Model Image
Manufacturer

Panasonic

Model Number

WVCK2020A

Description

Color Monitor

Interactive Exploded View

Parts List

Part Number Description
2SA564AQR 2SA564AQR 2SA1127-S
2SC945Q 2SC945Q 2SC945A
2SD601-RS 2SD601-RS 2SD601A-R
AN5265 AN5265 AN5265
AN78M05LB AN78M05LB AN78M05LB
AN78M09 AN78M09 AN78M09LB
AU02 AU02 AU02
TBM4C1A028-0 TBM4C1A028-0 BADGE
TPE4C1A00201 TPE4C1A00201 BAG
TPE4C1A014 TPE4C1A014 BAG
42S13217A02 42S13217A02 BAND
TMM81416 TMM81416 BAND
TJB4C1A035 TJB4C1A035 BRACKET
ECQV1H104JZ ECQV1H104JZ CAPACITOR
ECKD3D471KBP ECKD3D471KBP CAPACITOR
ECA1AHG101B ECA1AHG101B CAPACITOR
ECA1CHG101B ECA1CHG101B CAPACITOR
ECA1HEN010 ECA1HEN010 CAPACITOR
ECA1HHG471E ECA1HHG471E CAPACITOR
ERJ6GEYJ203Z ERJ6GEYJ203Z CAPACITOR
ECA160V33UE ECA160V33UE CAPACITOR
ECA2EHG220E ECA2EHG220E CAPACITOR
ECEA0JTK101B ECEA0JTK101B CAPACITOR
ECEA0JTK220B ECEA0JTK220B CAPACITOR
ECEA1ATK330B ECEA1ATK330B CAPACITOR
ECEA1ATK331B ECEA1ATK331B CAPACITOR
ECEA1ATK470B ECEA1ATK470B CAPACITOR
ECEA1CTK100B ECEA1CTK100B CAPACITOR
ECEA1CTK220B ECEA1CTK220B CAPACITOR
ECEA1CTK330B ECEA1CTK330B CAPACITOR
ECEA1CTK4R7B ECEA1CTK4R7B CAPACITOR
ECEA1CTK470B ECEA1CTK470B CAPACITOR
ECEA1CTK471B ECEA1CTK471B CAPACITOR
ECEA1ETK101B ECEA1ETK101B CAPACITOR
ECEA1ETK102E ECEA1ETK102E CAPACITOR
ECEA1ETK220B ECEA1ETK220B CAPACITOR
ECEA1ETK471B ECEA1ETK471B CAPACITOR
ECEA1HTKR22B ECEA1HTKR22B CAPACITOR
ECEA1HTKR33B ECEA1HTKR33B CAPACITOR
ECEA1HTKR47B ECEA1HTKR47B CAPACITOR
ECEA1HTK0R1B ECEA1HTK0R1B CAPACITOR
ECEA1HTK010B ECEA1HTK010B CAPACITOR
ECEA1HTK100B ECEA1HTK100B CAPACITOR
ECEA1HTK2R2B ECEA1HTK2R2B CAPACITOR
ECEA1HTK3R3B ECEA1HTK3R3B CAPACITOR
ECEA1JTK100B ECEA1JTK100B CAPACITOR
ECEA1VTK101B ECEA1VTK101B CAPACITOR
ECEA1VTK102E ECEA1VTK102E CAPACITOR
ECEA1VTK222E ECEA1VTK222E CAPACITOR
ECEA1VTK330B ECEA1VTK330B CAPACITOR
ECEA1VTK332E ECEA1VTK332E CAPACITOR
ECKCNA221MBB ECKCNA221MBB CAPACITOR
