Manufacturer

Panasonic

Model Number

DMRE80HP

Description

Dvd Recorder

Interactive Exploded View

Parts List

Part Number	Description
REP3497M	AUTHORIZATION REQUIRED19
2SB766A-QR	NLA TRANSISTOR
2SB710RS	2SB710A-RS
2SD1476-QR	2SD2000-P
2SD602ARS	2SD602A-S
RMA1639	ANGLE
RMA1640	ANGLE
VMD4598	ARM
VMD4606	ARM
VGB0560	BADGE
VPF0505	BAG (DISCONTINUED)
RMA1675	BRACKET
RGU2185A-K	BUTTON
RGU2186-S	BUTTON
RGU2187A-K	BUTTON
RGU2188-S	BUTTON
RGU2206-Q	BUTTON
RGU2207-Q	BUTTON
RFKZ0164	CABLE
RFKZ0165	CABLE
RFKZ0166	CABLE
RFKZ0168	CABLE
RFKZ0169	CABLE
RFKZ0170	CABLE
RFKZ0171	CABLE
VEE0U08	CABLE
VEK0D56	CABLE
VJB90484	CABLE
VWJ1650	CABLE
VJA1091	CABLE
K2KA6CA00001	CABLE, AV
ECJ1VC1H020C	CAP
ECJ1VC1H470J	CAP
ECJ2FB0J106K	CAP
DE1SL151J	CAPACITOR
ECA1AHG102	CAPACITOR
ECA1EHG102E	CAPACITOR
ECEA1CKS101B	CAPACITOR
ECEA1CKA470B	CAPACITOR
ECEA1HSN010S	CAPACITOR
ECJ1VB0J105K	CAPACITOR
ECJ1VB0J394K	CAPACITOR
ECJ1VB0J474K	CAPACITOR
ECJ1VB0J564K	CAPACITOR
ECJ1VB0J684K	CAPACITOR
ECJ1XB1C104K	CAPACITOR
ECJ1VB1C333K	CAPACITOR
ECJ1VB1E223K	CAPACITOR
ECJ1VB1H102K	CAPACITOR
ECJ1VB1H103K	CAPACITOR
ECJ1VB1H182K	CAPACITOR
F1H1H222A219	CAPACITOR
ECJ1VB1H332K	CAPACITOR
ECJ1XB1H472K	CAPACITOR
ECJ1VB1H473K	CAPACITOR
ECJ1VB1H562K	CAPACITOR
ECJ1VB1H822K	CAPACITOR
ECJ1VC1H030C	CAPACITOR
ECJ1VC1H100C	CAPACITOR
ECUX1H101JCV	CAPACITOR
ECJ1XC1H102J	CAPACITOR
ECJ1VC1H120J	CAPACITOR
ECJ1XC1H121J	CAPACITOR
ECJ1XC1H150J	CAPACITOR
ECJ1XC1H180J	CAPACITOR
ECJ1VC1H220J	CAPACITOR
ECJ1VC1H270J	CAPACITOR
ECJ1XC1H330J	CAPACITOR
ECJ1XC1H331J	CAPACITOR
ECJ1VC1H390J	CAPACITOR
ECJ1VC1H560J	CAPACITOR
ECJ1VC1H561J	CAPACITOR
ECJ1XF1A105Z	CAPACITOR
F1H1C1040004	CAPACITOR
ECJ1VF1E104Z	CAPACITOR
ECUX1H103KBV	CAPACITOR
TCJ2VC1H102J	CAPACITOR
ECJ2VC1H680J	CAPACITOR
ECJ2XB1H333K	CAPACITOR
ECQB1H223KF3	CAPACITOR
ECQB1H333JF3	CAPACITOR
ECQU2A104ML	CAPACITOR
ECQU2A224ML	CAPACITOR
ECST1AY106R	CAPACITOR
ECUV1H010CC	CAPACITOR
ECUV1H221JCV	CAPACITOR
ECUV1H680JCV	CAPACITOR
ECUV1H681JCX	CAPACITOR
ECUX1C683KBV	CAPACITOR
