Manufacturer
Saeco
Model Number
10002292
Description
Incanto De Luxe A9 A13 Sup021ybdr
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
(0301.R04.150)SPARE SLEEVE UNIT GREY |
|
|
(0701.014.150)SEAL CONTAINER GREY |
|
|
(0701.031.150)SEAL COVER GREY |
|
|
(11000197)PROTEZIONE X SCHIZZI GRUPPO CAFFE SMART |
|
|
(11000467)BLACK GRINDER SUPP. PLATE V3 SMART1 UL 120V |
|
|
(11000514)GENERAL MOTOR ASS.MC/V3.1 120V 120V |
|
|
(11000516)GENERAL MOTOR ASS.MC/V3.1 230V |
|
|
(11000750)TEA/BRASS CONNECT.FOR SILICONE TUBE |
|
|
(11001021)MATT SILVER CASING SMART |
|
|
(11001556)MOLLA RASATORE H=49 X GRUPPO CAF.SMART |
|
|
(11001695)AS.CONTEN.CAFFE GRUPPO SMART1 NEW NER |
|
|
(11001845)BLACK POWER CABLE KOREA 3X1,25 L=1600 |
|
|
(11001860)SILVER 13 COVER SMART/UL S/SCREEN DLX KOREA COMPLETE |
|
|
(11001861)SILVER 13 COVER SMART/UL S/SCREEN DLX KOREA |
|
|
(11002322)COFF. DISPENSER TUBE FOR ADJUST.SHAFT FROM S/N 9006SA40349625 |
|
|
(11002323)CONIC SEAL FOR COFFEE DISPENSER TUBE FROM S/N 9006SA40349625 |
|
|
(11002606)BOILER SUPPORT CONNECTOR |
|
|
(11002814)ELECTR.BOARD POWER SUP021YBDR/V1 230V |
|
|
(11002849)AS.PIST.C/DOCCIA S/MOLLA GRUP.SMART1 NER |
|
|
(11003037)MOTOR FOR RATIOMOTOR ASSY. |
|
|
(11003075)AS.CONT.CAF.C/BOCC.SALD.GRUP.P124 8G.NER |
|
|
(11003077)AS.PISTONE INTEGRALE GRUP.P124 8GR.NERO |
|
|
(11003078)BIELLA X GRUPPO P124 8GR.NERO |
|
|
(11003426)BLACK BREW UNIT V3 NEW/SBS SMART (SEE EV FOR DETAIL) |
|
|
(11003428)CONTROPISTONE X GRUPPO CAFF.SMART NERO |
|
|
(11004161)RASATORE X GRUPPO CAFFE NERO |
|
|
(11004209)SUPPORT FOR ALLUMINIUM BOILER SMART |
|
|
(11004354)MOTOR COFFEEGRINDER/V3.1 IME ASSY. 230V FROM S/N 9005SA40362332 |
|
|
(11004409)MOTOR COFFEEGRINDER/V3.1 IME ASSY. 120V |
|
|
(11004550)BLECKMAN RESISTANCE SMART ASSY. 230V |
|
|
(11004667)ALUM.BOILER WITH RESISTANCE 230V-1100W |
|
|
(11004689)TEA/BRASS SAFETY VALVE 16-18 BAR ASSY. |
|
|
(11005044)SAECO KLUBER TRIBOSTAR SIL 2 TUBE 5GR. |
|
|
(11005099)NATURAL CURSOR V2 FOR BOILER P119 |
|
|
(11005343)BLACK FAUCET SUPPORT V2 SMART |
|
|
(11005555)BLACK DUMP BOX SMART SILK/SCREEN |
|
|
(11005920)PIASTRA ANT.GRUPPO SMART S/F.NER.SER.NEW |
|
|
(11006440)BLACK GRINDER SUPPORT PLATE V3 SMART1 230V |
|
|
(11007641)POWER BOARD P120/V1 DL 120V |
