Model Image
Manufacturer

Panasonic

Model Number

NNS542BF

Description

Microwave Oven

Interactive Exploded View

Parts List

Part Number Description
F900C4T00AP F900C4T00AP AC CORD
F10014T00AP F10014T00AP BASE
F40084T00AP F40084T00AP BLADE
AEFBTFM571 AEFBTFM571 BUZZER
F110D5A00HAP F110D5A00HAP CABINET
F110D5Y30BAP F110D5Y30BAP CABINET
F05477600AP F05477600AP CARD
F201A4T10AP F201A4T10AP CAVITY
F66175L00AP F66175L00AP CONNECTOR
AEEMXH01505W AEEMXH01505W CONNECTOR
AEEMF00703W AEEMF00703W CONNECTOR
F20555L00AP F20555L00AP COVER
F67005U40XN F67005U40XN COVER
F0926100BB F0926100BB CUSHION
F302K5L00AP F302K5L00AP DOOR
F30015L00HAP F30015L00HAP DOOR A
F30015L00BAP F30015L00BAP DOOR A
F30854T00AP F30854T00AP DOOR C
F31456V60XP F31456V60XP DOOR SCREEN
F603L5L20AP F603L5L20AP DP CIRCUIT
F603L5L10AP F603L5L10AP DP CIRCUIT
F80345L00HAP F80345L00HAP ESCUTCHEON
F80345L00BAP F80345L00BAP ESCUTCHEON
F01045L00AP F01045L00AP FILLER (DISCONTINUED)
F01055L00AP F01055L00AP FILLER (DISCONTINUED)
F10084T00APS F10084T00APS FOOT
F62308F00AP F62308F00AP FUSE
F40254T00AP F40254T00AP GUIDE
F030A5L20AP F030A5L20AP HARNESS
F62315G10XN F62315G10XN HOLDER
F30208790XN F30208790XN HOOK
UPC358G2 UPC358G2 IC
F00035L10AP F00035L10AP INSTRUCT BOOK
A606Y4T00AP A606Y4T00AP INVERTER
F02459660AP F02459660AP LABEL
F01705L20AP F01705L20AP LABEL
F01705L10AP F01705L10AP LABEL
F00339660AP F00339660AP LABEL
B00066260AP B00066260AP LABEL
F00337D00RP F00337D00RP LABEL
F612E5Y30AP F612E5Y30AP LAMP
F03528100XN F03528100XN LEAD WIRE
B030E4U00AP B030E4U00AP LEAD WIRE
F31378790XN F31378790XN LEVER
MN101C589DJ MN101C589DJ LSI
2M261-M32KLP 2M261-M32KLP MAGNETRON
F01265L00AP F01265L00AP MATERIAL
F63266Z80AP F63266Z80AP MOTOR
F400A5Y00AP F400A5Y00AP MOTOR
F41444T00AP F41444T00AP ORIFICE
NNS542BF_EX NNS542BF_EX OTC MICROWAVE (DISCONTINUED)
F01134T00AP F01134T00AP PACKAGING
F01078100XN F01078100XN PACKAGING
F01068100XN F01068100XN PACKAGING
A01924T00AP A01924T00AP PACKAGING
F01025L10BAP F01025L10BAP PACKAGING (DISCONTINUED)
F01025L20HAP F01025L20HAP PACKAGING (DISCONTINUED)
F61844T00AP F61844T00AP PLATE
F00075L20HAP F00075L20HAP PLATE
F00075L10BAP F00075L10BAP PLATE
AEGG5G1A18 AEGG5G1A18 RELAY
K6B1AZA00013 K6B1AZA00013 RELAY
F290D9330AP F290D9330AP ROLLER
F31465L00HAP F31465L00HAP SCREEN B
F31465L00BAP F31465L00BAP SCREEN B
XTTAFE4T12A0 XTTAFE4T12A0 SCREW
XTCA4_12AFW XTCA4_12AFW SCREW
XTCAFL4_12AFS XTCAFL4_12AFS SCREW
XTCA4_12AFK XTCA4_12AFK SCREW
F21314W00AP F21314W00AP SHAFT
F3097-5L00 F3097-5L00 SPRING
F30214000AP F30214000AP SPRING
F30216P40AG F30216P40AG SPRING
J61415G10XN J61415G10XN SWITCH
F61415U30XN F61415U30XN SWITCH
F630Y5L20HAP F630Y5L20HAP SWITCH
F630Y5L10BAP F630Y5L10BAP SWITCH
F61785U30XN F61785U30XN SWITCH
G4C2AAD00005 G4C2AAD00005 TRANSFORMER
F06014T00AP F06014T00AP TRAY
AEVTZ6TLT103 AEVTZ6TLT103 VARISTOR
AERZ271KD10A AERZ271KD10A VARISTOR
F2177-F80 F2177-F80 WASHER
