Model Image
Manufacturer

Panasonic

Model Number

MCV5037

Description

Upright Vacuum

Interactive Exploded View

Parts List

Part Number Description
AC61LAGMZ00 AC61LAGMZ00 AC61LAGM100
AC84RBZDZ000 AC84RBZDZ000 AC84RZSZ0U
MC-V145MT MC-V145MT BAG
MC-115P MC-115P BAG
AC55EV0ZV07 AC55EV0ZV07 BASE
MC-V270B MC-V270B BELT
AMC27FAV000 AMC27FAV000 BRUSH
AC96DZSZ0U AC96DZSZ0U CAP
AC68KJMZV06 AC68KJMZV06 CASE
AC40KBJYZV07 AC40KBJYZV07 COMPARTMENT
AMC37G-V020U AMC37G-V020U CORD
AC03EV07V06 AC03EV07V06 COVER
AC60KBZBZUU1 AC60KBZBZUU1 COVER
AMC02H-F70E AMC02H-F70E COVER
AMC43S-V00 AMC43S-V00 COVER
AC92FBJYZ00 AC92FBJYZ00 FAN MOTOR
AMC37K-V00 AMC37K-V00 FILTER
AC39AYUZV00 AC39AYUZV00 GASKET
AC40AYUZV00 AC40AYUZV00 GASKET
AMC66K-V01V006 AMC66K-V01V006 GASKET
AC73KV0ZV06 AC73KV0ZV06 GASKET
AMC64B-V2Z00 AMC64B-V2Z00 HANDLE
AMC53E-V0ZV007 AMC53E-V0ZV007 HOOK
AC54EV0ZV06 AC54EV0ZV06 HOOK
AC01AARRZUU1 AC01AARRZUU1 HOUSING
AMC60H-F74VU06 AMC60H-F74VU06 INLET
AC01ZBZBZ000 AC01ZBZBZ000 INSTRUCT BOOK
AC99WAJDZ00 AC99WAJDZ00 LEAD WIRE
AC27AAGMZV07 AC27AAGMZV07 LOWER PLATE
AC09FBJXZU01 AC09FBJXZU01 MOTOR CASE
AMP21B-17Z00 AMP21B-17Z00 NUT
MCV5037_EX MCV5037_EX OTC VACUUM (DISCONTINUED)
AC19FJPZV06 AC19FJPZV06 PACKING
AMC75A-V00 AMC75A-V00 PACKING
AC91AAGMZV07 AC91AAGMZV07 PLATE ASSY
AC09FBJXZV07 AC09FBJXZV07 RESISTOR
AMC03F-V00 AMC03F-V00 RUBBER
AMC68A-ZAZ0000 AMC68A-ZAZ0000 SCREW
AXTN4-20BFY AXTN4-20BFY SCREW
AXTN4_16BFY AXTN4_16BFY SCREW
AXTN4_30BFY AXTN4_30BFY SCREW (10)
AMC73B-V0Z00 AMC73B-V0Z00 SCREW (10/1)
AC16CUSZ00 AC16CUSZ00 SHAFT
AMC25S-V00 AMC25S-V00 SHAFT
AMC57A-V00 AMC57A-V00 SPRING
AMC76N-F70 AMC76N-F70 SPRING
AMC32K-V0Z00 AMC32K-V0Z00 SUPPORT
AC18MJMZV06 AC18MJMZV06 SUPPORTER
AC99GAMMZ00 AC99GAMMZ00 SUPPRESSOR
AMC596-702 AMC596-702 TIE
AC02TARRZU01 AC02TARRZU01 TOP MARK
AMC58B-F70 AMC58B-F70 WASHER
AMC681-424 AMC681-424 WASHER (10)
AXWG6E115FY AXWG6E115FY WASHER (10)
AMC01C-V00U AMC01C-V00U WHEEL
AC74SUSZ00 AC74SUSZ00 WHEEL (10)
AMC-1CTCE23 AMC-1CTCE23 WIRE
