Manufacturer
Sharp
Model Number
R1850A
Description
Sharp Microwave
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
1-7 - THERMAL CUT-OUT N.O. 60DEGREE |
|
|
12-PIN CONNECTOR (CN-G)3-1F |
|
|
2-2 HOOD EXHAUST LOUVER R-1852A |
|
|
3-PIN CONNECTOR (CN-A)3-1A |
|
|
7-24 SCREW; 4MM X 8MM FOR CTROF LOUVER |
|
|
AH SENSOR1-21 |
|
|
ALARM I\O RALM-A014DRE0SP40 |
|
|
BASE COVER2-8 |
|
|
BASE PLATE LEFT2-4 |
|
|
BASE PLATE RIGHT2-3 |
|
|
BASEPLATE I/O PREFHB005MRP04-34 |
|
|
CAPACITOR 0.01 MICRO FARADS 16C7 |
|
|
CAPACITOR 7 MICRO FARADS 230VC100 |
|
|
CAPACITOR HOLDER4-4 |
|
|
CAPACITOR P/R AGC2 |
|
|
CERAMIC RESONATOR (CST4.00MGW)CF1 |
|
|
CHARCOAL FILTER |
|
|
CHOKE COVER5-4 |
|
|
COLLER4-18 |
|
|
CONTROL UNIT SAME AS LINE 120 |
|
|
CONVECTION FAN BLADE |
|
|
CONVECTION HEATER UNIT4-8 |
|
|
CONVECTION MOTOR ANGLE4-11 |
|
|
CONVECTION MOTOR FAN4-10 |
|
|
CORD BUSHING4-24 |
|
|
CORD HOLDER6-1-3 |
|
|
COUPLING4-9 |
|
|
COVER, LAMP, HOOD, GLASS |
|
|
CUSHION4-27 |
|
|
CUSHION4-38 |
|
|
CUSHION4-47 |
|
|
CUSHION4-48 |
|
|
CUSHION4-49 |
|
|
CUSHION4-50 |
|
|
CUSHION4-51 |
|
|
CUSHION4-52 |
|
|
DAMPER CAM4-28 |
|
|
DAMPER CUSHION4-29 |
|
|
DAMPER MOTOR1-22 |
|
|
DAMPER PLATE4-31 |
|
|
DIODE (1SS270A)D20 |
|
|
DISPLAY WINDOW |
|
|
DOOR GLASS FRONT R-1850A5-3 |
|
|
DOOR STOPPER4-35 |
|
|
E-RING7-15 |
|
|
EXHAUST CUSHION A4-45 |
|
|
EXHAUST CUSHION B4-46 |
|
|
EXHAUST DAMPER ASSY |
|
|
EXHAUST DUCT4-25 |
|
|
FAN BLADE4-21 |
|
|
FAN DUCT4-23 |
|
|
FAN MOTOR1-19 |
|
|
FLUORESCENT DISPLAY TUBE3-1G |
|
|
FUSE HOLDER1-10 |
|
|
GLASS STOPPER5-6 |
|
|
GREASE FILTER |
|
|
HEAT PROTECT L4-17 |
|
|
HEAT PROTECT R4-30 |
|
|
HEATER COVER L4-19 |
|
|
HEATER MOUNTING HOLDER4-13 |
|
|
HIGH RACK |
|
|
HOOD EXHAUST DUCT4-39 |
|
|
HOOD FAN MOTOR1-17 |
|
|
HOOD INTAKE DUCT L4-20 |
|
|
HOOD INTAKE DUCT R4-42 |
|
|
HOOD LAMP GLASS ANGLE R-1851A2-7-1 |
|
|
HOOD LAMP GLASS ANGLE R-1852A2-7-1 |
|
|
HOOD LAMP GLASS ASSEMBLY R-1852-7 |
|
|
HOOD LAMP GLASS2-7-2 |
|
|
HOOD LAMP SOCKET & OVEN LAMP S1-14 |
|
|
HV CAP |
|
|
HV DIODE |
|
|
INSTALLATION INSTRUCTIONS6-2 |
|
|
KEY FIXING3-2-6 |
|
|
KEY UNIT R-1850A3-2-1 |