|
|
(11007666)AS.COP.SMART/NT UL C/AP.A13/120V SER.DLX U.S.A. COMPLETE |
|
|
(11009013)TEA/BRASS PIN FOR PISTON L=10 |
|
|
(11009019)TEA/BRASS PISTON L=20,9 ASSY. |
|
|
(11009162)DOCCIA D=35,8 276FORI C/VITE M3X20 LUCID |
|
|
(11009327)BLACK BOILER COVER SMART UL |
|
|
(11009360)BOILER SUPPORT PLATE SMART UL ASSY. 120V |
|
|
(11009371)NATURAL TURBINE SUPPORT SMART UL |
|
|
(11010353)BOILER SMART/RS V3 230V ASSY. COMPLETE |
|
|
(11010624)TRANSP.SILICONE TUBE 10,5X12,3 L=200 MM |
|
|
(11011205)TEA/ZAMA INCREASE SCREW GRINDER FROM S/N.9008GA40111061 |
|
|
(11012031)TRANSP.SILICONE TUBE 10,5X12,3 L=170 MM |
|
|
(11023086)AS.GEN.PISTONE INTEGR.GRUP.CAF.8GR.NER. |
|
|
(11023172)MOUNTING PLATE WITH PIN V2 NESPR.UL ASSY KOREA |
|
|
(11026355)BLK GROUND COFF.OUTLET CONVEYOR V4 ASSY. |
|
|
(12000131)ULKA PUMP EP5/S 120V-60HZ |
|
|
(12000140)ULKA PUMP EP5/S GW 230V-50HZ |
|
|
(12000182)ULKA PUMP EP5/S GW 220V-60HZ |
|
|
(12000381)SCREW TSP PZ2/TT M3X8 UNI 8109 ZINC |
|
|
(12000450)SCREW TCBR TORX 10 3,5X12 PLAST.GALVANIZ |
|
|
(12000550)VITE TCB 3X25 PLAST.INOX |
|
|
(12000892)OETIKER CLAMP D=9,5 16700004 |
|
|
(12000895)VITE TSP 3X10 PLAST.INOX |
|
|
(12000897)VITE TCB 3,5X20 PLAST.INOX |
|
|
(122842121)EXTERNAL COVER ST.STEEL PANNAR.G100 |
|
|
(123030200)RADIAL BEARING 61900.2RS1 |
|
|
(123030300)AXIAL BEARING EKKO 342.35252 |
|
|
(123453102)SELF LOCK NUT M4 DIN 982 HIGH GALV. |
|
|
(123453602)FLANGE NUT M8 TOOTHED BASE GALV. |
|
|
(123453902)SELF-LOCKI.NUT M5X0,8 DIN 980 CLA.8 |
|
|
(125743421)STAINLESS STEEL GRATE SMART |
|
|
(126764718)SPRING FOR WATER CONTAINER VALVE |
|
|
(126772018)SPRING DI=7,5 FOR FABRIC FINISH TUB |
|
|
(126772518)SPRING FOR CREAM ADJUSTMENT SHAFT |
|
|
(126772918)SPRING FOR ADJUSTMENT GRINDING GEAR |
|
|
(126773318)MOLLA X PISTONE GRUPPO SMART1 |
|
|
(126838117)2 THERMOSTATS FIXING SPRING |
|
|
(126838217)SENSOR FIXING SPRING |
|
|
(126838818)SPRING FOR BEAN COFFEE CONTAINER |
|
|
(126838918)SPRING FOR BUTTON BEAN CONTAINER COF. |
|
|
(127390100)BRUSH FOR CLEANING |
|
|
(127473603)STEEL PIN M4-M6 FOR INCREMENT SCREW UP TO S/N.9008GA40111060 |
|
|
(127535319)THERMAL FUSE FIXING PLATE |
|
|
(127535820)PLATE FOR DOOR METALLIC SMART |
|
|
