Model Image
Manufacturer

Panasonic

Model Number

PT52LCX16

Description

Multi Media Display

Interactive Exploded View

Parts List

Part Number Description
LSXA0733 LSXA0733 ANGLE
LSXA0734 LSXA0734 ANGLE
LSMA0923 LSMA0923 ANGLE
LSMA0924 LSMA0924 ANGLE
LSXA0771-HBR LSXA0771-HBR ASSEMBLY
CALL_800-743-2335 CALL_800-743-2335 ASSEMBLY
LSGB0056 LSGB0056 BADGE
LSQT1060-B LSQT1060-B BAG
ZR-6XA_2B ZR-6XA_2B BATTERY
LSKU0041 LSKU0041 BODY
LSGU0724 LSGU0724 BUTTON
LSGU0725 LSGU0725 BUTTON
LSJA0551 LSJA0551 CABLE
LSJA0605-1 LSJA0605-1 CABLE
LSUA0013 LSUA0013 CABLE
LSUA0038 LSUA0038 CABLE
LSUA0039 LSUA0039 CABLE
LSUA0040 LSUA0040 CABLE
LSUA0041 LSUA0041 CABLE
LSUA0042 LSUA0042 CABLE
LSXA0833 LSXA0833 CABLE
RP-CA2020 RP-CA2020 CABLE
RP-CA2030A RP-CA2030A CABLE
RP-CDHG100 RP-CDHG100 CABLE
RP-CDHG15 RP-CDHG15 CABLE
K1HA19DA0005 K1HA19DA0005 CABLE
RP-CDHG50 RP-CDHG50 CABLE
RP-CDHG70 RP-CDHG70 CABLE
LSJA0597 LSJA0597 CABLE
RP-SDR02GU1A RP-SDR02GU1A CARD
RP-SDR256U1A RP-SDR256U1A CARD
LSSC0866 LSSC0866 CASE
LSVE0018 LSVE0018 CHASSIS
TMME047 TMME047 CLAMP
TMM16452 TMM16452 CLAMP
LSGQ0176 LSGQ0176 CLAMPER
K1KA02AA0300 K1KA02AA0300 CONNECTOR
K1KA07BA0061 K1KA07BA0061 CONNECTOR
K1KA08BA0061 K1KA08BA0061 CONNECTOR
K1KA12BA0062 K1KA12BA0062 CONNECTOR
LSGV0129 LSGV0129 COVER
LSYF0605 LSYF0605 COVER
LSYF0606 LSYF0606 COVER
LSGH0071 LSGH0071 CUSHION
LSMF0524 LSMF0524 CUSHION
B3AAA0000538 B3AAA0000538 DIODE
B3AGA0000072 B3AGA0000072 DIODE
LSYF0599 LSYF0599 DOOR
ECEA1CKA470B ECEA1CKA470B ECEA0JKS470L
ERJ3GEYJ471V ERJ3GEYJ471V ERJ3GEYG471
ERJ3GEYJ101 ERJ3GEYJ101 ERJ3GEYJ101
D0GB181JA057 D0GB181JA057 ERJ3GEYJ181
ERJ3GEYJ272 ERJ3GEYJ272 ERJ3GEYJ272
ERJ3GEYJ562 ERJ3GEYJ562 ERJ3GEYJ562
LSGY0326 LSGY0326 ESCUTCHEON
LSLQ0307 LSLQ0307 FERRITE CORE
RRTPTLCX16-66 RRTPTLCX16-66 FIRMWARE
LSKA0031-1 LSKA0031-1 FOOT
LSYF0593 LSYF0593 FRONT COVER UNIT
LSJA0583 LSJA0583 FUSE
TMME075 TMME075 GUARD
LSJH0093 LSJH0093 HOLDER
LSYF0602 LSYF0602 HOLDER
LSYF0603 LSYF0603 HOLDER
C3ABRG000060 C3ABRG000060 IC (DISCONTINUED)
TZSC03061 TZSC03061 KIT
TZSC03065 TZSC03065 KIT
