Model Image
Manufacturer

Panasonic

Model Number

KXTGE232B

Description

Dect 6.0 Expandable Cordless Phone W/large Keypad

Interactive Exploded View

Parts List

Part Number Description
PNLV226-0X PNLV226-0X AC ADAPTER
PNLV233-AZ PNLV233-AZ AC ADAPTER HARD
PNJT1177Z PNJT1177Z BATTERY TERMINA
PNJT1184Z PNJT1184Z BATTERY TERMINA
PNJT1185Z PNJT1185Z BATTERY TERMINA
PNKF1314Z2 PNKF1314Z2 CABINET
PNKF1315X2 PNKF1315X2 CABINET
PNKM1524Y2 PNKM1524Y2 CABINET
PNKM1527Z1 PNKM1527Z1 CABINET
PNYM1060Y2 PNYM1060Y2 CABINET
PQJA10075Z PQJA10075Z CABLE
ECJ1VB0G106M ECJ1VB0G106M CAPACITOR
ECUE0J105KBQ ECUE0J105KBQ CAPACITOR
ECUE1A104KBQ ECUE1A104KBQ CAPACITOR
ECUE1A333KBQ ECUE1A333KBQ CAPACITOR
ECUE1A823KBQ ECUE1A823KBQ CAPACITOR
ECUE1C103KBQ ECUE1C103KBQ CAPACITOR
ECUE1H100DCQ ECUE1H100DCQ CAPACITOR
ECUE1H101JCQ ECUE1H101JCQ CAPACITOR
ECUE1H102KBQ ECUE1H102KBQ CAPACITOR
ECUE1H120JCQ ECUE1H120JCQ CAPACITOR
ECJ0EB1H222K ECJ0EB1H222K CAPACITOR
ECUE1H680JCQ ECUE1H680JCQ CAPACITOR
ECUE1H821KBQ ECUE1H821KBQ CAPACITOR
ECUV0J225KBV ECUV0J225KBV CAPACITOR
ECUV1A225KBV ECUV1A225KBV CAPACITOR
ECJ1VB0J475K ECJ1VB0J475K CAPACITOR
ECUV1C105KBV ECUV1C105KBV CAPACITOR
ECUX1C223MB ECUX1C223MB CAPACITOR
ECUV1C393KBV ECUV1C393KBV CAPACITOR
ECU1H102KBV ECU1H102KBV CAPACITOR
ECUV1H103KBV ECUV1H103KBV CAPACITOR
F1G1H1R1A765 F1G1H1R1A765 CAPACITOR
F1G1H1R5A765 F1G1H1R5A765 CAPACITOR
F1G1H2R4A765 F1G1H2R4A765 CAPACITOR
F1K1E1060001 F1K1E1060001 CAPACITOR
F1K2H681A008 F1K2H681A008 CAPACITOR
F2A1A102B641 F2A1A102B641 CAPACITOR
F2G0J331A146 F2G0J331A146 CAPACITOR
F1H0J4750005 F1H0J4750005 CERAMIC CAPACITOR MULTI L
PNLC1050ZB PNLC1050ZB CHARGER
G1C2N7Z00009 G1C2N7Z00009 COIL
PNKE1311Z2 PNKE1311Z2 COVER
PNPD1827Z PNPD1827Z CUSHION
KX-TGTA61B KX-TGTA61B DIGITAL CORDLESS HANDSET
KX-TGMA44W KX-TGMA44W DIGITAL CORDLESS HANDSET
KX-TGMA44B KX-TGMA44B DIGITAL CORDLESS HANDSET
KX-TGLA40B KX-TGLA40B DIGITAL CORDLESS HANDSET
KX-TGFA30N KX-TGFA30N DIGITAL CORDLESS HANDSET
KX-TGEA40S KX-TGEA40S DIGITAL CORDLESS HANDSET
KX-TGEA40B KX-TGEA40B DIGITAL CORDLESS HANDSET
KX-TGDA66M KX-TGDA66M DIGITAL CORDLESS HANDSET
KX-TGDA63W KX-TGDA63W DIGITAL CORDLESS HANDSET