(127573900)PLATE WITH LOGO SAECO SMART DIAMOND |
|
|
(128310321)WASHER UNI 8842 A3 SS |
|
|
(128310402)GALV.WASHER UNI 8842 A4 FROM S/N.9008GA40111061 |
|
|
(128310404)WASHER UNI 8842 A4 BURNISHED |
|
|
(128381800)CRINKLE WASHER 21,8X15,8X0,2 |
|
|
(128381902)GALVAN.FLAT WASH.DI=4,3 DE=14 SP=1,5 |
|
|
(129511903)SCREW TCB 2,9X6,4 DIN 7981 BZ NICK |
|
|
(129512503)SCREW TCB 2,9X9,5 DIN 7981 NICK |
|
|
(129532521)SCREW TSP2,9X9,5 DIN 7982 SS |
|
|
(129533202)SCREW TSPTORX T10 3,5X9,5 D7982 NI |
|
|
(129535721)SCREW TSP3,5X9,5 DIN 7982 SS |
|
|
(129562603)SCREW TSC PZ-B 2,9X9,5 UNI 6956 NI |
|
|
(129571121)SCREW TCB PH/SW 3X14 UNI 8112 INOX |
|
|
(129571521)SCREW TCB PH/SW 3X18 UNI 8112 INOX |
|
|
(129573202)SCREW TCB TORX 20 M4X8 AUTOF. ZN-B |
|
|
(129573402)SCREW TAPT M4X10 DIN 7985 GALV |
|
|
(129574802)SCREW TCB TORX 20 M4X30 ZN-B FROM S/N.9008GA40111061 |
|
|
(129660902)SCREW PANELVIT TCB 3,5X12 D.7505 ZNP |
|
|
(129661702)SCREW TCB TORX 3,5X30 PLAST.ZN-B |
|
|
(129670302)PANE.TCB SCREW 2,9X9,5 TES.D=7,5 ZN |
|
|
(129740202)SCREW TSP PH/TT 4X10 UNI 8113 ZNP UP TO S/N 9005SA40022836 |
|
|
(129823802)TCB SCREW M4X8 UNI 7687 ZNP |
|
|
(129852821)VITE TSP M3X14 UNI 7688 INOX |
|
|
(129910103)HI LO TC SCREW 3,5X15 RIF.910189 |
|
|
(129910921)VITE TCB 3X10 PLAST.INOX |
|
|
(129912521)VITE TCBR 3,5X14 PLAST.INOX |
|
|
(129912902)SCREW TCB TORX 10 2,9X6,5 SHEET ZN-B |
|
|
(129913202)SCREW TCB TORX 10 3X8 PLAST.ZN-B |
|
|
(129913902)SCREW TCB TORX 10 3X12 PLAST.ZN-B |
|
|
(129914002)SCREW TCB TORX 10 3,5X16 PLAST.ZN-B |
|
|
(129932202)ROUND HEAD SCREW 10.9 M5X20 GALV |
|
|
(129932502)GALVANIZDE SELF DRILLING SCREW 5X30 |
|
|
(140320459)OR METRICO 0080-20 SILICON.PTFE/FDA |
|
|
(140320461)OR ORM 0080-20 IN TERMOIL |
|
|
(140320762)OR 108 IN SILICONE |
|
|
(140321961)OR 2031 IN TERMOIL |
|
|
(140324362)OR METRIC 0060-30 IN SILICONE |
|
|
(140324461)OR ORM 0060-20 IN TERMOIL |
|
|
(140326661)OR METRIC 0040-20 IN EPDM |
|
|
(140328059)OR 2015 IN SILICONE PTFE/FDA |
|
|
(140328461)EPDM OR METRIC 0190-10 |
|
|
(140328960)NBR FDA OR METRIC 0530-15 |
|
|
(140329162)OR 117 IN SILICONE 70 SH |
|
|
(140329262)OR METRICO 0380-40 IN SILICONE |
|
|
(140329361)OR METRICO 0100-25 IN TERMOIL |
|
|
(140360500)FELT RING 45,4X39,4X4 |
