Manufacturer
Sharp
Model Number
R3A86
Description
Sharp Microwave
Interactive Exploded View
Parts List
| Part Number | Description |
|---|---|
|
|
12-PIN CONNECTOR (G)3-1C |
|
|
ALARM I\O RALM-A014DRE0SP40 |
|
|
CAPACITOR 0.01 UF 16VC4 |
|
|
CAPACITOR 47 UF 16VC3 |
|
|
CLIP I/O PCLIC0026WRE04-24 |
|
|
COUPLING4-15 |
|
|
COVER, WAVE GUIDE |
|
|
DHHS CAUTION LABEL6-11 |
|
|
DIODE (1SS270A)D20 |
|
|
DOOR OPEN LEVER |
|
|
FAN BLADE4-22 |
|
|
FAN MOTOR |
|
|
FOOT\ USE GLEGPA013WRE0 |
|
|
FUSE HOLDER1-2 |
|
|
HIGH VOLTAGE DIODE |
|
|
HIGH VOLTAGE WIRE B6-7 |
|
|
LAMP |
|
|
LAMP FILTER4-3 |
|
|
LATCH SPRING5-6 |
|
|
MAGENTRON |
|
|
MONITOR CAUTION LABEL6-9 |
|
|
MOTOR I/O RMOTEA276WRE01-9 |
|
|
OVEN LAMP SOCKET1-11 |
|
|
PARTITION ANGLE4-16 |
|
|
PATENT LABEL6-13 |
|
|
RELAY (VRB24)RY2 |
|
|
RESISTOR 1M OHM 1/4WR60 |
|
|
RESISTOR 47K OHM 1/4WR10 |
|
|
SCREW CONTROL UNIT MTG.3-5 |
|
|
SCREW I/O XEPSD30P060005-8 |
|
|
SCREW; 3MM X 6MM7-12 |
|
|
SCREW; 4MM X 12MM7-11 |
|
|
SCREW; 4MM X 12MM7-8 |
|
|
SCREW; 4MM X 6MM7-5 |
|
|
SCREW; 4MM X 8MM7-1 |
|
|
SCREW; 4MM X 8MM7-9 |
|
|
SEALER FILM5-7 |
|
|
SECONDARY AND DOOR SENSING SWITCH |
|
|
SPECIAL SCREW7-2 |
|
|
THERMAL CUT-OUT 145-C1-5 |
|
|
TRANSFORMERT1 |
|
|
TRANSISTOR (DTD143ES)Q21 |
|
|
TURNTABLE PACKING4-4 |
|
|
UPPER OVEN HINGE4-13 |
|
|
USER CAUTION LABEL6-10 |
|
|
ZENER DIODE (HZ16-1)ZD1 |