ECKCNB222MB ECKCNB222MB CAPACITOR
ECKR1H331KB ECKR1H331KB CAPACITOR
ECKD1H471MB ECKD1H471MB CAPACITOR
ECKR1H561KB ECKR1H561KB CAPACITOR
ECKR2H331KB ECKR2H331KB CAPACITOR
ECKR2H471KB5 ECKR2H471KB5 CAPACITOR
ECKR2H561KB ECKR2H561KB CAPACITOR
ECKW3D102KB ECKW3D102KB CAPACITOR
ECKW3D471KB ECKW3D471KB CAPACITOR
ECKW3D821KB ECKW3D821KB CAPACITOR
ECKD3D821JBP ECKD3D821JBP CAPACITOR
ECQB1682KF ECQB1682KF CAPACITOR
ECQE1224KF ECQE1224KF CAPACITOR
ECQF2H824JZ ECQF2H824JZ CAPACITOR
ECQM1H182JZ ECQM1H182JZ CAPACITOR
ECQM1H223JZ ECQM1H223JZ CAPACITOR
ECQM1H822JZ ECQM1H822JZ CAPACITOR
ECQM2223JZ ECQM2223JZ CAPACITOR
ECQM4223JZB ECQM4223JZB CAPACITOR
ECQM4273JZ ECQM4273JZ CAPACITOR
ECQU2A104MNB ECQU2A104MNB CAPACITOR
ECQU2A224KHB ECQU2A224KHB CAPACITOR
ECQV1H104JZ3M ECQV1H104JZ3M CAPACITOR
ECQV1H224JZ ECQV1H224JZ CAPACITOR
ECUV1C683KBN ECUV1C683KBN CAPACITOR
ECUV1E104ZFG ECUV1E104ZFG CAPACITOR
ECUV1H101JCN ECUV1H101JCN CAPACITOR
ECUV1H102JCN ECUV1H102JCN CAPACITOR
ECUV1H104ZFN ECUV1H104ZFN CAPACITOR
F1J1H122A400 F1J1H122A400 CAPACITOR
ECUV1H153KBN ECUV1H153KBN CAPACITOR
ECUV1H222KBN ECUV1H222KBN CAPACITOR
ECUX1H223ZFN ECUX1H223ZFN CAPACITOR
ECUV1H330JCN ECUV1H330JCN CAPACITOR
ECUV1H332KBN ECUV1H332KBN CAPACITOR
ECUV1H471JCN ECUV1H471JCN CAPACITOR
ECUV1H473KBN ECUV1H473KBN CAPACITOR
ECUV1H561JUN ECUV1H561JUN CAPACITOR
ECUV1H680JCN ECUV1H680JCN CAPACITOR
ECUV1H681JCN ECUV1H681JCN CAPACITOR
ECUZ1H102KBN ECUZ1H102KBN CAPACITOR
ECWH12H153JS ECWH12H153JS CAPACITOR
TAC4R6B472JC TAC4R6B472JC CAPACITOR
EC0S2CA102CB EC0S2CA102CB CAPACITOR
TEK4C1A004 TEK4C1A004 CATCHER
TKK4C1A07101 TKK4C1A07101 CLAMP
TMM15404-1 TMM15404-1 CLAMP
CK2020-DY CK2020-DY COIL
ELEP4CJR47KA ELEP4CJR47KA COIL
ELEP4CJ101KA ELEP4CJ101KA COIL
TALL08T682JA TALL08T682JA COIL
TLH6667P-1 TLH6667P-1 COIL
TLK153152Q1 TLK153152Q1 COIL
TLK4C9013P TLK4C9013P COIL
TL0ABTA100K TL0ABTA100K COIL
TL0ABTA180K TL0ABTA180K COIL