|
|
(140640200)CREAM ADJUSTMENT SHAFT |
|
|
(141600750)BIELLA X GRUPPO SMART1 NERA |
|
|
(142816500)WATER CONTAINER LID SMART NAT./GREY |
|
|
(142905450)UPPER BODY WITH COFFE.GROUND OUTLET |
|
|
(142990150)CONTROPISTONE GRUPPO SMART1 NERO |
|
|
(144752300)DEADLOCK MOTOR FLANGE SMART1 |
|
|
(145501211)RED FLOAT FOR DRIP TRAY SMART |
|
|
(145842900)WATER CONTAIN.VALVE SEAL GACO DIM14 |
|
|
(145854360)GROUND COFFEE CONT.SEAL UPPER SMART1 |
|
|
(145854462)GROUND COFFEE CONT.SEAL LOWER SMART1 |
|
|
(145854562)COFFEGRIND.MOTOR SUPP. SEAL SMART1 |
|
|
(145854662)COFEGRIND.MOTOR ANTIVIBR.SEAL SMART |
|
|
(145854760)BEAN COFFEE CONTAINER SEAL SMART |
|
|
(145854962)SEAL FOR COFFEE DISPENSER V2 SMART |
|
|
(145896949)RETAINING INSERT TEFLON TUBE |
|
|
(145897300)INSERT GRINDING ADJUSTM.KNOB SMART |
|
|
(145951600)ELECTRIC INSULATING DISK D=16 |
|
|
(146002150)COFFEE GRINDIN. ADJUSTMENT GEAR SMART |
|
|
(146313740)DISENGA. LEVER GREY/SILVER DOOR SMART |
|
|
(146520100)BAKED CLAY GRINDER 48X28 |
|
|
(146580950)BLACK KNOB WATER CONTAINER LID SMAR |
|
|
(146680850)BLACK COFFEE MEASURE SMART |
|
|
(147472750)PIN FOR DEADLOCK SPRING SMART1 DIG. |
|
|
(147623150)BLACK SQUARE ADHESIVE FOOT 5023 |
|
|
(147660562)GREY WATER VALVE CONTAINER PISTON |
|
|
(147700200)LOADING PUMP DIAMETER 17 MM |
|
|
(147755800)INT.CASING PROTECTION POWER CABLE |
|
|
(147755900)HEAT.ELEM. PROTECTION BLECKM. SMART |
|
|
(147756400)PROTECTION FAUCET BODY WATER/STEAM |
|
|
(147756562)PROTECT. FOR FOLK SPRING TUBE D=4 |
|
|
(147757050)STEAM TUBE PROTECTION |
|
|
(147920150)90CONNECTOR PUMP INLET |
|
|
(147922249)CONNECTOR FOR ARTICULATED JOINT |
|
|
(147990150)RASATORE X GRUPPO SMART1 NERO |
|
|
(148380200)WASHER BAKELIZZATE D=5,5 |
|
|
(148380800)MYLAR WASHER DE=19 DI=12 SP=0,2 |
|
|
(148600600)CABLE CLAMP V0 MAGIC ESP COMBI UL |
|
|
(148601650)GROMMET FOR POWER CABLE SMART |
|
|
(148620900)SEMISPHERE SEAL FOR ARTICULAT.JOINT |
|
|
(149185850)SUPPORT FOR EATON PUMP |
|
|
(149194618)SUPPORT WATER CONT. W/O LAMP HOUSING |
|
|
(149194650)SUPPORT WATER CONT. W/O LAMP HOUSING |
|
|
(149194800)TURBINE SUPPORT SMART |
|
|
(149197700)SUPPORT FOR ALLUMINIUM BOILER SMART FROM S/N 9005SA40230572 |
|
|
(149198250)UPPER GRINDER SUPPORT COFFEEGRINDER |