ECUX1H471JCV	CAPACITOR
ECUX1H681JC	CAPACITOR
EEE0JA101SP	CAPACITOR
EEE0JA220SR	CAPACITOR
EEE0JA470SR	CAPACITOR
EEE1CA100SR	CAPACITOR
EEVHB1E4R7	CAPACITOR
EXCELDR35	CAPACITOR
F1J0J4750004	CAPACITOR
F1K1C475A026	CAPACITOR
F2A0J221A016	CAPACITOR
F2A0J470A012	CAPACITOR
F2A0J470A013	CAPACITOR
F2A0J470A179	CAPACITOR
F2A0J471A247	CAPACITOR
F2A0J471A256	CAPACITOR
F2A1A101A206	CAPACITOR
F2A1A470A140	CAPACITOR
F2A1A471A211	CAPACITOR
F2A1C100A019	CAPACITOR
F2A1C102A236	CAPACITOR
F2A1C221A019	CAPACITOR
F2A1E221A210	CAPACITOR
F2A1E4700048	CAPACITOR
F2A1E470A205	CAPACITOR
F2A1H100A146	CAPACITOR
F2A1H100A236	CAPACITOR
F2A1H1R0A147	CAPACITOR
F2A1V470A116	CAPACITOR
F2G0J331A015	CAPACITOR
F2H0J101A001	CAPACITOR
F2H0J1500006	CAPACITOR
F3F1A1060010	CAPACITOR
F3K0J3360002	CAPACITOR
F3K1A1060001	CAPACITOR
F3K1C1060005	CAPACITOR
K1KB08A00084	CAPACITOR
KH101K	CAPACITOR
KH102M	CAPACITOR
KH222M	CAPACITOR
KMG1E470	CAPACITOR
KMG1H2R2	CAPACITOR
KMG1H4R7	CAPACITOR
KMG1V470	CAPACITOR
KMM2E121	CAPACITOR
KY0J152	CAPACITOR
KY1A122	CAPACITOR
KY1A221	CAPACITOR
KY1A471	CAPACITOR
KY1C102L	CAPACITOR
KY1C471	CAPACITOR
KY1V560	CAPACITOR
MBB104K2	CAPACITOR
MBB104K5	CAPACITOR
MBB105K1	CAPACITOR
MBC101K2D	CAPACITOR
RR3AD471K	CAPACITOR
TBB224K2	CAPACITOR
VCEV1CRV470V	CAPACITOR
ECEC1HKS010	CAPACITOR
ERJ3RHD183V	CAPACITOR
ECEA0JKS220I	CAPACITOR
SCEA0JFE331E	CAPACITOR
ECQP1H102JZ	CAPACITOR
RPQF0250	CASE
VXA7398	CASSETTE
VMD4705A	CHASSIS
JSM0048	CLAMP
VMD4029	CLAMP
VMD4768	CLAMP
ELESN101KA	COIL
ELJPA101KF	COIL
ELJPA181KF	COIL
ELJPA220KFB	COIL
EXCELSA35	COIL
G0C120JA0019	COIL
G0C220JA0019	COIL
G0C4R7JA0019	COIL
G0ZZ00001936	COIL
H2D400500001	COIL
J0JGC0000020	COIL
J0JHC0000045	COIL
LAV35VB150K	COIL
LHLZ1R5M	COIL
LHLZ2R2M	COIL
LHLZ4R7M	COIL
J0JCC0000103	COIL
VLQ0599J6R8	COIL
ELESE220KA	COIL
UN5113TW	COMBINATION
UN5213TX	COMBINATION
127602110K	CONNECTOR
B4B-EH-A	CONNECTOR
K1KA02B00053	CONNECTOR
K1KA06A00328	CONNECTOR
K1KA08A00355	CONNECTOR
K1KA10B00196	CONNECTOR
K1KA15A00124	CONNECTOR
K1KA19A00016	CONNECTOR