TSKA069 TSKA069 COIL
TSKA075 TSKA075 COIL
TSKA077 TSKA077 COIL
CK2020AA11S5 CK2020AA11S5 CONNECTOR
CK2020AA12S4 CK2020AA12S4 CONNECTOR
CK2020AS1S5 CK2020AS1S5 CONNECTOR
TJSC4C9101 TJSC4C9101 CONNECTOR
TJS5A8730 TJS5A8730 CONNECTOR
TJS5A8750 TJS5A8750 CONNECTOR
ERG2ANJ150 ERG2ANJ150 CONTROL
EVNDXAA03B22 EVNDXAA03B22 CONTROL
TKP4C1A111 TKP4C1A111 CONTROL DOOR
PC123ZY2 PC123ZY2 COUPLER
A51AEZ90X15K A51AEZ90X15K CRT
EF0EC1205B4 EF0EC1205B4 CRYSTAL
B0EBNT000002 B0EBNT000002 DIODE
ERA15-01V5 ERA15-01V5 DIODE
ERB06-15V1 ERB06-15V1 DIODE
YEADGMB01 YEADGMB01 DIODE
MA171 MA171 DIODE
MA4024-H MA4024-H DIODE
MA4051H MA4051H DIODE
MTZJ5R1BTA MTZJ5R1BTA DIODE
RD6_8ESB3 RD6_8ESB3 DIODE
MA4108J MA4108J DIODE
MA4110-H MA4110-H DIODE
MAZ41500MF MAZ41500MF DIODE
MA4330-M MA4330-M DIODE
MA4360-L MA4360-L DIODE
MA4360-M MA4360-M DIODE
TVSRU2AMV1 TVSRU2AMV1 DIODE
TVSSSR2KSV1 TVSSSR2KSV1 DIODE
YWD1NL20U YWD1NL20U DIODE
YWS2L60 YWS2L60 DIODE
MA4056L MA4056L DIODE (I)
ECA1EHG331 ECA1EHG331 ECA1EHG331
ECA1EHG102E ECA1EHG102E ECEA1EGE102E
ECKD2H472KB5 ECKD2H472KB5 ECKD2H472KB5
ECKD2H103PE ECKD2H103PE ECKW2H103PE
ECQB1H273JF ECQB1H273JF ECQB1H273JF
ECQF2H474JZA ECQF2H474JZA ECQF2H474JZA
ECTRM1H473KZ ECTRM1H473KZ ECQM1H473KZ
ECQM1H333JZ ECQM1H333JZ ECQV1H333JZ3
ECQM1H683MZW ECQM1H683MZW ECQV1H683JZ
ECSF25E1VB ECSF25E1VB ECSF1EE105VE
ECUV1C224KBN ECUV1C224KBN ECUV1C224KBM
PQCUV1H103KB PQCUV1H103KB ECUV1H103KBM
MCUV1H103ZFN MCUV1H103ZFN ECUV1H103ZFV
ECUX1H221KBV ECUX1H221KBV ECUX1H221KBV
ECUX1H223KBN ECUX1H223KBN ECUX1H223KBN
ERDS2TJ471 ERDS2TJ471 ERD16TJ471
ERD25FJ100K ERD25FJ100K ERD25FJ100P
ERDS2TJ101 ERDS2TJ101 ERD25FJ101
ERDS2TJ750TD ERDS2TJ750TD ERD25FJ750
ERD25TJ202 ERD25TJ202 ERD25TJ202
ERD25TJ393T ERD25TJ393T ERD25TJ393T
ERDS1FJ1R5 ERDS1FJ1R5 ERDS1FJ1R5
ERDS2TJ102 ERDS2TJ102 ERDS2FJ102
ERDS2FJ103 ERDS2FJ103 ERDS2TJ103T
ERDS2TJ222TD ERDS2TJ222TD ERDS2TJ222TD
