Manufacturer
Rheem
Model Number
RKKLB180DL25EDNG
Description
Commercial Packaged Gas Electric
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
-.35-INCH WC SPST PRESSURE SWITCH |
|
|
-0.20-INCH WC SPST PRESSURE SWITCH |
|
|
-0.35 PRESSURE SWITCH KIT |
|
|
1/2HP 380-415/460V 1075RPM CCW |
|
|
1/8-INCH COPPER TUBE |
|
|
120-140F AUTO LIMIT SWITCH |
|
|
18X9 48BLADE WHEEL 1BORE |
|
|
24 5/8X19 5/8X1 3/4 FILTER |
|
|
24V 32A 3POLE CONTACTOR |
|
|
24V 40A 3POLE CONTACTOR |
|
|
3/16X18-INCH RUBBER SILICONE TUBING |
|
|
3/4-INCH HSI/DSI STDOP 2STG NG VLV |
|
|
3HP 208/230/460V 1SPD BLWR MTR |
|
|
40X1 BLOWER SHAFT |
|
|
460/575VPRI 25VSEC 100VA XFRMR |
|
|
460V INDUCED DRAFT BLWR W/GSKT |
|
|
4BLD 24-INCH DIA CCW 24DEG FAN BLDE |
|
|
A/R HI LIMIT 610OP 420CL |
|
|
ADJUSTABLE SHEAVE |
|
|
ANGLE BLOWER CONNECTOR |
|
|
BEARING BRACKET |
|
|
BEARING W/CUSHING; 1-INCH BORE |
|
|
BLOWER HOUSING ASSEMBLY |
|
|
BURNER BRACKET |
|
|
BURNER HALVES ASSEMBLY |
|
|
CAPAC 10 MFD 440V OVAL |
|
|
CAPACITOR STRAP |
|
|
COMPRESSOR MOUNTING GROMMET |
|
|
DIRECT SPARK IGNITOR |
|
|
DISCONNECT PLATE |
|
|
DRAIN PAN |
|
|
EVAPORATOR COIL |
|
|
FLAME SENSOR |
|
|
GAS MANIFOLD |
|
|
GASKET |
|
|
INDUCER GASKET |
|
|
INDUCER MOUNTING PLATE |
|
|
INDUCER PLATE GASKET |
|
|
INTEGRATED FURNACE CONTROL |
|
|
KEY |
|
|
LIMIT SWITCH/DEFROST SENSOR |
|
|
LIMITSHIELDASSEMLBY |
|
|
LOW PRESS LIMIT 250#OP 450#CL |
|
|
LOW#LIMIT OPEN50 CLOSE95 |
|
|
MANIFOLD PLUG 1/8-INCH |
|
|
MICRO CHANNEL COIL |
|
|
NATURAL GAS BURNER ORIFICE |
|
|
PRESSURE CONTROL BOARD |
|
|
RHEEM 47-22861-01 LIMIT SWITCH - L350F MANUAL RESE |
|
|
RUN CAPAC 10 MFD 370V OVAL |
|
|
SPST N/C M/R LIMIT; 400OP |
|
|
TERMINAL BLOCK |
|
|
TURBULATOR |
|
|
VALVE CORE |
|
|
VARIABLEPITCHSHEAVE 7/8-INCH BORE |
|
|
WIRE GRILL |