KX-TGDA51M KX-TGDA51M DIGITAL CORDLESS HANDSET
KX-TGDA50W1 KX-TGDA50W1 DIGITAL CORDLESS HANDSET
KX-TGA680S KX-TGA680S DIGITAL CORDLESS HANDSET
KX-TGA659T KX-TGA659T DIGITAL CORDLESS HANDSET
B0EDER000009 B0EDER000009 DIODE
B0BC4R3A0006 B0BC4R3A0006 DIODE
B0ECKM000008 B0ECKM000008 DIODE
B3ACB0000190 B3ACB0000190 DIODE
DY2J25000L DY2J25000L DIODE
L5DYBYY00043 L5DYBYY00043 DISPLAY
PNKK1094Z2 PNKK1094Z2 DOOR
KX-TGE232B KX-TGE232B EXPANDABLE DIGITAL PHONE WITH ANSWERING MACHINE 2 CORDLESS HANDSET
ERJ2GEJ472 ERJ2GEJ472 FIXED RESISTOR 4 7K 1 16W
PQHA10023Z PQHA10023Z FOOT
K5H252Y00002 K5H252Y00002 FUSE
K5H302Y00003 K5H302Y00003 FUSE
PNHR1919Z PNHR1919Z GUIDE
PNHR1920Z PNHR1920Z GUIDE
PNMH1308Z PNMH1308Z GUIDE
PNKE1312Z2 PNKE1312Z2 HANGER
B3CAT0000004 B3CAT0000004 IC
C0DBEYY00102 C0DBEYY00102 IC
C0DBZYY00357 C0DBZYY00357 IC
C1CB00004121 C1CB00004121 IC
C2HBCY000142 C2HBCY000142 IC
PNWI1TGE230H PNWI1TGE230H IC
PNWI2TGE230H PNWI2TGE230H IC
PNWI3TGE230H PNWI3TGE230H IC
PNWITGEA20R PNWITGEA20R IC
J0JDC0000045 J0JDC0000045 INDUCTOR
PNQT2006Z PNQT2006Z LABEL
PNQT2859Z PNQT2859Z LABEL
B3AAB0000347 B3AAB0000347 LED
B3AFB0000806 B3AFB0000806 LED
PNHR1922Z PNHR1922Z LED
PNMH1304Z PNMH1304Z METAL PARTS
ERJ2GEJ681 ERJ2GEJ681 MGF CH RES 680 1 32W
L0CBAY000053 L0CBAY000053 MICROPHONE
PNGT7990Z PNGT7990Z NAME PLATE
H0J103500037 H0J103500037 OSCILLATOR
H0J138500003 H0J138500003 OSCILLATOR
PNPK3770002Y PNPK3770002Y PACKAGING
PNGP1316Y2 PNGP1316Y2 PANEL
PNGP1317Y2 PNGP1317Y2 PANEL
PNWP1TGE230H PNWP1TGE230H PC BOARD
PNWP1TGEA20R PNWP1TGEA20R PC BOARD
PNWP2TGE230H PNWP2TGE230H PC BOARD
PNGT7989Z PNGT7989Z PLATE
PNGT7995Z PNGT7995Z PLATE
PNHR1921Z PNHR1921Z PLATE
PNBC1491X6 PNBC1491X6 PUSH BUTTON
PNBC1523Z1 PNBC1523Z1 PUSH BUTTON
PNBC1524Z1 PNBC1524Z1 PUSH BUTTON
PNBC1530Z1 PNBC1530Z1 PUSH BUTTON
ERJ2GEJ334 ERJ2GEJ334 RESISTOR
D0GG390JA007 D0GG390JA007 RESISTOR
D1H810240004 D1H810240004 RESISTOR
D1H83314A013 D1H83314A013 RESISTOR
ERJ2GE0R00X ERJ2GE0R00X RESISTOR
ERJ2GEJ102X ERJ2GEJ102X RESISTOR
ERJ2GEJ103 ERJ2GEJ103 RESISTOR
ERJ2GEJ104 ERJ2GEJ104 RESISTOR
ERJ2GEJ123 ERJ2GEJ123 RESISTOR
ERJ2GEJ124 ERJ2GEJ124 RESISTOR
ECEA0JKS220 ECEA0JKS220 RESISTOR
