Manufacturer
Sharp
Model Number
JX9300
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
26T GEAR I/O NGERH0383FCZZ T/18 |
|
|
28P IC SOCKET11 |
|
|
64P IC SOCKET12 |
|
|
AC CORD I/O 7613QCN3 T/R SP-1329 |
|
|
AC SWITCH ANGLE14 |
|
|
ANGLE (TC-92) (30 X 36 X 1T)142 |
|
|
ARM I/O 0065FCZZ T/R SP-1532 &15 |
|
|
BAND I/O LBNDJ0013FCZZ,2003SCZ33 |
|
|
BEARING20 |
|
|
CAPACITOR (16WV 22UF)29 |
|
|
CAPACITOR (16WV 471UF)30 |
|
|
CAPACITOR (2KV 220UF)70 |
|
|
CAPACITOR (50WV 1000PF)31 |
|
|
CAPACITOR (50WV 330PF)26 |
|
|
CAPACITOR (6.3WV 220UF)27 |
|
|
CAPACITOR (C2012CH1H150J)7 |
|
|
CARD GUIDE4 |
|
|
CASSETTE SPRING (SILVER) I/O M5 |
|
|
CASSETTE STOPPER14 |
|
|
CASSETTE TURNING PLATE4 |
|
|
CG ROM 1 (27256)76 |
|
|
CGROM2(27256)76 |
|
|
CHARGER WIRE6 |
|
|
CLUTCH SPRING22 |
|
|
CLUTCH STUD I/O FCZZ/Z1 SP-1624 |
|
|
CONNECTOR6 |
|
|
COUNTER HEAT ROLLER I/O NROLI022 |
|
|
DIODE (CTU-22S)22 |
|
|
DIODE (DSS133HV)34 |
|
|
DV SWITCH UNIT29 |
|
|
E TYPE RING (4F)21 |
|
|
E TYPE RING (5MM)18 |
|
|
E TYPE RING (7MM)9 |
|
|
E TYPE RING (8E)21 |
|
|
E TYPE RING(3E)17 |
|
|
FD CHANGE SWITCH UNIT26 |
|
|
FUSE (AC 125V 6.3A)2 |
|
|
FUSE HOLDER5 |
|
|
FUSING BEARING19 |
|
|
FUSING JOINT PLATE16 |
|
|
GEAR (16T)16 |
|
|
GEAR (18/39T)10 |
|
|
GEAR (18T)8 |
|
|
GEAR (30/42T)15 |
|
|
GEAR (37T)19 |
|
|
GEAR I/O 0401FCZZ18 |
|
|
GEAR I/O FCZZ T/R SP-133221 |
|
|
GEAR(37TL20 |
|
|
HOLDER I/O LHLDZ0758FCZ132 |
|
|
HOLDER I/O NBRGP0260FCZZ23 |
|
|
IC (PC358G)56 |
|
|
IC (PC393G)57 |
|
|
IC (T74LS00)51 |
|
|
IC (T74LS30)64 |
|
|
IC (T75188)48 |
|
|
ICU PWB14 |
|
|
LAMP COVER F36 |
|
|
LAMP SPRING R15 |
|
|
MAIN HARNESS31 |
|
|
MANUAL PAPER FEED SIZE LABEL (20 |
|
|
MICROSWITCH (MS1.3) I/O QSW-L031 |
|
|
MICROSWITCH (POWER SW)8 |
|
|
MS2 ACC LEVER10 |
|
|
MSW LEVER UNIT34 |
|
|
NUT (3NS)43 |
|
|
NUT (M4)46 |
|
|
OPTICAL UNIT (100V SERIES)1 |
|
|
PAPER GUIDE C43 |
|
|
PAPER TURN GUIDB49 |
|
|
PCU PWB I/O CPWBN0680FC32 LPE5 |
|
|
PIN22 |
|
|
PS PULLEY SHAFT26 |
|
|
PS SOLENOID FIXING PLATE20 |
|
|
PS SWITCH SPRING6 |
|
|
PULLEY (21MXL)13 |
|
|
RESISTOR (1/4W 1.0K +-5%)80 |
|
|
RESISTOR (1/4W 100)102 |
|
|
RESISTOR (1/4W 10K +-5%)81 |
|
|
RESISTOR (1/4W 15K)86 |
|
|
RESISTOR (1/4W 220K)90 |
|
|
RESISTOR (1/4W 5.6K +-5%)90 |
|
|
RESISTOR (1/6W 1K)88 |
|
|
RESISTOR (1/6W 5.6K)87 |
|
|
RIGHT EXTERIOR SUPPORT PLATE22 |
|
|
RING (GTW-6)33 |
|
|
ROLLER I/O NROLR0515FCZZ28 |
|
|
ROLLER STOPPER17 |
|
|
ROM 1 (27512)77 |
|
|
ROM 2 (27512)77 |
|
|
SCREW (3 X 10)4 |
|
|
SCREW (3 X 3)12 |
|
|
SCREW (3 X 4)41 |
|
|
SCREW (3 X 6)14 |
|
|
SCREW (3 X 8)12 |
|
|
SCREW (4 X 6)16 |
|
|
SCREW (4 X 6K)15 |
|
|
SCREW (4 X 8K)48 |
|
|
SCREW I/O LX-BZ0039FCZZ,T/R SP15 |
|
|
SCREW I/O XBPSD40P10K00 T/R FA47 |
|
|
SCREW I/O XCPSD40P08000 T/R SP23 |
|
|
SCREW11 |
|
|
SEAL INST.OF PSHEZ1606FCZZ,3262 |
|
|
SHAFT I/O NSFTZ0854FCZZ,T/R S-16 |
|
|
STOPPER SPRING7 |
|
|
TC HOLDER F9 |
|
|
TC HOLDER R8 |
|
|
TC HOLDER SPRING7 |
|
|
THERMOSTAT E1 LOAD 6/15/93, I/5 |
|
|
TM HOLDER4 |
|
|
TONER MOTOR GEAR (29T)6 |
|
|
TRANSISTOR I/O VSJC501-///-191 |
|
|
TRIAC I/O -08C ,VHSBCR30GM8R113 |
|
|
TURNING PLATE STOPPER6 |
|
|
V RING (GTW-5)5 |
|
|
WASHER (3HW)43 |
|
|
WASHER (M4)18 |
|
|
WASHER(INST.OF XWHSD50-08100)36 |
|
|
WIRE FIXING BAND2 |
