Model Image
Manufacturer

Panasonic

Model Number

KVS1045C

Description

Scanner

Interactive Exploded View

Parts List

Part Number Description
PJSWC0004W PJSWC0004W AC ADAPTER
PJSWC0004X PJSWC0004X AC ADAPTER (EXCEPT FOR KV-S1045C-U)
PJWE0B410U PJWE0B410U AC ADAPTER(ONLY FOR KV-S1045C-U)
PJPCC0011Z PJPCC0011Z ACCESSORY BOX
PJJTC0034Z PJJTC0034Z ADF FG CABLE
PJUKC0099Z PJUKC0099Z ARM GUIDE
EXBV8V470JV EXBV8V470JV ARRAY
EXBV8V220JV EXBV8V220JV ARRAY
MNR14E0AJ103 MNR14E0AJ103 ARRAY
EXBV8V101JV EXBV8V101JV ARRAY
SG-110 SG-110 BAND
PJUJC0031Z PJUJC0031Z BASE PLATE
PJDJ06061CZ PJDJ06061CZ BEARING
B-F6-1389 B-F6-1389 BEARING 2
PJMCC0081Z PJMCC0081Z BOTTOM COVER
K2CA2DA00036 K2CA2DA00036 CABLE
F2G1E1010017 F2G1E1010017 CAPACITOR
F2G1C4700026 F2G1C4700026 CAPACITOR
F2G1C1010014 F2G1C1010014 CAPACITOR
F2G1C1000014 F2G1C1000014 CAPACITOR
F2G1A2210014 F2G1A2210014 CAPACITOR
F1J1A106A024 F1J1A106A024 CAPACITOR
EEEFC1V101P EEEFC1V101P CAPACITOR
ECUX1H102KBV ECUX1H102KBV CAPACITOR
ECUX1H150JCV ECUX1H150JCV CAPACITOR
ECJ1VF1E104Z ECJ1VF1E104Z CAPACITOR
ECJ1VC1H820J ECJ1VC1H820J CAPACITOR
ECJ1VC1H470J ECJ1VC1H470J CAPACITOR
ECJ1VC1H390J ECJ1VC1H390J CAPACITOR
ECJ1VC1H270J ECJ1VC1H270J CAPACITOR
ECJ1XC1H220J ECJ1XC1H220J CAPACITOR
ECJ1XC1H101J ECJ1XC1H101J CAPACITOR
ECJ1VC1H100C ECJ1VC1H100C CAPACITOR
ECJ1VB1H561K ECJ1VB1H561K CAPACITOR
ECJ1VB1H103K ECJ1VB1H103K CAPACITOR
F1H1E105A153 F1H1E105A153 CAPACITOR
PJJRC3455Z PJJRC3455Z CCD(F) CABLE
PJJXC0592W PJJXC0592W CD ROM
PJJXC0203K PJJXC0203K CD ROM
PNJX1038X PNJX1038X CD-ROM
PJJXC0592X PJJXC0592X CD-ROM
PNJX1024Z PNJX1024Z CD-ROM (EXCEPT FOR CHINA)
PJJXC0560Y PJJXC0560Y CD-ROM (ONLY FOR CHINA)
HC-6B HC-6B CLAMP
LAMS-05 LAMS-05 CLAMPER
J0JCC0000059 J0JCC0000059 COIL
J0JCC0000042 J0JCC0000042 COIL
G1C471KA0131 G1C471KA0131 COIL
G1A680H00002 G1A680H00002 COIL
PJDEB0024Z PJDEB0024Z COLLAR
K1KA22AA0202 K1KA22AA0202 CONNECTOR
K1KA16AA0202 K1KA16AA0202 CONNECTOR
K1KA07AA0618 K1KA07AA0618 CONNECTOR
K1KA07AA0193 K1KA07AA0193 CONNECTOR
K1KA06BA0061 K1KA06BA0061 CONNECTOR
K1KA06A00452 K1KA06A00452 CONNECTOR
K1KA05AA0193 K1KA05AA0193 CONNECTOR
K1KA04BA0061 K1KA04BA0061 CONNECTOR
K1KA03BA0285 K1KA03BA0285 CONNECTOR
K1KA03BA0150 K1KA03BA0150 CONNECTOR
K1KA03BA0148 K1KA03BA0148 CONNECTOR
K1KA02BA0061 K1KA02BA0061 CONNECTOR