ERD10TLJ332 ERD10TLJ332 ERDS2TJ332T
ERDS2TJ470 ERDS2TJ470 ERDS2TJ470
ERD25FJ4R7 ERD25FJ4R7 ERDS2TJ4R7T
ERDS2TJ751 ERDS2TJ751 ERDS2TJ751T
ECKF1H050C5 ECKF1H050C5 ERG2ANJ102H
ERG2ANJ122 ERG2ANJ122 ERG2ANJP122H
ERG2SJ222E ERG2SJ222E ERG2ANJP222S
ERJ6GEY0R00A ERJ6GEY0R00A ERJ6GEY0R00V
ERJ6GEYJ102Z ERJ6GEYJ102Z ERJ6GEYF102
ERJ6GEYF333 ERJ6GEYF333 ERJ6GEYF333
ERJ6GEYK4R7V ERJ6GEYK4R7V ERJ6GEYF393
ERJ6GEYJ472V ERJ6GEYJ472V ERJ6GEYF472
ERJ6GEYG103 ERJ6GEYG103 ERJ6GEYG103
ERJ6GEYG222 ERJ6GEYG222 ERJ6GEYG103
ERJ6GEYJ181 ERJ6GEYJ181 ERJ6GEYG181
ERJ6GEYJ242 ERJ6GEYJ242 ERJ6GEYG242
ERJ6GEYJ330 ERJ6GEYJ330 ERJ6GEYG330
ERJ6GEYJ332 ERJ6GEYJ332 ERJ6GEYG332
ERJ6GEYG391 ERJ6GEYG391 ERJ6GEYG391
ERJ6GEYJ560V ERJ6GEYJ560V ERJ6GEYG560
ERJ6GEYG750 ERJ6GEYG750 ERJ6GEYG750
ERJ6GEYJ122V ERJ6GEYJ122V ERJ6GEYJ122V
ERJ6GEYJ123V ERJ6GEYJ123V ERJ6GEYJ123V
ERJ6GEYG154 ERJ6GEYG154 ERJ6GEYJ154V
ERJ6GEYJ182V ERJ6GEYJ182V ERJ6GEYJ182V
ERJ6GMYG221 ERJ6GMYG221 ERJ6GEYJ221V
ERJ6GEYJ224Z ERJ6GEYJ224Z ERJ6GEYJ224V
ERJ6GEYG272 ERJ6GEYG272 ERJ6GEYJ272V
ERJ6GEYG273 ERJ6GEYG273 ERJ6GEYJ273V
ERJ6GEYJ334 ERJ6GEYJ334 ERJ6GEYJ334B
ERJ6GEYJ471V ERJ6GEYJ471V ERJ6GEYJ471V
ERJ6GEYJ562V ERJ6GEYJ562V ERJ6GEYJ562V
ERJ6GEYJ823 ERJ6GEYJ823 ERJ6GEYJ823V
ERJ6GMYJ183 ERJ6GMYJ183 ERJ6GMYJ183
ERJ6GEYJ563V ERJ6GEYJ563V ERJ6RBD563
EU02V1 EU02V1 EU02A
ADL-CN1738E ADL-CN1738E FILTER
ELF18D666P ELF18D666P FILTER
ETF46L333AY2 ETF46L333AY2 FLYBACK
ETF-46L333AY ETF-46L333AY FLYBACK TRANSFORMER
TKY4C1A015D2 TKY4C1A015D2 FRONT CABINET
XBA2C31TR0 XBA2C31TR0 FUSE
ERQ1CJP102S ERQ1CJP102S FUSE RESISTOR
ERQ12ZJ1R0 ERQ12ZJ1R0 FUSE RESISTOR
ERQ16NK1R0E ERQ16NK1R0E FUSE RESISTOR
TKK4C1A033A TKK4C1A033A GLASS
TMM6024-1 TMM6024-1 GUM
TUC4C1A054A TUC4C1A054A HEAT SINK
TUC4C1A066-A TUC4C1A066-A HEAT SINK
TUC4C1A068 TUC4C1A068 HEAT SINK
TUC4C1A069 TUC4C1A069 HEAT SINK
TP00351-51 TP00351-51 HOLDER
C0EAS0000018 C0EAS0000018 IC
BA225 BA225 IC
LA7840 LA7840 IC
