Model Image
Manufacturer

Smeg

Model Number

CVIU138RG1

Description

Wine Coolers

Interactive Exploded View

Parts List

Part Number Description
819130696 819130696 3 WAYS VALVE
975770638 975770638 ADJUSTABLE FOOT M10
017690351 017690351 BACK COVERING
769210662 769210662 BASIN COMPRESS
691890228 691890228 CABLE ASSEMBLY
811770819 811770819 CAPACITOR
762210366 762210366 CARD COVER
695652513 695652513 CENTRAL SHELF
783410778 783410778 COALS FILTER
971750898 971750898 COMPRESSOR
971750957 971750957 COMPRESSOR ELT1104Y
690074926 690074926 COMPRESSOR MOUNTING KIT
761810718 761810718 CONDUCTOR
69613B845 69613B845 DOOR
814491320 814491320 DOOR REED
765770218 765770218 EL.UNIT FOOT
513110403 513110403 EVAPORATOR
769290276 769290276 FAN
5P2210368 5P2210368 FAN COVER
691291649 691291649 FEEDER CABLE ASSEMBLY
113411055 113411055 FILTER
768452522 768452522 FILTER CAP
566251891 566251891 FIXING PROFILE
698591323 698591323 FRAME
754132302 754132302 GASKET
184932151 184932151 HANDLE
762173290 762173290 LED BAR COVER
821291428 821291428 LED WIRING 1400MM
811652167 811652167 LED-BAR
769350313 769350313 LIGHT DIFFUSER
691331863 691331863 LOWER HINGE ASSEMBLY
812750081 812750081 MAGNET
691653529 691653529 MAIN BOARD+DISPLAY
017690352 017690352 PIPES BACK COVERING
069451054 069451054 PLINTH
691653528 691653528 POWER ELECTRON.UNIT
821292002 821292002 POWER SUPPLY CORD
705652236 705652236 SHELF
763850521 763850521 SHELF HOOK
768415975 768415975 SUPPORT
691331864 691331864 UPPER HINGE ASSEMBLY
823370336 823370336 VALVE WIRING
767210673 767210673 WASHER