K1KA02AA0193 K1KA02AA0193 CONNECTOR
K1FA104B0028 K1FA104B0028 CONNECTOR
CALL_800-334-4881 CALL_800-334-4881 CONTROL BOARD
PJDVC0101Z PJDVC0101Z CONVEYOR BELT
PJZC0B410M PJZC0B410M CONVEYOR CHASSIS LOWER
PJUAC0299Z PJUAC0299Z CONVEYOR CHASSIS UPPER
PJDAC0011Z PJDAC0011Z CONVEYOR DRIVE PULLEY
PJDRC0108X PJDRC0108X CONVEYOR ROLLER
PJBVC0139Z PJBVC0139Z CONVEYOR ROLLER ASSIST SPRING
PNDJ1080Z PNDJ1080Z CONVEYOR ROLLER BEARING
PJBVC0138Z PJBVC0138Z CONVEYOR ROLLER SPRING
PLT-1M PLT-1M CORD CLAMP
J0KF00000018 J0KF00000018 CORE
B3NAA0000097 B3NAA0000097 COUPLER
PJPFC0047Z PJPFC0047Z COVER 1
PJPNC0271Z PJPNC0271Z CUSHION (L) EXCEPT FOR KV-S1045C-K
PJYE0B411K PJYE0B411K CUSHION (L) ONLY FOR KV-S1045C-K
PJPNC0270Z PJPNC0270Z CUSHION (R) (EXCEPT FOR KV-S1045C-K)
PJYE0B410K PJYE0B410K CUSHION (R) (ONLY FOR KV-S1045C-K)
PJDAC0012Z PJDAC0012Z DECELERATION PULLEY
PJMCC0162Z PJMCC0162Z DF PLATE LOWER
PJMCC0161Z PJMCC0161Z DF PLATE UPPER
PJURC0085Z PJURC0085Z DFP ROLLER COVER
MA132A MA132A DIODE
LN28RPXTA3 LN28RPXTA3 DIODE
B0JCPG000015 B0JCPG000015 DIODE
B0JCME000041 B0JCME000041 DIODE
B0BC6R2A0035 B0BC6R2A0035 DIODE
B0BC6R100024 B0BC6R100024 DIODE
B0BC3R9A0027 B0BC3R9A0027 DIODE
B0BC017A0028 B0BC017A0028 DIODE
B0BC01200027 B0BC01200027 DIODE
B0ACCK000005 B0ACCK000005 DIODE
PJMEC0066Z PJMEC0066Z DISCHARGE BRUSH
PJHRC0501Y PJHRC0501Y DOCUMENT GUIDE (L)
PJHRC0500Y PJHRC0500Y DOCUMENT GUIDE (R)
PJGFC2624Z PJGFC2624Z DOCUMENT LABEL (L)
PJGFC2623Z PJGFC2623Z DOCUMENT LABEL (R)
PJWP0B415M PJWP0B415M DOOR DETECTION BOARD
PJBCC0039Z-1 PJBCC0039Z-1 DOOR OPEN BUTTON
PJHRC0293Z PJHRC0293Z DOOR OPEN HOOK
PJBVC0142Z PJBVC0142Z DOOR OPEN SPRING
PJWP0B413M PJWP0B413M DOUBLE FEED (G) BOARD
PJJRC3461Z PJJRC3461Z DOUBLE FEED (G) CABLE
PJWP0B411M PJWP0B411M DOUBLE FEED (R) BOARD
PJJRC3460Z PJJRC3460Z DOUBLE FEED (R) CABLE
PJZC0B410M1 PJZC0B410M1 DOUBLE-FEED PREVENTION ROLLER
PJDVC0100Z PJDVC0100Z DRIVE BELT
PJHRC0308Z PJHRC0308Z DUST RESISTANT SHEET
PJMZC0005Z PJMZC0005Z DUST RESISTANT SHEET
PJHEC0239Z PJHEC0239Z DUST SHEET 1
PJHEC0240Z PJHEC0240Z DUST SHEET 2
PJMEC0064Z PJMEC0064Z EARTH PLATE
PJMEC0065Z PJMEC0065Z EARTH PLATE
RMA02M705-08 RMA02M705-08 ECO SOLDER
EDS-0607M EDS-0607M EDGE SADDLE
EDS-1208UV0 EDS-1208UV0 EDGE SADDLE
J0KF00000015 J0KF00000015 EMI FILTER
PJDRC0111Z PJDRC0111Z EXHAUST ROLLER
