Model Image
Manufacturer

Panasonic

Model Number

DMWFL500

Description

External Flash

Interactive Exploded View

Parts List

Part Number Description
ZR-6XA_2B ZR-6XA_2B BATTERY
SS013-63 SS013-63 BOARD
SS095-67FKIT SS095-67FKIT BODY
SS095-68FKIT SS095-68FKIT BODY
SS095-70F SS095-70F BODY
SS095-71F SS095-71F BODY
SS992-28F SS992-28F BODY
ECJ1VB1E473K ECJ1VB1E473K CAP
YFUGAC221BJ YFUGAC221BJ CAPACITOR
ECA1VM101 ECA1VM101 CAPACITOR
ECJ0EB1A104K ECJ0EB1A104K CAPACITOR
ECJ0EB1A473K ECJ0EB1A473K CAPACITOR
ECJ0EB1C103K ECJ0EB1C103K CAPACITOR
ECJ0EB1E472K ECJ0EB1E472K CAPACITOR
ECJ0EB1H101K ECJ0EB1H101K CAPACITOR
ECJ0EB1H222K ECJ0EB1H222K CAPACITOR
ECJ0EB1H332K ECJ0EB1H332K CAPACITOR
F1H1C105A118 F1H1C105A118 CAPACITOR
ECJ1XB1C104K ECJ1XB1C104K CAPACITOR
ECJ2FB0J106M ECJ2FB0J106M CAPACITOR
ECJ2FB1C334K ECJ2FB1C334K CAPACITOR
EMK316BJ475K EMK316BJ475K CAPACITOR
F1G1H102A401 F1G1H102A401 CAPACITOR
HE40SJYB221K HE40SJYB221K CAPACITOR
SC002-73F SC002-73F CAPACITOR
SC102-60F SC102-60F CAPACITOR
SC102-61F SC102-61F CAPACITOR
SC202-05 SC202-05 CAPACITOR
SS307-39F SS307-39F CAPACITOR
SS505-98F SS505-98F CAPACITOR
VC40R2E473K VC40R2E473K CAPACITOR
SS095-69F SS095-69F CASE
SS200-89F SS200-89F CASE
SS991-52F SS991-52F CASE
SS992-24F SS992-24F CASE
VFC4216 VFC4216 CASE
N05DB680K N05DB680K COIL
PI22A02M PI22A02M CONNECTOR
PI22A03M PI22A03M CONNECTOR
PI22J05M PI22J05M CONNECTOR
PI28A02M PI28A02M CONNECTOR
PI28A03M-RE PI28A03M-RE CONNECTOR
PI28A04M PI28A04M CONNECTOR
PI28A04MRE PI28A04MRE CONNECTOR
PI28A05M PI28A05M CONNECTOR
PI28A06M PI28A06M CONNECTOR
PI28E05M PI28E05M CONNECTOR
PI28K03M PI28K03M CONNECTOR
PI25C03M-1 PI25C03M-1 CONNECTOR
SS707-14F SS707-14F CONNECTOR
SS707-15F SS707-15F CONNECTOR
SS990-47F SS990-47F CONNECTOR
SS040-26F SS040-26F COVER
SS043-35 SS043-35 CUSHION
SS043-36 SS043-36 CUSHION
B0ECKR000017 B0ECKR000017 DIODE
CRG02 CRG02 DIODE
MAZS0620ML MAZS0620ML DIODE
MA132WA MA132WA DIODE
MA2S11100L MA2S11100L DIODE
RB161M-20FTR RB161M-20FTR DIODE
RSX501L RSX501L DIODE
SC105-25F SC105-25F DIODE
SC105-67F SC105-67F DIODE
SC105-68F SC105-68F DIODE
SC125-26F SC125-26F DIODE
SC125-27F SC125-27F DIODE
SC125-28F SC125-28F DIODE
SM-1XF20 SM-1XF20 DIODE
