Model Image
Manufacturer

Panasonic

Model Number

TH32LRH30U

Description

32-inch Professional Healthcare Grade Lcd Tv

Interactive Exploded View

Parts List

Part Number Description
K1KA15AA0409 K1KA15AA0409 15P CONNECTOR
K1KA16AA0658 K1KA16AA0658 16P CONNECTOR
K1KY02A00001 K1KY02A00001 2P CONNECTOR
K1KY02BA0257 K1KY02BA0257 2P CONNECTOR
K1KA04A00192 K1KA04A00192 4P CONNECTOR
K1KA04AA0104 K1KA04AA0104 4P CONNECTOR
K1MN55BA0076 K1MN55BA0076 55P CONNECTOR
K1KA05A00466 K1KA05A00466 5P CONNECTOR
K1KA05B00219 K1KA05B00219 5P CONNECTOR
K1KA06A00508 K1KA06A00508 6P CONNECTOR
K1KA07A00292 K1KA07A00292 7P CONNECTOR
K1KA07B00135 K1KA07B00135 7P CONNECTOR
K1KY08AA0719 K1KY08AA0719 8P CONNECTOR
K1KA08A00506 K1KA08A00506 8P CONNECTOR
K1KA08AA0714 K1KA08AA0714 8P CONNECTOR
K1KA08B00270 K1KA08B00270 8P CONNECTOR
K1KY09AA0719 K1KY09AA0719 9P CONNECTOR
K2CG3YY00111 K2CG3YY00111 AC CORD
TXAKZ011DFU TXAKZ011DFU AC INLET COMP
TXJTNR1MDU TXJTNR1MDU ANALOG - DIGITAL TUNER - CABLE
TXFKU67ZSER TXFKU67ZSER BACK COVER COMPLETE
TMK2AX216 TMK2AX216 BARRIER_METAL_COVER_BTM
TMX4GE010 TMX4GE010 BRACKET-IP
TXFKY011WEU TXFKY011WEU CABINET ASSY
J0B1075B0060 J0B1075B0060 CERAMIC FILTER
J0B1075B0061 J0B1075B0061 CERAMIC FILTER
TXN_A11DFUS TXN_A11DFUS CIRCUIT BOARD A
TXNFP11DFU TXNFP11DFU CIRCUIT BOARD FP
TXN_P11DFU TXN_P11DFU CIRCUIT BOARD P
TXNTA11WEU TXNTA11WEU CIRCUIT BOARD TA
TXN_V10QMMM TXN_V10QMMM CIRCUIT BOARD V
K1KY04AA0719 K1KY04AA0719 CONNECTOR
K1FY315A0006 K1FY315A0006 CONNECTOR
K1FY119D0018 K1FY119D0018 CONNECTOR
K1FY119E0028 K1FY119E0028 CONNECTOR
K1QYY1YB0078 K1QYY1YB0078 CONNECTOR
EVMAASA00B14 EVMAASA00B14 CONTROL 10KOHMB
K0RB00700018 K0RB00700018 CONTROL PANEL ASS'Y
TKK2AA7901 TKK2AA7901 COVER (ADJ. WINDOW)
H0J245500101 H0J245500101 CRYSTAL
H0J120500062 H0J120500062 CRYSTAL
H0J250500079 H0J250500079 CRYSTAL
H0J270500137 H0J270500137 CRYSTAL
H0J400400025 H0J400400025 CRYSTAL
H1A3935B0002 H1A3935B0002 CRYSTAL
H0J222500009 H0J222500009 CRYSTAL
H0J227500001 H0J227500001 CRYSTAL
EZAEG2A50AX EZAEG2A50AX ESD SUPPRESSOR
EXC28CE201U EXC28CE201U FILTER
K5H1522A0018 K5H1522A0018 FUSE
K5H1022A0018 K5H1022A0018 FUSE
K5H4022A0031 K5H4022A0031 FUSE
K5H1622A0031 K5H1622A0031 FUSE
K5H502YA0080 K5H502YA0080 FUSE
K3GE1ZA00010 K3GE1ZA00010 FUSE HOLDER