PJKNC0043Z PJKNC0043Z EXIT EXTENSION TRAY
PJDRC0112X PJDRC0112X EXIT ROLLER
PJBVC0140Z PJBVC0140Z EXIT ROLLER SPRING
PJKPC0096Z PJKPC0096Z EXIT STOPPER
PJKNC0042Z PJKNC0042Z EXIT TRAY
PJDRC0168Z PJDRC0168Z FEED ASSIST ROLLER
PJDGC0176Z PJDGC0176Z FEED DRIVE GEAR
PJHRC0298Y PJHRC0298Y FEED GUIDE SHEET
PJURC0084Z PJURC0084Z FEED ROLLER COVER
PJDGC0175Z PJDGC0175Z FEED ROLLER DRIVE GEAR
PJDFC0192Z PJDFC0192Z FEED ROLLER DRIVE SHAFT
PJKNC0018Z-1 PJKNC0018Z-1 FEED TRAY
PJKNC0019Z-1 PJKNC0019Z-1 FEED TRAY EXTENSION
PJKUC0003Z-1 PJKUC0003Z-1 FRONT COVER
K5H402A00010 K5H402A00010 FUSE
PJUJC0029Y PJUJC0029Y GAP ADJUSTMENT CONVEYOR
PJHRC0361Y PJHRC0361Y HOLDER
PJWII0B410M PJWII0B410M IC
C3EBEG000079 C3EBEG000079 IC
C3ABPG000145 C3ABPG000145 IC
C2CBYK000001 C2CBYK000001 IC
C1DB00001183 C1DB00001183 IC
C1CB00002333 C1CB00002333 IC
C0ZBZ0001718 C0ZBZ0001718 IC
C0JBAZ001411 C0JBAZ001411 IC
C0JBAA000393 C0JBAA000393 IC
C0GAY0000010 C0GAY0000010 IC
C0EBE0000338 C0EBE0000338 IC
C0DBGYY00056 C0DBGYY00056 IC
C0DBGYY00055 C0DBGYY00055 IC
C0DBAYY00573 C0DBAYY00573 IC
C0ABEB000111 C0ABEB000111 IC
C0ABBA000138 C0ABBA000138 IC
PJDGC0177Z PJDGC0177Z IDLE GEAR
PJDKC0002Z PJDKC0002Z IDLE PULLEY
J0JCC0000178 J0JCC0000178 INDUCTOR
PJQXC0282Z PJQXC0282Z INSTALLATION MANUAL (ONLY FOR CHINA)
PJQXC0281Z PJQXC0281Z INSTALLATION MANUAL (ONLY FOR KOREA)
PJQXC0283Z PJQXC0283Z INSTALLATION MANUAL FOR KV-S1045C-T
PJQXC0274Y PJQXC0274Y INSTALLATION MANUAL KV-S1045C/-A/-B/-J/-U
PJHEC0241Z PJHEC0241Z INVERTER SHEET
K2EE2B000003 K2EE2B000003 JACK
PJSIC0007Z PJSIC0007Z LAMP CABLE
N0ZZ00000024 N0ZZ00000024 LAMP DRIVE BOARD
PJUFC0002Z PJUFC0002Z LAMP HOLDER (B)
PJUFC0001Z PJUFC0001Z LAMP HOLDER (F)
LN38GPX LN38GPX LED
PJDFC0193Z PJDFC0193Z LOCK LEVER PLATE
PJBVC0137Z PJBVC0137Z LOCK LEVER SPRING
PJKNC0021Z-1 PJKNC0021Z-1 MIXED BATCH CARD
PJMMC0001Z PJMMC0001Z MOTOR BRACKET
PJDGC0178Z PJDGC0178Z ONE WAY GEAR
PJGDC0027Z PJGDC0027Z OPT UNIT COVER BL
PJGDC0028Z PJGDC0028Z OPT UNIT COVER BR
PJGDC0025Z PJGDC0025Z OPT UNIT COVER FL
PJGDC0026Z PJGDC0026Z OPT UNIT COVER FR
PJWU0B410M PJWU0B410M OPTICAL UNIT (B)
PJWU0B411M PJWU0B411M OPTICAL UNIT (F)
H1Z1246BA007 H1Z1246BA007 OSCILLATOR
H0J250500061 H0J250500061 OSCILLATOR
H0J240500020 H0J240500020 OSCILLATOR
PJYC0B410CN PJYC0B410CN OUTER CARTON FOR KV-S1045C-CN/-J