MN1871681TG MN1871681TG IC
M52770ASP M52770ASP IC
S-80741AL-Z S-80741AL-Z IC
S24C02ADP-P S24C02ADP-P IC
0N3111 0N3111 IC
TJS2A9560 TJS2A9560 JACK
TBX4C1A062 TBX4C1A062 KNOB (S) POWER
TQF4C1A06813 TQF4C1A06813 LABEL
TQF4C1A07403 TQF4C1A07403 LABEL
SLR-56VC3FN SLR-56VC3FN LED
MA4047H MA4047H MA4047H
MA4120M MA4120M MA4120M
MAZ41800MF MAZ41800MF MA4180MTA
CK2020-CY CK2020-CY MAGNET
ECUV1H104KBN ECUV1H104KBN MCUV1E104KBM
ECUM1H121JCN ECUM1H121JCN MCUV1H121JCN
ECUV1H560JCN ECUV1H560JCN MCUV1H560JCN
TAFCSB500F48 TAFCSB500F48 OSCILLATOR
TSS4C816M32T TSS4C816M32T OSCILLATOR
TPD4C1A016A TPD4C1A016A PAD
TPC4C1A302 TPC4C1A302 PAPER
TPC4C1A303 TPC4C1A303 PAPER
CK2020P-CMA CK2020P-CMA PC BOARD
CK2020AP-CMA CK2020AP-CMA PC BOARD
CK2020AP-CML CK2020AP-CML PC BOARD
CK2020AP-CMS CK2020AP-CMS PC BOARD
TKP4C1A112 TKP4C1A112 PLATE
TSX4C1A013P TSX4C1A013P POWER CORD
ESB92DA1B ESB92DA1B POWER SWITCH
TMZ4C1A01001 TMZ4C1A01001 RAIL
TMZ4C1A01101 TMZ4C1A01101 RAIL
TKU4C1A017AA TKU4C1A017AA REAR CABINET
ERJ6GEYJ561V ERJ6GEYJ561V RESISTOR
ERJ6GEYJ223 ERJ6GEYJ223 RESISTOR
ERDS2FJ331 ERDS2FJ331 RESISTOR
ERJ8GCJ271 ERJ8GCJ271 RESISTOR
DGC3R05M DGC3R05M RESISTOR
ERC12ZGK335C ERC12ZGK335C RESISTOR
ERC12ZGK825C ERC12ZGK825C RESISTOR
ERDS1VJ4R7 ERDS1VJ4R7 RESISTOR
ERDS1TJ152 ERDS1TJ152 RESISTOR
ERDS1TJ154TT ERDS1TJ154TT RESISTOR
ERDS1TJ202 ERDS1TJ202 RESISTOR
ERDS1TJ222 ERDS1TJ222 RESISTOR
ERDS1TJ272 ERDS1TJ272 RESISTOR
ERDS2TJ223 ERDS2TJ223 RESISTOR
ERDS2TJ241 ERDS2TJ241 RESISTOR
ERDS2TJ562TD ERDS2TJ562TD RESISTOR
ERD2FAVJ1R5 ERD2FAVJ1R5 RESISTOR
ERD25FJ272 ERD25FJ272 RESISTOR
ERDS2FJ823 ERDS2FJ823 RESISTOR
ERG1ANJ332 ERG1ANJ332 RESISTOR
ERG2ANJ123 ERG2ANJ123 RESISTOR
ERG2ANJ3R3W ERG2ANJ3R3W RESISTOR
ERG2ANJ331 ERG2ANJ331 RESISTOR
ERG2ANJ360 ERG2ANJ360 RESISTOR
ERG2ANJ470H ERG2ANJ470H RESISTOR
ERG2ANJ6R2W ERG2ANJ6R2W RESISTOR
ERG3ANJ391 ERG3ANJ391 RESISTOR
ERJ6ENF1002 ERJ6ENF1002 RESISTOR
