Manufacturer
Sharp
Model Number
R3A84
Description
No description available
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
12-PIN CONNECTOR (G)3-1C |
|
|
ALARM I\O RALM-A014DRE0SP20 |
|
|
CAPACITOR 0.01 UF 16VC6 |
|
|
CAPACITOR 10 UF 16VC5 |
|
|
CAPACITOR 3.3 UF 50VC3 |
|
|
CAPACITOR 47 UF 16VC4 |
|
|
CUSHION4-25 |
|
|
DHHS CAUTION LABEL6-11 |
|
|
DIODE (1SS270A)D20 |
|
|
DOOR ASSEMBLY COMPLETE. (EXCEP5 |
|
|
DOOR SENSLNG AND SECONDARY INT1-4 |
|
|
FAN BLADE4-22 |
|
|
FUSE HOLDER1-2 |
|
|
H.V. RECTIFIER ASSEMBLY1-7 |
|
|
LAMP FILTER4-3 |
|
|
LATCH HEAD (EXCEPT R-3A94)5-5 |
|
|
LATCH SPRING5-6 |
|
|
MAGNETRON I/O RV-MZA162WRE01-10 |
|
|
NAME PLATE (R-3A54)6-12 |
|
|
NUT7-17 |
|
|
OPERATION MANUAL6-3 |
|
|
OVEN LAMP EHKN-122, 7/91 <ABC>1-12 |
|
|
OVEN LAMP SOCKET1-11 |
|
|
PATENT LABEL6-13 |
|
|
POWER RELAY (RY2) |
|
|
Q31 |
|
|
RESISTOR 1M OHM 1/4WR100 |
|
|
SCREW 3MM X 10MM7-7 |
|
|
SCREW 3MM X 6MM7-14 |
|
|
SCREW 4MM X 12MM7-10 |
|
|
SCREW 4MM X 12MM7-9 |
|
|
SCREW 4MM X 6MM7-15 |
|
|
SCREW 4MM X 8MM7-1 |
|
|
SCREW 4MM X 8MM7-5 |
|
|
SCREW CONTROL UNIT MTG.3-5 |
|
|
SCREW I/O XEPSD30P060005-8 |
|
|
SEALER FILM5-7 |
|
|
SPECIAL SCREW7-3 |
|
|
SWITCH LEVER4-14 |
|
|
THERMAL CUT-OUT 145DEG1-5 |
|
|
TURNTABLE PACKING4-4 |
|
|
USER CAUTION LABEL ((R-3A94)6-10 |
|
|
USER CAUTION LABEL (EXCEPT R-36-10 |