PJYC0B410N PJYC0B410N OUTER CARTON FOR KV-S1045C-N
PJPGC1140Z PJPGC1140Z OUTER CARTON FOR KV-S1045C/-A/-B/-K/-T/-U
PJGPC0137Z-1 PJGPC0137Z-1 PANEL
PJWP0B418M PJWP0B418M PANEL BOARD
PJJRC3458Z PJJRC3458Z PANEL_LAMP DRIVE (B) CABLE
PJZR0B411M PJZR0B411M PAPER FEED ROLLER
PJDGB0180Z PJDGB0180Z PAPER GUIDE GEAR
PJDGB0179Z PJDGB0179Z PAPER GUIDE RACK
PJBLC0032Z PJBLC0032Z PAPER SENSOR ARM
PJWP0B417M PJWP0B417M PAPER SENSOR BOARD
PJJRC3456Z PJJRC3456Z PAPER_DOOR DETECTOR_CCD(B) CABLE
PJBAC0059Z PJBAC0059Z PICK UP ACTUATOR
PJBVC0204Z PJBVC0204Z PICK UP SPRING
K2CJ2DA00011 K2CJ2DA00011 POWER CORD FOR KV-S1045C-A
K2CR2YY00013 K2CR2YY00013 POWER CORD FOR KV-S1045C-B
K2CA2DA00030 K2CA2DA00030 POWER CORD FOR KV-S1045C-CN
K2CR2CA00003 K2CR2CA00003 POWER CORD FOR KV-S1045C-K
K2CA2YY00026 K2CA2YY00026 POWER CORD FOR KV-S1045C-N
K2CA2CA00028 K2CA2CA00028 POWER CORD FOR KV-S1045C-T
K2CT3DA00004 K2CT3DA00004 POWER CORD FOR KV-S1045C-U
K2CA2YY00275 K2CA2YY00275 POWER CORD FOR KV-S1045C/-J
PJDRC0134Z PJDRC0134Z PRESSURE ROLLER
PJDYC0020Z PJDYC0020Z PRESSURE ROLLER SHAFT
PJDYC0017Z PJDYC0017Z PRESSURE ROLLER SHAFT
PJKUC0002Z-1 PJKUC0002Z-1 REAR COVER
PJGHC0001Z PJGHC0001Z REFLECTION SHEET
PJUCC0009Z PJUCC0009Z REINFORCEMENT PLATE
PJMCC0163Z PJMCC0163Z RELAY SHIELD PLATE 1
EXBV8V820JV EXBV8V820JV RESISTOR
ERJ8GEYJ392 ERJ8GEYJ392 RESISTOR
ERJ6ENF3161V ERJ6ENF3161V RESISTOR
ERJ6ENF1001 ERJ6ENF1001 RESISTOR
ERJ3GEYJ821 ERJ3GEYJ821 RESISTOR
ERJ3GEYJ682 ERJ3GEYJ682 RESISTOR
ERJ3GEYJ681V ERJ3GEYJ681V RESISTOR
ERJ3GEYJ562 ERJ3GEYJ562 RESISTOR
ERJ3GEYJ473V ERJ3GEYJ473V RESISTOR
ERJ3GEYJ472V ERJ3GEYJ472V RESISTOR
ERJ3GEYG471 ERJ3GEYG471 RESISTOR
ERJ3GEYJ470 ERJ3GEYJ470 RESISTOR
ERJ3GEYJ393 ERJ3GEYJ393 RESISTOR
ERJ3EKF3302V ERJ3EKF3302V RESISTOR
ERJ3GEYJ332V ERJ3GEYJ332V RESISTOR
ERJ3GEYJ330V ERJ3GEYJ330V RESISTOR
ERJ3GEYJ273V ERJ3GEYJ273V RESISTOR
ERJ3GEYJ272 ERJ3GEYJ272 RESISTOR
ERJ3RED270 ERJ3RED270 RESISTOR
ERJ3GEYJ222 ERJ3GEYJ222 RESISTOR
ERJ3GEYJ271 ERJ3GEYJ271 RESISTOR
ERJ3GEYJ220 ERJ3GEYJ220 RESISTOR
ERJ3GEYJ182V ERJ3GEYJ182V RESISTOR
ERJ3GEYG152 ERJ3GEYG152 RESISTOR
ERJ3GEYJ123V ERJ3GEYJ123V RESISTOR
ERJ3GEYJ121V ERJ3GEYJ121V RESISTOR
ERJ3GEYJ105V ERJ3GEYJ105V RESISTOR
ERJ3GEYJ104V ERJ3GEYJ104V RESISTOR
PQ4R10XJ103 PQ4R10XJ103 RESISTOR
D0GB102JA057 D0GB102JA057 RESISTOR
