Model Image
Manufacturer

Rheem

Model Number

RLNNA048CM000

Description

Commercial Packaged Ac

Interactive Exploded View

Parts List

Part Number Description
51-100998-30 51-100998-30 1/3HP 208-230V 1075RPM 48 MTR
70-23589-01 70-23589-01 10-INCHDIA 10-INCHW CCW 3/4-INCHWHEEL
46-101904-02 46-101904-02 208/240V-PRI 24V-SEC 50VA
70-23137-01 70-23137-01 24-INCH DIA 19DEG 1/2-INCH CCW 2BLD FAN
70-42484-01 70-42484-01 24-INCHDIA 25DEG 1/2-INCH CCW 3BLD FAN
42-25103-01 42-25103-01 24V 32A 3POLE CONTACTOR
42-25104-06 42-25104-06 24V SPDT NO/NC RELAY
70-21933-02 70-21933-02 3/4-INCHX17 3/8-INCH BLOWER SHAFT
51-21909-01 51-21909-01 3/4HP 208-230/460V 1725RPM MTR
83-25151-41 83-25151-41 3/8-INCH 8CUIN LIQUIDLINEDRIER
61-102211-33 61-102211-33 3/8-INCHX3/8-INCH 3TON R-410A TXV
44-ATC3-5PK 44-ATC3-5PK 3A FUSE; 5PK 44-ATC3-5PK
71-104627-01 71-104627-01 6.45-INCH FIXED SHEAVE; 3/4-INCH BORE
47-102240-03 47-102240-03 95#-CLS 50#-OPN AUTO RESET LMT
47-23699-04 47-23699-04 A/R HI LIMIT 610OP 420CL
AS-58990-01HT AS-58990-01HT ACCESS PANEL
70-41911-01 70-41911-01 BEARING & CUSHION
AS-101336-85 AS-101336-85 BLOWER ASSEMBLY - BELT DRIVE
AE-101124-01 AE-101124-01 BLOWER BRACKET
AE-64401-05 AE-64401-05 BLOWER CUT-OFF
AS-101341-01 AS-101341-01 BLOWER HOUSING
AE-58950-02 AE-58950-02 BLOWER SUPPORT
56-18518-06 56-18518-06 COMPRESSOR MOUNTING GROMMET
45-100834-80 45-100834-80 COMPRESSOR WIRING HARNESS
AS-104518-01 AS-104518-01 CONDENSER COIL
AE-101467-01 AE-101467-01 CROSS BRACE
68-23559-01 68-23559-01 DRAIN PAN
AS-104531-01 AS-104531-01 EVAPORATOR COIL
54-17531-10 54-17531-10 FILTER
AE-58934-01 AE-58934-01 FILTER CHANNEL
47-23699-06 47-23699-06 HI PRESSURE LIMIT M/R 610#
94-22030-01 94-22030-01 KEY 3/16-INCH X 3/16-INCH X 1 1/4-INCH
AS-59152-01 AS-59152-01 LIMITSHIELDASSEMLBY
83-ADK-083S 83-ADK-083S LIQUID LINE FILTER DRIER
AS-101340-01 AS-101340-01 MOTOR MOUNT ASSEMBLY
43-25134-02 43-25134-02 RUN CAPAC 5 MFD 370V OVAL
42-21593-03 42-21593-03 TIME DELAY RELAY
95-101660-01 95-101660-01 TOP WIRE GRILL
70-41723-03 70-41723-03 TRI-ARM ASSEMBLY
64-21106-02 64-21106-02 TXV BULB STRAP MOUNTING KIT
61-18551-01 61-18551-01 VALVE CORE
71-104625-05 71-104625-05 VARIABLEPITCHSHEAVE 5/8-INCH BORE