MA132WK MA132WK DIODE
ERJ6GEYJ470 ERJ6GEYJ470 ERJ6GEYG470
ERJ6GEYJ331V ERJ6GEYJ331V ERJ6GEYJ331
SC014-18F SC014-18F FUSE
U2JL U2JL FUSE
BU4066BCFV BU4066BCFV IC
C0CBADE00031 C0CBADE00031 IC
C0FBBD000187 C0FBBD000187 IC
EF0SS8004E5 EF0SS8004E5 IC
RN5RL40AA RN5RL40AA IC
R3111Q361A R3111Q361A IC
SS208-13F SS208-13F IC
SS535-10F SS535-10F IC
SS535-11F SS535-11F IC
SS535-12F SS535-12F IC
SS535-13F SS535-13F IC
SS535-14F SS535-14F IC
TA75S01F TA75S01F IC
UPD7225GB UPD7225GB IC
C0BBAA000038 C0BBAA000038 IC (DISCONTINUED)
BL-F14 BL-F14 INDUCTOR
VQT0Z61 VQT0Z61 INSTRUCT BOOK
SS046-04F SS046-04F KNOB
SS046-06F SS046-06F KNOB
SS178-47 SS178-47 KNOB
SS178-48 SS178-48 KNOB
SE5217BGXYF SE5217BGXYF LED
SML-512MW SML-512MW LED
SML-512WW SML-512WW LED
SS060-24 SS060-24 LENS
SS020-20 SS020-20 LEVEL
SS046-05F SS046-05F LEVER
SS037-86F SS037-86F LID
SS992-25F SS992-25F LIGHT
SS992-26F SS992-26F LIGHT
SS184-07 SS184-07 LOCK
ERJ8GEYJ155 ERJ8GEYJ155 METAL GLAZE RES
SS114-28 SS114-28 MOLD
SS991-53 SS991-53 MOLD
SS992-21F SS992-21F MOLD
SS121-23 SS121-23 NUT
SS150-03 SS150-03 NUT
VPK3206 VPK3206 PACKAGING
VPN6468 VPN6468 PACKAGING
SS060-40 SS060-40 PANEL
SS991-50 SS991-50 PANEL
SS992-20 SS992-20 PANEL
SS307-38 SS307-38 PC BOARD
SS307-40 SS307-40 PC BOARD
SS307-65F SS307-65F PC BOARD
SS413-79FKIT SS413-79FKIT PC BOARD
SS221-83 SS221-83 PIN
SS226-04 SS226-04 PIN
SS022-19F SS022-19F PLATE
ERJ2GED563X ERJ2GED563X RESISTOR
ERJ2GEJ102X ERJ2GEJ102X RESISTOR
ERJ2GEJ103X ERJ2GEJ103X RESISTOR
ERJ2GEJ104 ERJ2GEJ104 RESISTOR
ERJ2GEJ153 ERJ2GEJ153 RESISTOR
ECEA0JKS220I ECEA0JKS220I RESISTOR
ECEA0JKA221 ECEA0JKA221 RESISTOR
ERJ2GEJ220 ERJ2GEJ220 RESISTOR
ERJ2GEJ222X ERJ2GEJ222X RESISTOR
ERJ2GEJ224 ERJ2GEJ224 RESISTOR
ERJ2GEJ331 ERJ2GEJ331 RESISTOR
ERJ2GEJ335 ERJ2GEJ335 RESISTOR
ERJ2GEJ362 ERJ2GEJ362 RESISTOR
ERJ2GEJ363X ERJ2GEJ363X RESISTOR
ERJ2GEJ393 ERJ2GEJ393 RESISTOR
ERJ2GEJ471 ERJ2GEJ471 RESISTOR
ERJ2GEJ473 ERJ2GEJ473 RESISTOR
ERJ2GEJ822 ERJ2GEJ822 RESISTOR
ERJ2RKD1002V ERJ2RKD1002V RESISTOR
ERJ2RKD1624V ERJ2RKD1624V RESISTOR
ERJ2RKD1652V ERJ2RKD1652V RESISTOR
ERJ2RKD2003V ERJ2RKD2003V RESISTOR
ERJ2RKD2432V ERJ2RKD2432V RESISTOR
ERJ2GEJ330X ERJ2GEJ330X RESISTOR
ERJ2RKD394 ERJ2RKD394 RESISTOR