K1U812A00001 K1U812A00001 JACK
K2HC1YYA0036 K2HC1YYA0036 JACK
K2LB106A0014 K2LB106A0014 JACK
K2HA101B0030 K2HA101B0030 JACK
TC-32LC54-EX TC-32LC54-EX LCD PANEL
B3AAB0000343 B3AAB0000343 LED
TKK4GC5024-1 TKK4GC5024-1 LED PANEL(WITHOUT IR PRINT)
TSCKE0040001 TSCKE0040001 LVDS CABLE
D0GAR00Z0001 D0GAR00Z0001 M 0 OH
D0GDR00Z0002 D0GDR00Z0002 M 0 OHM, 1/4W
THNA010N THNA010N NUT
TMME215 TMME215 NYLON CLAMPER (FOR AC CORD )
TXFMK011MDU TXFMK011MDU PANEL LVDS BARRIER ASS'Y
K6B1AYY00060 K6B1AYY00060 RELAY
K6B1AYY00061 K6B1AYY00061 RELAY
K6B2CYY00044 K6B2CYY00044 RELAY
PNJ4815M01TV PNJ4815M01TV REMOTE SENSOR
XYN4_F20FJK XYN4_F20FJK SCREW
K1NA12E00017 K1NA12E00017 SD CARD CONNECTOR
TXFKP13ZSER TXFKP13ZSER SIDE AV BRACKET
TQB2AA0632-1 TQB2AA0632-1 SIMPLE INSTRUCTION BOOK
TMW2AX031-1 TMW2AX031-1 SP BRACKET L
TMW2AX032-1 TMW2AX032-1 SP BRACKET R
TXJA121DFU-1 TXJA121DFU-1 SPEAKER LEAD (A12-SP)
L0AA16C00002 L0AA16C00002 SPEAKER UNIT
TMMX246 TMMX246 SUPPORT MOLD
K4ZZ01000267 K4ZZ01000267 TERMINAL
K4AD01A00002 K4AD01A00002 TERMINAL
K4AK06B00001 K4AK06B00001 TERMINAL BOARD
D4CAY8R0A010 D4CAY8R0A010 THERMISTOR
K5D502BNA005 K5D502BNA005 TIME LAG FUSE HIGH
ENG36F15KF ENG36F15KF TUNER
K1SYYYYB0004 K1SYYYYB0004 TUNER EXTENSION ADAPTER
EZJZ0V120JA EZJZ0V120JA VARISTOR
D4EAC6210002 D4EAC6210002 VARISTOR
TKZ4GX5015 TKZ4GX5015 VESA METAL TOP
TKZ4GX5018-2 TKZ4GX5018-2 VESA RAIL L
TKZ4GX5019 TKZ4GX5019 VESA RAIL R
THW40973N THW40973N WASHER
THWC018N THWC018N WASHER
DZ2J140M0L DZ2J140M0L ZENER DIODE
DZ2J062M0L DZ2J062M0L ZENER DIODE
DZ2J160M0L DZ2J160M0L ZENER DIODE
DZ2J056M0L DZ2J056M0L ZENER DIODE
DZ2J200M0L DZ2J200M0L ZENER DIODE
DZ2J330M0L DZ2J330M0L ZENER DIODE
B0BC4R700007 B0BC4R700007 ZENER DIODE
B0BC17000001 B0BC17000001 ZENER DIODE
B0BC01000035 B0BC01000035 ZENER DIODE
DZ2J240M0L DZ2J240M0L ZENER DIODE
DZ2J047M0L DZ2J047M0L ZENER DIODE
DZ2J033M0L DZ2J033M0L ZENER DIODE
DZ2J180M0L DZ2J180M0L ZENER DIODE
DZ2J110M0L DZ2J110M0L ZENER DIODE
B0BC03900015 B0BC03900015 ZENER DIODE
B0BC01100001 B0BC01100001 ZENER DIODE
B0BC015A0336 B0BC015A0336 ZENER DIODE
B0BA01000070 B0BA01000070 ZENER DIODE
B0BC8R100004 B0BC8R100004 ZENER DIODE
DZ2J068M0L DZ2J068M0L ZENER DIODE
DZ2J051M0L DZ2J051M0L ZENER DIODE
B0BC019A0007 B0BC019A0007 ZENER DIODE