|
|
(149198350)LOWER GRINDER SUPPORT COFFEEGRINDER |
|
|
(149198700)SUPPORT CREAM ADJUSTMENT SHAFT |
|
|
(149198850)SUPPORTO TUBO TEFLON GRUPPO SMART NER |
|
|
(149198859)SUPPORTO TUBO TEFLON GRUPPO SMART GRI |
|
|
(149199050)SENSOR SUPPORT FOR COFF.GRIND.MOTOR |
|
|
(149199750)UPPER GEAR SUPP. COFFEEGRINDER SMART |
|
|
(149199850)LOWER GEAR SUP. COFFEEGRINDER SMART |
|
|
(149200450)SUPPORT FOR ARTICULATED JOINT |
|
|
(149202550)SWITCH GENERAL SUPPORT BLACK SMART |
|
|
(149205710)PUMP SUPPORT HOLE 13,2 RED |
|
|
(149213000)TRANSP.CAP FOR KNOBS BEAN CONTAINER |
|
|
(149213450)CAP FOR COFFEE DISPENSER TUBE FROM S/N 9006SA40349625 |
|
|
(149214359)BLACK CAP FOR FLOATING SPACE LAV. |
|
|
(149214800)CAP FOR WORM SCREW MC/V3 CENTRING |
|
|
(149252850)OPENING BUTTON BEAN CONTAINER COFFE |
|
|
(149253100)TOUCH PANEL 4+3 BUTTONS SMART DIGIT |
|
|
(149261350)TRAMOGGIA GRUPPO CAFFE SMART1 NERO |
|
|
(149261500)HOPPER GROUND COFFEE DOSER SMART |
|
|
(149360200)SILICONE TUBE 5X8 70SR IN ROLL |
|
|
(149361200)BLACK SILICONE TUBE 7,5X9,3 IN ROLL |
|
|
(16000380)5X8,9 SILICONE TUBE IN ROLL |
|
|
(165897300)INSTRU.MANUAL SAECO TYPE SUP021YBDR |
|
|
(165897327)INSTRU.MANUAL SAECO TYPE SUP021YBDR |
|
|
(175897300)LOWER TECHMATE INSERT FOR BOX SMART |
|
|
(175898600)UPPER TECHMATE INSERT FOR BOX SMART1 |
|
|
(178517600)DISPLAY BOX SAECO INCANTO S-CLASS |
|
|
(179990300)BAND FOR LIFTING L=1550 H=300 MM |
|
|
(181540900)ELECTRONIC BOARD WITH SENSOR HAL506 |
|
|
(183440800)CABLE 1 WIRE SILIC.BLACK THERM/FUSE 229 |
|
|
(183922450)CAVO AL.USA SJT 3C 16AWG NERO L=1500 |
|
|
(183930850)BLACK POWER CABLE CH H05+3FAST.L=1500 |
|
|
(183940950)BLACK POWER CABLE AUST.H05+3FAS.L=1500 |
|
|
(184320200)SPRING HOSE CLAMP D=9,5MM |
|
|
(184651100)ANTIDISTURB FILTER 0,47X2+1000Y2+0,5L 230V |
|
|
(184651500)FILTRO ANTIDIST.16A F.NC.16.10.474.472.A 120V |
|
|
(186400903)FLAT TABS 6,3 210380440 |
|
|
(186723800)MICROSWITCH SAIA X3M502K2KAM92AS |
|
|
(186724200)MICROSWITCH SAIA X3M502K2KAJ32AV |
|
|
(189428200)THERMOSTAT 175 1NT-08L-3794 |
|
|
(189428300)THERMOSTAT 175 INTERCONTR.161471002 |
|
|
(189428600)THERMOSTAT 175 1NT-08L-5125 UP TO S/N. 9008GA40129106 |
|
|
(192200300)20X2 LCD WHITE DISPLAY FSTN |
|
|