K1KA20B00132	CONNECTOR
K1KA30A00180	CONNECTOR
K1KB20B00040	CONNECTOR
K1KB30A00135	CONNECTOR
K1KB40A00118	CONNECTOR
K1MN24B00013	CONNECTOR
K1MN40B00010	CONNECTOR
K1MN40B00022	CONNECTOR
K1MN40B00027	CONNECTOR
TWGP15XA1	CONNECTOR
TWGP19XA1	CONNECTOR
VJS3801D030	CONNECTOR
K2AB2H000004	CONNECTOR
K1MN40A00018	CONNECTOR
EVMEASA01B52	CONTROL
K2CB2CB00022	CORD, POWER
CNC1S171R	COUPLER
RKM0485-S	COVER
RMN0751	COVER
UR76EC2403A	COVER
VMD4664	COVER
VMG1529	DAMPER
B0JACE000001	DIODE
BRF1560	DIODE
D2SBA60	DIODE
ERA15-04	DIODE
ERA91-02	DIODE
GPP20J	DIODE
MA111TX	DIODE
YEAD1SS133	DIODE
TVS1N4148V	DIODE
MA2C18500E	DIODE
MA2ZV0100L	DIODE
MA3S132E0L	DIODE
MA3Z142D0RG	DIODE
MA3Z142K0LG	DIODE
MA4075N	DIODE
MA4300N-M	DIODE
MA784	DIODE
MA8039	DIODE
MA8051	DIODE
MAZ4240NMF	DIODE
MAZ8051	DIODE
MA8270	DIODE
MN103S31ESC	DIODE
RK36	DIODE
RK39	DIODE
RK46	DIODE
RL2ZLF	DIODE
RN2Z	DIODE
B0HCMM000014	DIODE
MA8027H	DIODE
ERA22-08V3	DIODE
ERA2202	DIODE
LM-RF120LU	DISC
FWVD9022E80	DISC
LM-RS47V25-U	DISC (DISCONTINUED)
DMRFIRMWARE	DISK
RKF0666E-S	DOOR
RKF0667-K	DOOR
RMX0268	DOOR
RFKV0112HDK	DRIVE
ECEA0JKS220L	ECEA0JKS220
ECEA0JU102	ECEA0JU102
ELJNAR10MF	ELJNAR10MB
ER010CKF1000	ER010CKF1000
ERDS2FJ100	ERD25FJ100P
ERDS2FJ121	ERD25FJ121K
ERDS2FJ331	ERD25FJ331
ERDS2TJ470	ERD25FJ470T
ERJ3GEYJ333	ERJ3GEYG333
ERJ3GEYJ471V	ERJ3GEYG471
ERJ3GEYG473	ERJ3GEYG473
ERJ3GEYJ271V	ERJ3GEYJ221
ERJ3GEYJ272	ERJ3GEYJ272
D0GB393JA041	ERJ3GEYJ393
ERJ3GEYJ562	ERJ3GEYJ562
ERJ3GEYJ912V	ERJ3GEYJ912
ERJ3RBD102V	ERJ3RBD102
ERJ3RBD103	ERJ3RBD103
ERJ3RBD562	ERJ3RBD562
ERJ6GEYG750	ERJ6GEYG750
EXCELSA24B	EXCELSA24B
F1H0J1050018	FILTER
J0JHC0000032	FILTER
LH8TB100K	FILTER
19396-2_5A	FUSE
B1ZAZ0000030	FUSE
K5H1R5100001	FUSE
SB125V-3_15	FUSE
VDG1536	GEAR
VDG1537	GEAR
VDG1538	GEAR
RGQ0327-Q	GUIDE
RMA1674	HOLDER
RMR1526-H	HOLDER
RMX0244	HOLDER
VMD4594	HOLDER
VMD4597	HOLDER
VMD4812	HOLDER
74LCX16244MT	IC
AN1431T	IC
AN8716FH	IC
AN8719FH	IC
AN8727FH	IC
C0ABBA000121	IC
NJM2115VTE1	IC
C0ABBB000118	IC
C0CBAYG00008	IC
C0CBCAC00009	IC
