Manufacturer
Smeg
Model Number
FAB28ULOR3
Description
Lh L0 Refrigerator Fab28
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ASSY DOOR EVAP. NEW |
|
|
BACK FIXING STRIP |
|
|
BOTTLE SHELF |
|
|
BOTTLE SHELF |
|
|
BRACKET WHEEL FD48APSNF |
|
|
CAP SREW HINGE |
|
|
CHE BUT.SHELF COVER |
|
|
CHE BUT.SHELF GR |
|
|
CHE BUT.SHELF SMEGTHINCUT |
|
|
CHILLER COVER |
|
|
COMPRESSOR BASE |
|
|
COMPRESSOR BRACKET |
|
|
COMPRESSOR FMXA9C |
|
|
CONDENSER 60CM/24 |
|
|
CONTROL PANEL |
|
|
COVER SENSOR |
|
|
COVER SENSOR |
|
|
CRISPER CHILLER LEFT |
|
|
CRISPER CHILLER RIGHT |
|
|
CRISPER FLAP GR |
|
|
CRISPER FRONT FRAME |
|
|
CRISPER ROLLER |
|
|
DOOR FAB28LOR3 |
|
|
DOOR GASKET |
|
|
DOOR HINGE |
|
|
DOOR HINGE |
|
|
DOOR SHELF BOTTLE WIRE 32 |
|
|
DOOR SHELF WIRE 328 RV1 |
|
|
DRYER(XH9,0.40MM,5.5GR) |
|
|
DUCT REAR PROTECTION |
|
|
EVAP. TRAY GR |
|
|
F DOOR GR |
|
|
F DOOR HANDLE GR |
|
|
F DOOR LOCK |
|
|
FAB ORANGE PEN |
|
|
FMXA9C 115 V INVERTER |
|
|
FOOT M8X35 |
|
|
FREEZER CAP |
|
|
FREEZER HINGE CAP |
|
|
GLASS SHELF ABV.CHIL |
|
|
GLASS SHELF ABV.CRISP |
|
|
HANDLE FIXING PIN |
|
|
HANDLE SCREW M4X6 INX304 |
|
|
HEAD PANEL CAP |
|
|
HINGE BUSHING |
|
|
HINGE,F DOOR |
|
|
LED + COVER ASSY |
|
|
LEFT DOOR HANDLE |
|
|
LETTER "E" PLATE |
|
|
LETTER "G" PLATE |
|
|
LETTER "M" PLATE |
|
|
LETTER "S" PLATE |
|
|
LOWER HINGE |
|
|
MAGNET 20X10X3. FAB28RCR3 |
|
|
MIDDLE SHELF |
|
|
MIDDLE SHELF |
|
|
MOTOR FAN KAU.916-NEW |
|
|
PIN WHEEL FD54APXNF |
|
|
PLINTH |
|
|
PLINTH CAP |
|
|
POT CARD |
|
|
POT CARD/(20BDY14)NSOKET |
|
|
POW,CORD 60CM |
|
|
POW.CORD 2.1M |
|
|
R GLASS SHELF |
|
|
R MULTI FLOW ASSY |
|
|
R.GLASS SHELF PRF |
|
|
R.GLASS SHELF TRIM-BACK |
|
|
REED SWITCH |
|
|
REF FAN COVER |
|
|
REFRIGERATOR FAN MOTOR |
|
|
REFRIGERATOR SENSOR |
|
|
SCREW |
|
|
SCREW CAP |
|
|
SERVICE TUBE |
|
|
SIDE |
|
|
SP 2MM. HINGE DOOR FAB |
|
|
SPACER |
|
|
TERM.GR(RAL9005$)(HOTS)/N |
|
|
THERMOSTAT GR |
|
|
THERMOSTAT KNOB PIM PS |
|
|
TOP |
|
|
TOP CAP |
|
|
TOP CRISPER COVER TRIM |
|
|
UPPER FACIA |
|
|
UPPER HINGE |
|
|
WHEELS |
|
|
WINE SHELF 328 OPTIONAL |
|
|
WIRING CABLE PROTECTION |
