Manufacturer
Rheem
Model Number
RQNLB024JK000
Description
Residential Heat Pump - Packaged Unit
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1/3HP 208-230V 825RPM 1PH MTR |
|
|
1/4HP 208-230V 1075RPM 3SP MTR |
|
|
1/8-INCH COPPER TUBE |
|
|
208-230V1PH 1/5HP 1075RPM MTR |
|
|
208/230-24V 40VA TRANSFORMER |
|
|
208/230V1PH 21300BTU R410A |
|
|
22-INCH DIA 21DEG 1/2-INCH CCW 2BLD FAN |
|
|
22-INCH DIA 28DEG 1/2-INCH CCW 3BLD FAN |
|
|
24V 30A 1POLE CONTACTOR |
|
|
24V SPDT NO/NC RELAY |
|
|
3/4X1/2 24V 4TON REVERSING VLV |
|
|
3/4X1/2 24V REVERSING VALVE |
|
|
3/8-INCH BI-FLOW FILTER DRIER |
|
|
3/8-INCH LIQUID LINE FILTER DRIER |
|
|
3/8X3/8 R410A 2TON TXV; 30-INCH CAP |
|
|
40/5/370 DUAL ROUND CAPACITOR |
|
|
40/5MFD 370V RND RUN CAPACITOR |
|
|
40/5MFD 440V ROUND CAPACITOR |
|
|
5/8X3/8-INCH 2TON REVERSING VALVE |
|
|
9-INCH DIA 7-INCH W CW 1/2-INCH WHEEL |
|
|
A/R LOW # LIMIT; 15OP 40CL |
|
|
AUXILIARY DRAIN PIPE |
|
|
BLOWER ASSEMBLY |
|
|
BLOWER CUT OFF |
|
|
BLOWER HOUSING |
|
|
BULB STRAINER |
|
|
BULKHEAD VALVE |
|
|
COMPRESSOR MOUNTING GROMMET |
|
|
COMPRESSOR WIRING HARNESS |
|
|
CONDENSER COIL |
|
|
DEFROST AND AMBIENT SENSOR KIT |
|
|
DEFROST CONTROL BOARD KIT |
|
|
DEFROST CONTROL BOARD KIT |
|
|
DEFROST CONTROL BOARD KIT |
|
|
DEFROST CONTROL BOARD KIT |
|
|
DEFROST CONTROL KIT |
|
|
DISTRIBUTOR ASSEMBLY |
|
|
DRAIN PAN |
|
|
DRAIN PAN FITTING GROMMET |
|
|
EVAPORATOR COIL W/DRAIN PAN |
|
|
MOTOR MOUNT ARM W/GROMMET |
|
|
MOTOR MOUNT BAND |
|
|
PVC TRAP |
|
|
RUN CAPAC 5 MFD 370V OVAL |
|
|
SPST N/C A/R LIMIT;145OP 125CL |
|
|
TIME DELAY RELAY |
|
|
TRANSFORMER |
|
|
TXV BULB STRAP MOUNTING KIT |
|
|
VALVE CORE |
|
|
WIRE GRILLE |