ERJ3GEYJ101 ERJ3GEYJ101 RESISTOR
ERJ3GEYJ100 ERJ3GEYJ100 RESISTOR
ERJ3GEY0R00 ERJ3GEY0R00 RESISTOR
ERJ3EKF6201V ERJ3EKF6201V RESISTOR
D0XGR68KA020 D0XGR68KA020 RESISTOR
PJDJC0086Z PJDJC0086Z RETARD BEARING
PJBVC0141Z PJBVC0141Z RETARD ROLLER SPRING
PBHSA0055Z PBHSA0055Z ROLLER CLEANING PAPER
PJHGC0054Z PJHGC0054Z RUBBER FOOT 4 ISO:PET
PJQXC0284Z PJQXC0284Z SAFETY GUIDE FOR KV-S1045C-B/-U
PJYK8531M PJYK8531M SCANNING GLASS
XTW3_6LFJ XTW3_6LFJ SCREW
XYN3_F6FJ-18PK XYN3_F6FJ-18PK SCREW
XYN3_F6FJ XYN3_F6FJ SCREW
XTW26_8PFJ XTW26_8PFJ SCREW
XSN3_6FJ XSN3_6FJ SCREW
XTW3_12LFJ XTW3_12LFJ SCREW
XTW3_10PFJ XTW3_10PFJ SCREW
XTW3_8LFJ XTW3_8LFJ SCREW
L2FA00000021 L2FA00000021 SENSOR
L2FA00000010 L2FA00000010 SENSOR
PJQXC0081Z-J PJQXC0081Z-J SHADING SHEET (10 PIECES)
PJKEC0039Z-1 PJKEC0039Z-1 SIDE COVER (L)
PJKEC0038Z-1 PJKEC0038Z-1 SIDE COVER (R)
PJMDC0055Y PJMDC0055Y SIDE PLATE ASSY FOR PRODUCT VERSION B
LH-5-6 LH-5-6 SPACER
PJNW4111Z PJNW4111Z SPACER
RWPS6-050 RWPS6-050 SPACER 1 ISO:PA6
PJNW313Z PJNW313Z SPACER 2
PJKLC0003Z PJKLC0003Z STAND
PJBCC0040Z PJBCC0040Z START STOP BUTTON
PJJRC3457Z PJJRC3457Z STARTING DETECTOR_LAMP DRIVE (F) CABLE
PJBLC0024Z PJBLC0024Z STARTING SENSOR ARM
PJBWC0053Z PJBWC0053Z STARTING SENSOR ARM SPRING
PJWP0B416M PJWP0B416M STARTING SENSOR BOARD
L6HBYYYC0001 L6HBYYYC0001 STEPPING MOTOR
PJDJC0087Z PJDJC0087Z SUPPORT BEARING
K0H1BA000401 K0H1BA000401 SWITCH
PJWS0B410M PJWS0B410M SWITCH
A3A-241 A3A-241 SWITCH FLANGE
A3A-200 A3A-200 SWITCH SPRING
T4E30725-2 T4E30725-2 TAPE
PJULC0051Z PJULC0051Z TENSION PLATE ASSY
PJBVC0165Z PJBVC0165Z TENSION SPRING FOR PRODUCT VERSION B
PBQX90095Z-J PBQX90095Z-J TEST CHART A4 (10 PIECES)
B2ABBP000011 B2ABBP000011 THYRISTOR
PJKFC0002X PJKFC0002X TOP COVER
UN2211 UN2211 TRANSISTOR
UNR211100L UNR211100L TRANSISTOR
DRA2114E0L DRA2114E0L TRANSISTOR
B1GBCFGH0001 B1GBCFGH0001 TRANSISTOR
B1DHGD000024 B1DHGD000024 TRANSISTOR
B1ADCF000001 B1ADCF000001 TRANSISTOR
B1ABCF000011 B1ABCF000011 TRANSISTOR
PNZT0B410M PNZT0B410M TRAY
PJKNC0020Z-1 PJKNC0020Z-1 TRAY COVER
PJWP0B414M PJWP0B414M ULTRASONIC SENSOR (G) BOARD
PJJRC3463Z PJJRC3463Z ULTRASONIC SENSOR (G) CABLE
PJWP0B412M PJWP0B412M ULTRASONIC SENSOR (R) BOARD
PJJRC3462Z PJJRC3462Z ULTRASONIC SENSOR (R) CABLE
K1HY04YY0003 K1HY04YY0003 USB CABLE 1
Main Menu x