C0CBCBD00040	IC
C0DBCBD00001	IC
C0DBEFG00002	IC
C0DBZFE00003	IC
C0DBZGG00010	IC
C0DBZHE00014	IC
C0DBZHG00012	IC
C0DBZJG00006	IC
C0EBF0000182	IC
C0EBH0000263	IC
C0EBJ0000143	IC
C0FBAK000008	IC
C0FBBK000035	IC
C0GBG0000013	IC
C0GBN0000005	IC
C0JBAB000474	IC
C0JBAD000107	IC
C0JBAF000206	IC
C0JBAM000109	IC
NJM79M15F	IC
C0JBAR000438	IC
C0JBAR000332	IC
C0JBAS000166	IC
C0JBAZ001770	IC
C0ZBZ0000732	IC
C1DB00000895	IC
C1ZBZ0002255	IC
C1ZBZ0002277	IC
C2BBFE000137	IC
C2BBGF000419	IC
MT16V16SAT7S	IC
C3ABPG000063	IC
C3ABQG000007	IC
C3ABRG000016	IC
C3CBKD000119	IC
C3FBKD000139	IC
C3FBQC000011	IC
C9ZB00000377	IC
CD152M	IC
FA13844N	IC
MN102H460B	IC
MN85572R	IC
MN85620GL	IC
MNZE0500YDR	IC
NJM431U	IC
RFKFE30DR	IC
TC7S66FUTL	IC
C0EBE0000130	IC
C3ABPJ000048	IC
C3EBFC000030	IC
MN673744R	IC
RFKFE80HP	IC
C0BBBB000024	IC
C1AB00001735	IC
MN6775511S	IC
RQT6984-P	INSTRUCT BOOK
K1U413A00005	JACK
K1U820B00002	JACK
K1U822B00001	JACK
K1U407B00003	JACK
B3ABA0000396	LED
LNJ201LPQJA	LED
RKA0143-K	LEG
VMD4592	LEVER
VMD4604	LEVER
VMD4605	LEVER
CR-2032_1GUF	LITHIUM BATTERY
L6KACANH0001	MOTOR
L6FALCCE0008	MOTOR
VMD4595	OPENER
CALL_800-833-9626	OPTICAL ASSY
RGK1622-K	ORNAMENT
RGK1623A-K	ORNAMENT
RGK1625A-S	ORNAMENT
RGK1651-S	ORNAMENT
EFJC1695F5B	OSCILLATOR
H0A327200082	OSCILLATOR
H0D419400020	OSCILLATOR
H0D800400016	OSCILLATOR
H0J540500006	OSCILLATOR
H2D330500001	OSCILLATOR
DMRE80HS_EX	OTC VIDEO (DISCONTINUED)
RPF0375	PACKAGING (DISCONTINUED)
RPG6574	PACKAGING (DISCONTINUED)
RPN1624A	PACKAGING (DISCONTINUED)
RPN1624B	PACKAGING (DISCONTINUED)
RPQ1450	PACKAGING (DISCONTINUED)
RPQ1594	PAD
RGR0337J-B	PANEL
RYP1197A-S	PANEL
REP3467A	PC BOARD
REP3496F	PC BOARD
REP3528DB	PC BOARD
REP3528EA	PC BOARD
ETXMM447A4GR	PC BOARD
REP3497MR	PC BOARD
VMD4603	PIECE
VMD4609	PIECE
RMC0549	PLATE
K9ZZ00001279	PLATE
VMA0N16	PLATE
VMA0N17	PLATE
VMA0Q12	PLATE
VMA0R30	PLATE
VMD4602	PLATE
VMD4607	PLATE
ERDS1FJ223	PQRQ25AJ223
YEAMZAL0001	PQVINJM2904F
ICPN15	PROTECTOR
JEE0176A	PULLEY
RD5_6EB	RD5.6E
CR100R00	RESISTOR
