Model Image
Manufacturer

Rheem

Model Number

RGEA14048AJT081AAAJA

Description

Commercial Packaged Gas Electric

Interactive Exploded View

Parts List

Part Number Description
60-105055-01 60-105055-01 1/2-INCH HSI/DSI GAS VALVE
60-106207-01 60-106207-01 1/2-INCH SLOW OPEN NG GAS VALVE
51-100998-29 51-100998-29 1/3HP 208-230V 1SPD 1075 MOTOR
51-100998-19 51-100998-19 1/3HP 208/230V CCW FAN MOTOR
83-CD3608-6PK 83-CD3608-6PK 1/8-INCH COPPER TUBE
51-104306-00 51-104306-00 120/230V 1HP ECM MOTOR(NON-PR)
51-103823-00 51-103823-00 1HP 208-230V UNPROGRAMMED MTR
42-101208-02 42-101208-02 208-230V SPST N/O RELAY
46-25107-03 46-25107-03 208-240V-PRI 24V-SEC 40VA TRAN
70-23594-02 70-23594-02 22-INCHDIA 24DEG 1/2-INCH CCW 3BLD FAN
42-25101-01 42-25101-01 24V 30A 1POLE CONTACTOR
79-21491-83 79-21491-83 3/16X18-INCH RUBBER SILICONE TUBING
51-102497-00 51-102497-00 3/4HP 208/230V BLANK VARSPD MT
83-25151-41 83-25151-41 3/8-INCH 8CUIN LIQUIDLINEDRIER
47-22861-02 47-22861-02 300F M/R LIMIT SWITCH
62-22175-45 62-22175-45 45 NATURAL GAS ORIFICE
43-26271-48 43-26271-48 45/10MFD 370V ROUND RUN CAPAC.
43-25133-24 43-25133-24 45/10MFD 440V RND RUN CAPAC.
56-22114-01 56-22114-01 7/8-INCH DIAMETER VINYL GROMMET
47-102290-01 47-102290-01 A/R HIGH # LIMIT; 610OP 420CL
62-24340-05 62-24340-05 BLOWER CONTROL BOARD
703016 703016 BLOWER WHEEL 11 X 9-INCH 1/2-INCHBORE
70-100840-02 70-100840-02 BLOWER WHEEL AND HOUSING
61-22369-04 61-22369-04 BULKHEAD VALVE
AS-60993-04 AS-60993-04 BURNER ASSEMBLY
AE-61588-02 AE-61588-02 BURNER BRACKET
AE-58594-01 AE-58594-01 BURNER FLOOR
AE-58588-01 AE-58588-01 COLLECTOR BOX
AE-58599-01HT AE-58599-01HT COMBUSTION AIR INLET HOOD
56-18518-06 56-18518-06 COMPRESSOR MOUNTING GROMMET
45-100834-80 45-100834-80 COMPRESSOR WIRING HARNESS
AS-104395-03 AS-104395-03 CONDENSER COIL
62-23556-82 62-23556-82 DIRECT SPARK IGNITOR
56-23601-01 56-23601-01 DRAIN PAN FITTING GROMMET
AS-104910-01 AS-104910-01 EXHAUST HOOD ASSEMBLY
AS-58607-36 AS-58607-36 EXHAUST TRANSITION ASSEMBLY
62-23543-02 62-23543-02 FLAME SENSOR
45-25323-02 45-25323-02 FLAME SENSOR WIRE
68-23644-01 68-23644-01 GASKET - COLLECTOR BOX
AS-58632-87 AS-58632-87 HEAT EXCHANGER ASSEMBLY SS
70-23641-86 70-23641-86 INDUCED DRAFT BLOWER W/GASKET
68-23643-01 68-23643-01 INDUCER BLOWER GASKET
62-23599-05 62-23599-05 INTEGRATED FURNACE CONTROL
47-102436-06 47-102436-06 L110F LIMIT SWITCH AUTO RESET
47-102436-04 47-102436-04 L115F LIMIT SWITCH
83-ADK-083S 83-ADK-083S LIQUID LINE FILTER DRIER
81-101154-01 81-101154-01 MANIFOLD
81-23593-01 81-23593-01 MANIFOLD PLUG 1/8-INCH
65-104387-03 65-104387-03 MICRO CHANNEL EVAP COIL
65-104387-02 65-104387-02 MICRO CHANNEL EVAP COIL
70-19929-09 70-19929-09 MOTOR MOUNT ARM W/ GROMMET
70-19927-03 70-19927-03 MOTOR MOUNT BAND
60-103901-01 60-103901-01 NATURAL GAS VALVE
68-23603-01 68-23603-01 PVC TRAP
AE-58595-01 AE-58595-01 RADIATION SHIELD
42-105601-20 42-105601-20 SPSP PRESSURE SWITCH -.45WC
AE-58591-02 AE-58591-02 TURBULATOR
64-21106-02 64-21106-02 TXV BULB STRAP MOUNTING KIT
61-102211-41 61-102211-41 TXV3/8-INCH SWT.3 TONR410A30-INCH CAP
61-18551-01 61-18551-01 VALVE CORE
95-100906-08 95-100906-08 WIRE GRILLE
45-102393-82 45-102393-82 WIRE HARNESS 9PIN TO 9INSTERMS
51-103823-16 51-103823-16 X-13 MOTOR W/ROTOR 230V 1 HP
51-102497-27 51-102497-27 X-13 MOTOR W/ROTOR 230V 3/4 HP
51-102497-26 51-102497-26 X-13 MOTOR W/ROTOR 230V 3/4 HP