(20000202)SPARES KIT MOTOR COFFEEGRIND./V3 230V UP TO S/N 9005SA40362331 |
|
|
(20000204)SPARES KIT SUPPORT BOILER SMART UP TO S/N 9005SA40230571 |
|
|
(20000230)KIT SPARES FOR SENSOR MC/V3 SMART UP TO S/N 9005SA90357734 |
|
|
(20000440)GRUPPO RICAMBIO MANICOTTO NERO |
|
|
(20000960)SPARES KIT FOR COF. DISPENSER TUBE NEW UP TO S/N 9006SA40349624 |
|
|
(20007014)KIT AS.RUB.VAP.SMART COMPLETE |
|
|
(21001406)ACC SAE MAVEA UNI.WAT.FILTERX1 USA |
|
|
(220380259)ROTATING RING SMART WITH 3 FEET WITH PART. #92 |
|
|
(222270249)UPPER TUBE ASS.FOR PANNARELLO |
|
|
(222360450)CASING WITH KNOB SMART BLACK |
|
|
(222630526)DOOR HINGE SMART SILVER A13 FROM S/N 9005SA40022837 |
|
|
(222630550)DOOR HINGE SMART BLACK FROM S/N 9005SA40022837 |
|
|
(222802340)CUP WARMING LID SMART STAINSTEEL-SB |
|
|
(222802400)GROUND COF.CONT.LID CLASSIC NATGREY |
|
|
(222813826)SILVER 13 COVER SMART SILK/SCREEN DLX |
|
|
(222813850)BLACK COVER SMART SILK/SCREEN DELUXE |
|
|
(222847926)SILVER 13 COVER SMART SILK/SCREEN DLX COMPLETE |
|
|
(222847950)BLACK COVER SMART SIL/SCREEN DELUXE COMPLETE |
|
|
(223701026)SILVER/A13 COFFEE DISPENSER AS.SMART |
|
|
(223701050)BLACK COFFEE DISPENSER AS.SMART |
|
|
(224640200)EXTERNAL FILTER FOR WATER CONTAINER ASSY WITH PART.#10 |
|
|
(224890626)SILVER A13 FRONT.PANEL SMART DELUXE AS. |
|
|
(224890650)BLACK FRONT.PANEL SMART DELUXE ASSY. |
|
|
(225920108)HANGRIP DX SMART CHROMED |
|
|
(225920141)HANGRIP SX SMART SILVER |
|
|
(225920208)HANGRIP SX SMART CHROMED |
|
|
(225920241)SILVER LEFT HANDGRIP SMART |
|
|
(226000300)GEAR SX Z=38 FOR GRINDER MOTION ASSY. |
|
|
(226481426)DOOR HINGE KIT SMART SILVER A13 UP TO S/N 9005SA40022836 |
|
|
(226481450)DOOR HINGE KIT SMART BLACK UP TO S/N 9005SA40022836 |
|
|
(227470150)PIN BLACK ASS.FOR PERCOLATOR |
|
|
(227532950)PIASTRA ANT.GRUPPO SMART S/FORO NER.SER |
|
|
(227533000)ASSEMBLY BOILER SUPPORT PLATE SMART 230V |
|
|
(227660950)AS.PISTONE C/INS.M3 X GRUPPO SMART1 NERO |
|
|
(227680150)AS.PIST.C/DOCCIA C/MOLLA GRUP.SMART1 NER |
|
|
(227701104)CREAM ADJUSTM.KNOB GLOSS CHR.PLATED |
|
|
(227710904)STEAM KNOB ZAMAS CHROM.PLATED SMART |
|
|
(227721800)GRIND.ADJUST.NATGREY KNOB SMART S/S |
|
|
(227751808)CUPS PROTECTION SMART/DIG.CHROMED |
|
|
