Manufacturer
Smeg
Model Number
FAB32ULPG3
Description
Lh L0 Refrigerator Fab32
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
ACID GREEN FAB PEN |
|
|
ASS EVAP COVER FF K60365N |
|
|
ASSEMBLY LOWER METAL PLIN |
|
|
ASSY DISPLAY BOX SMEG |
|
|
ASSY DRAWER COVER 148MM |
|
|
ASSY DRAWER COVER FF 167M |
|
|
ASSY UPPER DOOR SHELF 69M |
|
|
BACK PANEL |
|
|
BOTTLES TRAY |
|
|
CABINET HINGE |
|
|
CABINET HINGE |
|
|
CARD BOX COVER |
|
|
CENTRAL HINGE |
|
|
COMPRESSOR SUPPORT |
|
|
CONDENSER |
|
|
CONTROL BOARD GR U-1 NEW |
|
|
COVER |
|
|
COVER BIORESH |
|
|
CRISPER COVER |
|
|
DOOR HINGE |
|
|
DOOR HINGE |
|
|
DOOR HINGE |
|
|
DOOR SHELF 69MM |
|
|
DOOR SHELF 94MM |
|
|
DRAWER |
|
|
DRAWER |
|
|
DRAWER |
|
|
DRAWER |
|
|
DRAWER COVERS HOTSP 190 |
|
|
DRAWER COVERS HOTSP 235 |
|
|
DRYER |
|
|
EGGS TRAY |
|
|
EVAP. COVER CAP WHITE |
|
|
EVAPORATOR FRONT COVER AS |
|
|
FAN COVER |
|
|
FAN COVER HOTSTP |
|
|
FAST CONNECTION COMPRESSO |
|
|
FEEDER CABLE ASSEMBLY |
|
|
FF FAN_MOTOR_DC 12 V |
|
|
FILTER COVER |
|
|
FILTER PHOTOCATALYST |
|
|
FINNED_EVAPORATOR_ASSEMBL |
|
|
FREEZER EVAPORATOR SENSOR |
|
|
FRIDGE EVAPORATOR |
|
|
FRIDGE EVAPORATOR SENSOR |
|
|
FRZ FAN ASSY CANADA |
|
|
FZ GLASS ASS. DEEP 3.2 MM |
|
|
GLASS COVER ORNAMENT |
|
|
GLASS PROFILE SMEG |
|
|
GLASS SHELF |
|
|
GLASS SHELF ASSY |
|
|
GLASS SHELF BACK PROFILE |
|
|
GLASS SHELF BACK PROFILE |
|
|
GUIDE |
|
|
GUIDE |
|
|
HANDLE FIXING PIN |
|
|
HANDLE SCREW M4X6 INX304 |
|
|
HEATER K60400 |
|
|
HINGE BUSHING |
|
|
HINGE BUSHING |
|
|
HINGE BUSHING |
|
|
ICE ASSY |
|
|
ICE TRAY |
|
|
INSERT |
|
|
LEFT BACK FIXING FILLET |
|
|
LEFT DOOR HANDLE |
|
|
LETTER "E" PLATE |
|
|
LETTER "G" PLATE |
|
|
LETTER "M" PLATE |
|
|
LETTER "S" PLATE |
|
|
LONG LED LIGHT LEFT |
|
|
LONG LED LIGHT RIGHT |
|
|
LOWER DOOR FAB32LPG3 |
|
|
LOWER DOOR GASKET |
|
|
LOWER HINGE |
|
|
MAGNET |
|
|
MIDDLE DOOR HINGE |
|
|
MIDDLE HINGE COVER |
|
|
MIDDLE HINGE PLUG (WHITE) |
|
|
MOTORCOMPRESSOR FIXING PA |
|
|
NEW TEMP.SENS. COVER ASSY |
|
|
PIPE ADAPTER |
|
|
PLINTH |
|
|
PLINTH CAP |
|
|
RAIL ASSEMBLY |
|
|
RAIL ASSEMBLY |
|
|
RIGHT BACK FIXING FILLET |
|
|
RUBBER VALVE |
|
|
SCREW |
|
|
SCREW |
|
|
SENSOR 800MM |
|
|
SENSOR COVER |
|
|
SENSOR TEMPERATURE AIR |
|
|
SHELF COVER |
|
|
SIDE |
|
|
SIDE BACK REINFORCEMENT |
|
|
SLEEVE SCREW M 8X35/ARC |
|
|
SP 2MM. HINGE DOOR FAB |
|
|
SPACER |
|
|
SQUARE FAN DAMPER |
|
|
STEAM TANK (EMBRACCO_BUIL |
|
|
SUP 1 COMPR_WITH WHELS_60 |
|
|
THERMAL INSURANCE |
|
|
TOP CAP |
|
|
TOP+CONTROL PANEL |
|
|
UPPER DOOR FAB32LPG3 |
|
|
UPPER DOOR GASKET |
|
|
UPPER FACIA |
|
|
UPPER HINGE |
|
|
VCC COMPRESSOR |
|
|
VEMX5C VCC INVERTER |
|
|
WASHER |
|
|
WHEEL |
|
|
WHEEL PIN |
|
|
WIRE SHELF BIG BALCONY |
|
|
WIRE SHELF SMALL BALCONY |
|
|
WIRING PROTECTION |