ERJ6ENF1001	RESISTOR
CR10F1002	RESISTOR
CR10F1502	RESISTOR
CR10F2210	RESISTOR
CR10F2211	RESISTOR
CR10F2321	RESISTOR
CR10F3320	RESISTOR
CR10F3321	RESISTOR
CR10F4642	RESISTOR
CR10F4752	RESISTOR
CR10F6191	RESISTOR
CR10F6981	RESISTOR
CR10J100	RESISTOR
CR10J101	RESISTOR
CR10J102	RESISTOR
CR10J103	RESISTOR
CR10J104	RESISTOR
CR10J221	RESISTOR
CR10J222	RESISTOR
CR10J223	RESISTOR
CR10J272	RESISTOR
CR10J333	RESISTOR
CR10J471	RESISTOR
CR10J472	RESISTOR
CR10J473	RESISTOR
CR10J561	RESISTOR
CR10J682	RESISTOR
CR10J683	RESISTOR
CR10J6R8	RESISTOR
CR10J752	RESISTOR
CR10J822	RESISTOR
CR10JR16	RESISTOR
CR12JR33	RESISTOR
D0HB153ZA002	RESISTOR
D0HB752ZA002	RESISTOR
D1H81034A024	RESISTOR
D1H82204A024	RESISTOR
D1H82224A024	RESISTOR
D1H83304A024	RESISTOR
D1H83324A024	RESISTOR
D1H83334A024	RESISTOR
D1H84724A024	RESISTOR
D1H88204A024	RESISTOR
ER0S2TKF1430	RESISTOR
ER0S2TKF4420	RESISTOR
VRE0071E332	RESISTOR
ERDS1FJ105	RESISTOR
ERDS1FJ271	RESISTOR
ERDS1FJ821	RESISTOR
ERD25FJ221K	RESISTOR
ERD25FJ330S	RESISTOR
ERD25FJ3R9	RESISTOR
ERG1SJ330P	RESISTOR
ERG2ANJ471H	RESISTOR
ERJ12YJ100U	RESISTOR
ERJ12YJ513	RESISTOR
ERJ3EKF1800	RESISTOR
ERJ3EKF3600	RESISTOR
ERJ3GEYJR00V	RESISTOR
ERJ3GEYF821	RESISTOR
ERJ3GEYJ101	RESISTOR
ERJ3GEYJ103V	RESISTOR
ERJ3GEYJ104V	RESISTOR
ERJ3GEYJ105	RESISTOR
ERJ3GEYJ123V	RESISTOR
ERJ3GEYJ151V	RESISTOR
ERJ3GEYG152	RESISTOR
ERJ3GEYJ183V	RESISTOR
ERJ3GEYJ184V	RESISTOR
ERJ3GEYJ220	RESISTOR
ERJ3GEYJ222	RESISTOR
ERJ3GEYJ223V	RESISTOR
ERJ3GEYJ224V	RESISTOR
ERJ3GEYJ273	RESISTOR
ERJ3GEYJ330	RESISTOR
ERJ3GEYJ331	RESISTOR
ERJ3GEYJ332V	RESISTOR
ERJ3GEYJ390V	RESISTOR
ERJ3GEYJ391V	RESISTOR
ERJ3GEYJ470V	RESISTOR
ERJ3GEYJ472V	RESISTOR
ERJ3GEYJ563V	RESISTOR
ERJ3GEYJ622V	RESISTOR
ERJ3GEYJ680V	RESISTOR
ERJ3GEYJ681	RESISTOR
ERJ3GEYJ683	RESISTOR
ERJ3GEJ750V	RESISTOR
ERJ3GEYJ820V	RESISTOR
ERJ3GEYJ821V	RESISTOR
ERJ3GEYJ822V	RESISTOR
ERJ3GEYJ823V	RESISTOR
ERJ3RBD122V	RESISTOR
ERJ3RBD133V	RESISTOR
ERJ3RBD152	RESISTOR
ERJ3RBD203	RESISTOR
ERJ3RBD182V	RESISTOR
ERJ3RBD221	RESISTOR