TZSC03067 TZSC03067 KIT
LSKC0008 LSKC0008 LATCH (DISCONTINUED)
LSGP0557 LSGP0557 LENS
LSDL0310 LSDL0310 MIRROR
LSPF0111 LSPF0111 PACKAGING
LSPG2212 LSPG2212 PACKAGING
LSPG2265 LSPG2265 PACKAGING
LSPG2290 LSPG2290 PACKAGING
LSPN0703 LSPN0703 PACKAGING
LSPN0706 LSPN0706 PACKAGING
LSPN0709 LSPN0709 PACKAGING
LSPN0712 LSPN0712 PACKAGING
LSPN0729 LSPN0729 PACKAGING
LSEP3199A LSEP3199A PC BOARD
LSEP3200A LSEP3200A PC BOARD
LSEP3201A-HB LSEP3201A-HB PC BOARD
LSXA0773 LSXA0773 PC BOARD
LSGL0447 LSGL0447 PIECE
LSGL0499 LSGL0499 PIECE
LSGL0500 LSGL0500 PIECE
LSMC0150 LSMC0150 PLATE
LSSC0867 LSSC0867 PLATE
LSSC0877 LSSC0877 PLATE
LSEP1206A1 LSEP1206A1 POWER PC BOARD COMPLETE- NO COMPONENTS AVAILABLE
PNA4618M14VT PNA4618M14VT RECEIVER
TY-LA1001 TY-LA1001 REPLACEMENT LAMP
ERJ3GEYJ103V ERJ3GEYJ103V RESISTOR
ERJ3GEYG152 ERJ3GEYG152 RESISTOR
ERJ3GEYJ183V ERJ3GEYJ183V RESISTOR
ERJ3GEJ750V ERJ3GEJ750V RESISTOR
ERJ3GEYJR00V ERJ3GEYJR00V RESISTOR
ERJ3GEYJ122 ERJ3GEYJ122 RN4B2AY122J
LSGP0558 LSGP0558 SCREEN
LSYK1874 LSYK1874 SCREEN
LSHD0099-FJ LSHD0099-FJ SCREW
XTV3_8FFJ XTV3_8FFJ SCREW
XTV3_8GFJ XTV3_8GFJ SCREW
XTV3_8JFJ XTV3_8JFJ SCREW
XTV4_12AFJ XTV4_12AFJ SCREW
XTV4_16AFJ XTV4_16AFJ SCREW
XTV4_16AFJK XTV4_16AFJK SCREW
XTW3_8TFJ XTW3_8TFJ SCREW
XYE3_FJ8 XYE3_FJ8 SCREW
143PTLCX16 143PTLCX16 SD CARD
LSGH0069 LSGH0069 SHEET
LSGH0077 LSGH0077 SHEET
LSMF0435 LSMF0435 SHEET
VMFS0116 VMFS0116 SHEET
K1U412A00008 K1U412A00008 SOCKET
LSMF0499 LSMF0499 SPACER
LSMF0505 LSMF0505 SPACER
LSMF0509 LSMF0509 SPACER
LSMG0171 LSMG0171 SPACER
EAS15S19A EAS15S19A SPEAKER
LSMF0270 LSMF0270 SPONGE
LSMB0321 LSMB0321 SPRING
LSMC0151 LSMC0151 SPRING
EVQ11G05R EVQ11G05R SWITCH
K0L1BA000114 K0L1BA000114 SWITCH
T18S T18S T18S
LSGH0076 LSGH0076 TAPE
LSEP3216A LSEP3216A TEST TOOL
D4CE31330001 D4CE31330001 THERMISTOR
LSUA0043 LSUA0043 TOOL
B1ABCF000020 B1ABCF000020 TRANSISTOR
B1ADCF000075 B1ADCF000075 TRANSISTOR
2SB1218A 2SB1218A TRANSISTOR
2SD1819AWL 2SD1819AWL TRANSISTOR
LSXA0771-HB LSXA0771-HB UNIT *CALL 800-743-2335*
LSMG0169 LSMG0169 WASHER
TMM14414 TMM14414 WEDGE