ERJ2RKD4023V ERJ2RKD4023V RESISTOR
ERJ2RKD5622V ERJ2RKD5622V RESISTOR
ERJ2RKD8063V ERJ2RKD8063V RESISTOR
ERJ6GEYG222 ERJ6GEYG222 RESISTOR
ERJ8GEYJ100 ERJ8GEYJ100 RESISTOR
ERJ8GEYJ5R1 ERJ8GEYJ5R1 RESISTOR
EVM2WSW80B24 EVM2WSW80B24 RESISTOR
SC013-87F SC013-87F RESISTOR
SC033-19 SC033-19 RESISTOR
SC033-20 SC033-20 RESISTOR
SC033-21 SC033-21 RESISTOR
SC208-98F SC208-98F RESISTOR
SC208-99F SC208-99F RESISTOR
SC209-01F SC209-01F RESISTOR
SC209-02F SC209-02F RESISTOR
SC209-03F SC209-03F RESISTOR
ERJ2GEJ363 ERJ2GEJ363 RESISTOR
SG001-42F SG001-42F SCREW
SG012-17F SG012-17F SCREW
SG012-56F SG012-56F SCREW
SG022-81F SG022-81F SCREW
SG022-83F SG022-83F SCREW
SG024-37F SG024-37F SCREW
SG052-35 SG052-35 SCREW
SG052-61F SG052-61F SCREW
SG053-84F SG053-84F SCREW
SG053-85F SG053-85F SCREW
SG054-08F SG054-08F SCREW
SS806-78F SS806-78F SEAL
SS013-65F SS013-65F SHAFT
SS992-19F SS992-19F SHAFT
SS802-62 SS802-62 SHEET
SS802-85F SS802-85F SHEET
SS802-86F SS802-86F SHEET
SS802-87F SS802-87F SHEET
SS802-88F SS802-88F SHEET
SS804-27 SS804-27 SHEET
SS114-29 SS114-29 SPRING
SS164-35 SS164-35 SPRING
SS164-81 SS164-81 SPRING
SS164-82 SS164-82 SPRING
SS164-91 SS164-91 SPRING
SS164-99 SS164-99 SPRING
SS178-49 SS178-49 SPRING
SS184-06 SS184-06 STOPPER
SS043-33 SS043-33 SWITCH
SS228-45 SS228-45 TABLET
SG901-49 SG901-49 TAPE
SG901-84F SG901-84F TAPE
SS163-70 SS163-70 TERMINAL
SS163-71 SS163-71 TERMINAL
RFKZ0410 RFKZ0410 TEST TOOL
RFKZ0411 RFKZ0411 TEST TOOL
VFK1772 VFK1772 TEST TOOL
VFK1880 VFK1880 TEST TOOL
CR05AS CR05AS THYRISTOR
F06EL F06EL TRANSFORMER
F1624 F1624 TRANSFORMER
B1ADCF000020 B1ADCF000020 TRANSISTOR
DTA114Y DTA114Y TRANSISTOR
DTB113ZK DTB113ZK TRANSISTOR
DTB143EK DTB143EK TRANSISTOR
DTD113ZK DTD113ZK TRANSISTOR
MCH3406 MCH3406 TRANSISTOR
PN126S PN126S TRANSISTOR
UNR9214J0L UNR9214J0L TRANSISTOR
UNR9219J UNR9219J TRANSISTOR
2SA1759 2SA1759 TRANSISTOR
2SB1148-T 2SB1148-T TRANSISTOR
2SB1219A-S 2SB1219A-S TRANSISTOR
2SB1462JHL 2SB1462JHL TRANSISTOR
2SC4505 2SC4505 TRANSISTOR
2SC4617-R 2SC4617-R TRANSISTOR
2SD2098T100S 2SD2098T100S TRANSISTOR
2SD2321-Q 2SD2321-Q TRANSISTOR
2SK1590 2SK1590 TRANSISTOR
SS992-29F SS992-29F TUBE
SS706-57F SS706-57F WIRE
SS707-13F SS707-13F WIRE
