Model Image
Manufacturer

Panasonic

Model Number

SRDE102

Description

Rice Cooker

Interactive Exploded View

Parts List

Part Number Description
ARH01T961 ARH01T961 BASE
ARE10T962-W9 ARE10T962-W9 CABINET
ARF26T961 ARF26T961 CASE
ARH01U964-0U ARH01U964-0U CONTROL
ARQ00A961-0U ARQ00A961-0U CORD
ARQ00A96110U ARQ00A96110U CORD
ARE40T961-W9 ARE40T961-W9 COVER
ARF27T961-W9 ARF27T961-W9 COVER
ASR792-454DK ASR792-454DK CUP
ARE00A9641W9 ARE00A9641W9 FRAME
ARE00A964W9U ARE00A964W9U FRAME
ARE00T962-W9 ARE00T962-W9 FRAME
ARE00T964W9U ARE00T964W9U FRAME
ARE20T921 ARE20T921 FRAME
ARE20T9211 ARE20T9211 FRAME
ARE31T962 ARE31T962 FRAME
ARB10T962-W9 ARB10T962-W9 HANDLE
ARL20A962-0U ARL20A962-0U HEATER
ARF19T934-0U ARF19T934-0U INLET
ARG10T920-0U ARG10T920-0U INLET
ARB32A961 ARB32A961 LABEL
ARY30A964-W9 ARY30A964-W9 LABEL
ARB01A964W9U ARB01A964W9U LID
ARC80A964-0U ARC80A964-0U LID
ARC80T964-0U ARC80T964-0U LID
ARZ01A964-W9 ARZ01A964-W9 PACKAGING
ARZ01A9642W9 ARZ01A9642W9 PACKAGING
ARZ04T96200U ARZ04T96200U PACKAGING
ARZ11T96200U ARZ11T96200U PACKAGING
ASR758T344B ASR758T344B PACKAGING
ARN21H964-NK ARN21H964-NK PANEL
ARN24A964-NK ARN24A964-NK PANEL
ARN24H963-NK ARN24H963-NK PANEL
ARR30U964 ARR30U964 PC BOARD
ARY00A964-W9 ARY00A964-W9 PLATE
ASR79WT281AK ASR79WT281AK SCOOP
ASR270-977AZ ASR270-977AZ SCREW
XTB4_12CFJ XTB4_12CFJ SCREW
XTB4_12GFJ XTB4_12GFJ SCREW
XTB4_14CFJ XTB4_14CFJ SCREW
XTN4_16AVW XTN4_16AVW SCREW
XTT4_8FFJ XTT4_8FFJ SCREW
XYN4_C10S XYN4_C10S SCREW
XYN4_C7FN6 XYN4_C7FN6 SCREW
AQS61T2701 AQS61T2701 SPRING
ARE06EA29 ARE06EA29 SPRING
ARS10A962-0U ARS10A962-0U THERMOSTAT
ARR30A9642 ARR30A9642 UNIT
ARE46H962 ARE46H962 WIRE
ARN97A962-0U ARN97A962-0U WIRE
ARN98A962-0U ARN98A962-0U WIRE