ERJ6ENF1243V ERJ6ENF1243V RESISTOR
ERJ6ENF1472 ERJ6ENF1472 RESISTOR
ERJ6ENF1962V ERJ6ENF1962V RESISTOR
ERJ6ENF2201V ERJ6ENF2201V RESISTOR
ERJ6ENF3301 ERJ6ENF3301 RESISTOR
ERJ6GEYJ271 ERJ6GEYJ271 RESISTOR
ERJ6GEYJ100 ERJ6GEYJ100 RESISTOR
ERJ6GEYJ101V ERJ6GEYJ101V RESISTOR
ERJ6GEYG104 ERJ6GEYG104 RESISTOR
ERJ6GEYG121 ERJ6GEYG121 RESISTOR
ERJ6GEYJ152V ERJ6GEYJ152V RESISTOR
ERJ6GEYJ155V ERJ6GEYJ155V RESISTOR
ERJ6GEJ274V ERJ6GEJ274V RESISTOR
ERJ6GEYJ331V ERJ6GEYJ331V RESISTOR
ERJ6GEYF473 ERJ6GEYF473 RESISTOR
ERJ6GEYG681 ERJ6GEYG681 RESISTOR
ERJ6GEYJ682V ERJ6GEYJ682V RESISTOR
ERJ6GEYJ683 ERJ6GEYJ683 RESISTOR
ERJ6GEYJ684V ERJ6GEYJ684V RESISTOR
ERJ6GEYJ821 ERJ6GEYJ821 RESISTOR
ERJ6GEYJ911 ERJ6GEYJ911 RESISTOR
ERJ6GEYJ915V ERJ6GEYJ915V RESISTOR
ERQ2CJP1R2S ERQ2CJP1R2S RESISTOR
ERQ2CJP100S ERQ2CJP100S RESISTOR
ER025TKF1783 ER025TKF1783 RESISTOR
TRF7ZK2R2T-1 TRF7ZK2R2T-1 RESISTOR
THT4C1A535 THT4C1A535 SCREW
XTB4_12CFX XTB4_12CFX SCREW
XTB4_15CFX XTB4_15CFX SCREW
XTB4_20CFX XTB4_20CFX SCREW
XTW3_12BFX XTW3_12BFX SCREW
TJS4CP05-L TJS4CP05-L SOCKET
TJS4C1144TA1 TJS4C1144TA1 SOCKET
TJS4C1145TA1 TJS4C1145TA1 SOCKET
TKK4C1A037-B TKK4C1A037-B SPACER
TMM4C1A052 TMM4C1A052 SPACER
TMM4C1A059 TMM4C1A059 SPACER
EAS12D310A6 EAS12D310A6 SPEAKER
TES201 TES201 SPRING
TMX4C1A009 TMX4C1A009 SUPPORT
EVQ4CTSVR-2T EVQ4CTSVR-2T SWITCH
TQB4C1A227 TQB4C1A227 TQB4C1A178
ETS29AK286NC ETS29AK286NC TRANSFORMER
TLH15462M TLH15462M TRANSFORMER
2SD601ARTX 2SD601ARTX TRANSISTOR
MSB709RT1 MSB709RT1 TRANSISTOR
2SC2258 2SC2258 TRANSISTOR
2SC5241 2SC5241 TRANSISTOR
2SD1275A-P 2SD1275A-P TRANSISTOR
2SD2499LBMA 2SD2499LBMA TRANSISTOR
2SD789ETZ 2SD789ETZ TRANSISTOR
VCUSTBH820JC VCUSTBH820JC VCUSTBH820JC
B800-0740-10 B800-0740-10 WIRE
B800-0740-17 B800-0740-17 WIRE
CK2020A1AWPB CK2020A1AWPB WIRE
CK2020A20WPA CK2020A20WPA WIRE
FBTFS3740-2 FBTFS3740-2 WIRE
XYN3_F12FJ XYN3_F12FJ XYN3+F10R
Main Menu x