ERJ3RBD222V	RESISTOR
ERJ3RBD223	RESISTOR
ERJ3RBD273V	RESISTOR
ERJ3RBD682	RESISTOR
ERJ3RBD822	RESISTOR
ERJ3RED360V	RESISTOR
ERJ3RED750	RESISTOR
ERJ6ENF1622	RESISTOR
ERJ6ENF5231	RESISTOR
ERJ6GEYJ271	RESISTOR
ERJ8GEYJR39V	RESISTOR
ERJ8RQJR27	RESISTOR
JAR0816P103D	RESISTOR
ERJ3GEYJ561V	RESISTOR
UNR511100L	RESISTOR
D1H84704A024	RESISTOR
ERJ8GCJ271	RESISTOR
ERG1SJ121P	RESISTOR
ERJ3GEYJ153V	RESISTOR
ERJ3RBD332	RESISTOR
ERJ6GEYJ821	RESISTOR
ERJ6GEYJ101V	RESISTOR
ERJ3GEYJ122	RN4B2AY122J
VMD4596	ROLLER
RKA0144-K	RUBBER
RHD30106	SCREW
SNE2129-4	SCREW
VHD1571	SCREW
XQNQC17	SCREW
XSN3_4FZ-C	SCREW
XTBS26_8J	SCREW
XTN2_6GFJ	SCREW
XTN26_4F	SCREW
XTS26_7J	SCREW
XTW3_6M	SCREW
XYA26_JG8	SCREW
VHD0690	SCREW
RHD26046-J	SCREW
XTV26_8G	SCREW (1/10)
XYN17_J85	SCREW (10)
XTN3_23JFZ	SCREW (20/10)
XTN3_7F-C	SCREW (20/10)
PNA4618M13VT	SENSOR
VMS6724	SHAFT
VMS7116	SHAFT
RGQ0324-K	SHEET
RMX0253	SHEET
RMZ0693	SHEET
RMZ0700	SHEET
RQCA1004	SHEET
RQCA1119	SHEET
RQCC2431	SHEET
RXQ1073-1	SHEET
VMZ3260	SHEET
VMZ3368	SHEET
RMC0539	SPRING
VHD1518	SPRING
VMB3211	SPRING
VMB3611	SPRING
VMB3612	SPRING
VMB3613	SPRING
VMB3614	SPRING
VMB3620	SPRING
VMC1569	SPRING
RMB0871-1	SPRING
ESE22MH22	SWITCH
ESE22MH27T	SWITCH
ESE22MH28T	SWITCH
ESE24MH6T	SWITCH
K0H1BA000372	SWITCH
UN2111T	T-R COMBINATION
VGQ5954	TAPE
RFKZ0125	TEST TOOL
NC21F104J	THERMISTER
ETB28BF1N6AD	TRANSFORMER
ETS13TB119AP	TRANSFORMER
2SA153200L	TRANSISTOR
2SB1218A	TRANSISTOR
MSB709RT1	TRANSISTOR
2SB766-RS	TRANSISTOR
2SC393000L	TRANSISTOR
B1ABCC000004	TRANSISTOR
2SD0874A0L	TRANSISTOR
2SD1328QRS	TRANSISTOR
2SD1819AWL	TRANSISTOR
2SD1994B	TRANSISTOR
2SD965Q	TRANSISTOR
2SK2543	TRANSISTOR
2SK3366	TRANSISTOR
UPA1717G	TRANSISTOR
B1HFGDA00001	TRANSISTOR
D4FAR4000001	TRANSISTOR
UNR221300L	TRANSISTOR
UN2214	TRANSISTOR
DTC143EK	TRANSISTOR
UN5212TX	TRANSISTOR
UNR521L00L	TRANSISTOR
UPA1720G	TRANSISTOR
2SD1328STTW	TRANSISTOR
2SD601-RS	TRANSISTOR
VMD4813	TRAY
A2BD00000070	TUBE
ENGD6201D	TUNER
VXY1791-C	UNIT
ERZVA7D471	VARISTOR
VLQS0166	VLQS0167
RKW0724-S	WINDOW