(227874900)CONNECTOR AS.TEFLON 2X4 L=250 MM |
|
|
(227875400)CONNECTOR AS.TEFLON 2X4 L=330 MM |
|
|
(227876800)CONNECTOR AS.TEFLON 2X4 L=235 MM |
|
|
(227900303)BRASS/NIK.CONNEC.FOR BOILER SUPPORT |
|
|
(227961303)STRAIGHT CONNECTOR |
|
|
(228660204)CONNECTOR FOR STEAM TUBE |
|
|
(228660304)CONNECTOR FOR STEAM TUBE |
|
|
(228982950)DOOR METALL SMART BLACK |
|
|
(229141008)BUTTON SMART DELUXE CHROMIUM PLATED |
|
|
(229170450)SEALING SUPPORT AS.WATER DRIP TRAY |
|
|
(229171626)SUPPORT ELEC.CARD AS.021YBDR SILVER |
|
|
(229171650)SUPPORT ELECT.CARD AS.021YBDR BLACK |
|
|
(229183126)SUPPORT DOOR METAL.SMART SILVER A13 |
|
|
(229183150)SUPPORT DOOR METALLIC SMART BLACK |
|
|
(229183526)SUP.HINGE DOOR METAL.SMART SILV.A13 |
|
|
(229183550)SUPPOR.HINGE DOOR METAL.SMART BLACK |
|
|
(229183726)SILVER A13 SUPPORT GRATE METAL SMART |
|
|
(229183750)BLACK SUPPORT GRATE METAL SMART |
|
|
(229184704)COFFEE DISPENSER SUPPORT WITH HOLE |
|
|
(229200250)BLACK CAP FOR KNOB CREAM ADJUSTMENT |
|
|
(229452100)COMPENSATION ANDSAFETY VALVE16BAR ASSY |
|
|
(229452400)AS.GEN.VALV.SAECO BREWING SYSTEM SMART |
|
|
(229630826)SILVER A13 DRIP TRAY SMART |
|
|
(229630850)BLACK DRIP TRAY SMART |
|
|
(281565158)ELECT.BOARD CPU SMART SUP021YBDR ASSY. WITH PART.#115 |
|
|
(282058855)ALU.BOILER WITH RESISTANCE 120V -1100W |
|
|
(282058858)ALUM.BOILER WITH RESISTANCE 230V -1100W |
|
|
(282135558)ALUM.BOILER 230V AS.WITH RESISTANCE COMPLETE |
|
|
(283551300)3POLE CONNECT.AS.TURBINE JP18 SMART |
|
|
(283551900)2 POLE LEVEL SENSOR AS.SMART 230V |
|
|
(283551955)2 POLE LEVEL SENSOR AS.SMART 120V -220V |
|
|
(286473300)VDE TURBINE WITH SENS |
|
|
(288140455)AS.RESIS.BLECKMAN 30176 FILET. 120V-1000W |
|
|
(288140458)HEATING-ELEMENT BLECKMAN ASSY. 230V-1000W |
|
|
(288582300)SENSOR ELECT.BOARD WITH CONNECT. ASSY. |
|
|
(289201000)AS.TERMPR.TERMICO 120C CAV.125/365 120V |
|
|
(301.961)WATER HARDNESS TEST |
|
|
(311.807)YELLOW HARNESS KLIXON JP 13 230V |
|
|
(4301018000)LOWER INTERNAL PIPE |
|
|
(9011.1)PEG FOR VALVE IN PLASTIC |
|
|
(9011.132)SPRING FOR PIN |
|
|
(9011.144)FORK FOR TUBE D.4 |
|
|
(9121.042)GEAR Z.12/90 |
|
|
(9121.044)ANTIVIBRATION FOR MOTOR |
|
|
(9121.046)SINTERED BUSH FOR MOTOR |
|
|
(9121.069.150)GEAR Z=108 FOR MOUNTING PLATE M4000 |