|
|
KEY UNIT R-1852A3-2-1 |
|
|
LAMP, OVEN, OUTSIDE |
|
|
LATCH HEAD5-5 |
|
|
LATCH HOOK4-15 |
|
|
LATCH SPRING5-7 |
|
|
LOUVER, HOOD, BLACK |
|
|
LOW RACK |
|
|
MAGNETRON |
|
|
MAGNETRON DUCT4-41 |
|
|
MAIN HARNESS C6-11 |
|
|
MAIN WIRE HARNESS A6-8 |
|
|
MONITOR SWITCH AND FUSE ASSEMB1-12 |
|
|
MOUNTING HARDWARE |
|
|
NOISE RESISTOR1-23 |
|
|
OPEN BUTTON R-1850A3-2-4 |
|
|
OPEN BUTTON R-1851A3-2-4 |
|
|
OPEN BUTTON R-1852A3-2-4 |
|
|
OPEN LEVER4-26 |
|
|
OUTER CASE CABINET R-1850A2-5 |
|
|
OUTER CASE CABINET R-1851A2-5 |
|
|
OUTER CASE CABINET R-1852A2-5 |
|
|
OVEN LAMP COVER4-36 |
|
|
OVEN LIGHT SCREEN4-43 |
|
|
PLATE, WALL MOUNTING |
|
|
POWER SUPPLY CORD1-13 |
|
|
POWER TRANSFORMER |
|
|
RACK, HIGH, BAKING |
|
|
RACK, LOWER, BROILING |
|
|
REAR STAY2-10 |
|
|
RELAY (DU241-1P(M))RY1 |
|
|
RELAY (OJE-SS-124LM)RY4 |
|
|
RESISTOR 220 OHMS 1/4WR63 |
|
|
SASH LEFT CORRECT PART # PERSHARP 10-26-01 LAO |
|
|
SCHEMATIC DIAGRAM2-6 |
|
|
SCREW I/O XCPSD40P08000 T/R SP7-1 |
|
|
SCREW5-8 |
|
|
SCREW; 3MM X 10MM3-3 |
|
|
SCREW; 3MM X 6MM7-12 |
|
|
SCREW; 3MM X 6MM7-4 |
|
|
SCREW; 3MM X 8MM7-3 |
|
|
SCREW; 4MM X 10MM R-1850A7-2 |
|
|
SCREW; 4MM X 10MM R-1851A, R-17-8 |
|
|
SCREW; 4MM X 8MM7-14 |
|
|
SCREW; 4MM X 8MM7-18 |
|
|
SCREW; 4MM X 8MM7-6 |
|
|
SCREW; 4MM X 8MM7-9 |
|
|
SCREW; 5MM X 60MM6-1-4 |
|
|
SECONDARY INTERLOCK, DOOR SENS1-11 |
|
|
SPECIAL SCREW7-13 |
|
|
SPRING WASHER7-19 |
|
|
STIRRER COVER ASSY(WAVE GUIDE)4-5 |
|
|
STIRRER FAN MW-132 NO FUTURE A4-6 |
|
|
STIRRER MOTOR1-6 |
|
|
T/T TRAY |
|
|
THERMAL COVER R4-32 |
|
|
THERMISTOR1-15 |
|
|
TOP DUCT4-40 |
|
|
TOP TEMPLATE6-4 |
|
|
TRANSFORMERT1 |
|
|
TRANSISTOR (2SB1238)Q1 |
|
|
TRANSISTOR (DTA123ES)Q4 |
|
|
TRANSISTOR (KRA101M)Q3 |
|
|
TRANSISTOR (KRC101M)Q20 |
|
|
TRANSISTOR (KRC243M)Q27 |
|
|
TURNTABLE MOTOR PACKING4-12 |
|
|
TURNTABLE MOTOR1-5 |
|
|
TURNTABLE SUPPORT ASSEMBLY4-2 |
|
|
UNIT MOUNTING SCREW7-10 |
|
|
WALL TEMPLATE6-5 |
|
|
WASHER; 4MM X 0.8MM7-22 |
|
|
WASHER; 5MM X 0.8MM7-23 |
|
|
WASHER; 5MM X 2MM7-21 |
|
|
WHITE SELECT BUTTON |
|
|
ZENER DIODE (HZ16-1)ZD2 |
|
|
ZENER DIODE (HZ4A-2)ZD4 |
