042 RESISTOR NETWORKS
XQN14_BJ4FJK XQN14_BJ4FJK SCREW
VHD2480 VHD2480 SCREW
VHD2476 VHD2476 SCREW
VHD2473 VHD2473 SCREW
VHD2457 VHD2457 SCREW
VHD2431 VHD2431 SCREW
VHD2384 VHD2384 SCREW
VHD2337 VHD2337 SCREW
VHD2306 VHD2306 SCREW
VHD2296 VHD2296 SCREW
VHD2291 VHD2291 SCREW
VHD2290 VHD2290 SCREW
VHD2252-B VHD2252-B SCREW
VHD2246 VHD2246 SCREW
VHD2240 VHD2240 SCREW
VHD2190 VHD2190 SCREW
XQN16_BJ4FNK XQN16_BJ4FNK SCREW STEEL
VHD1681 VHD1681 SCREW STEEL
VGQ0X85 VGQ0X85 SHEET
VMC2111 VMC2111 SHOE SPRING
VFC5167 VFC5167 SHOULDER STRAP
K0L1BA000152 K0L1BA000152 SWITCH
K0F212A00006 K0F212A00006 SWITCH
K0F111A00598 K0F111A00598 SWITCH
DA2SF650EL DA2SF650EL SWITCHING DIODES
K4ZZ01000208 K4ZZ01000208 TERMINAL
D4CC11030013 D4CC11030013 THERMISTOR
G5DYA0000152 G5DYA0000152 TRANSFORMER
FK3503010L FK3503010L TRANSISTOR
FC6943010R FC6943010R TRANSISTOR
B1JBLP000030 B1JBLP000030 TRANSISTOR
B1CHPB000008 B1CHPB000008 TRANSISTOR
B1CHMB000007 B1CHMB000007 TRANSISTOR
B1CFRD000100 B1CFRD000100 TRANSISTOR
B1CFGC000022 B1CFGC000022 TRANSISTOR
B1ABCF000302 B1ABCF000302 TRANSISTOR
B1CFGD000003 B1CFGD000003 TRANSISTOR FET 0 15W
B1GKCFJN0008 B1GKCFJN0008 TRANSISTOR RESISTOR
B1GKCFYY0029 B1GKCFYY0029 TRANSISTOR-RESISTOR
B1GDCFYY0150 B1GDCFYY0150 TRANSISTOR-RESISTOR
B1GBCFYY0219 B1GBCFYY0219 TRANSISTOR-RESISTOR
D4ED18R00008 D4ED18R00008 VARISTOR
VMC2220 VMC2220 WAVE WASHER
DZ2J082M0L DZ2J082M0L ZENER DIODE
VMS8326 VMS8326 ZOOM PIN