|
|
(9141.001)BRASS NCREMENT SCREW MC UP TO S/N.9008GA40111060 |
|
|
(9160.075)PERCOLATOR DE=35,8 ELFO ASSY. |
|
|
(9161.018)BRACKET FOR TURBINE |
|
|
(9161.046)MOLLA X RASATORE GRUPPO |
|
|
(9161.064.050)MANICOTTO ENTRATA ACQUA GRUP.CAFF.NERO |
|
|
(9161.066.050)ALBERO A GOMITO X GRUPPO NERO |
|
|
(9161.094.050)BLOCCHETTO FORATO GRUP.CAFFE PA/NERO |
|
|
(9161.112.150)LEVEL FLOAT GREY |
|
|
(9161.132)MYLAR WASHER FOR RATIOMOTOR |
|
|
(9161.167)DOCCIA D.35,8 |
|
|
(9161.191)BOCCOLA PISTONE GRUP.CAFF.M5000 NEUTRO |
|
|
(9161.198)MOLLA PISTONE GRUPPO CAFFE M5000 |
|
|
(9161.206)INSULATING SPACER FOR BOILER |
|
|
(9161.331.920)RATIOMOTOR COVER TRANSPARENT |
|
|
(9161.332.050)EXT.COVERING BLACK PUMP SPACE |
|
|
(9161.333.050)BOILER BLACK COVER |
|
|
(9161.345.050)INT.COVERING BLACK PUMP SPACE |
|
|
(9161.373.050)PIASTRINA AGGANCIO GRUP.CAF.SMART NERO |
|
|
(9161.374.050)PIASTRA FISS.TRAMOG.GRUP.CAF.SMART NERO |
|
|
(9161.375.050)PIASTRA POSTERIORE GRUPPO SMART NERO |
|
|
(9161.378)MOLLA TRAMOGGIA GRUPPO CAFFE SMART |
|
|
(9991.096)ADHESIVE FOOT 8X15X3,2 |
|
|
(JS01.019)SILIC. TUBE FABRIC FINISH 3X7 IN ROLL |
|
|
(JS01.022)SILICONE TUBE 5X10 60 SHORE IN ROLL |
|
|
(NE01.120)CABLE SCHUKO GREY H05 |
|
|
(NE03.038)BIPOLAR SWITCH FUSIT C1250AR FROM S/N. 9003ROY0465195 X 230V |
|
|
(NE05.038)MICROSWITCH |
|
|
(NF11.052)OETIKER CLIP |
|
|
(NM01.035)OR ORM 0090-20 SILICONE |
|
|
(NM01.044)OR ORM 0320-40 IN SILICONE PTFE/FDA |
|
|
(NM01.057)OR ORM 0050-20 SILICONE |
|
|
(NM02.006)OR R5 TERMOIL |
|
|
(NM02.007)OR 2025 TERMOIL |
|
|
(NM02.018)OR ORM 0090-25 TERMOIL |
|
|
(NM02.028)OR 2015 EPDM FDA |
|
|
(U044.020)SREW TSP M5,0X30 UNI 7688 GALV. UP TO S/N 9005SA40230571 |
|
|
(U046.003)SCREW TCBC M4,0X12 INDENT. WASH.8 |
|
|
(U109.006)SCREW AUT.TCB 2,2X9,5 DIN 7981 C NIK |
|
|
(U109.013)VITE AUT.TCB 3,5X13 DIN 7981 C NIK |
|
|
(U109.026)SS.SCREW AUT.TCB 3,5X19 DIN 7981 C |
|
|
(U109.027)SCREW TCB TORX 10 2,9X19 SHEET SS |
|
|
(U109.028)VITE AUT.TCB 2,9X9,5 DIN 7981 C INOX |
|
|
(U142.005)PANELVIT TSP 4,5X16 DIN 7505 A GAL |
|
|
(U143.018)SCREW TORX TCB 3,5X16 F TIP BL |
|
|
(U207.003)PLAIN WASHER 3,2X7 UNI 6592 GAL |
|
|
(U302.003)NUT HEXAGONAL M4 UNI 5588 |
|
|
(U310.003)NUT SELF LOCK.M5 UNI 7473 |