ERJ2GEJ1R0 ERJ2GEJ1R0 RESISTOR
ERJ2GEJ222 ERJ2GEJ222 RESISTOR
ERJ2GEJ223 ERJ2GEJ223 RESISTOR
ERJ2GEJ271 ERJ2GEJ271 RESISTOR
ERJ2RHD272 ERJ2RHD272 RESISTOR
ERJ2GEJ303 ERJ2GEJ303 RESISTOR
ERJ2GEJ332 ERJ2GEJ332 RESISTOR
ERJ2GEJ333 ERJ2GEJ333 RESISTOR
ERJ2GEJ392 ERJ2GEJ392 RESISTOR
ERJ2GEJ473 ERJ2GEJ473 RESISTOR
ERJ2GEJ563 ERJ2GEJ563 RESISTOR
ERJ2GEJ682 ERJ2GEJ682 RESISTOR
ERJ2GEJ823 ERJ2GEJ823 RESISTOR
ERJ2RKF1000 ERJ2RKF1000 RESISTOR
ERJ2RKF1400 ERJ2RKF1400 RESISTOR
ERJ2RKF5602 ERJ2RKF5602 RESISTOR
ERJ3GEY0R00 ERJ3GEY0R00 RESISTOR
ERJ3GEYJ104V ERJ3GEYJ104V RESISTOR
ERJ3GEYJ154 ERJ3GEYJ154 RESISTOR
ERJ3GEYJ1R0 ERJ3GEYJ1R0 RESISTOR
ERJ3GEYJ273V ERJ3GEYJ273V RESISTOR
ERJ3GEYJ565 ERJ3GEYJ565 RESISTOR
ERJ3GEYJ821 ERJ3GEYJ821 RESISTOR
ERJ3GEYJ822 ERJ3GEYJ822 RESISTOR
ERJ3GEYJ825 ERJ3GEYJ825 RESISTOR
ERJ8GEYJ1R0 ERJ8GEYJ1R0 RESISTOR
ERJ8GEYJ4R3V ERJ8GEYJ4R3V RESISTOR
EXB24V221JX EXB24V221JX RESISTOR
EXB24V332JX EXB24V332JX RESISTOR
EXB28V332JX EXB28V332JX RESISTOR
EXB28V561JX EXB28V561JX RESISTOR
PQ4R10XJ184 PQ4R10XJ184 RESISTOR
PQ4R18XJ272 PQ4R18XJ272 RESISTOR
PNHA1032Z PNHA1032Z RUBBER
PQHG10729Z PQHG10729Z RUBBER
XTB2_8GFJ XTB2_8GFJ SCREW
K2ECYZ000002 K2ECYZ000002 SOCKET
K2HD103D0001 K2HD103D0001 SOCKET
PQJJ1T039L PQJJ1T039L SOCKET
PNHS1079Z PNHS1079Z SPACER
PNYE1125Z PNYE1125Z SPACER
L0AA02A00087 L0AA02A00087 SPEAKER
L0AD01A00026 L0AD01A00026 SPEAKER
PNKL1044Z2 PNKL1044Z2 STAND
K0H1BA000578 K0H1BA000578 SWITCH
K0H1BB000094 K0H1BB000094 SWITCH
PNJK1209V PNJK1209V SWITCH
PNJK1211Z PNJK1211Z SWITCH
PNJK1212Y PNJK1212Y SWITCH
PNYE1124Z PNYE1124Z TAPE
PNJT1176Z PNJT1176Z TERMINAL
PNVE1002Z PNVE1002Z TERMINAL
PQJC10056W PQJC10056W TERMINAL
PNZZTGE230M PNZZTGE230M TEST TOOL
PQZZ1CD300E PQZZ1CD300E TEST TOOL
PQZZ430PIR PQZZ430PIR TEST TOOL
PQZZ430PRB PQZZ430PRB TEST TOOL
D4DAY220A022 D4DAY220A022 THERMISTER
2SA1776P 2SA1776P TRANSISTOR
2SC6054JSL 2SC6054JSL TRANSISTOR
B1ABDM000001 B1ABDM000001 TRANSISTOR
B1ADCF000040 B1ADCF000040 TRANSISTOR
B1ADGE000012 B1ADGE000012 TRANSISTOR
B1ADNB000003 B1ADNB000003 TRANSISTOR
DRC9113Z0L DRC9113Z0L TRANSISTOR
DSC7003S0L DSC7003S0L TRANSISTOR
J0LE00000047 J0LE00000047 VARISTOR
