Manufacturer
Sharp
Model Number
R1850
Description
Sharp Microwave
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1-11 SECONDARY INTERLOCK, DOOR SENSING/DAMP |
|
|
12-PIN CONNECTOR CN-G3-1F |
|
|
2-7-1 HOOD LAMP GLASS ANGLE [R-1851] |
|
|
2-7-2 HOOD LAMP GLASS (JUST GLASS) |
|
|
3-PIN CONNECTOR CN-A3-1A |
|
|
4-12 TURNTABLE MOTOR PACKING |
|
|
4-9 COUPLING I/O B006 |
|
|
ADAPTER, EXHAUST |
|
|
AH SENSOR1-21 |
|
|
ALARM I\O RALM-A014DRE0SP40 |
|
|
BASE COVER |
|
|
BASE PLATE LEFT2-4 |
|
|
BASE PLATE RIGHT2-3 |
|
|
BASEPLATE I/O PREFHB005MRP04-34 |
|
|
BLADE I/O NFANPB004MRK04-21 |
|
|
BUSHING LBSHC0040MRE06-1-1 |
|
|
C100 230V-7MFD CAP |
|
|
C2 |
|
|
CAPACITOR 0.01 UFC7-8 |
|
|
CAPACITOR HOLDER4-4 |
|
|
CAUTION LABEL I/O TCAUAB019MRR6-13 |
|
|
CERAMIC RESONATOR (CST4.00MGW)CF1 |
|
|
CHARCOAL FILTER |
|
|
CHOKE COVER5-4 |
|
|
COLLER4-18 |
|
|
CONTROL UNIT |
|
|
CONVECTION FAN BLADE4-14 |
|
|
CONVECTION HEATER1-4 |
|
|
CONVECTION MOTOR ANGLE4-11 |
|
|
CONVECTION MOTOR FAN4-10 |
|
|
COVER, LAMP, HOOD, GLASS |
|
|
COVER, WAVEGUIDE/STIRRER |
|
|
CUSHION4-27 |
|
|
CUSHION4-38 |
|
|
CUSHION4-47 |
|
|
CUSHION4-49 |
|
|
CUSHION4-50 |
|
|
CUSHION5-8 |
|
|
DAMPER |
|
|
DAMPER CUSHION4-29 |
|
|
DAMPER MOTOR1-22 |
|
|
DAMPER PLATE4-31 |
|
|
DISPLAY WINDOW / LENS |
|
|
DOOR ASSY OTX WHT |
|
|
DOOR GLASS FRONT [R-1850]5-3 |
|
|
DOOR LATCH ALL ONE PART |
|
|
DOOR STOPPER4-35 |
|
|
E-RING7-15 |
|
|
EXHAUST CUSHION A4-45 |
|
|
EXHAUST CUSHION B4-46 |
|
|
EXHAUST DUCT4-25 |
|
|
FAN DUCT FOR FAN MOTOR |
|
|
FAN MOTOR |
|
|
FAN NUT I/O XNEUW40-32000 |
|
|
FILTER, GREASE, 2 PER MICROWAVE |
|
|
FLUORESCENT DISPLAY TUBE3-1G |
|
|
FUSE HOLDER1-10 |
|
|
GLASS STOPPER5-6 |
|
|
HEAT PROTECT L4-17 |
|
|
HEAT PROTECT R4-30 |
|
|
HEATER COVER L4-19 |
|
|
HEATER MOUNTING HOLDER4-13 |
|
|
HIGH VOLTAGE CAPACITOR |
|
|
HOOD EXHAUST DUCT4-39 |
|
|
HOOD FAN MOTOR ASSY (NO PARTS) |
|
|
HOOD INTAKE DUCT L4-20 |
|
|
HOOD INTAKE DUCT R4-42 |
|
|
HV DIODE |
|
|
HV TRANSFORMER |
|
|
INSTALLATION INSTRUCTIONS- MOUNTING INSTRUCT |
|
|
INSTALLATION MATERIAL(MOUNTING HARDWARE |
|
|
INSTRUCTION BOOK |
|
|
KEY FIXING3-2-6 |
|
|
KEY UNIT [R-18S0]3-2-1 |
|
|
LAMP, HOOD, OUTSIDE |
|
|
LATCH HOOK (SWITCH HOLDER)4-15 |
|
|
LATCH SPRING5-7 |
|
|
LEFT SASH |
|
|
LOUVER, HOOD, BLACK |
|
|
LOW AND HIGH RACK KIT |
|
|
LV TRASFORMER T1 |
|
|
MAG DUCT |
|
|
MAGNETRON |
|
|
MAIN HARNESS C6-11 |
|
|
MONITOR SW AND FUSE ASSY |
|
|
NUT 4MM X 3.2MM LOC 7-18 USELX-NZA002WRE0 |
|
|
OPEN BUTTON |
|
|
OPEN BUTTON [R-1851]3-2-4 |
|
|
OPEN LEVER I/O MLEVPB013MRF0A/4-26 |
|
|
OUTER CASE CABINET R1850ONLY |
|
|
OVEN LAMP COVER4-36 |
|
|
OVEN LAMP SOCKET |
|
|
OVEN LIGHT SCREEN4-43 |
|
|
PLATE, WALL MOUNTING |
|
|
POWER CORD |
|
|
RACK, BAKING, HIGH |
|
|
RACK, BROILING, LOW |
|
|
REAR STAY2-10 |
|
|
RELAY (DU24DL-LP(M))RY1-3 |
|
|
RESISTOR 220 OHM 1R63 |
|
|
SCREW : 3MM X 6MM7-12 |
|
|
SCREW : 3MM X 8MM7-3 |
|
|
SCREW : 4MM X 12MM 27-7 |
|
|
SCREW : 4MM X 6MM7-6 |
|
|
SCREW : 4MM X 8MM5-9 |
|
|
SCREW : 4MM X 8MM7-14 |
|
|
SCREW : 4MM X 8MM7-24 |
|
|
SCREW : 4MM X L0MM (BLACK) [R-7-2 |
|
|
SCREW : 4MM X LQMM7-25 |
|
|
SCREW : 5MM X 60MM6-1-4 |
|
|
SCREW I/O XCPSD40P08000 T/R SP7-1 |
|
|
SCREW, MOUNTING, LONG |
|
|
SELECT BUTTON [R-1851]3-2-5 |
|
|
SPECIAL SCREW7-13 |
|
|
SPRING WASHER7-19 |
|
|
STIRRER FAN MW-132 NO FUTURE A4-6 |
|
|
STIRRER MOTOR |
|
|
SUPPORT, TURNTABLE |
|
|
T/T TRAY |
|
|
TEMPLATE, TOP OF OVEN |
|
|
TEMPLATE, WALL (NLA) |
|
|
THERMAL COVER R4-32 |
|
|
THERMAL CUTOUT |
|
|
THERMISTOR |
|
|
TOP DUCT4-40 |
|
|
TRANSISTOR (2SB1238)Q1 |
|
|
TRANSISTOR (DTA123ES)Q4 |
|
|
TRANSISTOR (KRAL0LM)Q3 |
|
|
TRANSISTOR (KRC243M)Q27 |
|
|
TURNTABLE KIT |
|
|
TURNTABLE MOTOR |
|
|
WASHER : 4MM X 0.8MM7-22 |
|
|
WASHER : 5MM X 2MM7-21 |
|
|
WASHER : 5MM X Q.8MM7-23 |
|
|
ZENER DIODE (HZ16-1)ZD2 |
|
|
ZENER DIODE (HZ4A-2)ZD4 |
